WARNING: If incorrectly used this machine can cause
severe injury. Those who use and maintain this machine
should be trained in its proper use, warned of its dangers and
should read the entire manual before attempting to set up,
operate, adjust or service the machine.
RJL 100 September 2014
24715G-PT (R6)
Safety, Operation and Maintenance Manual
Manual de segurança, utilização e manutenção
Jacobsen AR3, Kubota D1105-E4B
Jacobsen AR3, Kubota D1105-E3B
Series / Séries: EK
Product code / Código do produto: AR30001
Series / Séries: FZ
Product code / Código do produto: AR30002
Series / Séries: GX
Product code / Código do produto: AR30003
Series / Séries: KG
Product code / Código do produto: AR30004
WARNING
WARNING:Ifincorrectlyusedthismachinecancause
severe injury. Those who use and maintain this
machine must be trained in its proper use, warned of
its dangers and must read the entire manual before
attempting to set up, operate, adjust or service the
machine.
AVISO
AVISO: Quando incorretamente utilizada, esta
máquina pode provocar lesőes graves. Aqueles que
utilizarem esta máquina e fizerem a manutençăo da
mesma tęm de ter formaçăo para a sua utilizaçăo
correta, tęm de ser informados acerca dos perigos e
devem ler todo o manual antes de tentar configurar,
utilizar, afinar ou fazer a manutençăo da máquina.
PT
Portugal

INTRODUCTION
Important ............................................................................3
Product Identification ......................................................... 4
Guidelines For The Disposal Of Scrap Products ...............6
During Service Life .............................................................6
End Of Service Life ............................................................6
Parts Manual ......................................................................7
Key Numbers .....................................................................7
SAFETY
How To Operate Safely.......................................................8
Safe Operation ...................................................................8
Preparation ........................................................................ 8
Operation ........................................................................... 9
ROPS................................................................................. 10
Safe Handling of Fuels.......................................................10
Maintenance And Storage ................................................ 10
When You Put A Mower On A Trailer ................................11
Important Safety Notes .....................................................12
SPECIFICATIONS
Engine Specification .......................................................... 15
Machine Specification .......................................................15
Dimensions ....................................................................... 15
Vibration Level ..................................................................16
Noise Emissions ............................................................... 17
Cutting Unit Specification ..................................................18
Cutting Performance (Area) ..............................................18
Recommended Lubricants ................................................19
Conformity Certificates ......................................................20
DECALS
Safety Decals EC............................................................... 22
Instruction Decals EC ....................................................... 22
Safety Decals USA ........................................................... 23
Instruction Decals USA ...................................................... 23
CONTROLS
Instrument Panel ...............................................................24
Starter Key Switch ........................................................... 25
Parking Brakes .................................................................. 25
Working Light Switch ........................................................25
Cutting Unit Switch ............................................................25
Weight Transfer Switch .....................................................26
Blocked Hydraulic Filter Indicator Lamp. .......................... 26
Engine Coolant Temperature Warning Lamp .................... 26
Engine Oil Pressure Warning Lamp................................... 26
Throttle Control Lever ...................................................... 27
Joystick Unit Lift/lower Control ..........................................27
Safety Module Malfunction.................................................27
Engine Preheat ..................................................................27
Multi-function Gauge..........................................................28
Traction Foot Pedal .......................................................... 29
Steering Tilt Control ..........................................................29
Power Outlet ..................................................................... 29
Parking Brake Release Valve ...........................................30
Transport Latches .............................................................30
OPERATION
Daily Inspection ................................................................. 31
Operator Presence And Safety Interlock System ............. 32
Operating Procedure .........................................................33
Fitting The Cutting Units To The Machine ........................ 34
Starting The Engine .........................................................35
Driving .............................................................................. 35
Mowing .............................................................................. 35
To Stop The Engine ..........................................................35
Transporting ......................................................................36
Transporting On A Trailer Or Flatbed ................................37
Mowing On Slopes .............................................................38
Inclinometer........................................................................41
MAINTENANCE AND LUBRICATION
Maintenance & Lubrication Chart ......................................42
Engine Lubrication ............................................................44
Engine: Fan Belt ................................................................44
Engine Coolant ..................................................................45
Hydraulic System ..............................................................46
Hydraulic Test Ports ..........................................................47
Fuel System ......................................................................48
Air Cleaner ........................................................................49
Battery ...............................................................................49
Machine Maintenance .......................................................50
Freewheel Control .............................................................50
ADJUSTMENTS
Traction Control Pedal .......................................................51
Weight Transfer Adjustment ..............................................51
Height Of Cut ....................................................................52
Blade Change ....................................................................54
Blade Sharpening...............................................................54
Speed Limiter ....................................................................55
Seat Milsco CE-9.16 ..........................................................55
Seat Michigan V-5300........................................................56
General Instructions For Grammer Seats .........................57
Seat (Grammer MSG85) ...................................................59
Weight Adjustment ............................................................60
Fore/aft Adjustment ...........................................................60
Backrest Extension.............................................................61
Seat Heater ........................................................................61
Lumbar Support ................................................................61
Armrests.............................................................................62
Armrest Adjustment............................................................62
Backrest Adjustment .........................................................62
Maintenance ......................................................................63
ACCESSORIES
Ops Frame (Lmac164) ......................................................64
Transport Latch Kit (Lmac174) ..........................................64
Working Lamp Kit (Lmac163) ............................................64
PROBLEM SOLVING
Engine General .................................................................65
Quality Of Cut Problem Solving..........................................66
Washboarding ....................................................................66
Step Cutting .......................................................................67
Scalping .............................................................................68
Stragglers...........................................................................69
Streaks ...............................................................................70
Windrowing.........................................................................71
Mismatched Cutting Units .................................................72
SCHEMATICS
Hydraulic Circuit ................................................................74
Electrical Circuit Instrument ...............................................76
Electrical Circuit Main ........................................................78
Electrical Circuit Fuses And Relays ..................................80
TORQUES
Torques .............................................................................82
GUARANTEE
Warranty ............................................................................83
Service ..............................................................................83
© Ransomes Jacobsen Limited. All Rights Reserved
SECTION PAGE
1 CONTENTS
SECTION PAGE

