OPERATOR’S MANUAL
BM25 BEVELLING MACHINE
PART NO. WA-BM25
TO PREVENT SERIOUS INJURY OR DAMAGE TO YOUR WATER PUMP, READ
AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONS BEFORE USE
! !
ul. Elewatorska 23/1, 15-620 Białystok
Phone: [phone], Fax: [phone]
www.promotech.eu e-mail: [e-mail]
OPERATOR’S MANUAL
BEVELLING MACHINE
BM-25

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
TABLE OF CONTENTS
Contents
1. GENERAL INFORMATION ............................................................................................... 3
1.1. Application ................................................................................................................. 3
1.2. Technical data............................................................................................................ 3
1.3. Dimensions ................................................................................................................ 4
1.4. Equipment included ................................................................................................... 5
1.5. Design ....................................................................................................................... 6
2. SAFETY PRECAUTIONS.................................................................................................. 7
3. SYMBOLS......................................................................................................................... 9
4. STARTUP AND OPERATION ..........................................................................................10
4.1. Handle installation.....................................................................................................10
4.2. Handle adjustment ....................................................................................................11
4.3. Beveling angle adjustment ........................................................................................12
4.4. Horizontal guide guards ............................................................................................13
4.5. Vertical guide guard ..................................................................................................14
4.6. Beveling depth adjustment........................................................................................15
4.7. Cutting inserts installation .........................................................................................16
4.8. Replacing the cutting inserts .....................................................................................17
4.9. Turning the guide unit ...............................................................................................18
4.10. Positioning the horizontal guide rollers................................................................19
4.11. Preparation for machining...................................................................................19
4.12. Operating............................................................................................................20
4.13. Bevel width .........................................................................................................24
4.14. Working at angle of 0° ........................................................................................26
4.15. Working at angle of 90° ......................................................................................26
4.16. Head disassembly ..............................................................................................27
4.17. Replacing the brushes ........................................................................................29
4.18. Cleaning .............................................................................................................29
5. DECLARATION OF CONFORMITY .................................................................................30
6. ENVIRONMENTAL PROTECTION ..................................................................................31
7. WARRANTY CARD..........................................................................................................32
2www.itmtools.com.au

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
3
1. GENERAL INFORMATION
1.1. Application
The BM-25 is a beveling machine designed to bevel plates made of non-alloy steel.
It allows for beveling at the angle from 0° to 90° and with the maximum bevel width of
25 mm, however, the recommended range is from 15° to 75°.
It is equipped with the ergonomic handle allowing for positioning the machine in a
comfortable position according to the machining angle, workbench height, and
operator’s body type, as well as optimal load distribution between the operator’s hands.
The rollers on the horizontal guide may be set in position suitable for the width of
workpiece.
1.2. Technical data
Voltage
1~ 220-240 V, 50-60 Hz
Power
2200 W
Rotational speed with no load
1800-5850 rpm
Protection level
IP 20
Protection class
II
Maximum bevel width (b, Fig. 1)
25 mm (0.98″)
Maximum milling head depth (d, Fig. 1)
12.5 mm
Bevel angle (ß, Fig. 1)
0°-90°
Minimum workpiece thickness
2 mm
Noise level
More than 70 dB
Vibration level
2.3 m/s2(7.5 ft/s2)
Machine harmful for health.
Take periodic breaks during work.
Weight
12.5 kg
Required ambient temperature
0-40°C
Fig. 1 Bevel dimensions
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
3
1. GENERAL INFORMATION
1.1. Application
The BM-25 is a beveling machine designed to bevel plates made of non-alloy steel.
It allows for beveling at the angle from 0° to 90° and with the maximum bevel width of
25 mm, however, the recommended range is from 15° to 75°.
It is equipped with the ergonomic handle allowing for positioning the machine in a
comfortable position according to the machining angle, workbench height, and
operator’s body type, as well as optimal load distribution between the operator’s hands.
The rollers on the horizontal guide may be set in position suitable for the width of
workpiece.
1.2. Technical data
Voltage
1~ 220-240 V, 50-60 Hz
Power
2200 W
Rotational speed with no load
1800-5850 rpm
Protection level
IP 20
Protection class
II
Maximum bevel width (b, Fig. 1)
25 mm (0.98″)
Maximum milling head depth (d, Fig. 1)
12.5 mm
Bevel angle (ß, Fig. 1)
0°-90°
Minimum workpiece thickness
2 mm
Noise level
More than 70 dB
Vibration level
2.3 m/s2(7.5 ft/s2)
Machine harmful for health.
Take periodic breaks during work.
Weight
12.5 kg
Required ambient temperature
0-40°C
Fig. 1 Bevel dimensions
3
www.itmtools.com.au

