J-TECH Extend User manual

USER GUIDE

User Guide
[e-mail]
800.321.6221
THANK YOU!
Thank you for purchasing this JTECH Extend portable two-way radio by JTECH. The JTECH Extend
delivers the latest technology, has the most stable components, and has the most advanced
production technology. The JTECH Extend radio will provide you with reliable performance and
high quality you demand.
This user manual should be read to ensure that the user understands the operation of the JTECH
Extend radios. Please read the Safety Information Manual before use.
•Only qualified technicians are allowed to maintain this product.
•To avoid electromagnetic interference, turn off your radio in places where posted notices
instruct you to do so. Hospitals or health care facilities may be using equipment that is
sensitive to external RF energy. When traveling on aircraft, turn off your radio when the airline
crew instructs you to do so.
•When in vehicles equipped with an airbag, do not place a portable radio in the
airbag deployment area.
•Turn off your radio prior to entering any area with apotentially explosive atmosphere. Do
not remove, install, or change batteries in such areas.
•To avoid possible interference with blasting operations, turn off your radio when you are
near electrical blasting caps.
•Do not expose the radio to direct sunlight for long periods of time. Do not place the radio in
direct contact with any heating source.
PLEASE READ THIS IMPORTANT INFORMATION BEFORE USING YOUR
JTECH PORTABLE TWO-WAY RADIO.

User Guide
[e-mail]
800.321.6221
Safety Instructions
Please observe the following safety instructions to prevent fire, accidents, personal injury, or equipment
damage.
•Do not modify the radio or its charger in any way.
•Do not expose the radio to direct sunlight for extended periods of time, leave near heaters or other heat sources.
•Do not store or use unprotected radios for prolonged periods in areas of high dust or excessive moisture.
• Users may experience signal interference if the unit is used near devices such as televisions or electric
generators.
•If the unit emits smoke or you notice a strange smell, immediately turn off the power and send it to the closest
repair station.
•The radios are small but contain high power components. It is not uncommon to notice slight warming of
the handset. This is normal and the unit may be continued to be used.
If there is any problem with the radio, please contact JTECH or your local distributor.

User Guide
[e-mail]
800.321.6221
Compliance and Control Guidelines and Operating Instructions for Portable
Two-Way Radios to Control Your Exposure and Ensure Compliance with the
Occupational/ Controlled Environment Exposure Limits, Always Adhere to
the Following Procedures:
•Transmit no more than 50% of the time.To transmit (talk), push the Push-To-Talk (PTT) button.
To receive calls, release the PTT button.Transmitting 50%of the time or less is important since
the radio generates measurable radio frequency (RF) energy exposure only when transmitting
(in terms of measuring standards compliance).
•For body-worn operation, always place the radio in a JTECH approved belt clip or similar
accessory that contains no metallic components and provides a minimum separation distance
of 1.3 cm between the back of the radio and the user’s body. JTECH approved accessories,
antennas, and device combinations comply with the occupational/controlled environment RF
exposure limits. Using accessories not approved by JTECH may result in exposure levels which
exceed the FCC ’s occupational/controlled environment RF exposure limits. JTECH approved
accessories have been tested and comply with FCC RF exposure requirements.
•If you are not using a body-worn accessory and are not using the radio held in front of the face,
ensure the radio is kept at aminimum of 1.3 cm from the body when transmitting. Keeping the
radio at a proper distance is important since RF exposure decreases with increasing distance
from the antenna.
• Use only FCC approved, supplied or replacement headsets, batteries, and accessories intended
for use with this radio. Use of non FCC approved headsets, batteries, and accessories may
exceed FCC RF exposure guidelines.
Product Safety and RF Exposure for Portable Two-Way
Radios Compliance with RF Energy Exposure Standards
NOTICE: This radio is intended for use in occupational/controlled applications where users have
been made aware of the potential for exposure and can exercise control over their exposure. This
radio device is NOT authorized for general population, consumer, or similar use.
BEFORE USING THIS RADIO, READ THE TRAINING MATERIAL BELOW WHICH CONTAINS IMPORTANT
OPERATING INSTRUCTIONS FOR SAFE USAGE AND RF ENERGY AWARENESS AND CONTROL
INFORMATION FOR COMPLIANCE WITH RF ENERGY EXPOSURE LIMITS IN APPLICABLE NATIONAL AND
INTERNATIONAL STANDARDS.