en-3
The Jacobsen AR3 is a Diesel engined self propelled Rotary mower. The hydraulic systems are for the
traction drive, the cutting unit lift and the lower and cutting unit drives and steering.
IMPORTANT: The reliability and cutting performance of this machine will depend on the its care and use.
Failure to operate and maintain within the practices given in this manual will shorten component life and affect
cutting performance.
This SAFETY AND OPERATORS MANUAL is part of the machine and must stay with the machine always.
Suppliers of both original and used machines need to keep the documentation that comes with the machine.
You must use the machine to cut the grass only and not for any other purpose. Compliance with the conditions
of operation, service and repair specified by the manufacturer, are understood to be part of the correct use.
ALL operators MUST read through this manual and understand the Safety Instructions, controls, lubrication
and maintenance procedures.
Make sure that you obey all safety and road traffic regulations.
You must not make any changes to the machine that the manufacturer does not approve. This type of change
can release the manufacturer from the liability for any damage or injury.
Discard worn parts, taking note of the environmental result, use the systems available in the country where
the machine is used. When the machine is at its end of life, there are guidelines in this manual for the removal
of the machine from use.
Use only Ransomes Jacobsen Genuine spare parts to make sure that European conformity is controlled.
2006/42/EC
These instructions are the Original instructions confirmed by Ransomes Jacobsen Limited
INTRODUCTION 2

en-4
MADE IN JAPAN
D1105
Serial No.:
Code No.:
XXXXXXX
XXXXX-XXXXX
MADE IN JAPAN
V2203
Serial No.:
Code No.:
XXXXXXX
XXXXX-XXXXX
Kg Kw Kg Kg
WestRoad
RansomesEuropark
IpswichIP39TT
England
ABCDE
FG
HJ
L
WA
1
05
05 dB
2.1 PRODUCT IDENTIFICATION
A Maximum front axle load in Kg (for machines being driven on
the highway)
B Gross weight (mass) in Kg
C Maximum rear axle load in Kg (for machines being driven on
the highway)
D Power in Kw
E Date code
F Machine type (Designation)
G Product code
H Product name
J Serial number
Location of Serial number plate
The serial number plate (A) is found on the chassis under the operator seat.
Chassis Stamp
The Serial number and date code (B) are marked on the chassis centre unit arm
mounting
Engine Identification
Serial Plate
Location of Serial number plate
The engine serial number plate is found on the engine block. The label shows
the engine group and serial number.
The engine serial number is also found stamped on the engine block.
2 INTRODUCTION
Kg Kw Kg Kg
West Road
Ransomes Europark
Ipswich IP3 9TT
England
ABCD E
FG
HJ

en-5
A
MADE IN U.K.
A.B.T. PRODUCTS LTD.
ROSS-ON-WYE,
HEREFORDSHIRE,
HR9 7BW
TEL: [phone]
LMAC 164
### - ##
INTRODUCTION 2
ROPS Serial Plate
ROPS Serial Plate Location
The ROPS serial plate (C) is located at the base of the of the ROPS main
left hand beam.

