ITW Gema EasyTronic Guide

23
EasyTronic
Issued 07/02
Operating Instructions and Spare Parts List
EasyTronic
Control Unit
E

24 EasyTronic
Issued 07/02
Mains connectionAux
Gun
1.1 IN
5 ... 10 bar
73...145 PSI
1.4 2.2 2.3
2.1
1.3
1.2 1.5
Input voltage:
Input power:
Degree of protection:
Output:
Corresponding guns:
85 – 264 V
47 – 440 Hz
65 VA
IP 54
10 V 1,2 A
EasySelect
POWDER GUN CONTROL
TYPE EASYTRONIC
CONNECTIONS ON THE REAR OF THE EASYTRONIC CONTROL UNIT
1Diagnostic LEDs
2Powder output display
3Key for setting the
powder output
4Electrode rinsing air key
5Application key for flat
parts
6Application key for
complicated parts
7Application key for
overspraying
8On / Off Push button
9Key for setting the total
air volume
10 Diagnostic LED for High-
voltage
11 Total air volume display
EASYTRONIC CONTROL UNIT - FRONT VIEW
1.1 IN Compressed air input
1.2 Conveying air connection
1.3 Supplementary air connection
1.4 Rinsing air connection
1.5 Fluidizing air connection
2.1 Mains input (85-264 V)
2.2 Gun connection for the
EasySelect Manual Powder
Gun.
PG 1 manual powder guns
cannot be connected here!
2.3 Output for Vibrator (EASY 1-B
only) and Stirrer control unit
(EASY 1-S only)
Ground connection
11
1
0
9
8765
4
3
2
1

25
EasyTronic
Issued 07/02
Table of Contents
Directions for use
Safety rules for electrostatic Powder coating
Technical Data - EasyTronic Control unit
EasyTronic Control Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Field of Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Operating mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Description of the EasyTronic Control unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation of the Powder coating equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Preparation for Start up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
a) Setting the Operating mode on the Electronic board . . . . . . . . . . . . . . . . . . . . . 4
b) Preparation of the Powder hopper / container . . . . . . . . . . . . . . . . . . . . . . . . . . 5
c) Switching on the Booth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
d) Function check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Daily Start up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
a) Setting the Powder output, and Powder cloud . . . . . . . . . . . . . . . . . . . . . . . . . 6
Set the Total air volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Select the Powder output volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Select the electrode rinsing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
b) Powder coating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
c) Remote control through the Powder gun . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
d) Switching off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
When the Powder coating equipment is not used for a number of days . . 7
Repairs to Electrical parts of the Control unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
a) Replacing fuse(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
b) Replacing the CG 01 Printed Circuit Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
c) Replacing the Front plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Dismantle Main switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Repairs to Pneumatic parts in the Control unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
a) Replacing a Pneumatic Part . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Removing the pneumatic tubes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Replacing the pneumatic tubes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Pneumatic diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Display of the Operating Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Spare parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Ordering Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
EasyTronic Control Unit - Pneumatic Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
EasyTronic Control Unit - electrical Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
EasyTronic Control Unit - Accessory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

26 EasyTronic
Issued 07/02

27
EasyTronic
Issued 07/02
DIRECTIONS FOR USE
Safety rules for electrostatic Powder coating
1. This equipment can be dangerous when not operated according
to the following standards:
EN 50 050 (or VDE 0745 Part 100),
EN 50 053 Part 2 (or VDE 0745 Part 102),
and specification sheet, ZH 1/443 Electrostatic Powder Coating.
2. All electrically conductive parts within 5 m of the coating area,
especially the workpieces, must be grounded.
3. The floor in the coating area must be electrically conductive
(normal concrete is generally conductive).
4. The operating personnel must wear electrically conductive foot-
wear (i.e. leather soles).
5. The operating personnel should hold the powder gun in the bare
hand. If gloves are worn they must be electrically conductive.
6. Connect the grounding cable (green/yellow) supplied to the
grounding screw of the electrostatic manual powder coating
equipment. The grounding cable must have a good metal to metal
connection with the powder coating booth, the powder recovery
equipment and the chain conveyor or the hangers of the objects.
7. The electric cables and powder hose to the guns must be laid out
so that they are protected from possible mechanical damage.
8. The powder coating equipment must switch on only after the
powder booth is in operation. If the booth breaks down, then the
powder coating equipment must switch off.
9. The grounding of all conductive parts is to be checked at least
once a week.
10. When cleaning the powder gun and when replacing nozzles the
control unit must be switched off.