User Guide
[e-mail]
800.321.6221
FCC License Information
Your JTECH radio operates on communications frequencies which are subject to FCC (Federal Communications Commission)
Rules &Regulations. FCC rules require that all operators using Private Land Mobile radio frequencies obtain a radio license
before operating their equipment. Application for license must be made on FCC main form 601, and schedules D, E, and H.
FAX: Forms can be obtained by fax from the FCC Fax-On-Demand system. Call 1-202-418-0177 from your fax machine and
request document number 000600 for the form, schedules, and instructions.
MAIL: Forms can be ordered by telephone, and will be sent to you by first class mail. Call the FCC Forms Hotline at 1-800-
418-FORM (1-800-418-3676).
INTERNET: Form 601 and instructions can be downloaded from the FCC Forms website at:
http://www.fcc.gov/Forms/Form601/601.html
Before filling out your Form 601 application Technical Data section, you must decide which frequency (or frequencies) you
will operate on.
QUESTIONS? Call the FCC for license application questions at 1-888-CALL-FCC (1-888-225-5322). If you have
any questions, call JTECH at 1-800-321-6221.
Federal Communication
Commission (FCC) Regulations
The FCC has established limits for safe exposure to radio frequency (RF) emissions from radio devices. The FCC requires
manufacturers to demonstrate compliance with RF exposure limits before radio devices may be marketed in the U.S. When
two-way radios are approved for occupational/controlled environment exposure limits, the FCC requires users to be fully
aware of, and exercise control over, their exposure. Awareness and control of RF exposure can be accomplished using
labels, or by education and training through appropriate means such as information and instructions in user manuals or safety
booklets. Your JTECH two-way radio has an RF exposure information label in the battery compartment. The training material
below includes useful information about RF exposure and helpful instructions.
Your JTECH two-way radio device was designed and tested to comply with several national and international standards and
guidelines regarding human exposure to RF electromagnetic energy. In terms of measuring RF energy for compliance with
FCC exposure guidelines, your radio device radiates measurable RF energy only while transmitting (during talking), not when
it is receiving (listening), or in stand-by mode.

User Guide
[e-mail]
800.321.6221
WARNING
As the qualified end-user of this radio device, you must control the exposure conditions in the area to ensure the minimum
separation distance is maintained between the antenna and nearby persons for satisfying RF exposure compliance. The
operation of this transmitter must satisfy the requirements of occupational/controlled exposure environment. For work-
related use, transmit only when the person(s) is at least the minimum distance from the properly installed, externally
mounted antenna. Transmit only when people are outside the vehicle or away from the repeater antenna and are at least
the recommended minimum lateral distance away from the antenna/vehicle.
General Items
This warranty policy establishes the liability limits for which JTECH is responsible. JTECH has the right to decide, in their
sole discretion, whether to repair, replace, or refund the purchase price of any equipment subject to this warranty. There
are no other options available under this warranty. This express warranty is the complete agreement.
OTHER THAN AS EXPRESSLY SET OUT IN THESE TERMS OR ADDITIONAL TERMS, NEITHER JTECH NOR ITS SUPPLIERS OR
DISTRIBUTORS MAKE ANY SPECIFIC PROMISES ABOUT THE SERVICES OR PRODUCTS.
JTECH Radio Quality Warranty and Liability
The Warranty Range and Limitation
JTECH is committed to quality and stands behind its products. JTECH will, during the warranty period specified for each
product, repair or replace components that fail as aresult of poor workmanship or materials. This warranty does not
cover improper use or intentional damage.
The Warranty Policy Does Not Include the Following Conditions:
•Defects or damages caused by working in abnormal or unusual situations.
•Defect or damages caused by misuse, accident, or water submersion.
•Defect or damages caused by unauthorized installation, repair, tampering, or adjustment.
•Warranty does not extend to cosmetic scratches or damages as a result of normal use or misuse.
•This warranty is void if the product information label is removed, or if the serial number is tampered with, changed,
or cannot be identified. It is also void if the repeater enclosure is tampered with or unsealed.