en-6
2 INTRODUCTION
2.1 GUIDELINES FOR THE DISPOSAL OF SCRAP PRODUCTS
2.1.1 DURING SERVICE LIFE
Used oil, oil filters and engine coolant are hazardous materials. Recommended procedures must be followed
for their safe removal.
If a fluid leaks, contain the spill to make sure that the leak does not flow into the ground or drainage system.
Follow the local laws to make sure that leaks are controlled safely.
The maintenance procedures in this manual make sure that the damage that the machine can cause in the
local environment is controlled safely.
When the machine completes its full service life, the following actions must be taken.
2.1.2 END OF SERVICE LIFE
These guidelines must be used with applicable Health, Safety and Environmental laws. Always use the
approved local waste disposal and agencies for recycled materials.
• Park the machine in a location to use all of the necessary lifting equipment.
• Use correct tools and Personal Protective Equipment (PPE) and take instruction from the technical
manuals applicable to the machine.
• Remove and store correctly
1.Batteries
2.Fuel
3.Engine coolant
4.Oils
• Disassemble the structure of the machine and refer to the technical manuals where applicable. Give
attention to parts that have mechanical pressure or tension applied to the part in the machine,
including springs.
• Items that continue to have a service life must be separated and returned to the local store.
• Items that are worn must be separated into the material groups and removed according to the
agencies for recycled materials that are available. Common types are as follows:
• Steel
• Non ferrous metals
• Aluminium
• Brass
• Copper
• Plastic materials
• Identified
• Can be recycled
• Can not be recycled
• Not identified
• Rubber
• Electrical and Electronic Components
• If an item is not easily separated into different material groups, the material must be added to the
“General discarded materials” area.
• Do not burn discarded materials.
Change the machinery records to show that the machine is not in service and is discarded. Supply this serial
number to Ransomes Jacobsen Warranty Department to close their records.

en-7
2.1 PARTS MANUAL
In compliance with the ISO14001 standard, Ransomes Jacobsen Limited does not send a paper parts manual
with every product.
To refer to a parts list for this mower you have four options:
1. Website – www.RansomesJacobsen.com. Select the “GENUINE PARTS” tab followed by the
“ONLINE PARTS LOOK-UP” tab. You now have access to Parts drawings and lists to help with the
identification of spare parts.
2. Website – www.ransomesjacobsen.com. Select the “SUPPORT” tab. You now have access to a PDF
version of the parts manual.
3. Complete the form included in the technical manual pack supplied with the machine for one of the two
options below
a. A disc that contains an electronic copy of the Parts Book.
b. A paper copy of the parts manual.
2.2 KEY NUMBERS
Record the key numbers shown below:
Starter Switch:-
Diesel tank:-
Record the machine and engine numbers shown below:
The machine serial number is found on the registration plate and the engine serial number can be found on the
rocker cover.
Machine Number:-...............................................................
Engine Number:-.................................................................
INTRODUCTION 2

