iQunet SERV199310-IPC-FR201 User manual

D1526-en-CUST
DVDB-230104
<199310 IPC iQunet Server Quick Start SERV199310-IPC-FR201-DoC-D1526-en-CUST-230104>
QUICK START INFORMATION
iQunet | Broekstraat 82, B-9220 Hamme, Belgium | T [phone] | [email protected] page 1/2
Subject to reasonable modicaons due to technical advances
iQunet Server
SAFETY INSTRUCTIONS AND QUICK START GUIDE
Type: SERV199310-IPC-FR201 ID: 199310
SAFETY INSTRUCTIONS
IMPORTANT: PLEASE RETAIN THIS INFORMATION FOR FUTURE
REFERENCE
WARNINGS
•This product shall only be connected to an external power supply
rated at 8~24VDC (power consumption 22 W max.). Any external
power supply used with the iQunet Server shall comply with
relevant regulations and standards applicable in the country of
intended use.
•This product should be operated in a well-ventilated environment
and the case should not be covered.
•This product should be placed on a stable cabinet.
•All peripherals used with the iQunet Server should comply with
relevant standards for the country of use and be marked
accordingly to ensure that safety and performance requirements are
met. These articles include but are not limited to keyboards,
monitors, and mice used in conjunction with the iQunet Server.
•Where peripherals are connected that do not include the cable or
connector, the cable or connector used must offer adequate
insulation and operation in order that the requirements of the
relevant performance and safety requirements are met.
INSTRUCTIONS FOR SAFE USE
To avoid malfunction or damage to your iQunet Server please observe
the following:
•Do not expose it to water, moisture, or place on a conductive
surface whilst in operation.
•Do not expose it to heat from any source; the iQunet Server is
designed for reliable operation at normal ambient room
temperatures.
•Take care whilst handling to avoid mechanical or electrical damage
to the printed circuit board and connectors.
•The iQunet Server is not designed to be powered from a USB
port on other connected equipment, if this is attempted it may
malfunction.
GETTING STARTED
For full set up and installation instructions please visit
https://iqunet.com/resources/user-manuals/
•Mount the iQunet Server on DIN rail (35mm).
Mounting brackets for back or side installation are included.
•Install the External Dual Band Wifi Antenna (161mm) hand tight
only.
•Power with 8-24VDC / 22W max. (not included) using the 3-pole
connector supplied (mind the polarity!).
•Activate the hotspot: do not plug in a network cable for activating
the hotspot.
LOGGING ONTO YOUR IQUNET SERVER
Log on to your iQunet Server via hotspot or WebRTC:
Hotspot:
1. A WiFi hotspot is automatically created after 60 seconds once
the iQunet Server is connected to the mains. To activate the
hotspot, the ethernet cable must be unplugged.
2. Select the hotspot (SERN-xxxxxxxxxxxx) in the network center
on your PC or mobile phone and click Connect. The hotspot’s
password is the Sensor Proxy ID (server-xxxxxxxx). The
Sensor Proxy ID is provided by iQunet.
3. Open a new browser page. Browse to
192.168.42.1:8000/dashboard/app to open the iQunet
Sensor Dashboard.
WebRTC:
1. Install a network safely connected to internet by using the
above Hotspot functionality in the “Wired” or “Wifi” tab of the
dashboard.
2. Connect your PC to the internet. Surf to connect.iqunet.com.
Log in with your Google account or create a new account
using your email address.
3. Click on “Add Server Node”. Enter the Sensor Proxy ID
(server-xxxxxxxx) and provide an alias name for the Server.
Click “Save”. The Sensor Proxy ID is provided by iQunet.
4. Click on the created server node to open the iQunet Sensor
Dashboard.
GENERAL
IP degree (IEC 529): IP20 (indoor only)
Operating temperature & humidity:
•-20°C to +60°C
•10%-95% humidity – noncondensing

D1526-en-CUST
DVDB-230104
<199310 IPC iQunet Server Quick Start SERV199310-IPC-FR201-DoC-D1526-en-CUST-230104>
QUICK START INFORMATION
iQunet | Broekstraat 82, B-9220 Hamme, Belgium | T [phone] | [email protected] page 2/2
Subject to reasonable modicaons due to technical advances
REGULATORY COMPLIANCE
Hardware: FR201 FCC ID: 2ABCB-RPICM4
IC: 20953-RPICM4
Assembled in: EU
Other compliance:
•CE / FCC / UKCA / VCCI / ISED ICES-003
•SAFETY IEC/UL/EN 62368-1
•EMC CISPR 32/35 Class A
•FCC Part 15 Class A
•IEC/EN 60601-1-2:2014 EMC Ready
•Radio Equipment Directive (2014/53/EU)
•RoHS 3 Directive (2015/863/EU)
•REACH
•WEEE Directive (2012/19/EU)
FCC COMPLIANCE STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for
an uncontrolled environment. End users must follow the specific
operating instructions or satisfying RF exposure compliance. This
transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
DIMENSIONAL DRAWING [mm]
Dimensions excl. external WiFi antenna:
102.5 x 129 x 38 mm
(4.04 x 5.08 x 1.50 in)
Weight: 400g (incl. WiFi antenna)
Case: ABS / Aluminum
Din Rail Mount (excl. WiFi Antenna):
Back Din Rail Mount (excl. WiFi Antenna):