28 EasyTronic
Issued 07/02
TECHNICAL DATA - EASYTRONIC CONTROL UNIT
Mains connection:
Input voltage: 90 - 264 V
Frequency: 47 - 440 Hz
Nominal output voltage (to gun): max. 12 VS
Nominal output current (to gun): max. 1 A
Type of protection: IP 54
Temperature range: 0 °C to +40 °C
(+32 °F to +104 °F)
Approval:
Pneumatic Data
Main compressed air input: B.S.P.1/4" (Female)
Max. Input pressure: 10 bar
Min. Input pressure: 6 bar
Max. water content of the compressed air: 1.3 g/m3
Max. oil vapour content of the compressed air: 0.1 mg/kg
Dimensions:
Width: 248 mm
Depth: 250 mm
Height: 174 mm
Weight: 5.2 kg
The EasyTronic Control Unit can only be used with the EasySelect
manual gun.
IMPORTANT

1
EasyTronic
Issued 07/02
EASYTRONIC CONTROL UNIT
Field of Application
The electrostatic EasyTronic Control Unit is designed exclusively for the
controlling powder coating with the EasySelect manual powder gun.
This equipment is not to be used for any other purpose. Any damage
resulting from its misuse is not the responsibility of the manufacturer,
the entire risk is carried by the customer alone.
All settings for efficient powder coating have been made simple and
reproducible on the EasyTronic. The built-in electronics permit exact
setting of the optimum powder output, and the values set can be seen
on the digital display windows and can even be checked from a
distance. According to the selected application mode, the spray voltage
is set automatically and spray current is limited automatically.
The EasyTronic Control Unit can be connected to all usual mains
voltages.
For a better understanding of the relationships in powder coating it is
recommended to read the operating instructions of other components,
thoroughly, so as to be familiar with their functions also.
Operating mode
The EasyTronic Control Unit is foreseen as standard for operation with
all manual coating equipment in the EASY range. The desired
functionality must, however, be determined by means of a "jumper" on
the electronic board inside the control unit. If the control unit is supplied
as a component of an EASY unit, then the "jumper" will be
correspondingly set in the correct position at the factory.
In every other case, it is recommended to check the setting of the
"jumper" (see also the corresponding section "Setting the operating
mode on the electronic board ").
An incorrectly set "jumper" can lead to malfunctioning or to
reduced functioning of the Vibration, Fluidization or Stirrer!
NOTICE

2EasyTronic
Issued 07/02
The operating panel of the EasyTronic control unit consists of 4 main
areas: Diagnostic LEDs, Displays, "+/–" Keys, and Function keys.
1. The Diagnostic LEDs 1–8 serve to show the status of the equip-
ment, and equipment faults. Detailed information is found in the
"Troubleshooting Guide"
2. There are two Displays with whose help the following values are
displayed:
•Powder output (Setting range 0–100 %) Powder output in %
always refers to the max. possible output volume to the total
air volume setting.
•Total air volume (Setting range 1.6–6.0 Nm3/h)
3. The Keys "+" and "–" are for setting the powder output, and the
total air volume used.
If a key is pressed once, the value is increased or decreases,
respectively, by one step. If a key is pressed continuously, the
setting change rapidly.
4. The Function keys have the following functions:
•Electrode rinsing air for flat jet nozzles
•Electrode rinsing air for round jet nozzles
When a key is pressed once, the corresponding function is
activated, and the corresponding LED illuminates.
If a key with an illuminated LED is pressed for longer than 1
second, the function is deactivated.
ITW Gema recommends leaving the electrode rinsing air
switched on, but can, however, remain switched off for
applications with very small amounts of powder.
•Application keys: With these keys the electrostatic (High-
voltage, and current) are automatically set so that the setting
for the selected application is the optimum.
– Settings for flat parts
– Settings for complicated parts with depressions
– Settings for coating parts already coated
High-voltage and current can be deactivated, when the
corresponding key pad with the illuminated LED is pressed for
longer than 1 second.
The EasyTronic control unit is switched on and off with a Push button.
If the equipment is switched on, the yellow lamp is illuminated.
When the equipment is first switched on the preselected factory
settings displayed:
60% 4.0 Nm3/h
Flat jet rinsing Complicated parts
After switching the equipment off (also when the equipment is discon-
nected from the Mains) the actual settings are retained.
DESCRIPTION OF THE EASYTRONIC CONTROL UNIT
Figure 1