en-8
3.1 HOW TO OPERATE SAFELY
3.1.1 Safe Operation
a Read the Operator’s Manual and other training material. If the operator or technician can not read this
manual, the owner is responsible to describe this material to the operators and technicians. Manuals in
additional languages may be available on the Jacobsen or RansomesJacobsen website.
a Read all of the instructions for this mower carefully. Know the controls and the correct operation of the
equipment.
b Children or persons who do not understand these instructions must not use the mower. The local
regulations can limit the age of the operator.
c Never use a mower near persons, including children or animals.
d Remember that the operator or owner is responsible for accidents or hazards that occur to other persons
or their property.
e Never carry passengers.
f Never allow persons to operate or service the mower or its attachments without correct instructions.
g Do not operate equipment while tired, sick or after you use alcohol or drugs.
3.1.2 Preparation
a When you operate the mower, wear correct clothing, slip resistant work shoes or boots, work gloves, hard
hat, safety glasses and hearing protection. Long hair, loose clothing or jewelry can be caught in moving
parts.
b Do not operate the equipment with the Interlock System disconnected or the system does not operate
correctly. Do not disconnect or prevent the operation of any switch.
c Never operate equipment that is not in correct order or without decals, guards, shields, deflectors or other
protective devices fastened. When you mow with a side discharge deck, DO NOT operate the cutting
unit without the discharge chute installed.
d Inspect the mower before you operate the mower. Check the tire pressure, engine oil level, the radiator
coolant level and the air cleaner indicator. Fuel is flammable. Use caution when you add the fuel to the
mower.
e Operate the mower in daylight or in good artificial light. Use caution when you operate the mower during
bad weather. Never operate the mower with lightning in the area.
f Inspect the area to select the accessories and attachments that are needed to correctly and safely do the
job. Only use parts, accessories and attachments approved by Jacobsen.
g Be careful of holes in the terrain and other hazards that are not visible.
h Inspect the area where the equipment is operated. Remove all objects you can find before you operate.
Be careful of obstructions above the ground (low tree limbs, electrical wires) and also underground
obstacles (sprinklers, pipes, tree roots). Enter a new area carefully. Look for possible hazards.
i Inspect the cutting system before you start the mower. Make sure the blades are free to rotate. When you
rotate one blade, other blades can rotate.
WARNING
EQUIPMENT OPERATED INCORRECTLY OR WITHOUT TRAINING CAN BE DANGEROUS.
Know the location and correct operation of controls. Operators without experience must receive instruction from
another person that knows the correct operation of the equipment before you operate the mower.
Only use parts, accessories and attachments approved by Jacobsen.
!
3 SAFETY

en-9
3.1.3 Operation
a Never operate the engine without enough ventilation or in an enclosed area. The carbon monoxide in the
exhaust fumes can increase to dangerous levels.
b Never carry passengers. Keep other persons or animals away from the mower.
c Disengage all drives and engage the parking brake before you start the engine. Only start the engine with
the operator in the seat. Never start the engine with persons near the mower.
d Keep your legs, arms and body inside the operator compartment while the mower is in operation. Keep
your hands and feet away from the cutting units.
e Do not use on the slopes greater than the safe slope limit for the equipment.
f To guard against over turning or loss of control:
– Operate the mower up and down on the face of slopes (vertically), but not across the face (horizontally).
– Do not start or stop suddenly on slopes.
– Decrease the speed when you operate on slopes or when you must turn. Use caution when you change
direction. Turf condition can change the mower stability.
– Use caution when you operate the mower near drop-offs, ditches or embankments.
– Be careful of holes in the terrain and other hazards that are not visible.
g When you drive in the reverse direction, look behind you and down to make sure the path is clear. Do not
operate the cutting units when you drive in the reverse direction.
h Use caution when you go near corners, trees or other objects that can prevent a clear view.
i Equipment must meet the current regulations to be driven on the public roads.
j Before you move across or operate on the paths or roads, turn off the PTO switch, lift the mowers and
travel at decreased speed. Look for traffic.
k Stop the blades when the mower is on any surface that is not grass.
l Do not release the cut grass in the direction of persons or allow persons near the mower while in
operation.
m Do not operate the mower with damaged guards or without safety devices in position.
n Do not change the engine governor setting or over-speed the engine. Never change or tamper with
adjusters that are closed with a seal for the engine speed control.
o Before you leave the operator compartment, for any reason:
– Disengage all the drives and lower attachments to the ground.
– Engage the parking brake.
– Stop the engine and remove the key.
p When you hit an object or mower starts to cause the vibration that is not normal, inspect the mower for
damage and make repairs.
q Decrease the throttle setting before you stop the engine.
r Do not use this equipment for uses that the mower was not made for.
SAFETY 3

