ITRON IPC-E200N User manual

i
HD Panorama Network Camera Quick Start Guide
Version 1.0.0

i
Welcome
Thank you for purchasing our network camera!
This user’s manual is designed to be a reference tool for your system.
Please read the following safeguard and warnings carefully before you use
this series product!
Please keep this user’s manual well for future reference!
1．Electrical safety
All installation and operation here should conform to your local electrical
safety codes.
The power shall conform to the requirement in the SELV (Safety Extra Low
Voltage) and the Limited power source is rated 12V DC in the IEC60950-1.
This series product supports PoE too.
Note: Do not connect these two power supplying sources to the device
at the same time; it may result in device damage!
We assume no liability or responsibility for all the fires or electrical shock
caused by improper handling or installation.
We are not liable for any problems caused by unauthorized modification or
attempted repair.
2．Transportation security
Heavy stress, violent vibration or water splash are not allowed during
transportation, storage and installation.
3．Installation
Do not apply power to the camera before completing installation.
Please install the proper power cut-off device during the installation
connection.
Always follow the instruction guide the manufacturer recommended.
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service
engineers.
We are not liable for any problems caused by unauthorized modifications or
attempted repair.

ii
5．Environment
This series network camera should be installed in a cool, dry place away from
direct sunlight, inflammable, explosive substances and etc.
Please keep it away from the electromagnetic radiation object and
environment.
Please make sure the CCD (CMOS) component is out of the radiation of the
laser beam device. Otherwise it may result in CCD (CMOS) optical
component damage.
Please keep the sound ventilation.
Do not allow the water and other liquid falling into the camera.
Thunder-proof device is recommended to be adopted to better prevent
thunder.
The grounding holes of the product are recommended to be grounded to
further enhance the reliability of the camera.
6. Daily Maintenance
Please shut down the device and then unplug the power cable before you
begin daily maintenance work.
Do not touch the CCD (CMOS) optic component. You can use the blower to
clean the dust on the lens surface.
Always use the dry soft cloth to clean the device. If there is too much dust,
please use the water to dilute the mild detergent first and then use it to clean
the device. Finally use the dry cloth to clean the device.
Please put the dustproof cap to protect the CCD (CMOS) component when
you do not use the camera.
Dome enclosure is the optical component, do not touch the enclosure when
you are installing the device or clean the enclosure when you are doing
maintenance work.
7. Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components
are included.
Contact your local retailer ASAP if something is broken in your package.
Accessory Name
Amount
Network Camera
1
Quick Start Guide
1
Installation Accessories Bag
1
CD
1

iii
Table of Contents
1 Structure....................................................................................................1
1.1 Multi-function Combination Cable .................................................1
1.2 Dimensions ...................................................................................1
1.3 Bidirectional Talk...........................................................................2
1.3.1 Device-end to PC-end.............................................................3
2 Installation .................................................................................................4
2.1 General Installation.......................................................................4
2.2 Device Installation Steps...............................................................4
2.3 Micro SD Card Installation.............................................................5
2.4 Manual Zoom Lens Focus Operation............................................6
3 Quick Configuration Tool...........................................................................7
3.1 Overview.......................................................................................7
3.2 Operation ......................................................................................7
4 Web Operation ........................................................................................10
4.1 Network Connection....................................................................10
4.2 Login and Main Interface.............................................................10
4.3 Panorama Function on Web........................................................12
4.3.1 Installation Mode...................................................................12
4.3.2 Display Mode........................................................................13
5 FAQ.........................................................................................................14
Appendix Toxic or Hazardous Materials or Elements ....................................15

1
1 Structure
1.1 Multi-function Combination Cable
Figure 1- 1
The multi-function cable is in Figure 1- 1.
Please refer to the following sheet for corresponding information.
1.2 Dimensions
You can refer to the following figures for dimension information. The Unit is mm. See
Figure 1- 2, Figure 1- 3, and Figure 1- 4.
Figure 1- 2
No.
Port
Port Name
Connector
Description
1
LAN
Network port
Ethernet
Connect to Ethernet cable.
2
DC12V
Power input
/
Power port, input 12V DC.

2
Figure 1- 3
Figure 1- 4
1.3 Bidirectional Talk

3
1.3.1 Device-end to PC-end
Device Connection
Please connect the speaker to the audio input port of the PC.
Login the Web and then click the Talk button to enable the bidirectional talk function.
You can see the button becomes orange after you enabled the bidirectional talk function.
Click Talk button again to stop the bidirectional talk function.
Listening Operation
At the device end, speak via the speaker, and then you can get the audio at the pc-end.

4
2 Installation
Important
Before you complete the installation and setup, do not remove the electrostatic
attraction film on the transparent enclosure. Otherwise it may result in injury.
After remove electrostatic attraction film, do not touch dome enclosure in case
it may leave stain.
Before the installation, please make sure the installation surface can sustain at
least 3X weight of the bracket and the camera.
2.1 General Installation
Please refer to Figure 2- 1 for device installation information. You can see there are
installation screws in the accessories bag for you to install the device conveniently.
Figure 2- 1
2.2 Device Installation Steps
Step 1
Use the inner hex wrench from the accessories bag to unfasten the 3 hex screws on the
dome camera enclosure and then remove it.
Step 2
Take the installation position diagram from the accessories bag and then paste it on the
installation ceiling or the wall according to the monitor area. Please dig three bottom holes

5
of the plastic expansion bolts according to the diagram. Take three expansion bolts from
the accessories bag and then insert them to the holes you just dug and then fix firmly. If
you need to dig a hole to pull through the cable on top of installation surface, you need to
dig a cable exit hole on the installation surface according to the installation positioning
diagram. If you need to pull through the cable on the side, you need to dig through the U-
shape exit hole on the side of chassis.
Step 3
Adjust the device chassis and pull the cable through the exit hole. Make “TOP” direction
of the device identical with installation diagram. Make fixture hole on chassis face the
three plastic expansion bolts (in Step 1). Take 3 ST3.0 self-tapping screw out from the
accessories bag and fix them on the three plastic expansion bolts to secure the chassis
on installation surface.
Step 4
Line up the dome camera protection enclosure and follow step 1 reversely to put it back.
Use the inner hex wrench from the accessories bag to fasten the 3 hex screws. For
Micro-SD card installation, please refer to Chapter 2.3.
See Figure 2- 2 for grounding hole (GND).
Figure 2- 2
Note: If connect the GND to ground lead, may improve device reliability. The GND
locates next to exit hole on chassis and the GND screw is M3.
2.3 Micro SD Card Installation
Warning!

6
Please unplug the device power cable and then shutdown the device before you
install the Micro SD card.
Please make sure the wire between power panel and device motherboard is firm,
otherwise may cause abnormity.
Please put the enclosure back and fasten the screws tightly to prevent dust.
Step 1
Please refer to Step 1 in chapter 2.2 to open the device protection enclosure.
Step 2
Please find the “SD” mark inside the device according to Figure 2- 3. Insert Micro-SD card
and put the enclosure back.
Figure 2- 3
2.4 Manual Zoom Lens Focus Operation
The lens of the HD panorama network camera is 180°, no manual zoom is required.