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
4
1.3. Dimensions
344
803
170
4www.itmtools.com.au

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
5
1.4. Equipment included
1
Beveling machine
1 unit
2
Plastic box
1 unit
3
Guard 45°
1 unit
4
Guard 30°
1 unit
5
Grease
1 unit
6
Drift
1 unit
7
Combination wrench 22 mm
1 unit
8
Hex wrench 4 mm
1 unit
9
10 mm hex wrench
1 unit
10
Cutting inserts
5 units
-
Operator’s Manual
1 unit
1
2
3
4
5
6
7
8
10
9
5
www.itmtools.com.au

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
6
1.5. Design
Speed knob
Switch lock
Handle
Air vents
Clamping lever
Chip guard
Handle
Vertical guide roller
Horizontal guide roller
Bevel depth knob
Power switch (ON/OFF)
Guide unit
Milling head
Vertical guide
Horizontal guide
6www.itmtools.com.au

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
7
2. SAFETY PRECAUTIONS
1. Before use, read this Operator’s Manual and complete a training in occupational
health and safety.
2. Use only in applications specified in this Operator’s Manual.
3. Make sure that the machine has all parts and they are genuine and not damaged.
4. Make sure that the specifications of the power source are the same as those
specified on the rating plate.
5. Do not carry the machine by the power cord and do not pull the power cord. This
may cause damage and electric shock.
6. Keep untrained persons away from the machine.
7. Before each use, ensure the correct condition of the machine, power source, power
cord, plug, control parts, and tools.
8. Before each use, make sure that no part is cracked or loose. Make sure to maintain
correct conditions that may influence the operation of the machine.
9. Keep the machine dry. Do not expose the machine to rain, snow, or frost.
10. Keep the work area well-lit, clean, and free of obstacles.
11. Do not use in explosive environments or near flammable materials.
12. Use only tools specified in this Operator’s Manual.
13. Do not use tools that are dull or damaged.
14. Make sure that the cutting inserts and the milling head are installed correctly.
Remove wrenches from the work area before you connect the machine to the
power source.
15. Do not use the machine with the milling head pointing up.
16. Do not carry the machine with rotating head. Before carrying unplug the machine
from the power source.
17. If the cutting edge of an insert is worn, turn all inserts by 180°. If all cutting edges
are worn, replace all inserts with new ones specified in this Operator’s Manual.
18. Use eye and ear protection, work boots, protective clothing and heat-resistant
gloves. The clothing must not be loose.
19. Due to high level of vibrations it is recommended to use the anti-vibration gloves.
20. Do not touch chips or moving parts with bare hands. Do not let anything catch in
moving parts.
7
www.itmtools.com.au

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
8
21. After use, clean the machine and the milling head with a dry cotton cloth and
without any chemical agents. Do not remove chips with bare hands.
22. Maintain the machine and attach/remove parts and tool only after you unplug the
machine from the power source.
23. Repair only in a service center appointed by the seller.
24. If the machine falls, is wet, or has any damage, stop the work and promptly send
the machine to the service center for check and repair.
25. If you are not going to use the machine, remove it from the work area and keep it
in a safe and dry place.
26. If you are not going to use the machine for an extended period, put anti-corrosion
agent on steel parts.
8www.itmtools.com.au

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
9
3. SYMBOLS
Before using the machine, familiarize yourself with the following symbols (tab. 1).
Use eyes protection
Use hearing protection
Read the Operator’s Manual
Warning against electric voltage
Tab. 1. Explanation of symbols
9
www.itmtools.com.au

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
10
4. STARTUP AND OPERATION
4.1. Handle installation
The beveling machine is delivered with dismantled handle. In order to install the handle
after unpacking the machine proceed as below.
Unscrew the domed nut from the threaded mandrels (1). Remove the spring washers
from the threaded mandrels (2). Leave the teeth lock washers (3) in place. Put the
handle (4) onto the threaded mandrels, bending it slightly out. Put the spring washers
on and screw the domed nuts on using 22 mm flat wrench.
1
2
3
2
3
4
1
10 www.itmtools.com.au

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
11
4.2. Handle adjustment
The beveling machine handle may be adjusted in three axes so the operator may adapt
it to their needs. To adjust, loosen the domed nuts (1) and screws (2) and (3) using 22
mm flat wrench. Perform adjustment and tighten the loosened elements.
3
2
1
11
www.itmtools.com.au