en-10
3.1.4 ROPS
a The ROPS is a safety device. Keep the ROPS in the vertical and locked position. Always use the seat
belt when you operate the mower. Make sure the seat belt can be released quickly in an emergency.
b Only operate the mower with the ROPS in the folded position on flat and level surfaces when necessary.
Do not operate the mower with the ROPS in the folded position on slopes, near sharp edges or near
water. There is no roll over protection with the ROPS in the folded position.
c Check for clearance before you drive below objects. Do not contact tree branches, electrical wires or
other objects with the ROPS.
d Do not use the seat belt with the ROPS in the folded position.
e Inspect the ROPS for damage. Keep the ROPS hardware fastened.
f Do not weld, drill, change or bend the ROPS. Replace a damaged ROPS. Do not try to correct a
damaged ROPS.
g Do not remove the ROPS from the mower.
h Jacobsen must approve any changes to the ROPS.
3.1.5 Safe Handling of Fuels
a The fuel and the fuel vapors are flammable. Use caution when you add the fuel to the mower. The
fuel vapors can cause an explosion.
b Never use the containers that are not approved to keep or transfer fuel.
c Never keep the mower or fuel containers near an open flame or any device that can cause the ignition of
fuel or fuel vapors.
d Never fill the fuel containers inside a vehicle or on a truck or trailer with a plastic liner. Always put the fuel
container on the ground away from your vehicle before you fill the container.
e Refuel the mower before you start the engine. When the engine is in operation or while the engine is hot,
never remove the fuel cap or add fuel to the mower.
f Refuel outdoors only and do not smoke when you add fuel. Extinguish all types of ignition.
g The fuel nozzle must touch the rim of the fuel tank when you add fuel to the mower. Do not use a device
to lock the fuel nozzle in the open position.
h Do not over fill the fuel tank. Leave at least 1 inch (25 mm) below the filler neck.
i Always tighten the fuel tank cap and container cap after you add fuel.
j If the fuel spills on your clothing, change your clothing immediately.
3.1.6 Maintenance and Storage
a Before you clean, adjust or repair this equipment, push PTO switch to the OFF position, lower the cutting
unit to the ground, engage the parking brake, stop the engine and remove the key.
b Make sure the mower is parked on a solid and level surface.
c Never work on a mower that is lifted only by the jack. Always use the jack stands.
d Never allow persons to service the mower or its attachments without correct instructions.
e When the mower is parked, put into storage or left without an operator, lower the cutting device unless a
positive mechanical lock is used.
When you put the mower on a trailer or put the mower in storage, close the fuel valve. Do not keep fuel near
flames or drain the fuel inside a building.
3 SAFETY

en-11
f Disconnect the battery before you service the mower. Always disconnect the negative battery cable
before the positive battery cable. Always connect the positive battery cable before the negative battery
cable.
g Charge the battery in an area with good airflow. The battery can release hydrogen gas that is explosive.
To prevent an explosion, keep any device that can cause sparks or flames away from the battery.
h Disconnect the battery charger from the power supply before you connect or disconnect the battery
charger to the battery. Wear protective clothing and use insulated tools when you service the battery.
i Be careful and wear gloves when you check or service the cutting unit blades. Replace any damaged
blades, do not try to correct a damaged blade.
j Keep your hands and feet away from parts that move. Do not adjust the mower with the engine in
operation, unless the adjustment needs the engine in operation.
k Carefully release the pressure from components with stored energy.
l To prevent injury from the hot, high pressure oil, never use your hands to check for oil leaks. Use the
paper or cardboard to find leaks.
m The hydraulic fluid pressure can have enough force to enter your skin. If hydraulic fluid has entered your
skin, a doctor must remove the hydraulic fluid surgically within a few hours or gangrene can occur.
n When you service the hydraulic system, make sure the hydraulic fittings, tubes and hoses are tightened
to the correct torque. Make sure the hydraulic system is in good condition before you start the engine.
o Keep the mower and the engine clean.
p Allow the engine to become cool before storage and always remove the ignition key.
q Keep all nuts, bolts and screws tight to make sure the equipment is in safe condition.
r Replace worn or damaged parts for safety. Replace damaged or worn decals. Only use parts,
accessories and attachments approved by Jacobsen.
s To decrease the fire hazard, remove materials that burn from the engine, muffler, battery tray and fuel
tank area.
t Disconnect the battery and controller connectors before you weld on this mower.
3.1.7 When you Put the mower on a trailer
a Be careful when you load or unload the mower on a trailer. Trailer must be wider than the mower and can
carry the weight of the mower.
b Use a full-width ramp to load or unload the mower on a trailer.
c Use straps, chains, cables or ropes to fasten the mower to the trailer. Both front and rear straps must be
sent down and toward sides of trailer.
Make sure that all latches are correctly fastened.
SAFETY 3