User Guide
[e-mail]
800.321.6221
CONTENTS
Getting Acquainted
Product Inspection 8
Common Package Items 8
Radio Controls 9
LCD Display Symbols 10
Programmable Auxiliary Functions 10
Safety and Care Instructions 11
Getting Started
Installing the Swivel Belt Holster 12
Installing the Belt Clip 12
Installing the Battery13
Charging the Battery 14
Turn the Unit ON/OFF 16
Adjusting the Volume 16
Select a Channel 16
Transmitting and Receiving 17
Keypad Lock 17
VOX Operation 18
Monitoring aChannel 19
Scanning 19
Wireless Cloning 21
Local Programming Mode 22
Entering Programming Mode 23
Advanced Features 28
Frequencies List 29
CTCSS/DCS Code List 30
Troubleshooting 31

User Guide
[e-mail]
800.321.6221
GETTING AQUAINTED
Product Inspection
Thank you for your purchase of JTECH Extend portable two-way radio. Before use, please inspect the
product as follows. First check the shipping carton for any signs of damage. If any damage has
occurred, please contact your dealer or JTECH immediately. Confirm the supplied product against
the packing slip to assure accuracy.
Common Package Items (Contents May Vary):
Item Qty.
1Radio (Extend) 1
2Battery 1
3Single Charger (with adapter) 1
4Charger Power Adapter 1
5Swivel Belt Holster 1

User Guide
[e-mail]
800.321.6221
RADIO CONTROLS
The following figures denote the radio keys, controls, and user interfaces of the JTECH Extend. The
user should note the operation of each and be familiar before deployment.
1. Charger Terminal
2. Speaker
3. Microphone
4. ▼,Channel Down Key -(Select item key in
Local setting Mode)
5. F , Programmable Function Key -(Default:
Key Lock @long press, Flashlight @short
press, exit current status key in local setting
mode)
6. S/M, Programmable Function Key - ( Default:
Menu @long press, Scan @short press)
7. ▲,Channel Up Key -(Select item key in Local
programming Mode)
8. LCD Display -refer to the below symbols list
9. SF2 ,Programmable Function Key -(Default:
Channel View @short press, Monitor @long
press)
10. SF1, Programmable Function Key -
(default: PTT )
11. LED Flashlight
12. LED Indicator (Tx &Busy)
13. Power Switch/ Volume Knob
14. Headset Jack/Programming Cable Jack
15. Belt Clip Screw Hole
16. Antenna
17. Battery Cover
18. Open Slot for Battery Cover

User Guide
[e-mail]
800.321.6221
LCD Display Symbols
Symbol Function
EXTEND2 Power on text, it can be
channel number/channel
alias/channel frequency
RSSI
High power: the current channel
is high power (H/M/L)
LED flashlight function enable
Headset connected
Headset function disable
Vibration function enable
Monitor indicator
Speaker opened
Speaker function disable
Battery indicator
Keypad lock
DTMF signalling enable
Scan
The current channel is in scan list
The current channel is prior channel
Compander enable
Scrambler enable
VOX enable
The SF1, SF2, S/M, and F keys can be programmed for a variety of functions. See “Local Programming Mode” menu list later
in this manual. Please contact your dealer for further details on these functions.
Programmable Auxiliary Functions

User Guide
[e-mail]
800.321.6221
Safety Precautions
Please observe the following safety precautions when setting up and using this product.
•LCD Panel -The LCD panel is made of glass and may break if the unit is dropped or impacted.
•Heat Sources -Keep the product away from heat sources such as radiators, stoves, heaters, and other heat-
generating products.
•Water and Moisture -Do not use the product in or near water or in high moisture areas such as abathroom or
outdoors when rain is present.
Safety and Care Instructions
To ensure you receive the maximum benefit from using this product, please observe the following
guidelines.
•Cleaning -Use a damp cloth. Do not use liquid cleaning agents, benzene, thinner, or aerosols.
•Repair -Do not attempt to repair the product or modify the circuitry by yourself. Only replacement parts that are
recommended by JTECH should be used. You can contact JTECH at [phone].
•Scratches -Do not scratch hard objects against the LCD display as this may cause damage.
Caring For This Product
•To avoid risk of fire or injury, do not attempt to charge non-rechargeable batteries.
•Please turn off the unit while charging.
•Only replace batteries with the same or equivalent type recommended by the manufacturer.
•Please dispose of old, defective batteries in an environmentally friendly manner in accordance
with the relevant laws and regulations.
•Do not dispose this product as unsorted municipal waste. Collection of such waste
separately for special treatment is necessary.
•Do not expose equipment and accessories to open flames, such as lighted candles, etc.
•To reduce the risk of electric shock, do not expose equipment to rain or moisture.
Caution

User Guide
[e-mail]
800.321.6221
GETTING STARTED
Installing the Swivel Belt Holster (Optional Accessory)
•Slide the bottom of the radio into the holster until it snaps into place.
•To remove, push the tab on the holster and pull the radio away from the holster.
NOTE: If there is a need to replace the holster, contact your account manager or call [phone] to order a
replacement.
Installing the Belt Clip
•Align the two screw holes on the metal bracket of the belt clip with holes on the back side of the radio. Then
secure the belt clip on the back side of the radio, as shown below, and then secure the screws.
•To remove, loosen the screw to remove the belt clip.

