Jacobsen Eclipse 2 User manual

When Performance Matters.
™
GB
United
Kingdom
SK
Slovakia
Eclipse®2
InCommand™
63334 – Eclipse 2 118, 18” 11 Blade Reel, Gen-Set
63343 – Eclipse 2 118, 18” 11 Blade Reel, Battery Pack
63335 – Eclipse 2 118, 18” 15 Blade Reel, Gen-Set
63344 – Eclipse 2 118, 18” 15 Blade Reel, Battery Pack
63336 – Eclipse 2 118F, Floating 18” 11 Blade Reel, Gen-Set
63345 – Eclipse 2 118F, Floating 18” 11 Blade Reel, Battery Pack
63337 – Eclipse 2 118F, Floating 18” 15 Blade Reel, Gen-Set
63346 – Eclipse 2 118F, Floating 18” 15 Blade Reel, Battery Pack
63338 – Eclipse 2 122, 22” 11 Blade Reel, Gen-Set
63347 – Eclipse 2 122, 22” 11 Blade Reel, Battery Pack
63339 – Eclipse 2 122, 22” 15 Blade Reel, Gen-Set
63348 – Eclipse 2 122, 22” 15 Blade Reel, Battery Pack
63340 – Eclipse 2 122F, Floating 22” 11 Blade Reel, Gen-Set
63349 – Eclipse 2 122F, Floating 22” 11 Blade Reel, Battery Pack
63341 – Eclipse 2 122F, Floating 22” 15 Blade Reel, Gen-Set
63350 – Eclipse 2 122F, Floating 22” 15 Blade Reel, Battery Pack
63342 – Eclipse 2 126, 26” 7 Blade Reel, Gen-Set
63351 – Eclipse 2 126, 26” 7 Blade Reel, Battery Pack
WARNING
WARNING: If incorrectly used this machine can cause severe
injury. Those who use and maintain this machine should be
trained in its proper use, warned of its dangers and should
read the entire manual before attempting to set up, operate,
adjust or service the machine.
VÝSTRAHA
VÝSTRAHA: Nesprávnym používaním stroja, môže príst’ k
vážnemu zraneniu. Osoby, ktoré používajú stroj alebo
vykonávajú jeho údržbu, musia byt’ pred nastavovaním,
prevádzkovaním alebo údržbou stroja vyškolené v správnom
používaní stroja, upozornené na jeho nebezpečenstvá a
musia si prečítat’ celú príručku.
4260472-SK-rev.B
Technical Manual
Technická príručka
63334 – Eclipse 2 118, 457 mm 11-lopatková sekacia hlava, benzínový agregát
63343 – Eclipse 2 118, 457 mm 11-lopatková sekacia hlava, batériový modul
63335 – Eclipse 2 118, 457 mm 15-lopatková sekacia hlava, benzínový agregát
63344 – Eclipse 2 118, 457 mm 15-lopatková sekacia hlava, batériový modul
63336 – Eclipse 2 118F, plávajúca 457 mm 11-lopatková sekacia hlava, benzínový agregát
63345 – Eclipse 2 118F, plávajúca 457 mm 11-lopatková sekacia hlava, batériový modul
63337 – Eclipse 2 118F, plávajúca 457 mm 15-lopatková sekacia hlava, benzínový agregát
63346 – Eclipse 2 118F, plávajúca 457 mm 15-lopatková sekacia hlava, batériový modul
63338 – Eclipse 2 122, 559 mm 11-lopatková sekacia hlava, benzínový agregát
63347 – Eclipse 2 122, 559 mm 11-lopatková sekacia hlava, batériový modul
63339 – Eclipse 2 122, 559 mm 15-lopatková sekacia hlava, benzínový agregát
63348 – Eclipse 2 122, 559 mm 15-lopatková sekacia hlava, batériový modul
63340 – Eclipse 2 122F, plávajúca 559 mm 11-lopatková sekacia hlava, benzínový agregát
63349 – Eclipse 2 122F, plávajúca 559 mm 11-lopatková sekacia hlava, batériový modul
63341 – Eclipse 2 122F, plávajúca 559 mm 15-lopatková sekacia hlava, benzínový agregát
63350 – Eclipse 2 122F, plávajúca 559 mm 15-lopatková sekacia hlava, batériový modul
63342 – Eclipse 2 126, 660 mm 7-lopatková sekacia hlava, benzínový agregát
63351 – Eclipse 2 126, 660 mm 7-lopatková sekacia hlava, batériový modul

© 2012, Jacobsen, A Textron Company/Textron Innovations Inc.