en-12
3.1.8 Important Safety Notes
This safety alert symbol is used to alert you to possible hazards.
DANGER:
Indicates a dangerous condition that WILL cause death or injury unless it is prevented.
WARNING:
Indicates a dangerous condition that CAN cause death or injury unless it is prevented.
CAUTION:
Indicates a dangerous condition that can cause injury and property damage unless it is prevented. Also, the label
can indicate work procedures that are not safe.
IMPORTANT:
Only drive the machine at road speed when you are on a highway. You must not select road speed on grass areas
or rough roads and gravel tracks.
Some illustrations in this manual can show shields, guards or plates removed for clearness. This equipment
must not be operated without these devices correctly fastened in position.
By following all instructions in this manual, you increase the life of your machine and keep its maximum
performance. Adjustments and maintenance must always be done by an approved technician.
If additional information or service is needed. Contact your Authorized Ransomes Jacobsen Dealer, who knows
the latest methods to service this equipment and can give that service.
WARNING
The Interlock System on this mower prevents the starting of the mower unless a.) The parking brake is Engaged.
b.) The mow switch is in the OFF position, c.) The traction pedal is in the Neutral position. d) The operator is in the
seat. The system stops the engine when the operator leaves the seat a.) without the parking brake engaged or b.)
the mow switch is not in the OFF position. NEVER operate the mower unless the Interlock System is working.
WARNING
1. Before leaving the operator’s position for any reason:
a. Return traction pedal to the Neutral position.
b. Disengage all drives.
c. Lower all implements to the ground.
d. Engage parking brake.
e. Stop the engine and remove the ignition key.
2. Keep your hands, feet, and clothing away from moving parts. Wait for all movement to stop before you
clean, adjust, or service the machine.
3. Keep the area of operation clear of all persons and animals.
4. Never carry any passengers.
5. Never operate the equipment without a correctly fastened grass deflector in position.
3 SAFETY

en-13
WARNING
California Proposition 65
Engine Exhaust, Some Of Its Constituents, And Some Vehicle Components Contain Or Release Chemicals
Known To The State Of California To Cause Cancer And Birth Defects Or Other Reproductive Harm.
WARNING
To Prevent Injury From The Hot Oil At High Pressure, Do Not Use Your Hands To Check For Oil Leaks. Make
Sure That You Use Paper Or Cardboard.
Release Of Hydraulic Fluid At High Pressure Has Enough Force To Enter Through The Skin. If The Fluid Enters
Through The Skin, The Fluid Must Be Surgically Removed Within Hours By A Specialist Doctor Or Gangrene
May Result.
WARNING
When The Machine Is Driven Off-Road, A Seat Belt Must Be Worn Only When A ROPS Frame Is In Position.
This Warning Is Because A Seat Belt Must Be Worn With A ROPS To Follow The Machinery Directive,
2006/42/EC Sections 3.2.2, Seating & 3.4.3, Rollover. (ANSI B71.4-2012 section 20.7)
Ransomes Jacobsen Limited Recommends That The Owner/User Of The Machine Completes A Local Risk
Assessment Of The Machine To Find Any Conditions That Do Not Follow This Rule. E.g. When You Drive The
Machine Next To Water Or On The Highway.
WARNING
Explosive Gases Are Released By Batteries. The Battery Contains Corrosive Acid And Supply An Electrical
Current That Is High Enough To Cause Burn Injuries To The Body.
WARNING
You Must Not Use This Machine To Tow Other Vehicles.
WARNING
Ear Protection Must Be Worn When You Operate Machines With
An Operator Ear Noise Level Of More Than 85 db(A) Leq.
SAFETY 3

