Jackson HH/GPX User manual

TempStar™ HH/GPX
Models
TempStar™ HH/GPX
Door Type
Project
Item
Quantity
CSI Section 11400
Approval
Date
Highway 25E
P. O. Box 1060
Barbourville, KY 40906
Tel: [phone]
Tel: [phone]
Fax: [phone]
E-mail: [email protected]om
www.jacksonmsc.com
07610-002-66-62 (09/07)
Mandatory Specs
Specify incoming water
temperature
Specify how far booster
will be placed from unit
Specify altitude for
proper booster size
Optional Features
Water hammer arrestor
Flanged feet
Drain quench system
Scaltrol
Multi-cycle timer (Extra Heavy,
Heavy, Medium, Normal)
Built-in pressure regulator and
gauge
Extended 15 second high tempera-
ture rinse provides superior cover-
age and rapid drying
20 3/4” (527 mm) wide X 27” (686
mm) high opening accommodates
18” (457 mm) X 26” (660 mm) sheet
pans and 60 quart mixing bowls
Auto-fill / auto-start
Safety door switch
External gas booster heater
- Capable of minimum 70˚F
(21˚C) degree temperature rise
- Recirculates water through stain-
less steel coils in wash tank to main-
tain 150˚F (66˚C) degree minimum
temperature
Hi-limit thermostat and low water
protection
Top mounted controls for ease of
installation
Unique lower counter-rotating
wash arms and upper wash arm
provide optimum spray coverage
and superior cleaning action
Unique split-door design for installa-
tions with low ceiling heights
Large scrap tray
Self-draining stainless steel pump
Detergent/rinse additive signal
connection fuse box
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Standard Features
Accessories
Uses 1.36 gallons (5 liters) of 180˚F
(82˚C) w a t e r p e r r a c k
T o t a l a u t o m a t i c n o r m a l c y c l e - 6 2
seconds
5 3 r a c k s p e r h o u r n o r m a l c y c l e
2 H P W a s h P u m p M o t o r
Single Point connections for all utilities
B u i l t - i n w a t e r p r e s s u r e r e g u l a t o r a n d
pressure gauge
Field convertible from straight through
t o c o r n e r o p e r a t i o n s
Heavy duty stainless steel
construction
Specifications
36” (914 mm) compartment
rack 4 1/6” (4 mm) tall
36” (914 mm) compartment
rack 5 5/8” (16 mm) tall
36” (914 mm) compartment
rack 7” (178 mm) tall
Combination rack
Peg rack
Sheet pan rack 18” X 26” /
(457 mm X 660 mm) baking
pans
Delime/manual wash switch
Adjustable bullet feet
Uses standard 20” X 20”
(508 mm X 508 mm) racks
Front dress panel
•
•
•
•

We reserve the right to change specications appearing in this bulletin without incurring any obligation for equipment previously or subsequently sold.
Highway 25E
P. O. Box 1060
Barbourville, KY 40906
Tel: [phone]
Tel: [phone]
Fax: [phone]
E-mail: [email protected]om
www.jacksonmsc.com
07610-002-66-62 (09/07)
How To Specify - TempStar™ HH/GPX
MODEL NO.
SIZE
DRAIN
HEIGHT
SHIPPING INFO DIMENSIONS
HEIGHT WIDTH DEPTH WEIGHT CLASS CUBE HEIGHT WIDTH DEPTH
TempStar™ HH/GPX 76-3/4”
(1949 mm)
25-1/4”
(641 mm)
25-1/4”
(641 mm)
11-3/4”
(298 mm)
420 lbs
(191 kg)
92.5 71.4
cu. ft.
85”
(2159 mm)
44”
(1118 mm)
33”
(838 mm)
DIMENSIONS--STANDARD MODEL
DIMENSION REQUIREMENTS
Minimum Ceiling Height (Recommended) 88” / (2 meters)
Wall Clearance (Minimum) 4” / (102 mm)
Standard Table Height 34” / (864 mm)
Inside Clearance 17-1/4”/ (438 mm)
OPERATING CAPACITY
Racks per Hour Normal
53
Medium
28
Heavy
19
Extra Heavy
11
OPERATING CYCLE (sec) Wash Rinse Dwell Total Cycle
Normal 45 15 2 62
Medium 103 15 2 120
Heavy 163 15 2 180
Extra Heavy 283 15 2 300
OPERATING TEMPERATURES
Wash (Minimum) 150˚F / (66˚C)
Rinse (Minimum) 180˚F / (82˚C)
WASH PUMP MOTOR
Wash Pump Motor Horsepower 2 HP
WATER REQUIREMENTS
Inlet Tempterature
40˚F / (4˚C) Rise 140˚F / (82˚C)
70˚F / (21˚C) Rise 110˚F / (60˚C)
Gallons per hour 72.1 / 273 Ltr.
Waterline Size IPS (Minimum-inches) 3/4
Drainline Size IPS (Minimum-Inches) 1-1/2
Flow Pressure (PSI) 15-25
Tank Capacity
Wash Tank 8 Gal. / (30 ltr)
Booster Tank 3 Gal. / (11 ltr)
Pump Capacity (GPM) 73 Gal / (276 ltr)
APPROXIMATE TOTAL LOAD AMPS
AMPS
115V/60HZ/1PH 25
208V/60HZ/1PH 13
230V/60HZ/3PH 13
230V/60HZ/1PH 13
230V/60HZ/3PH 13
GAS REQUIREMENTS
Maximum Minimum
Natural Gas (Inches-water column) 10.5 / (267 mm) 5.0 / (127 mm)
LP Propane Gas (Inches-water column) 13.0 / (330 mm) 11.0 / 292 mm)
Gas Booster Capacity (BTU)
Input 105,000
Output 84,800
4 [102mm]
4 [102mm]
34 [861mm]
25 [637mm]
863
4[2202mm]
17 [432mm]
C
73 [1856mm]
27 [687mm]
103
4[274mm]
113
4[298mm]
A
31
2[92mm]
E
1 [25mm]
73
4[194mm]
LEGEND
A - DRAIN 1 1/2” NPT
B - WATER INLET 1/2” NPT
C - ELECTRICAL CONNECTION
D - OUTLET TO BOOSTER
HEATER 3/4” NPT
E - INLET FROM BOOSTER
HEATER 3/4” NPT
All vertical dimensions are +/- 1/2"
due to adjustable bullet feet.
34 [866mm]
A
251
4[639mm]
3 [79mm]
C
151
4[387mm]
113
4[298mm]
B
D
E
18 [456mm]
163
4[426mm]
5 [126mm]
251
4[642mm]
32 [813mm]
3 [77mm]
C
