Ixos Divo User manual

Please read this User Guide before operating your Speaker System.
Please keep this User Guide for future reference.
USER GUIDE
XMS750
UK
Divo
2.1 Music System with iPod™ dock

Care & Safety Warning
Please read the User Guide before
operating your Speaker System. This will
enable you to set-up and operate DIVO
correctly and fully use all of its features.
Please keep the User Guide for future
reference.
• Handle with care. Avoid strong impacts.
• Avoid positioning the speaker and
docking station cables where they
might present a hazard to people
walking nearby.
• DO NOT position the active subwoofer
on a shelf or lightly built structue as the
vibrations may cause objects to fall.
• Unplug the Power adaptor from the
mains supply when away on vacation
(to conserve energy) or during lightning
storms (for safety). Always take care
not to overload mains power outlets.
• ONLY use the supplied power adaptor
with DIVO.
• DO NOT use the product near water or
allow liquids to spill into any part of the
system.
• DO NOT block ventilation openings.
• DO NOT place close to heaters or
radiators.
• This product contains no user-
serviceable parts. Dismantling any
part of the system may invalidate your
warranty and give risk of electric shock.
Refer servicing to qualied personnel
only.
• To remove dust use a soft, dry cloth.
Use a cloth dampened only with water
to remove marks. Do not use solvents,
chemicals or sprays to clean the unit.
1

Unpacking your IXOS®Speaker System
Check the packaging for the following
contents:
• iPod docking station
• Active subwoofer
• Satellite loudspeakers x 2
• Remote control
• Control cable
• IXOS auxiliary cable
• IXOS loudspeaker cable (0.5m) x 2
• IXOS loudspeaker cable (4.5m) x 2
• Power adaptor
• iPod adaptors x 6
2

Active subwoofer
Front View
A1. Power / Mode Button
A2. System volume Up / Down
A3. Bass volume Up / Down
A4. Power and Mode indicator LED
C1. Display
C2. Universal iPod dock
Rear View
B1. Phono inputs
B2. Power input
B3. Control cable input
B4. Loudspeaker outputs
D1. USB (iPod sync to iTunes)
D2. Auxiliary audio input
D3. Control cable output
A1A3 A2
A4
POWER iPod DOCK
RIGHT LEFT
SAT
SPEAKER
SAT
SPEAKER
PHONO INPUT
R L
B2B1
B4 B3
C2
C1
AUX
INPUT
MAIN CONTROL
USB
D2 D1
D3
iPod docking station
3

Connecting the DIVO
DIVO has been supplied with two lengths of loudspeaker cable making it possible
to integrate into a variety of living spaces
NOTE:
Use the shorter loudspeaker cables when connecting DIVO in restricted space
The iPod docking station contains the remote control sensor therefore this should be placed
in view
DO NOT position the active subwoofer on a shelf or lightly built structure as the vibrations
may cause objects to fall
ONLY use the supplied power adaptor with DIVO
•
•
•
•
AUX
INPUT
MAIN CONTROL
USB
POWER iPod DOCK
RIGHT LEFT
SAT
SPEAKER
SAT
SPEAKER
PHONO INPUT
R L
to power adaptor
4

Synchronising your iPod
Connecting the iPod
DIVO incorporates the Apple Universal docking well with 30pin connector
Universal Dock Adaptors (supplied)*
DIVO features a mini USB socket cable on the rear of the iPod docking station (D1).
This allows your iPod to be synchronised with iTunes while connected to the DIVO
Fit your iPod’s corresponding adaptor into the Universal iPod dock (C2)
Position your player rmly onto the 30pin connector ensuring that it is
correctly aligned
Select “iPod” as the source using the mode button on remote control
or subwoofer
Control the iPod as normal or by using the remote control
•
•
•
•
*If your iPod is not shown above, please use the universal dock adaptor provided with your hardware
5

Phono inputs
Auxiliary audio input
The auxiliary audio input (D2) can be used for connecting a music player with
3.5mm output
The phono inputs can be used for connecting home devices with RCA outputs
such as; CD/DVD players, receivers etc
Use the supplied auxiliary cable to connect your source to the auxilliary audio
input (D2)
Select “Auxiliary” as the source using mode button on the remote control or
subwoofer
Music playback is controlled using your music player
•
•
•
Use a stereo phono cable (not supplied) to the connect the audio output of the
home device to the phono inputs (B1) of the DIVO
Select “Phono” as the source using the mode button on the remote control or
subwoofer
Music playback is controlled using your home device
•
•
•
AUX
INPUT
MAIN CONTROL
USB
6

To switch DIVO on, press and hold the Power/Mode button (A1) until the
power LED illuminates (A4)
To change input source, press and release the Power/Mode button (A1)
The LED will change colour:
GREEN = iPod
ORANGE = Auxiliary
RED = Phono
To adjust system volume press and release the corresponding system volume
button (A2)
To adjust bass volume press and release the corresponding system volume
button (A3)
To switch DIVO off press and hold the Power/Mode button (A1) until the power
LED goes out
•
•
•
•
•
Operating DIVO
7