en-14
WARNING
Vibration Exposure Limits
Exposure limits are calculated as a combination of the vibration level (magnitude) of the tool and the
Daily Exposure Time (Trigger Time). E.g. A product with 5m/s² vibration can be used up to 2 hours/day to
reach the EAV and up to 8 hours/day to reach the ELV.
Exposure Action Value (EAV) - Daily vibration exposure A(8) = 2.5m/s²
Where daily vibration exposure A(8) is below 2.5m/s² the risk is relatively low and no action need be
taken
Exposure Limit Value (ELV) - Daily Vibration Exposure A(8) = 5.0m/s²
If several tools are use the exposure values must be combined:
Total exposure is then the combined value of the activities
WARNING
Never Mow If There Is A Risk Of Lightning Or You Hear Thunder. If You Are In The Middle Of Mowing,
Stop In A Safe Place, Turn Off The Engine And Go Inside a Building.
CAUTION
When You Do Any Welding On The Machine, The Battery, Controller And Display Must Be Disconnected
Before You Start. You Must Not Open The Controller. If The Controller Is Opened, This Can Cancel All Of The
Warranties And Can Cause The Failure Of The Machine.
CAUTION
Personal Protective Equipment (PPE), For Example Safety Glasses, Leather Work Shoes Or Boots, A Hard
Hat, Leather Work Gloves And Ear Protection Must Be Used After The Owner/User Completes A Local Risk
Assessment Of The Mower, To Prevent Injury.
Training In All Manual Operations Must Be Given By An Approved Person Before The Machine Is Used The
First Time.
3 SAFETY

en-15
4.1 ENGINE SPECIFICATION
Tier 4 Engine: Kubota 18.5KW (24.8HP) @
3000 RPM, 3 cylinder (in line)
Normally Aspirated Diesel
engine, 4 stroke, water cooled,
1123cc (68.53 cu.in) with 12V
1KW electric start, 12V 40Amp
Alternator
Model: D1105-E4B-RNS-1
Maximum Speed: 3150 ± 50 RPM (No load)
Idle Speed: 1650 ± 25 RPM
Oil Sump Capacity: 5.1 litres (1.35 US gals)
Fuel: No. 2-D Diesel fuel (ASTM D975)
Tier 3b Engine: Kubota 24.5KW (32.8HP) @
3000 RPM, 3 cylinder (in line)
Turbo charged Diesel engine, 4
stroke, water cooled, 1123cc
(68.53 cu.in) with 12V 1KW
electric start, 12V 30Amp
Alternator
Model: D1105-T-E3B-RNUK-3
Maximum Speed: 3150 ± 50 RPM (No load)
Idle Speed: 1650 ± 25 RPM
Oil Sump Capacity: 5.1 litres (1.35 US gals)
Fuel: No. 2-D Diesel fuel (ASTM D975)
4.2 MACHINE SPECIFICATION
Frame construction: Heavy duty formed steel chassis
with box section frame rails.
Cutting unit drive:Fixed displacement hydraulic
motors.
Transmission: 3-wheel drive. Direct coupled
variable displacement pump to
direct coupled 200cc/rev front,
400cc/rev rear wheel motor.
Speeds:
Cutting: 0 - 9.5 km/h (0 - 5.9 mph)
FORWARD
Transport: 0 - 14 km/h (0 - 8.5 mph)
FORWARD
Reverse: 0 - 6 km/h (0 -3.7 mph)
Steering: Hydrostatic power steering, with
adjustable tilt steering wheel.
Ground pressure: 1 kg/cm2 (14p.s.i.)
Brakes: Hydrostatic braking with hydraulic
parking brakes on front wheels.
Fuel Tank
Capacity: 45.4 litres (12 US galls)
Hydraulic Tank
Capacity: 25 litres (6.6 US galls)
Battery: Exide 093 (SAE 500)
4.3 DIMENSIONS
A Width of cut 183 cm 72 in
B Transport width 200 cm 79 in
C Overall height without ROPS 134 cm 52.7 in
DOverall height with ROPS,
add 48 cm 19 in
E Overall Length 312 cm 123 in
F Wheel Track 132 cm 52 in
G Wheel Base 151 cm 59.75 in
H Weight of Machine (less fuel) 821 kg 1810 lb
J Weight of Cutting Unit (each) 91kg 201 lb
KWeight of Fuel - 45.4 litres
(12 US gal) 39 kg 86 lb
SPECIFICATION 4

