Thermostat
Replacement
07610-003-12-41 A
September 23, 2005
R24/R30 Glasswasher
Maintenance Instructions

Jackson glasswasher machines come equipped with ther-
mostats to ensure proper ware washing results. Occasionally,
some of these components may need replacing to maintain opti-
mum performance.
Jackson offers all of the repair parts necessary for per-
forming this task.
The instructions provided here are for maintenance per-
sonnel only. Unauthorized persons should not attempt any of the
steps contained in these instructions.
Warning: many of the instructions and steps within
this document require the use of tools. Only authorized per-
sonnel should ever perform any maintenance procedure on
the dishmachine!
PREPARATION
1. Power must be secured to the unit at the service break-
er. Tag or lock out the service breaker to prevent accidental or
unauthorized energizing of the machine.
2. Ensure that incoming water to the machine is secured
either by use of a shut-off valve or disconnecting the incoming
water line.
3. The unit must be drained completely with the drain
stopper removed.
TOOLS REQUIRED
The following tools will be needed to perform this mainte-
nance evolution:
1. 3/8” Nutdriver
2. 7/16” Nutdriver
3. 7/16” Combination Wrench
4. Needlenose Pliers
5. Phillipshead Screwdriver
TIME REQUIRED
It is estimated that it will take (1) person twenty minutes to
perform this task, not including all of the items indicated in the sec-
tion entitled “PREPARATION”.
IMPORTANT NOTES
1. Read these instructions thoroughly before attempting
this maintenance task. Become familiar with the parts and what
actions need to be taken. This will save time in the long run!
STEPS
1. Remove the front door.
2. Remove the heater box cover with the 3/8” nutdriver to expose
the heater. Set the cover and hardware to the side.
3. Using the pair of needlenosed pliers (if necessary), remove the
terminals from the thermostat. Be careful not to damage the termi
-
nals or the wires or else they will have to be replaced.
4. Remove the thermostat bracket mounting nuts with the 7/16”
nutdriver. .
www.jacksonmsc.com
Thermostat Replacement Instructions
Revision A (09/23/2005)
2
Removing the heater cover.
Removing the terminals.

5. Remove the thermostat from the mounting bracket with the
phillipshead screwdriver.
6. Use the 7/16” combination wrench to loosen and remove the
imperial brass fitting. Once this is complete, you should be able to
completely remove the thermostat.
7. Take the new thermostat and place its probe in the new imperi
-
al brass fitting provided in your kit. Use the 7/16” combination
wrench to tighten it down after getting the fitting hand-tight in the
tank.
8. Mount the thermostat to the bracket.
9. Mount the bracket to the tank and tighten down the nuts with the
7/16” nutdriver.
10. Reconnect the wires per the machine schematic on the back of
the door.
11. Place the drain stopper back in the wash tank. Restore power
and water to the unit. Then allow the unit to operate normally.
12. Verify that the thermostat turns operates the heater contactor.
Once you have determined the heater contactor is working, adjust
the wash tank thermostat to ensure that the temperature is main
-
tained in accordance with the specifications on the machine data
plate.
13. Replace the heater cover.
14. Replace the front door.
AFTER MAINTENANCE ACTIONS
None
SPECIAL NOTES
Work performed on Jackson dishmachines by unautho
-
rized or unqualified personnel may void the warranty. Before begin
-
ning this or any other maintenance evolution on a unit under war
-
ranty, you should contact a certified Jackson technician or Jackson
Technical Service. You can find a list of qualified service agencies
in the back of you unit’s installation manual.
SPECIAL PARTS
Heater Replacement Kit: 6401-003-12-40*
*The kit contains a thermostat, imperial brass fitting, and
instructions.
CONTACT INFORMATION
Jackson MSC Inc. provides technical support for all of the
dishmachines detailed in this manual. We strongly recommend that
you refer to this manual before making a call to our technical sup
-
port staff. Please have this manual with you when you call so that
our staff can refer you, if necessary, to the proper page. Technical
support is available from 8:00 a.m. to 5:00 p.m. (EST), Monday
through Friday. Technical support is not available on holidays.
Contact technical support toll free at 1-888-800-5672. Please
remember that technical support is available for service personnel
only.