“All rights reserved, including the right to reproduce this material
or portions thereof in any form.”
This manual contains safety, operating, adjustment,
maintenance, troubleshooting instructions and parts list
for your new Jacobsen machine. This manual should be
stored with the equipment for reference during operation.
Before you operate your machine, you and each operator
you employ should read the manual carefully in its
entirety. By following the safety, operating and
maintenance instructions, you will prolong the life of your
equipment and maintain its maximum efficiency.
If additional information is needed, contact your
Jacobsen Dealer.
The serial plate is located on the rear crossbar of the
frame. Jacobsen recommends you record these numbers
below for easy reference.
11524WILMAR BLVD,
CHARLOTTE,NC 28273
®
kg kW
1-800-848-1636 (US)
PRODUCT OF U.S.A. A Textron Company
en-2
Proposition 65 Warning
This product contains or emits
chemicals known to State of California
to cause cancer and birth defects or
other reproductive harm.
FOREWORD
Suggested Stocking Guide
To Keep your Equipment fully operational and productive, Jacobsen suggests you maintain a stock of the more
commonly used maintenance items. We have included part numbers for additional support materials and training aids.
To order any of the following material:
1. Write your full name and complete address on your
order form.
2. Explain where and how to make shipment:
❑UPS ❑Regular Mail
❑Overnight ❑2nd Day
3. Order by the quantity desired, the part number, and
the description of the part.
4. Send or bring the order to your authorized Jacobsen
Dealer.
These are the original instructions verified by
Jacobsen, A Textron Company.
LITHO IN U.S.A. 11-2012
Service Parts
Service Support Material
Qty. Part No. Description Qty. Part No. Description
4102780 50 Amp Fuse 2811106 Motor to Pulley Belt
4262910 30 Amp Fuse 2811070 Pulley to Traction Drum Belt
4131618 Ignition Key
Qty. Part No. Description
4260472 Technical Manual
4260475 Operator Training Video 4262930 Floating Head Service Manual
4262932 Fixed Head Service Manual
Qty. Part No. Description

en-3
Table of Contents
1SAFETY
1.1 Operating Safety . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Important Safety Notes . . . . . . . . . . . . . . . . . 5
2 SPECIFICATIONS
2.1 Product Identification . . . . . . . . . . . . . . . . . . 6
2.2 Mower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.3 Traction and Differential . . . . . . . . . . . . . . . . 7
2.4 Weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.5 Gen-Set Power Module . . . . . . . . . . . . . . . . 7
2.6 Battery Power Module . . . . . . . . . . . . . . . . . 8
2.7 Accessories & Support Literature . . . . . . . . . 9
2.8 Declaration of Conformity . . . . . . . . . . . . . . 10
3DECALS
3.1 Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4 CONTROLS
4.1 Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.2 Handle Controls . . . . . . . . . . . . . . . . . . . . . 16
4.3 LCD Display . . . . . . . . . . . . . . . . . . . . . . . . 17
4.4 Frequency of Cut . . . . . . . . . . . . . . . . . . . . 22
4.5 Gas Power Module Controls . . . . . . . . . . . . 27
4.6 Battery Power Module Controls . . . . . . . . . 27
5 OPERATION
5.1 Daily Inspection . . . . . . . . . . . . . . . . . . . . . 28
5.2 Interlock System (O.P.C.) . . . . . . . . . . . . . . 28
5.3 Operating Procedures . . . . . . . . . . . . . . . . . 29
5.4 Starting/Stopping . . . . . . . . . . . . . . . . . . . . 30
5.5 Mowing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
5.6 Transport Wheels (Optional) . . . . . . . . . . . . 32
5.7 Kickstand . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5.8 Grass Catcher . . . . . . . . . . . . . . . . . . . . . . . 33
5.9 Daily Maintenance . . . . . . . . . . . . . . . . . . . 33
6 ADJUSTMENTS (ALL UNITS)
6.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
6.2 Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
6.3 Speed Paddle Stops . . . . . . . . . . . . . . . . . . 34
6.4 Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
6.5 Traction Belts . . . . . . . . . . . . . . . . . . . . . . . 35
6.6 Front Roller Weight . . . . . . . . . . . . . . . . . . . 36
6.7 Torque Specification . . . . . . . . . . . . . . . . . . 37
7 FIXED HEAD REEL ADJUSTMENTS
7.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
7.2 Reel To Bedknife . . . . . . . . . . . . . . . . . . . . 38
7.3 Bedknife Adjustment . . . . . . . . . . . . . . . . . . 39
