M3500 & E3500
Uncooled Infrared Modules & Engines
DRS Infrared Technologies
Key Product Features
●25 µm VOx µbolometer technology
●320 x 240 pixel resolution
●60 Hz video rate
●Low power operation
●Analog and 12-bit digital video
●Compact rugged design
The DRS M3500 is the world’s smallest 320 x
240 pixel resolution infrared module. At just over
two cubic inches, the M3500 easily can be inte-
grated into a variety of finished camera configura-
tions, including handheld or helmet mounted ap-
plications.
Building on the M3500’s core electronics, the
E3500 is a 60 Hz, 25µm pitch 320 x 240 pixel
camera engine providing unmatched integrator
flexibility and customization. Analog RS-170
video and optional 12 bit digital LVDS outputs are
provided at the camera back panel. Available
optics for the M3500 include 11mm and 25.7mm
f/1.0 Germanium lenses.
Both the M3500 module and E3500 camera en-
gine feature DRS’ 320x240 25µm pixel mi-
crobolometer for unsurpassed resolution and
thermal sensitivity. Camera level NEdT is typi-
cally better than 60 mKelvin.
Ruggedized packaging make the E3500 engine
suitable for a wide variety of OEM and end user
applications, including unmanned aerial and
ground vehicles, robotics, firefighting, and weap-
ons systems, to name but a few.
E3500 Camera Engine
Applications
●Homeland security
●Public safety
●Unmanned vehicles
●Process monitoring
●Research & development
●Firefighting
M3500 OEM Module

IRCAMERAS, INC.
877.IRcameras Toll Free ●508.668.5650 Voice ●508.668.5054 fax
[email protected] email
www.IRcameras.com
IRCAMERAS
M3500 & E3500 Uncooled Infrared Modules & Engines
System Specifications
M3500
Module
M3500 Module
With Shutter
E3500 Engine
Focal Plane Array
Detector Type Uncooled VOx Microbolometer
Array Size 320 x 240
Detector Pitch 25.4 µm
Spectral Response 8-12 µm
Temperature
Stabilization
None Required
Video
Frame Rate 60 Hz
Format RS-170
12-bit
(monochrome),
Single Ended
RS-170 (monochrome),
12-bit LVDS Digital (option)
Gain/Level/ Control Automatic (manual available)
Image Polarity White/Black Selectable
Serial Interface RS- 232
Electrical
Voltage 4 to 18 VDC
Power 1.8W Nominal
Environmental
Operating Temperature -20 to +49° C (-4 to +120°F)
Storage Temperature -46 to +71° C (-51 to +160°F)
Communication

IRCAMERAS, INC.
877.IRcameras Toll Free ●508.668.5650 Voice ●508.668.5054 fax
[email protected] email
www.IRcameras.com
IRCAMERAS
M3500
Module
M3500 Module
With Shutter
E3500 Engine
Optics
Lens NA No Lens 11mm 26mm
FOV NA NA 40°H x 30°V 18°H x 13°V
f/no. NA NA f/1 f/1
Mechanical
Dimensions/Module
Configuration
59 x 29 mm
(2.33 x 1.14”)
66 x 35mm
(2.61 x 1.38”)
NA
Dimensions/12-Pin
Standard Connector
NA 75.4x40.6mm 88.6x40.6mm 103.3x40.6mm
(2.97 x 1.60”) (3.49 x 1.60”) (4.07 x 1.60”)
Dimensions/LVDS
Digital Connector
NA 84.7x40.6mm 97.9x40.6mm 116.4x40.6mm
(3.34 x 1.60”) (3.86 x 1.60”) (4.58 x 1.60”)
Weight 56 g 65g 121g 162g 182g
