INSTALLATION GUIDE

2
TABLE OF CONTENTS
1. SAFETY AND LIABILITY ......................................................................................................................................................... 3
2. TOOLS AND SUPPLIES ......................................................................................................................................................... 4
3. INSTALLATION PROCESS .................................................................................................................................................. 4
3.1 Getting started ................................................................................................................................................ 4
3.2 Fillers ........................................................................................................................................................................ 9
3.3 General install information.................................................................................................................... 11
3.4 Appliances ............................................................................................................................................................ 11

3
1. SAFETY AND LIABILITY
The decision has been made to install the cabinets and accessories yourself. This Installation
Guide is meant to assist you in the general installation process. The installation of cabinetry can
be a challenging task and we do recommend that you use a qualied cabinet installer. However
you may have the skill set to complete the installation on your own. J Collection has no control
over the installation, so you are responsible and liable for completing the install correctly and
safely.
SAFETY AND LIABILITY DISCLAIMER:
 Please note that the following instructions are only a guide to cabinet installation.
J Collection will not be liable for any damage to cabinets, cabinet hardware, ooring,
walls, etc., due to improper installation or mishandling of cabinets.
 To reduce the risk of serious or fatal injury, read and understand this Installation Guide
before commencing with the installation.
 J Collection Installation Guide is not intended to cover every possible contingency that
might be encountered during installation or to endorse the use of any particular tool.
 J Collection hereby expressly disclaims all warranties and all liability for any claims
for injury or death related to or based upon the use of this Installation Guide.
 A qualied service professional should be used for any electrical or gas line work.
 All gas, electrical and water connections must be shut off in any work area.
ITEMS THAT YOU SHOULD CONSIDER:
 Do you have experience with carpentry and cutting miters?
 Required tools: for a quality installation you will require several tools. They can be
expensive and require experience to operate in a safe and efcient manner.
 Condition of the site: oors are level, walls are square and level.
 Basic plumbing and electrical skills may also be required.
 It is recommended that there are two people when installing the cabinets.

4
2. TOOLS AND SUPPLIES
The following may or may not be required depending on the complexity of your installation:
• UL approved safety goggles, steel toed shoes and earplugs.
• Table saw, miter saw, jig saw.
• Drill and bits, compressor, pin nailer and nails.
• Clamps, levels, squares, straight edge, line levels.
• Extension cord, lighting, ladders.
• Stud nder, handle jig, circuit tester.
• Tape measure, screwdrivers, hammer pencil, masking tape.
• Installation wood screws (1 1/8” and 2 1/2”) and screw caps (for wood stud construction).
• Carpenter glue.
3. INSTALLATION PROCESS
UNDERSTANDING OUR CABINET CODES - EXAMPLES
CODE DESCRIPTION
W1830 Wall cabinet 18” wide and 30” high
WA2440 Wall angle corner cabinet 24” wide and 40”
high
B30 Base cabinet, 30” wide and 34 1/2” high
T302484.5 Pantry cabinet, 30” wide, 24” depth and
84 1/2” high
• All measurements will be referred to in imperial.
3.1 GETTING STARTED
• Check to make sure the cabinets and accessories that you have received are what you
ordered. If anything is not on site, then do not start your project until you have everything
required.
• Double check that you have all the required tools.
• Appliances should be moved to another room for easier maneuvering in the work area.
• Walls should be nished with the rst coat of paint applied.

5
All Dimensions From Finish Floor
We realize that not all oors are perfectly level. All J Collection base and tall cabinets come with
adjustable legs to level your cabinets to make this installation simple and efcient.
Follow the steps below to properly install.
INSTALL BASE CABINETS: Draw a level line on your wall 34 1/2" up from the highest point on your
oor. Adjust the cabinet legs of your base cabinet to bring the top of each box up to the level
line. Using a level, level the base cabinets back to front from the wall out.
INSTALL WALL CABINETS: For all wall cabinets draw a level line or chalk line at 54 1/2" up from the
highest point of your oor. Install each wall cabinet box so the bottom edge is level with the line.
Cabinet legs are adjustable for leveling
84 ½” tall cabinet with 30” wall cabinet
94 ½” tall cabinet with 40” wall cabinet

6
1) Verify that walls are square and level. Walls that
are out of square or level will make installation
of cabinets more difcult. You can use the 3, 4, 5
method to check your corner.
2) Check the oor for level and
make note of where the highest
points are before installing
cabinets.
4) Using a stud nder, mark out
all of the wall studs that will be
behind your cabinets.
3) Snap a chalk line or draw a level line at 34 1/2" from the
highest point of your oor. Your base cabinets will be adjusted
up to that line (top of base cabinet without countertop). Snap
another chalk line or draw a level line at 54 1/2 (20” above your
base 34 1/2 base cabinet line).
The bottom of your wall
cabinets will be adjusted up to
that line. It may be helpful to
draw out your cabinet layout
on the wall. This will give you a
guide to follow as you go.
If you choose, install a 1x4 or 2x4
ledger board onto the wall at
the bottom of your wall cabinet
height to give a support for the
wall cabinet to set your wall
cabinets on when installing. This
can assist in keeping them level.
This method requires you to
screw into your wall and could
require hole patching.

7
5) Starting with the corner wall cabinet, install 4, 2 1/2"
cabinet screws through the fastening strips on the
cabinet into the wall studs. Be sure to check for level
before fastening the cabinet into place.
If you do not have a corner, start
with the end closest to a wall,
making sure to leave room for
the required ller as per your
plan.
6) The next cabinet will be set into place and
clamped to the previously installed cabinet.
Clamp the two cabinet boxes together so that the
front, top and bottom faces are ush. Verify that
the cabinet is level and install 4 cabinet screws
through the fastening strips into the wall studs.
With cabinets still clamped and ush, connect
together using 1 1/8" particle board screws.
7) Set base cabinet legs to be level with the 34 1/2"
chalk line. Adjust the base cabinet legs so the top
of the cabinet box is level with the line previously
drawn on the wall at 34 1/2" high.