User Guide
[e-mail]
800.321.6221
Installing the Battery
Your radio uses arechargeable Lithium Ion (Li Ion) battery.
•If the battery cover is already in place, use the fingers to press down the three circle position and in the meantime use
the thumb to pull up in the direction of arrow from the bottom side OPEN slot.Then lift the rear cover and remove it
from the radio’s body, as shown in the figure below.
•Insert the battery, printed arrows first, into the battery compartment and press down to secure firmly in place.
•Fit the one extension at the top of the battery cover into the slot at the top of the radio’s body, press the bottom of the
battery cover towards the radio until aclick is heard, and then the battery cover is securely attached to the radio, as
shown below.

User Guide
[e-mail]
800.321.6221
Charging the Battery
When the Battery Icon displays 0bars, you will hear avoice prompt “please charge”, then you need to recharge the
battery.
For optimum battery life, do not charge the battery for prolonged periods after it is fully charged.
Using the Drop-in Charger
1. Place the charger on aflat surface.
2. Insert the plug of the power cord into the jack on the charger.
3. Plug the cord into an AC outlet.
4. Turn the radio off. If the radio is on while charging, it will not fully charge.
5. Insert the radio (with battery installed) into the front charging pocket.
NOTE: The radio will fit in the charger with the holster or belt clip on. The drop-in charger will also charge aspare Extend Li Ion
battery. Both batteries will charge in approximately 3–6 hours.

User Guide
[e-mail]
800.321.6221
Using the Extend Multi-Unit Charger
The Multi-Unit Charger (MUC) allows drop-in charging of up to 6 radios or batteries. Batteries can be charged inside the
radios or removed and placed in the MUC Separately. Each of the 6charging pockets can hold a radio or battery, but not
both.
1. Place the charger on aflat surface.
2. Insert the power cord plug into the jack on the MUC.
3. Plug the cord into an AC outlet.
4. Turn the radio off.
5. Insert the radio or battery into the charging pocket.
Charging Status LEDs
On the drop-in charger, the radio and battery charging pockets have their own LEDs.
On the MUC, each of the 6charging pockets has an LED. The LED is solid red when the battery is
charging and solid green when charging is complete. See label at the bottom of the charger for
other LED conditions.
Battery Meter
The battery meter in the upper right corner of the display (see page XX) indicates how much
battery power is remaining.
3 Bars 2 Bars 1 Bar 0Bar
Voice Charging
Prompt
100%-85% 85%-25% 25%-10% Final 10%

User Guide
[e-mail]
800.321.6221
Turn clockwise to turn the radio on, and counterclockwise to turn the radio off. When you
turn the radio on, the radio will chirp and if enabled, speak the channel number. The display
briefly shows all features and display segments.
Adjusting the Volume
Turn clockwise to increase the volume, and counterclockwise to decrease the volume.
NOTE: Do not hold the radio too close to your ear when adjusting the volume.
Select aChannel
The transmitting and receiving radios must be on the same channel using the same CTCSS code or
DCS code in order for you to communicate with another party.
To Select Between Channels (Maximum 16):
Turn the Unit ON/OFF
1. Press
2. Press
to increase channel
number. to decrease
channel number.

User Guide
[e-mail]
800.321.6221
Transmitting and Receiving
For best transmission, speak about 1.5” away from the radio and leave a short pause before speaking once you have pressed the
PTT button.
To Talk to Another Radio
1. Press and hold “SF2” (this button is set to the Monitor function) to check for channel activity. Do not transmit if someone
is speaking on the channel.
2. Press and hold PTT button (SF1) and speak into the microphone to transmit.
3. Release the PTT button once you have finished speaking to allow other radios to respond. The radio will automatically hear
received transmissions.
The transmit LED on the top of the radio is red when transmitting and is green when receiving.
Signal Strength and Channel Busy Indicators
When there is activity on afrequency, the radio LCD displays and the green LED lights steady.
When there is activity on the same frequency and code as your radio (your radio is receiving), the radio displays an
and a signal strength from 1(weakest) to 4 (strongest). This can help determine when aradio is moving out of range.
Note: Obstacles that block the signal path may affect the strength of the incoming signal.
Keypad Lock
To avoid accidentally changing the channel and the unit’s preferred settings, you can lock the keypad.
To lock or unlock the keypad: Press and hold the F button for 2.0 seconds. appears on the LCD when
the keypad is locked.
Note:
1. The Fbutton Long Press is programmed for keylock (default).
2. While key lock is “on” you can still use the PTT button.

