The full-featured 700 Series cameras offer best-
in-class image quality ideal for diverse industrial,
municipal, and educational markets. Choose the
75x for exceptional low-light performance utilizing
a movable IR filter. IQfocus assist using the analog
service port reduces installation time to mere
minutes, saving both time and money for the
installer. The camera provides finely tuned image
parameter controls allowing image optimization
for any difficult lighting conditions. The external
compact flash memory expansion port in
combination with the IQrecorder application make
the 700 series a flexible stand-alone recording
platform ideal for remote monitoring or motion
based recording.
Megapixel IP Camera
33122 Valle Road
San Juan Capistrano, CA
92675-4853
USA
toll free within US 877.850.0805
phone [phone]
fax [phone]
www.iqeye.com
Features
>Resolutions up to 5 MP
>MJPEG Compression
>30 fps @ 1.3 MP, 10 fps @ 5 MP
>Day/Night Movable IR Filter on IQ75x
>Lightgrabber™ II Low-light Feature
>Power Over Ethernet, 12-24 VDC, 24 VAC
>Indoor Camera
>3 Year Warranty
IQeye 700 Series

Megapixel IP Camera
IQeye 700 Series
Video
Compression MJPEG
Sensor 1/3” CMOS 1 MP, 1/2” CMOS for
2 MP and 3 MP, 1/2.5” CMOS for 5 MP
JPEG Compression User Configurable
Quality Settings
Shutter Speed Auto/Programmable/Fixed
Image Settings Saturation, Contrast, Brightness,
Sharpness, Lightgrabber™ II,
Gain Styles
Exposure User Configurable
White Balance Auto/Programmable
Backlight Compensation Auto
IR Range 800 to 940 nm
Features
Virtual Cameras User Configurable Windows
Privacy Mask User Configurable Windows
Motion Detection User Configurable Windows
Access Hours User Configurable
Time Lapse Recording User Configurable
Event Based Recording User Configurable
Flip and Rotate 90, Horizontal, Vertical
Analog Service Port NTSC/PAL (Full time)
Focus Assist IQfocus
Analytics Ready Yes
On-Camera IQapps IQaccess, IQauthenticate,
IQnightlight, IQrecorder
System Integration IQfinder, IQmanager, IQsentry
Network
Supported Protocols TCP/IP, HTTP, DHCP, UDP, RTP, RTSP, DNS, ARP,
ICMP, NTP, SNMP, FTP, SMTP, Telnet
Password Protection Secure Multi-level
Input/Output
Input Power Power over Ethernet 802.3af Class 1,
24VAC, 12-24VDC
Power Consumption < 2.8W (typical)
AC Lighting 50 Hz/60 Hz Selectable
Network Interface RJ45 10Base-T/100Base-TX
Physical I/O 1 input, 1 output
On Camera Storage Compact Flash
Misc
Approvals FCC, CE
Temperature Range 32˚Fto104˚F,0˚Cto40˚C
Weight (grams) 369 g
Warranty 3 years
Lens Options V3 Wide Angle Lens 1/2” CS, 4.5-10 mm, F1.6, IR
V4 Telephoto Lens 1/3” CS, 5-50 mm, F1.3
V6 Telephoto Lens 1/2” CS, 12-40 mm, F1.8, IR
V7 Wide Angle Lens 1/2” CS, 4-12 mm, F1.4, IR
W2 Ultra Wide Lens 1/2” CS, 1.8-3 mm, F1.8, IR
Specifications
Part Number Max Resolution Max Framerate Min Illumination Compatible Lens
Day/Night with IR filter IQ751 1 MP - 1280 x 1024 30 fps Color: 0.2 lux, B/W: <0.05 lux V3, V6
IQ752 2 MP - 1600 x 1200 20 fps Color: 0.2 lux, B/W: <0.05 lux V6, V7, W2
IQ753 3 MP - 2048 x 1536 12 fps Color: 0.3 lux, B/W: <0.05 lux V6, V7, W2
IQ755 5 MP - 2560 x 1920 10 fps Color: 0.3 lux, B/W: <0.05 lux V6, V7, W2
Day Only IQ711 1 MP - 1280 x 1024 30 fps Color: 0.2 lux V4, V7, W1
IQ702 2 MP - 1600 x 1200 20 fps Color: 0.2 lux V6, V7
IQ703 3 MP - 2048 x 1536 12 fps Color: 0.3 lux V6, V7
IQ705 5 MP - 2560 x 1920 10 fps Color: 0.3 lux V6, V7
032211
Dimensions
Top Side
©2010 IQinVision. IQinVision and the IQinVision logo are trademarks or registered trademarks of IQinVision, registered in the U.S. and other countries. All other trademarks are the property of their respective owners. All rights reserved.
2.52”
64 mm
4.41”
112 mm