7.4 Cutting Height . . . . . . . . . . . . . . . . . . . . . . . 39
8 CLASSIC FLOATING HEAD REEL ADJUSTMENTS
8.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
8.2 Bedknife-To-Reel . . . . . . . . . . . . . . . . . . . . 40
8.3 Bedknife Adjustment . . . . . . . . . . . . . . . . . . 41
8.4 Reel Bearing . . . . . . . . . . . . . . . . . . . . . . . .41
8.5 Cutting Height . . . . . . . . . . . . . . . . . . . . . . .42
8.6 Reel Assembly Removal . . . . . . . . . . . . . . .42
9 TRUESET FLOATING HEAD REEL ADJUSTMENTS
9.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
9.2 Bedknife-To-Reel . . . . . . . . . . . . . . . . . . . . .43
9.3 Bedknife Adjustment . . . . . . . . . . . . . . . . . .44
9.4 Cutting Height . . . . . . . . . . . . . . . . . . . . . . .44
9.5 Reel Bearing . . . . . . . . . . . . . . . . . . . . . . . .45
9.6 Bedknife Adjuster Spring . . . . . . . . . . . . . . .45
9.7 Bedknife Adjuster Tension . . . . . . . . . . . . . .45
9.8 Grinding Bedknife . . . . . . . . . . . . . . . . . . . .45
9.9 Reel Assembly Removal . . . . . . . . . . . . . . .46
10 BATTERY POWER MODULE
10.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
10.2 General . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
10.3 Maintenance . . . . . . . . . . . . . . . . . . . . . . . .48
10.4 Cleaning Batteries . . . . . . . . . . . . . . . . . . . .48
10.5 Battery Charger . . . . . . . . . . . . . . . . . . . . . .49
10.6 Battery Installation . . . . . . . . . . . . . . . . . . . .50
10.7 Replacing Battery Pack . . . . . . . . . . . . . . . .51
11 GEN-SET POWER MODULE
11.1 Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
11.2 Engine Oil . . . . . . . . . . . . . . . . . . . . . . . . . .52
11.3 Engine Oil Change . . . . . . . . . . . . . . . . . . . .53
11.4 Engine Speed . . . . . . . . . . . . . . . . . . . . . . .53
11.5 Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
12 MAINTENANCE
12.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
12.2 Tires (Option) . . . . . . . . . . . . . . . . . . . . . . . .55
12.3 Wheel Bearing . . . . . . . . . . . . . . . . . . . . . . .55
12.4 Backlapping and Grinding . . . . . . . . . . . . . .56
12.5 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
13 TROUBLESHOOTING
13.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
14 MAINTENANCE & LUBRICATION CHARTS
14.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
14.2 Maintenance Chart . . . . . . . . . . . . . . . . . . .59
14.3 Lubrication Chart . . . . . . . . . . . . . . . . . . . . 60
15 PARTS CATALOG
15.1 How To Use The Parts Catalog . . . . . . . . . .61
15.2 To Order Parts . . . . . . . . . . . . . . . . . . . . . . .61
15.3 Parts Catalog Table of Contents . . . . . . . . .61

1 SAFETY
en-4
1 SAFETY
1.1 OPERATING SAFETY ______________________________________________________
1. Safety is dependent upon the awareness, concern
and prudence of those who operate or service the
equipment. Never allow minors to operate any
equipment.
2. It is your responsibility to read this manual and all
publications associated with this equipment (Engine
Manual, Battery Charger Manual, accessories, and
attachments). If the operator cannot read English it
is the owner’s responsibility to explain the material
contained in this manual to them.
3. Learn the proper use of the machine, the location
and purpose of all the controls before you operate
the equipment. Working with unfamiliar equipment
can lead to accidents.
4. Never allow anyone to operate or service the
machine or its attachments without proper training
and instructions; or while under the influence of
alcohol or drugs.
5. Wear all the necessary protective clothing and
personal safety devices to protect your head, eyes,
ears, hands, and feet. Long hair, loose clothing, or
jewelry may get tangled in moving parts. Operate
the machine only in daylight or in good artificial light.
6. Evaluate the terrain to determine what accessories
and attachments are needed to properly and safely
perform the job. Only use accessories and
attachments approved by Jacobsen.
7. Stay alert for holes in the terrain and other hidden
hazards.
8. Inspect the area where the equipment will be used.
Pick up all the debris you can find before operating.
Beware of overhead obstructions (low tree limbs,
electrical wires, etc.) and also underground
obstacles (sprinklers, pipes, tree roots, etc.) Enter a
new area cautiously. Stay alert for hidden hazards.
