High reliability, long and stable operation, maintenance unnecessary.
Infrared intelligent high-speed ball combines various control protocol, can support a variety of popular
system platform. With other system matching, each system connection and method of use not identical,
here do not specify, please contact the relevant system manufacturer or dealer contact to get necessary
information.
Infrared intelligent high-speed ball of various characteristics of large area, applicable to all walks of life
activities target surveillance. Such as power systems, telecom departments, bank security, mines,
intelligent building, intelligent community, city road monitoring, airports, railway stations, etc as security
monitoring situation, and the fire monitoring system of image monitoring equipment.
2.2 performance characteristics
1. Built-in OSD English onscreen menu, via the menu to display and change the ball machine information
and parameters can be set and call preset point, figure scanning, regional scanning and display area, etc.
2. Integrated design, compact structure, high reliability.
3. 255 preset points.
4.Adopt RS485 bus control.
5. Precision of motor drive, smooth operation, senstive reaction.
6. Level 360 ° continuous rotation, no monitoring blind spots.
7. Rotation speed camera variable times according to automatically adjust multiples,
8. 90 °, automatic vertical flipping 180 ° after continuous monitoring.
9.Automatic focus, automatic white balance.
10. Backlighting compensation function, have strong illuminant environment can see all the objects.
11. Combines various control protocol, baud rate is adjustable.
12. Wide dynamic camera support (SONY1010, SONY990) SONY490,
2.3 functional specification
Below briefly introduce infrared intelligent high-speed ball's main function, and describes the various
functions and operating the general principles, don't involve concrete operating methods.
1 set address coding, baud rate, control protocol
Any operation command has its target camera address coding, baud rate, control protocol, single camera
just response to their own address coding, baud rate, control protocol consistent operation orders. Camera
address coding, baud rate, control protocol specific setting methods please refer to dial the code Settings.
2 the target tracking.
The user can use the control on keyboard rocker control the camera up, down, left and right rotation, could
be used to track a moving target or mobile horizon, another can adjust focal length to change perspective
size or target image size. In automatic focus condition, with the rotation of the lens, cameras automatically
on the scenery changing quickly adjust, instant get a clear picture.
3. Focal length/speed automatic matching technology
Manual adjustment, focus the long ball machine, high-speed reflect make slight touches rocker may makes
the picture is moving, thereby causing loss of data. Based on the humanized design, intelligent ball focal
distance according to automatically adjust camera horizontal and vertical speed, make manual operation is
more easy target tracking.
Automatic flip 4.
The operator will lens pull bottom (vertical) if you still hold rocker, right now lens level automatically rotate
for 180 ° immediately after 90 °, upturned blade can be directly to watch on the back of the scenery, so as