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
12
4.3. Beveling angle adjustment
Unplug the power cord. Loosen the screws (1) on both sides of the guide unit and lift
the guards (2). Then loosen the screws (3) on both sides of the scale and guide unit
and set the required bevel angle (4).
Tighten the screws (5) on both sides of the scale, lower the guards (6) completely, and
tighten the all screws of the guide unit (7).
5
6
7
6
4
3
2
1
2
12 www.itmtools.com.au

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
13
4.4. Horizontal guide guards
During operation with beveling angles of 30° and 45° it is required to use the horizontal
guide guards dedicated for those angles. To replace the guard proceed as below.
Remove the hexagon socket head screws (1). Remove the basic guard (2). Install
guard (3) or (4) according to the machining angle. Tighten the hexagon socket head
screws.
The guard should touch the guide so the chips are not ejected onto the workpiece
surface.
1
2
3
4
45°
30°
13
www.itmtools.com.au

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
14
4.5. Vertical guide guard
Pay attention during adjustment of the vertical guide guard that the distance between
the guide and the guard should be approx. 5-6 mm. It allows for free falling of chips
without their accumulation behind the guard.
14 www.itmtools.com.au

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
15
4.6. Beveling depth adjustment
Unplug the power cord. Release the lever (1). Rotate the knob (2) so that the scale (3)
shows the bevel depth “d” (max. 12.5 mm) related to the required bevel width “b” (max.
25 mm). Lock the lever.
The depth change is 0.1 mm (0.02″) per graduation or 3 mm (0.16″) per one full turn of
the knob.
After adjusting the depth perform the test machining and correct the setting as required.
1
2
d = 0,1 mm
3
15
www.itmtools.com.au

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
16
4.7. Cutting inserts installation
Unplug the power cord. Remove the screws (1) and guards (2) on both sides of the
guide unit.
Position the guides in such way that the horizontal guide is parallel to the machine
body (1) (value of 90° on the scale). .Release the lever (2). Hold the guides by hand
and rotate the bevel depth knob (3) until the head protrudes fully.
1
2
3
2
1
16 www.itmtools.com.au

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
17
Prepare screws (1) covered with delivered grease. Put the insert (2) in the socket,
press it down and fix with screw, using T15 torx screwdriver. Make sure that the whole
bottom of the insert touches the socket.
At the end reinstall the guards and set the guides at appropriate angle.
4.8. Replacing the cutting inserts
When inserts become dull, they should be rotated or replaced.
Unplug the power cord. Set the guides and head like during installation of new inserts.
Use T15 torx screwdriver to remove the cutting inserts. Clean the sockets.
To change the cutting edge rotate the inserts by 180°. Press the inserts towards the
sockets and tighten them. If all cutting edges are worn, replace the inserts with new
ones. Make sure that the whole bottom of the insert touches the socket.
2
1
INCORRECT
×
CORRECT
✓
17
www.itmtools.com.au

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
18
4.9. Turning the guide unit
Unplug the power cord. Release the lever (1). Hold the bevel depth knob (2) so it
does not rotate in relation to the guide unit and turn the guide unit to the desired position
(3). Correct the bevel depth when required. Lock the lever (4).
2
3
2
4
1
18 www.itmtools.com.au

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
19
4.10. Positioning the horizontal guide rollers
When width of the workpiece is below 110 mm, the rollers on the horizontal guide may
be set in position suitable for that width.
Remove four hexagon socket head screws (1) of the roller to be moved. Move the roller
(2) to desired position. Fix the roller with use of hexagon socket head screws.
4.11. Preparation for machining
Set the required bevel width. Then use the speed knob to set the rotational speed.
Material
Rotational speed
Structural steel of standard quality, quality steel Setting 3-6
(3100-5850 rpm)
The speed knob allows for control of the rotational speed in the range of 1800-5850
rpm.
Setting
1
2
3
4
5
6
Speed
1800
rpm
2400
rpm
3100
rpm
3800
rpm
4500
rpm
5850
rpm
To machine the structural steel of standard quality or quality steel, set the speed to 6
and decrease the speed if much sparking occurs.
1
2
19
www.itmtools.com.au

BM25 BEVELLING MACHINE
OPERATOR’S MANUAL
BM-25
This document is protected by copyrights.
Copying, using, or distributing without permission of PROMOTECH is prohibited.
20
4.12. Operating
For the best results and optimum work, height of the workpiece above the surface on
which the operator stands should be approx. 70 cm, however, it depends on the
operator’s height. It allows the operator to work with slightly bent arms for lower
tiredness and better pressing force.
It is good to place the anti-slip mats on the floor in order to eliminate skid of operator’s
feet during stronger pressing. It is also favorable to use the perforated base to avoid
operator’s feet sliding on the chips.
20 www.itmtools.com.au