3
EasyTronic
Issued 07/02
INSTALLATION OF THE POWDER COATING EQUIPMENT
1. Connect the hose for the compressed air supply from com-
pressed air circuit directly to the main air connection - 1.1 IN on
the rear of the control unit (female thread: 1/4" B.S.P.).
The compressed air must be free from oil and water.
2. Connect the black hose for the fluidizing air (if required) to the
corresponding output (1.5) on the rear of the control unit.
3. Fit the grounding connection cable on the control unit with the
grounding screw , and the 5 m long grounding cable with the
clamping clip to the booth or on the hanger device.
4. Connect the gun cable with the 7 pin plug on the rear of the
control unit on the socket - 2.2 (Gun).
PG 1 Manual powder guns cannot be connected!
5. Connect the hose for
rinsing air to the rinsing air
output - 1.4 and to the
powder gun.
6. Plug the injector in, and
connect the powder hose
to the injector and to the
powder gun.
7. Connect the red hose for
the conveying air to the
corresponding output - 1.2
on the rear of the control
unit and to the injector.
8. Connect the black hose for
the supplementary air to
the corresponding output -
1.3 on the rear of the
control unit and to the
injector.
9. Connect the Mains cable on
the socket - 2.1.
Figure 2
Mains connectionAux
Gun
1.1 IN
5 ... 10 bar
73...145 PSI
1.4 2.2 2.3
2.1
1.3
1.2 1.5
Input voltage:
Input power:
Degree of protection:
Output:
Corresponding guns:
85 – 264 V
47 – 440 Hz
65 VA
IP 54
10 V 1,2 A
EasySelect
POWDER GUN CONTROL
TYPE EASYTRONIC
NOTICE
IMPORTANT

4EasyTronic
Issued 07/02
PREPARATION FOR START UP
The Mains plug of the EasyTronic Control Unit must be discon-
nected from the Mains before starting work!
The desired operating mode must be determined with a so-called
"jumper" the electronic board inside the control unit.
If the control unit is supplied as a component of an EASY unit, then
the "jumper" will be correspondingly set in the correct position at
the factory.
1. Unscrew the screws on
the front of the housing.
a) Setting the Operating mode on the Electronic board
2. Hold the front plate with one hand and fit the "jumper" in the
desired position:
Figure 3
Figure 4
3. Replace the front plate and tighten the screws.
Do not over-tighten the screw!
4. Reconnect the Mains cable.
5. Carry out a calibration:
a) Hold all Application keys
pressed and simultane-
ously press the Main switch.
The equipment carries out a calibration. An increase in noise
can be heard inside the control unit. Both displays show 888 .
After about 20 seconds the equipment is ready for operation
and returns to the factory setting.
B= Easy B
S= Easy S
F= Easy F
B
S
F
DANGER
IMPORTANT

5
EasyTronic
Issued 07/02
b) Preparation of the Powder hopper / container
Prepare the powder hopper or the powder container according to the
type of manual equipment to be used.
(Follow the instructions in the corresponding operating manuals)
c) Switching on the Booth
Switch on the powder coating booth according to the corresponding
operating instructions.
d) Function check
1. Press the push button on the control unit. The yellow control
lamp in the switch illuminates.
The equipment carries out a calibration, when it comes direct
from the factory. An increase in sound can be heard inside the
control unit. Both displays show 888 . The equipment is ready for
operation after about 20 seconds and switches to the factory
settings.
2. Take the powder gun in the hand and point it at a grounded
object in the booth, distance approx. 20 cm.
3. Press the gun trigger.
LED No. 8 illuminates. The High-voltage is switched on and
powder is conveyed.
If all tests are positive, the control unit, and the powder gun are ready
for operation. If one of the functions does not operate as expected,
check this in the "Troubleshooting Guide", on page 12.

6EasyTronic
Issued 07/02
DAILY START UP
a) Setting the Powder output, and Powder cloud
The powder output is dependent on the powder, and the setting of the
total air volume.
1. Switch on the control unit.
2. Set the total air volume (for more information, also see the
EasyFlow Operating Instructions).
The total air volume is dependent on the powder hose length, the
number of turns of the hose, the hose diameter, and the object
being coated.
The value set for the total air volume can be left as it is, as long
as the same powder hose is used. If the hose length and/or the
hose diameter are changed, then the total air volume must be
reset.
3. Select the powder output volume according to the desired coat-
ing thickness.
The selection takes place with the aid of the + or – keys, either on
the control unit or on the rear of the powder gun.
To start, a standard setting of 60% is recommended. The total air
volume is maintained constant automatically.
4. Check the fluidizing of the powder
5. Point the powder gun into the booth and press the powder gun
trigger
6. Select the correct electrode rinsing
When using flat jet nozzles:
- Press the key with the corresponding symbol . The LED of the
corresponding key illuminates.
When using round jet nozzles with air rinsed deflector plates:
- Press the key with the corresponding symbol . The LED of the
corresponding key illuminates.
7. Adjust the powder cloud to a test object
When using flat jet nozzles:
- Unscrew the threaded sleeve approximately 45°, so that the flat
jet nozzle (or extension) can only be turned slightly
- Turn the flat jet nozzle to the desired axial position
- Tighten the threaded sleeve again
When using round jet nozzles with air rinsed deflector plates
- Exchange the deflector plate (ø 16, 24, and 32 mm supplied with the
powder gun)
Set the Total air volume
Select the Powder
output volume
Select the electrode
rinsing