8
8) Start with the corner cabinet. Make sure the cabinet is level,
then install 2 cabinet screws through the top-fastening
strip into the wall studs.
9) The next cabinet will be set into
place and clamped to the previously
installed cabinet. Clamp the two
cabinet boxes together so that the
front, top and bottom faces are ush.
Verify that the cabinet is level and
install 2 cabinet screws through the
fastening strip into the wall studs.
With cabinets still clamped and ush,
connect cabinets together using 1 1/8"
particle board screws.
If you do not have a corner,
start with the cabinet closest
to the wall, making sure to
leave the correct space for
the required ller.
10) Click the toe-kick clip into place on
the cabinet leg. Set the toe-kick and
push down on the clips, until the
toe-kick is locked into place.

9
FILLER STRIP INSTALLATION
If a ller strip is required, measure the distance between the cabinet and the wall and cut the ller
strip to match.
3.2 FILLERS
Fillers are needed to take up odd dimensions when cabinets are installed next to a wall. They will
also allow clearances for doors and drawers to operate properly when turning a corner with a blind
corner cabinet.
Hold the ller in place; turn it over and on the back side make a pencil mark at top and bottom where
it should be cut. To prevent chipping when cutting llers, place masking tape over the surface that
is being cut. Join the two marks with a pencil line and saw along that line. Put the ller in place and
drill a pilot hole at hinge level through the cabinet and into the ller. Attach the ller to the adjacent
cabinet by fastening together with wood screws.
1) When installing a sink or cooktop, trimming may
be necessary to t within the cabinet. Mark cutout
lines where the sink or cooktop will be using the
countertop template that is provided, to ensure
correct measurements. Cut along the marked lines
using a jigsaw.
SINK/COOKTOP INSTALLATION

10
BBC (base blind corner) cabinets may be pulled out from the corner if required and the room is
available. When installing a base cabinet at a right angle to a BBC cabinet you must use a ller
to provide clearance for door and drawer handles. The ller width required is usually 1 3/4” - 3”
depending on the type of pull used on the cabinets. Cut the 3” ller to required width. Fasten the
ller to the two adjacent cabinets by drilling through the side of the cabinet into the ller. Screw
together. Ensure cabinets are square in corner and attach the unit to the wall. Make sure all cabinets
are plumb and level. The remaining base cabinets are installed in the same manner. Using the two
C-clamps, align stiles, drill and screw together. Proceed around the room making sure all cabinets
are plumb and level, shimming where necessary, then tighten all screws.
Install the remaining base cabinets by aligning the fronts of the cases. Clamp the cabinets together
and attach using the 1 1/8” screws. Level the cabinet, adjust as required and attach to the wall studs
using 2 1/2” screws through the hanging rail located at the top of the base cabinet. After inserting the
screws remove the clamps.
Base Corner Cabinet (BC36LS) - Base corner cabinets are placed squarely in the corner, leveled
and adjusted as required. They are held in place by cabinets on either side. Counter sink screws on
BC36LS door handles.
Dishwasher Gables - Measure 24 1/8” over from the cabinet at the front and the back and draw a line
on the oor. Draw a plumb line on the wall from the oor to the base cabinet line. These lines
mark the position of the inside of the dishwasher Gable. Install a ledger board 24 1/8” long below
the base cabinet guideline. The panel is then installed by attaching it to the ledger strip, oor and
countertop with metal L-brackets.
• Minimum 42 3/4"
does not allow
for ller/hardware
clearance.
• Maximum
45 3/4" is with
3" ller attached
to be ush with
the door. Filler not
included.
30"
18"
Trim this
side of
the ller
to make
it t
3" ller
#8 x 1 1/2"
screws

11
3.3 General Install Information
• The front edge of a fridge gable should be ush with front of the cabinet doors.
• Install all cabinets level and plumb.
• Install bumpers on all door and drawer fronts, especially corner cabinets.
• All cutouts for piping should be as close to pipes as possible with a clean cutout edge.
Fridge and Dishwasher Panels/Gables
• Fridge panels are fastened to the upper cabinet from the inside of the cabinet. The panel is
to be level and plum with the cabinet. Make sure to add the ller if specied.
• Where applicable, raise panels to allow for installation of hardwood ooring (typically
13/16” above sub-oor). Be aware of its construction: 3/4” hardwood, engineered hardwood,
laminate, tile or linoleum ooring have various requirements. The bottom is to be attached to
the nished oor with silicone or an L-bracket.
3.4 Appliances
Today’s appliances are available in all shapes and sizes. Because of this, you must conrm
opening sizes against the Spec Sheet provided with your paperwork, as well as the manufacturer's
specications.
• Standard Dishwasher openings are to be 24” wide (unless otherwise specied).
• Standard Fridge Opening is 36” wide x 72” high (unless otherwise specied).
• Standard Range openings are to be 31 1/4” wide between base cabinets (unless otherwise
specied).
• Slide-in Ranges – the opening and nished counter height is crucial when dealing with slide-
in ranges. Type of ooring and countertop thickness has to be taken into account. Fillers or
scribe on each side maybe required to make sure drawers and doors clear the range. If base
cabinets are set too low or high the range will not sit ush with the countertop. Countertop
top should be 36” unless otherwise noted.
Note: Never attempt to move an appliance on nished ooring. Do not connect or disconnect any
appliance that is hard-wired or connected to a water source. Always ask for help before attempting
to move an appliance, as appliances are often heavy and there is a high risk of personal injury or
property damage if not properly handled.