User Guide
[e-mail]
800.321.6221
VOX Operation
The Voice Activated Transmission (VOX) function allows your voice to acti¬vate transmission automatically when the
transceiver is used with an optional hands-free microphone / headset. If the unit is set to VOX level 1, 2, .....6, it will
automatically detect and transmit your voice through to the selected channel.
NOTE: The VOX level and transmission delay time should be set according to your voice loudness and personal preference.
To Set Up aVOX Headset:
When you enter the local programming mode, the key function is as below:
1. Turn the radio off.
2. Open the accessory cover.
3. Plug the headset into the accessory jack.
4. Turn the radio back on again. The radio displays
5. Lower the radio volume BEFORE placing the headset in or near your ear.
6. To transmit, speak into the accessory microphone. To receive, stop talking.
NOTE: This product is compatible with Motorola headsets, please ask your local Account Manager for further information.
Pressing the PTT button disables VOX.

User Guide
[e-mail]
800.321.6221
Monitoring aChannel
Monitoring allows you to check for activity on achannel. The JTECH Extend has three monitor modes. You can choose a mode
according to your preference.
•Squelch Off (Default): In this mode, the speaker is unmuted in any condition so as to receive any sound on the current
channel. When audio signal is received on the channel, audio will be heard. Otherwise, background noise will be heard.
Operation: Press and hold the Monitor (Default SF2) key to enter this mode, and release the key to exit.
•Monitor toggle: In this mode, the receiving party can receive incoming calls from the transmitting party regardless of
CTCSS/CDCSS condition. If the channel frequency is not the same, the receiving party will not receive any incoming calls.
Operation: Press the Monitor key to enter this mode, and press it again to exit.
•Monitor Momentary: Refer to Monitor toggle.
Operation: Hold down the programmed monitor key continuously to enter this mode, and release the key to exit.
You can scan up to 16 channels and frequencies. When the radio detects activity, it stops scanning and locks in on the
active channel. If programmed for talkback, you can talk and listen to the person transmitting without changing
channels.
NOTE: The icon will appear on the display when the current channel is added to the scan list. The icon will
appear on the display when the current channel is a priority channel.
1. To start scanning, press the key programmed as “Scan” (S/M default). The scan icon displays and the radio
begins to scan the channels. When the radio detects activity, it stops on that channel and displays and the channel
number.
2. To talk to the person transmitting without switching channels, press the PTT button before scan resumes. If no
transmission occurs, scanning resumes.
Note: these timers can be changed by the programming software.
3. To stop scanning, press the “Scan” Key. If you press PTT while the radio is scanning, the radio transmits on the
channel you were on before you activated scan.
Scanning
Skipping and Removing Channels While Scanning
Scan has two temporary features to make it easier to use.
1. Scan advance: If the radio stops scanning on a channel you do not want to listen to, press
2. Nuisance delete: Press and hold to temporarily remove achannel from the scan list. The channel returns to the scan
list when the radio is turned off &then on again.

User Guide
[e-mail]
800.321.6221
Without Priority Channel
Providing that there is a scan list with 6 channels and all channels are non-prioritized, the normal scan operation would
proceed in the following sequence, as shown in Figure 1.
With Priority Channel
If you prioritize Channel 2as priority, the scan operation would proceed in the following sequence, as shown in Figure
2.
This function enables users to scan the most frequently used channel so that messages will not be missed. The priority
channel is programmed by the dealer via programming software or by the radio’s keypad if full radio programming is
activated.
Note: If the radios receiving on a non-priority channel, the priority channel is still scanned. The radio will switch to the
priority channel once any activity is detected.
Power-On Scan
If power-on scan is enabled by your dealer, the radio will automatically enter scan mode when it is turned on. The radio is
always in scan mode. Scan cannot be turned off.