7
EasyTronic
Issued 07/02
When the Powder coating equipment is not used for a number of days:
1. Remove the Mains plug from the Mains
2. Clean the coating equipment, see corresponding operating
instructions
3. Turn off the main compressed air supply
b) Powder coating
Make sure that all electrically conductive parts within 5 m of the
coating booth are grounded!
1. Take the powder gun in hand and point it into the coating booth,
however, do not point it at an object to be coated yet
2. Select the application setting
Press the corresponding application key
on the control
unit. The LED of the corresponding key illuminates.
3. Press the powder gun trigger
4. Coat the object(s)
d) Switching off
1. Release the powder gun trigger
2. Switch off the control unit
The settings for high-voltage, rinsing air, and powder output are
retained.
c) Remote control through the Powder gun
The different functions can be remotely controlled with the aid of the +
and – keys on the rear of the powder gun:
1. Select the application setting
Press the + and – keys on the powder gun simultaneously
Check by observing the LED display on the powder gun:
Red = Flat parts
Green = Complicated parts
Red/Green (alternating) = Spraying over
2. Change the powder output
Press the + or – keys on the powder gun. The powder output is
correspondingly increased or decreased.
CAUTION

8EasyTronic
Issued 07/02
Figure 5
REPAIRS TO ELECTRICAL PARTS OF THE CONTROL UNIT
The Mains plug of the EasyTronic Control Unit must be discon-
nected from the Mains before starting work!
a) Replacing fuse(s)
1. Unscrew the screws on the front of the housing.
2. Hold the front plate with one hand and remove the fuse(s) (quick-
acting) from the fuseholder and replace with a new one.
3. Replace the front plate.
Do not over-tighten the screws!
4. Reconnect the Mains cable.
5. Carry out a calibration:
a) Hold all Application keys pressed and
simultaneously press the Main push button.
The equipment carries out a calibration. An increase in noise
can be heard inside the control unit. Both displays show 888 .
After about 20 seconds the equipment is ready for operation
and returns to the factory setting.
DANGER
4 AF, 250 V

9
EasyTronic
Issued 07/02
b) Replacing the CG 01 Printed Circuit Board
1. Disconnect all electrical and pneumatic connections on the rear of
the control unit.
2. Loosen the clamping element, dismantle the control unit and
place on an level surface.
3. Unscrew the screws on the front of the housing.
4. Press the spacers together
with pointed pliers and remove
the printed circuit board
5. Remove the plug from the
defective board and replace it
on the new board.
6. Place the new board on the
spacers and push them until
they snap into place.
7. Reassemble the control unit in
reverse order as described
above.
8. Reconnect the Mains cable
9. Carry out a calibration:
a) Hold all Application keys
pressed and
simultaneously press the Main push button.
The equipment carries out a calibration. An increase in noise
can be heard inside the control unit. Both displays show 888.
After about 20 seconds the equipment is ready for operation
and returns to the factory setting.
If there are any problems or uncertainties, please contact a ITW
Gema Service Centre.
Figure 6

10 EasyTronic
Issued 07/02
c) Replacing the Front plate
1. Disconnect all electrical and pneumatic connections on the rear of
the control unit.
2. Loosen the clamping element, dismantle the control unit and
place on an level surface.
3. Unscrew the screws on the front of
the housing.
4. Disconnect all plugs from the front
plate.
5. Unscrew the screws on the black
ring and unscrew the ring.
6. Push the switch through the hole.
Figure 7
7. Unscrew the aluminium ring (A) and
pull the push button out of the front
plate.
Dismantle Main switch
A
8. Replace the front plate.
9. Fit the plugs to the new front plate.
With the plug X10,X10,
X10,X10,
X10, take note of the
white marking!
10. Reassemble the front plate and
control unit in the reverse order as
described above.
Do not over-tighten the screw!
11. Reconnect the Mains cable.
12. Carry out a calibration:
a) Hold all Application keys
pressed and
simultaneously press the Main push button.
The equipment carries out a calibration. An increase in noise
can be heard inside the control unit. Both displays show
888 .
After about 20 seconds the equipment is ready for operation
and returns to the factory setting.
If there are any problems or uncertainties, please contact a ITW
Gema Service Centre.
Figure 8
Figure 9
NOTICE