9. Do not carry passengers. Keep bystanders and pets
a safe distance away.
10. Never direct discharge of material toward
bystanders, nor allow anyone near the machine
while in operation. The owner/operator can prevent
and is responsible for injuries inflicted to
themselves, to bystanders, and damage to property.
11. Never operate equipment that is not in perfect
working order or is without decals, guards, shields,
discharge deflectors, or other protective devices
securely fastened in place.
12. Never disconnect or bypass any switch.
13. Keep the unit clean. Disconnect the power
connector before storing. Do not store unit near an
open flame or flammable debris.
14. Place unit on a flat surface, disengage all drives,
and engage parking brake before energizing the
unit.
15. Local regulations may restrict the age of the
operator.
16. Operate the machine across the face of the slope
(horizontally), not up and down the slope (vertically).
Never operate on wet grass.
17. Always operate at speeds that allow you to have
complete control of the machine. Be sure of your
footing, keep a firm hold on the handle, and walk,
never run.
Gen-Set Power Module
18. Carbon monoxide in the exhaust fumes can be fatal
when inhaled. Never operate the engine without
proper ventilation.
19. Fuel is highly flammable, handle with care. See
Section 5.9 .
20. Before you clean, adjust or repair this equipment,
stop the engine, disconnect the spark plug wire, and
keep the wire away from the plug to prevent
accidental starting. Disconnect the power connector.
21. Keep the engine clean. Allow the engine to cool,
always close fuel shut off valve, and remove the
spark plug wire from the spark plug before storing.
Do not store unit near an open flame or flammable
debris.
Battery Power Module
22. Before you clean, adjust, or repair this equipment,
disconnect the power connector.
23. Do not remove battery pack without unit on
kickstand.
This machine is to be operated and maintained as specified in this manual and is intended for the professional
maintenance of specialized turf grasses. It is not intended for use on rough terrain or long grasses.
WARNING
EQUIPMENT OPERATED IMPROPERLY OR BY UNTRAINED PERSONNEL CAN BE DANGEROUS.
Familiarize yourself with the location and proper use of all controls. Inexperienced operator’s should receive
instruction from someone familiar with the equipment before being allowed to operate the machine.
!

SAFETY 1
en-5
1.2 IMPORTANT SAFETY NOTES________________________________________________
This safety alert symbol is used to alert you to potential hazards.
DANGER - Indicates an imminently hazardous situation which, if not avoided, WILL result in death or serious injury.
WARNING - Indicates a potentially hazardous situation which, if not avoided, COULD result in death or serious
injury.
CAUTION - Indicates a potentially hazardous situation which, if not avoided, MAY result in minor or moderate injury
and property damage. It may also be used to alert against unsafe practices.
NOTICE - Indicates a potentially hazardous situation which, if not avoided, MAY result in property damage. It may
also be used to alert against unsafe practices.
For pictorial clarity, some illustrations in this manual may show shields, guards or plates open or removed. Under no
circumstances should this equipment be operated without these devices securely fastened in place.
By following all instructions in this manual, you will prolong the life of your machine and maintain its maximum
efficiency. Adjustments and maintenance should always be performed by a qualified technician.
If additional information or service is needed, contact your Authorized Jacobsen Dealer who is kept informed of the
latest methods to service this equipment and can provide prompt and efficient service.
WARNING
The Interlock System on this machine will shut off the reel and traction drive
if the operator releases the O.P.C. (Operator Presence Control) bail.
To protect the operator and others from injury, never operate equipment with
the Interlock System disconnected or malfunctioning.
!
WARNING
1. Before leaving the operator’s position for any reason:
a. Disengage all drives.
b. Engage parking brake.
c. Disconnect power connector.
2. Keep hands, feet, and clothing away from moving parts. Wait for all
movement to stop before you clean, adjust, or service the machine.
3. Keep the area of operation clear of all bystanders and pets.
4. Chock or block the wheels if the machine is left on an incline.
5. Never operate mowing equipment without the discharge deflector
securely fastened in place.
!

2 SPECIFICATIONS
en-6
2 SPECIFICATIONS
2.1 PRODUCT IDENTIFICATION_________________________________________________
63334............................ Eclipse®2 118 base unit with 18 in.
(457 mm) 11 blade reel and
InCommand™ control system.
Gen-Set power module.
63343............................ Eclipse®2 118 base unit with 18 in.
(457 mm) 11 blade reel and
InCommand™ control system.
Battery power module.
63335............................ Eclipse®2 118 base unit with 18 in.
(457 mm) 15 blade reel and
InCommand™ control system.
