3X AUTO FOCUS ZOOM, FULL HD IP BOX CAMERA
IV601IP SPECIFICATIONS
Model Name
IV601IP
Imaging Sensor
Sony Exmor 1 / 2.9” Progressive Scan CMOS Sensor
Effective Pixels
1,936(H) x 1,097(V)
Min. Illumination
0.0008 Lux (@AGC MAX, DSS x2)
Output Video Resolution
1920x1080( 30p/25p)
TV system
US(60Hz)(switchable to EU(50HZ))
Sync. System
Internal
Format
16:9 Video format for most popular commercial HDTV monitors
Video Output
Ethernet thru LAN Port for RJ45 & CVBS thru BNC
S/N Ratio
More than 50dB (AGC OFF)
Lens type
3X Day & Night Zoom Lens, f3~9mm , F1.2 (wide) ~ F2.1 (tele)
Zoom Ratio
Optical 3X, Digital 32X Zoom
Day & Night
True Day & Night by ICR
Focus
Auto / Zoom Push / Manual
Exposure Control
Auto / Iris-Priority / Shutter-Priority / Manual / Flickerless
Flip
OFF / H / V / HV FLIP
White balance
ATW / ATWext / ONE PUSH / MANUAL
Minimum Focus Distance
1.0 m~
WDR
True WDR by dual scan in two frames at 15fps.
Functions
NORMAL, WDR, D-WDR, BLC, HLC
Special Feature
Motion Zoom (Automatic Zoom IN/OUT when motion is detected),
Pointing Zoom(Set the off-centered location to be the center of zoom in
Motion Zoom), Motion Detection, Privacy Mask, Pixel Defect Compensation,
Defog, Title Set, Lens Refresh Set, Motion Deblur, Focus Indicator
Language
English, German, French, Italian, Spanish, Polish, Japanese
Power
24VAC / 12VDC DUAL POWER, 6.5W
Circuit protection against faulty connection
Isolated power supply against ground loop problem
Operating Temperature
-10ºC ~ +50 ºC (Humidity : 30%RH ~ 80%RH)
Housing
Solid Aluminum Cast
External Dimension
74mm x 72mm x 125mm, 350g
IP SPECIFICATION
Video Encoding
H.264 / MJPEG dual streaming
Protocol
HTTP, TCP/UDP/IP, ARP, ICMP, RTP/RTSP, multicast, Telnet, ftp, PPPoE, SMTP(e-mail),
DHCP, NTP, uPNP, etc, ONVIF, PSIA support
Transmission Control
VBR, CBR ( 32K ~ 12M bps )
IP Installation &
maintenance
Connectivity
Configuration: installation wizard, HTTP, telnet and console, Upgrade
firmware: HTTP, telnet+ftp
Max. 16 simultaneous user connection
SD memory card
Slot for Standard SD memory card up to 32GB
Audio & Alarm
Two way audio input /output
PoE
IEEE Std. 802.3af
Key Features
• OnvifS / PSIA Compatibility
• Optical 3X Auto Focus Zoom / Digital 32X Zoom
• Wide Dynamic Range
• 3D Noise Reduction
• Focusing Status Indicator on Screen
-  Focusing In Process
- ☼Focusing Completed
•Zoom on Motion
(Automatic Zoom IN/OUT when motion is detected)
•Pointing Zoom
(Set the off-centered location to be the center of zoom
in Motion Zoom)
• OSD MENU & Video Sub-out port
for easy installation & Maintenance
• LSC(Lens Shade Compensation)
• H.264/MJPEG Dual stream
• PoE
• Locally recordable with Standard SD Memory
• Circuit protection against faulty connection.
• Isolated power supply against ground loop problem.
