Italinox GRN012 User manual

1
GAS GRIDDLE
User Manual
MODEL: GRN012 / GRN006
★All mirror stainless steel construction
★Automatic thermostat
★High-efficient, easy operable &safe
★Durable and elegant design
FOR THE PURPOSES OF THIS DOCUMENT THE FOLLOWING TERMS AND
DEFINITIONS APPLY.
I. Safety instructions

2
IMPORTANT, PLEASE READ INSTRUCTIONS FULLY BEFORE USE
THIS APPLIANCE IS ONLY FOR PROFESSIONAL USE AND MUST ONLY
BEUSED BY QUALIFIED PEOPLE.
Attention should be drawn to the fact that parts of this unit by necessity, will get VERY
HOT, and will cause burns if touched accidentally. Therefore it is the responsibility of
the supervisor or equivalent to provide SUITABLE PROTECTIVE CLOTHING for
the user.
THIS APPLIANCE MUST BE FITTED AND TESTED BY A REGISTERED FITTER
BEFORE USE.
The unit should be installed in compliance with the INSTALLATION
INSTRUCTIONS and the NATIONAL REGULATIONS in force at the time.
Particular attention should be paid to the Gas Safety (Installation and Use)
Regulations and the Health and Safety at Work Act.
Each appliance requires a flow of fresh air for combustion. Under no circumstances
should air vents on the appliances, or air vents installed by the fitter in the room of the
appliance to supply combustion air, be altered or omitted in any way.
To prevent shocks, all appliances whether gas or electric, must be earthed.
ANY GAS CONVERSIONS NEEDED TO BE MADE TO THE PRODUCT MUST
BE CARRIED OUT BY A QUALIFIED REGISTERED ENGINEER
To avoid scratching the highly polished exterior surface of this equipment whilst in
transit, the protective film on the exterior surfaces has NOT been removed. It is
IMPORTANT that this protective film need to be peeled off before the equipment is
used.

7
II. Technical Specification:
Model
Input Power
Dimension
Net Weight
Plate
GRN012
2800+2800
650*590*360
33.5
GAS GRIDDLE 650MM
SMOOTH PLATE
GRN006
2800+2800
650*590*360
32
GAS GRIDDLE 650MM
SPLIT TOP -RIBBED
AND SMOOTH
III. Clean, Repair and Maintenance:
1CLEAN
After use for each time, please clean it with soft dry fabric, avoid using sharp
metal, and strictly prohibit cleaning with water.
The remaining oil of the griddle in the bottom should be cleaned out after each
use.
2MAINTENANCE
The thermal protective device will operate and cut off the gas when the
temperature is too high while using. Please check the machine after the gas is cut
off .

6
EXPLODE

3
FOR THE PURPOSES OF THIS DICUMENT THE FOLLOWING TERMS AND
DEFINITIONS APPLY.
Correct Disposal of this product
This marking indicates that this product should not be disposed
with other household wastes throughout the EU. To prevent
possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used device,
please use the return and collection systems or contact the retailer
where the product was purchased. They can take this product for
environmental safe recycling.
IV. Installation
ALL APPLIANCES MUST BE FITTED AND OR CONVERTED BY
AREGISTERED INSTALLER, IN ACCORDANCE WITH CURRENT
REGULATIONS.
INSTALLATION
1. Appliances are designed to be installed, on factory for stability, should they be fitted
on any other surface they should be suitably secured, to prevent excessive movement.
All appliances must not be installed on or against any combustible surface.
2. Appliances are supplied in for use with either Natural Gas or LPG. The required gas
type must be
specified at the point of order. Natural Gas appliances have an LPG conversion kit
included as
standard. Conversion kits for LPG models must be purchased separately.
3. Clearances around appliances must be:

4
1）. CEILING/SHELF 1500mm
2）. REAR 350mm
3）. SIDES 100mm
It should be noted that the sides of the appliance will get hot and appliances with
components
sensitive to heat, should not be placed directly next to the unit.
4. Leg Installation see picture below. The leg channel is located on the package base.
This channel must be installed when using the legs.
5. Connection to the appliance is by ½ BSPT at the rear of the appliance.
6. Pressure test point is located at rear of appliance.
7. The low rate adjuster is factory set and sealed for natural gas. If a unit needs to be
converted, the qualified engineer must reseal the low rate adjuster after conversion.
8. Remove all protective film before use.
9. Ensure whoever is operating the appliance is fully conversant with its operation and
aware of dangers involved in incorrect operation and cleaning, especially the danger
of burns or scalds from the cooking medium and hot surfaces of working areas.
10. These appliances are to be installed with sufficient ventilation to prevent the
occurrence of unacceptable concentrates of substances harmful to health in the

5
room in which they are installed.
11. During installation provision must be made for combustion air supply to the
appliance, which enters the appliance through the base and rear of the appliance, this
should not be blocked at any time. SEE TECHNICAL
V. Operating Instruction:
FOR FITTING INSTRUCTIONS SEE INSTALLATION SECTION.
ALL GRIDDLES ARE FITTED WITH FLAME FAILURE DEVICE FOR SAFETY AND SPARK IGNITION
FOR EASE OF LIGHTING TO LIGHT BURNER:
1. Use your left hand to push in the tap and turn it anti-clockwise to position” ”.
2. Holding the tap fully in, use your right hand to depress the red ignitor button on the right
side and observe that the pilot lights. If it does not, repeatedly depress the ignitor button
until it does.
3. When the burner is lit, continue to hold the tap in for about 15 to 20 seconds, then release
it.
4. If it still couldn’t ignite after one minutes, then turn the tap back to position ”●”. Wait for
5 minutes, then repeat from step 1~3.
5. When you use this appliance at the first time, there will be air inside the air inlet pipe,
which may result in the failure in ignition. Ignite again in the above-mentioned way until
it is successful.
6. The fire is the most power when the switch of the appliance is turn to 90. When it is
turned to greater or less than 90, the fire will gradually reduce.
7. When the heating plate is heated to the require temperature, you can begin to griddle
food, When the food is done, take out the food lest the surface of the hot plate will be
scratched.
8. After use, turn the switch of the appliance clockwise until a ticking sound is heard and
turn off the control valve of the liquid gas storage tank.