en-16
4.4 VIBRATION LEVEL
The machine was tested for hand/arm vibration levels. The operator was in the normal position to drive the
vehicle, with two hands on the steering mechanism. The engine was in operation and the cutting device was in
rotation, while the machine was not moving.
The Machinery Safety Directive 2006/42/EC
By compliance to:
The Lawnmower Standard BS EN ISO 5395
Referenced to Hand/Arm: BS EN ISO20643:2008
Information Supplied for Physical Agents Directive 2002/44/EC
By reference to:
Hand/Arm Standards: BS EN ISO 5349-1 (2001)
BS EN ISO 5349-2 (2002)
The machine was tested for Whole Body vibration levels. The operator was in the normal position to drive the
vehicle, with two hands on the steering mechanism. The cutting device was in rotation with the machine driven
in a straight line at 6 Km/hr on a level and cut lawn.
The Machinery Safety Directive 2006/42/EC
By compliance to:
Whole Body EN1032:2003
Information Supplied for Physical Agents Directive 2002/44/EC
By reference to:
Whole Body Standards BS EN ISO 2631-1 (1997)
AR3
Hand / Arm
Acceleration
Level
Series EK, FZ, GX, KG with ROPS
Maximum LH or RH Accelerations m/s²
0.80 ± 0.40
AR3
Whole Body
Acceleration
Level
Series EK, FZ, GX, KG with ROPS
Maximum Weighted Acceleration m/s²
0.49 ± 1.57
4 SPECIFICATION

en-17
4.5 NOISE Emissions
When the machine was tested for sound pressure (Operator Ear).
The Machinery Safety Directive 2006/42/EC
And
Exposure Of Workers To The Risks Arising From Physical Agents (Noise) Directive 2003/10/EC
By compliance to:
The Lawnmower Standard BS EN ISO 5395:2013
And
Sound Pressure Standard EN ISO 3746: 2010
Measured Sound Pressure 89 dB(A) ± 0.86 LWA
When the machine was tested for sound power (Noise in the Environment).
The Machinery Safety Directive 2006/42/EC
And
Noise Emission In The Environment By Equipment For Use Outdoors
Directive 2000/14/EC
By compliance to:
Sound Power Standard EN ISO 3744:2010
104 dB(A) ± 0.86 LWA (4163101 Rear Discharge Blade)
105 dB(A) ± 0.86 LWA (4129639 Mulching Blade)
4.6 SLOPES
DO NOT USE ON SLOPES GREATER THAN 17°
The slope 17° was calculated using static stability measurements according to the requirements of
BS EN ISO 5395.
SPECIFICATION 4

en-18
4.7 CUTTING UNIT SPECIFICATION
General: Three 686mm (27in) rotary mulching/rear discharge decks.
Drive: Fixed displacement hydraulic motors directly coupled to cutting unit.
Control: Cutting unit lift lever with automatic shut off and safety interlock restart.
Construction:
Heavy duty, welded pressed steel.
Cutting Blades:
Rear Discharge
Low Lift Blade
Height of cut:
Adjustable in 6 mm (0.25 in) increments
19 mm(0.75 in) to 90mm (3.5 in)
Rear roller:
Series EK 76mm (3in) diameter smooth roller.
Series FZ 90mm (3.5in) diameter smooth roller
4.8 CUTTING PERFORMANCE (AREA)
1.0 hectares/hr. at 9.5 km/hr. ( 2.6 acres/hr at 5.9 mph)
10% allowance is included for normal overlaps and turning at the end of each cut.
4 SPECIFICATION

en-19
SPECIFICATION 4
4.9 RECOMMENDED LUBRICANTS
Engine oil: Should be to MIL-L-2104C or to
A.P.I. Classification CD grades.
[10W-30]
Grease:
For rear axle: K NATE (RJL No. 4213860), or
equivalent to MIL-G-23549C,
MIL-G-2345C, DIN 51 825, DIN
51 818.
General: Lithium based general purpose
grease.
TEMPERATURE VISCOSITY
ABOVE 25°C (77°F) SAE30 or SAE10W-30
SAE10W-40
0°C to 25°C (32°F to 77°F) SAE20 or SAE10W-30
SAE10W-40
BELOW 0°C (32°F) SAE10W or SAE10W-30
SAE10W-40
TYRE PRESSURE
Product Front Wheel Rear Wheel
Tyre Size Tyre Type Tyre Pressure Tyre Size Tyre Type Tyre Pressure
AR3 20 x 12.00 - 10 Grassmaster 6pr 1.00 - 1.37 bar
(14 - 20 psi) 20.00 x 10.00 - 8 Grassmaster 4pr 1.00 - 1.51 bar
(14 - 22 psi)