11
EasyTronic
Issued 07/02
Removing the pneumatic Tubes
Figure 11
Before exchanging pneumatic
parts all tube connections should
be removed. This is done by
pushing the pressure ring back,
with the thumb nail, on the quick-
release fitting of the tube connec-
tor. The tubing can now be with-
drawn.
Refitting the pneumatic tubes
This is done by pushing the plastic
tubing as far as it will go into the
quick-release fitting of the hose
connector. The hose is now fixed
securely.
Figure 10
REPAIRS TO PNEUMATIC PARTS IN THE CONTROL UNIT
1. Disconnect all electrical and pneumatic connections on the rear of
the control unit.
2. Loosen the clamping element, dismantle the control unit and
place on an level surface.
3. Unscrew the screws on the front of the housing.
4. Remove all pneumatic tubes from the part to be replaced (see
below).
5. Dismantle the defective part and replace.
6. Reconnect the pneumatic tubes (see below).
7. Reassemble the control unit in the reverse order as described
above.
If there are any problems or uncertainties, please contact a ITW
Gema Service Centre.
a) Replacing a Pneumatic Part

12 EasyTronic
Issued 07/02
Remedies
Replace Mains supply unit
Replace main valve spool
Connect the gun
Replace corresponding part
or send in for repair
Exchange remote control
(gun cover)
Replace solenoid valve spool
Replace solenoid valve spool
Replace corresponding part
or send in for repair
Replace corresponding part
or send in for repair
Exchange remote control
(gun cover)
Press the selection key
(Application key)
Send the gun in for repair
Check grounding, see also
"Safety rules"
Connect the mains cable to
the unit
Replace
Replace
Fault
LED 1-3 not illuminated
LED 4 illuminates red
LED 5 illuminates red
LED 6 illuminates red
LED 7 illuminates red
LED 8 not illuminated, in spite
of the trigger being pulled
and the LED 5 illuminates
green.
The gun LED remains
unilluminated, in spite of the
trigger being pulled, and the
LED 8 illuminates red.
Powder does not adhere to
the object, in spite of the
trigger being pulled, and the
gun sprays powder, the gun
LED, and the LED 8 are
illuminated.
The control lamp in the push
button does not illuminate in
spite of the control unit being
switched on.
Cause
Mains supply unit defect
Main valve defect
- Gun not connected
- Gun plug, gun cable or gun
cable connection defect
- Remote control on the gun
defect
Solenoid for rinsing air of the
flat jet nozzle defect
Solenoid for rinsing air of the
round jet nozzle defect
Gun plug, gun cable or gun
connection defect
- Gun plug, gun cable or gun
connection defect
- Remote control on the gun
defect
- High-voltage and current
deactivated
- High-voltage cascade defect.
- The objects are poorly
grounded.
No current:
- Control unit is not connected to
the Mains.
In the equipment:
- Bulb burnt out.
- Power pack defect
TROUBLESHOOTING GUIDE
The diagnosis LEDs 1-7 illuminate green when switched on, and LED 8 remains unilluminated.
It illuminates red when the gun trigger is pulled.
(continued)

13
EasyTronic
Issued 07/02
Faults
The powder is not
fluidized.
The gun does not spray
powder in spite of the con-
trol unit being switched on
and the gun trigger being
pressed
Causes
No compressed air present
- Reducing valve closed
- Reducing valve defect
No compressed air present
- Injector, check valve or nozzle
on the injector, powder hose
or gun clogged
- Nozzle in the injector clogged
- Nozzle not fitted
- Fluidizing does not function
No conveying air:
- Reduction valve defect
- Solenoid valve defect
- Electronic in the front plate
defect
Remedies
Connect the equipmentt h e
compressed air supply
Open
Replace
Connect the equipment to
the compressed air supply
Clean corresponding part
Replace
Fit nozzle
See above
Replace
Replace
Replace, send in for possible
repair
Troubleshooting Guide (cont.)

14 EasyTronic
Issued 07/02
PNEUMATIC DIAGRAM
Figure 12
EasyTronic
Conveying
air
Supplementary
air
Fluidizing
air
Electrode rinsing air
3-10 l/min.
P
S1 = Rinsing air unit
M1 = Throttle motor
E1 = Input unit
Compressed
air input
