Behringer Ultraroc GX110 Manual

Version 1.1 September 2002
Technical Specifications
ENGLISH
ULTRAROC GX110

2
ULTRAROC GX110
GX110
ULTRAROC
Ultra-flexible 30-Watt Guitar Workstation with digital ulti-effects processor
sPowerful 0-Watt RMS Guitar Workstation with authentic VIRTUBE tube simulation
sOriginal 5-Watt vintage 10" JENSEN guitar speaker model JCH10/ 5
sTwo independent channels with separate volume controls and effects
sCLEAN channel delivers clean and slightly distorted tube-type sounds
sOVERDRIVE channel offers a broad range of modern crunch to high-gain sounds
sClassical -band EQ with excellent sound characteristics
s24-bit stereo multi-effects processor with extremely high-resolution 24-bit AD/DA converters
s1 original VIRTUALIZER and MODULIZER presets with outstanding effects such as Reverb, Delay, Phaser,
Chorus, Flanger, Pitch Shifter, Speaker Simulation, Rotary Speaker, Magic Drive, Compressor, Expander,
Wah-Wah, Tube Emulator and various effect combinations
s99 easy-to-edit user presets
sAdditional 8 Ohm speaker output (built-in speaker is muted automatically)
sAdjustable AUX input for playback or other line-level signals (e.g. CD player, drum computer)
sFrequency-corrected line output for recording and live applications
sInsert facility for external effects devices (stomp boxes, wah-wah pedals, etc.)
sGX110 comes with footswitch FS112 for channel selection and effect bypass
sComplete MIDI implementation for channel and effect selection as well as real time control
sMaster volume control and frequency-corrected stereo headphones output
sFX MIX parameter can be stored in each preset
sExtremely rugged construction ensures long life even under the most demanding conditions
sRobust power supply ensures excellent transient response
sManufactured under ISO9000 certified management system

ULTRAROC GX110
SPECIFICATIONS
AUDIO INPUTS
Guitar input
Connector 1/4" mono
Type RF filtered input
Guitar input impedance approx. 1 MΩ unbalanced
Insert return
Connector 1/4" mono
Input impedance approx. 1 kΩ unbalanced
Aux input
Connector RCA
Input impedance approx. 10 kΩ unbalanced
AUDIO OUTPUTS
Insert send
Connector 1/4" mono
Type line level output
Output impedance approx. 100 Ω unbalanced
Line output
Connector RCA jacks
Output impedance approx. 100 Ω unbalanced
Max. output level +12dBu unbalanced
LOUDSPEAKER OUTPUT
Connector 1/4" mono
Load impedance (nom.) 8 Ω
SYSTEM SPECIFICATIONS (Master Section)
Power amp output 0 Watts R.M.S. into 8 Ω
MIDI INTERFACE
Type 5-pin DIN socket, MIDI IN
DIGITAL PROCESSING
Converters 24-bit Sigma-Delta, 64/128-times oversampling
Sampling rate 46.875 kHz
DISPLAY
Type 2-digit numeric LED display
LOUDSPEAKER
Type 10" heavy-duty loudspeaker, model JENSEN JCH 10/ 5
Impedance 8 Ω
Power rating 5 Watts
POWER SUPPLY
Mains voltages USA/Canada 120 V ~, 60 Hz
U.K./Australia 240 V ~, 50 Hz
Europe 2 0 V ~, 50 Hz
General export model 100 - 120 V ~, 200 - 240 V ~, 50 - 60 Hz
Power consumption 50 Watts @ 5 Watts/8 Ohms; 90 Watts max.
Fuse 100 - 120 V ~: T .25 A H
200 - 240 V ~: T 630 mA H
Mains connection Standard IEC receptacle
PHYSICAL
Dimensions (H * W * D) approx.
14.8" * 16.54" * 8.04"/9.66"
( 76 mm) * (420 mm) * (204/245 mm)
Weight approx. 10.5 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be
made from time to time to e isting products without prior notice. Specifications and appearance may differ from those listed or illustrated.