Operating DIVO using the remote
A. Power button
B. Mode button
C. Mute
D. System volume Up / Down
E. Bass volume Up / Down
F. Treble volume Up / Down
G. Display light toggle
H. iPod Play/Pause
I. iPod Previous / Next Track
J. iPod menu navigation Up /
Down
K. iPod menu mode
L. iPod OK/Select
A
D
F
C
B
G
I
L
J
I
H
K
E
8

Troubleshooting your DIVO
Problem Possible Solution
Will my
iPod™ t in
the docking
station?
DIVO is supplied with a selection of docking adaptors to t the
most popular models of iPod™ player. Your iPod™ will have
been supplied with a standard docking adaptor which can also
be used (excludes shufe and other models not compatible with
iPod’s 30-pin interface).
There is no
sound or poor
sound quality
1. Ensure that all cables are fully inserted in their corresponding
input/output sockets.
2. Where applicable, ensure that the iPod™ is rmly connected
on to the connector of the docking station.
3. Check that you have selected the music source (iPod™, AUX
or PHONO) correctly.
4. Check the music source is playing. Many MP3 players pause
playback whenever a connection is interrupted.
5. Check your music player’s volume level setting.
6. If your MP3 player has built-in tone controls or audio
equaliser, set these to at.
7. If you hear distortion from the subwoofer, reduce the SUB
level immediately.
Do I use AUX or
PHONO inputs
to connect my
audio player?
The AUX input on the docking station is intended for temporary
connection of portable music players using their headphone
output. The PHONO inputs are for more permanent connection
of CD or DVD players, or the audio output from a satellite
receiver or video recorder.
9

Problem Possible Solution
The remote
control
handset does
not change
functions
1. Ensure that the sender bulb on the front edge of the remote
control is pointing towards the docking station.
2. Objects positioned between the handset and the docking
station may mask the control signal.
3. Try operating the remote control close to the docking station.
If the functions now work, it is likely that the battery in the
handset needs to be replaced.
Display on/off
function
The dock display will initially show IXOS while the DIVO system
is powering up. If preferred, the display may be switched off
while the DIVO is playing. Use the ‘light bulb’ button (G) on the
remote control handset.
10

System
Total power (rms): 48 Watts
Frequency response: 20Hz to 20kHz
Speaker
Drivers: 2 x 50mm midrange
1 x 15mm tweeter
Dimensions: 300mm height x 60mm diameter
(105mm including base)
Weight: 0.6kg
Subwoofer
Drivers: 1 x 155mm AAS (Acoustic Air Spring)
1 x 155mm bass driver
Dimensions: 185mm height x 190mm diameter
Weight: 3kg
iPod Dock
Connector: 30 pin “Made for iPod”
Dimensions: 110mm height x 32mm diameter
Weight: 0.26kg
Power Supply
Input voltage: 100V to 240V
Output voltage: 2 x 14 Volts (dual rail supply)
Current: 2 x1.8 Amp
with local laws relating to this directive.
Limited Warranty
IXOS® provides Limited Warranty against
defects in materials or manufacturing. This
Warranty lasts one year from the date of
purchase. Defects that have resulted from
improper or unreasonable use or caused
by an accident, servicing, excess moisture,
improper packaging, lightning strikes, power
surges or unauthorised tampering, alteration
or modication are not covered.
WEEE Information
This product is classied as Electrical and
Electronic Equipment (EEE). Should the
time come for you to dispose of this product
please ensure that you do so in accordance
with the European Waste of Electrical and
Electronic Equipment Directive (WEEE) and
in compliance with local laws relating to this
directive.
Technical Specications
11

Model name/part no: IXOS®DIVO XMS750
Serial number: 7 5 0
Date purchased:
Retailer’s name:
Retailer’s address:
Important
Every effort has been made to provide accurate
usage guidance. IXOS® disclaims liability for
any difculties arising from the misinterpretation
of information contained within this guide.
As part of a continuous product development
programme, IXOS® Limited reserves the right
to alter specications without prior notice.
IXOS® is a registered trademark of IXOS®
Limited
For your convenience we recommend that
you record the serial number (the eight digit
number beginning 750xxxxx on the side of the
packaging) and other purchase information
below:
Path Group Ltd, Dormer Road, Thame
Industrial Estate, Thame, Oxfordshire OX9
3UD, UK Tel: [phone]
www.ixos.co.uk www.ixos-usa.com
iPod is a trademark of Apple Inc., registered in the U.S.
and other countries
iTunes is a trademark of Apple Inc., registered in the
U.S. and other countries
© IXOS Limited 2009 0909//1
Additional Information

www.ixos.co.uk
0909/01
