Ivation IVABMT05 User manual

MICRO BURNER
USER GUIDE
IVABMT05
Thank you for purchasing the Ivation® Butane Micro Burner. This User Guide is intended to provide you with guidelines
to ensure that operation of this product is safe and does not pose risk to the user. Any use that does not conform to
the guidelines described in this User Guide may void the limited warranty.
Please read all directions before using the product and retain this guide for reference.
This product is intended for household use only.
This product is covered by a limited one-year warranty. Coverage is subject to limits and exclusions.
See warranty for details.
TABLE OF CONTENTS
2 Safety Precautions
3 Product Overview
3 Packaging Content
3 Filling the Burner
4 Lighting the Burner
4 Adjusting the Flame
4 Extinguishing the Burner
4 Troubleshooting
5 Contact Information
1

Safety Precautions
1. Keep out of reach of children.
2. Make sure to thoroughly read and understand all instructions prior to use.
3. Only use this device on a sturdy, level surface in a well-ventilated room or outdoors.
4. Butane gas is extremely flammable. Please handle with care!
5. Under no circumstances should you attempt to operate or repair a damaged burner.
6. Do not touch the metal cover while the flame is burning or when the device is hot. (See Fig. 1)
7. Do not touch the flame head at any time! (See Fig. 2)
8. Keep the burner away from your own and other people’s faces, bodies, and clothing when igniting and/or operating
this device.
9. Do not store in direct sunlight or in any place where the temperature will exceed 104°F (40°C).
10. Never immerse in water.
11. Never leave the burner unattended while in operation.
12. Make sure the gas control knob is tightly closed and the flame is fully extinguished after every use.
13. When cooking, the bottom of the pan, kettle, etc. should always be at least 1¼"(3 cm) above the burner. (See Fig. 3)
14. Always make sure the valve is in good condition before filling the torch with gas.
15. Don’t place the burner under closed frames; only use open frames for this type of burner. (See Fig. 4)
16. Always store and transport the micro burner and butane canisters in an upright position.
17. WARNING: The burner flame can be invisible in sunlight. Never put your hand over the top of the unit if you’re
unsure if the flame is lit.
18. Never throw this appliance or the butane container into a fire. Dispose of these items properly in an
approved location.
2
Fig. 1 Fig. 2 Fig. 3 Fig. 4

3
Product Overview
Packaging Content
Butane Micro Burner
User Manual
Filling the Burner
To ensure that your burner operates for the average duration (approximately 40-60 min,
depending on the size of the flame), please follow these instructions to fill the burner
with butane gas.
1. Always refill the burner with filtered butane lighter gas in a well-ventilated
room or outdoors.
2. Never fill the burner near an open flame as this creates the risk of a fire
or an explosion.
3. Before filling, make sure the gas control knob is turned to the OFF position.
(See Fig. 5)
4. Flip the burner upside down to access the filler valve, and then turn the butane
canister upside down so the nozzle connects with the filler valve. If the nozzle
doesn’t fit correctly, you may need to use the tips inside the cap of the butane
canister. Push down to start filling with butane. (See Fig. 6)
NOTE: Do not touch or bump the flame head while refilling, as this could cause
damage or a burner malfunction.
5. When the liquid gas starts to escape from the filler valve instead of going into
the burner, the tank is full and you can stop filling. Do not overfill.
Fig. 5
Fig. 6
FLAME HEAD
METAL COVER
GAS CONTROL
KNOB
SAFETY BUTTON
GAS TANK
FILLER VALVE
* DO NOT ATTEMPT TO REPAIR OR DISMANTLE BURNER

4
Lighting the Burner
1. Press the red safety button down, and turn the gas control knob counterclockwise enough to hear a small hissing
sound. (See Fig. 7)
2. Push the gas control knob in to create a spark, or use a match or a lighter to ignite the flame. (See Fig. 8)
WARNING: Do not touch the unit cover or the body of the burner itself while it’s burning.
Adjusting the Flame
1. To adjust the flame, turn the gas control knob from right to left. (See Fig.7)
2. Set the flame at a low to medium gas flow setting depending on your usage. Ideally, the flame should burn blue. If the
flame starts to burn red, this means that the gas is almost used up, so you should extinguish the flame, close the gas
control knob, and refill the burner with butane.
WARNING:contents are hot. If you need to refill with butane, wait until the burner has cooled down before refilling.
Extinguishing the Burner
Troubleshooting
1. Turn the gas control knob clockwise (from left to right) to extinguish the flame. (See Fig. 5)
2. Make sure the flame is completely extinguished and the burner has cooled before storing or leaving it unattended.
Fig. 7 Fig. 8
Fig. 7
Problem Probable Cause(s)
Solutions
Burner does not ignite
Butane is empty.
Gas flow is too high
or too low.
1. Refill the burner
with butane gas.
2. Turn the gas control
knob to either
increase or decrease
gas flow.
Excessive gas flow 1. Flame setting is too
high.
1. Adjust the gas
control knob.
2. Re -ignite the burner
by gradually
increasing the gas.
Low gas pressure 1. Fuel is low.
1. Refill the burner
with butane gas.
1.
2.

5