Gen-Set power module.
63344............................ Eclipse®2 118 base unit with 18 in.
(457 mm) 15 blade reel and
InCommand™ control system.
Battery power module.
63336............................ Eclipse®2 118F base unit with
floating 18 in. (457 mm) 11 blade
reel and InCommand™ control
system. Gen-Set power module.
63345............................ Eclipse®2 118F base unit with
floating 18 in. (457 mm) 11 blade
reel and InCommand™ control
system. Battery power module.
63337............................ Eclipse®2 118F base unit with
floating 18 in. (457 mm) 15 blade
reel and InCommand™ control
system. Gen-Set power module.
63346............................ Eclipse®2 118F base unit with
floating 18 in. (457 mm) 15 blade
reel and InCommand™ control
system. Battery power module.
63338............................ Eclipse®2 122 base unit with 22 in.
(559 mm) 11 blade reel and
InCommand™ control system.
Gen-Set power module.
63347............................ Eclipse®2 122 base unit with 22 in.
(559 mm) 11 blade reel and
InCommand™ control system.
Battery power module.
63339............................ Eclipse®2 122 base unit with 22 in.
(559 mm) 15 blade reel and
InCommand™ control system.
Gen-Set power module.
63348............................ Eclipse®2 122 base unit with 22 in.
(559 mm) 15 blade reel and
InCommand™ control system.
Battery power module.
63340............................ Eclipse®2 122F base unit with
floating 22 in. (457 mm) 11 blade
reel and InCommand™ control
system. Gen-Set power module.
63349.............................Eclipse®2 122F base unit with
floating 22 in. (457 mm) 11 blade
reel and InCommand™ control
system. Battery power module.
63341.............................Eclipse®2 122F base unit with
floating 22 in. (457 mm) 15 blade
reel and InCommand™ control
system. Gen-Set power module.
63350.............................Eclipse®2 122F base unit with
floating 22 in. (457 mm) 15 blade
reel and InCommand™ control
system. Battery power module.
63342.............................Eclipse®2 126 base unit with 26 in.
(660 mm) 7 blade reel and
InCommand™ control system.
Gen-Set power module.
63351.............................Eclipse®2 126 base unit with 26 in.
(660 mm) 7 blade reel and
InCommand™ control system.
Battery power module.
Serial Number ...............An identification plate, like the one
shown, listing the serial number, is
attached to the rear crossbar.
Product Vibration M/S2
Arms
63334
63335
63336
63337
63338
63339
63340
63341
63342
63343
63344
63345
63346
63347
63348
63349
63350
63351
4.25 ± 1.3
4.25 ± 1.3
4.83 ± 1.3
4.83 ± 1.3
2.37 ± 1.3
2.37 ± 1.3
4.44 ± 1.3
4.44 ± 1.3
2.84 ± 1.3
1.44 ± 1.3
1.44 ± 1.3
0.90 ± 1.3
0.90 ± 1.3
1.00 ± 1.3
1.00 ± 1.3
1.07 ± 1.3
1.07 ± 1.3
0.89 ± 1.3
11524WILMAR BLVD,
CHARLOTTE,NC 28273
®
kg kW
1-800-848-1636 (US)
PRODUCT OF U.S.A. A Textron Company
92.3 2.6 XXXX
63334001651

SPECIFICATIONS 2
en-7
2.2 MOWER__________________________________________________________________
Reel..................................7, 9, 11, or 15 blades, hardened
high manganese carbon steel.
Reel Diameter..................5 in. (127 mm)
Cutting Width ...................18, 22 or 26 in. (457, 559 or
660 mm)
Height of cut.....................1/16 to 7/16 in. (1.6 to 11 mm)
Bedknives ........................Hardened carbon steel
High Profile ................5/32” - 7/16” (4 - 11 mm) cut
Low Profile.................1/8” - 7/32” (3.2 - 5.6 mm) cut
Tournament................3/32” - 5/32” (2.4 - 4 mm) cut
Super Tournament.....5/64” - 7/64” (2.1 - 2.8 mm) cut
Championship............1/16” - 7/64” (1.6 - 2.8 mm) cut
Frequency of Cut
15 Blade Reel............0.064 - 0.133 in. (1.6 - 3.4 mm)
11 Blade Reel ............0.087 - 0.178 in. (2.2 - 4.5 mm)
9 Blade Reel..............0.106 - 0.217 in. (2.7 - 5.5 mm)
2.3 TRACTION AND DIFFERENTIAL______________________________________________
Transport Tires (Option)...11 x 4 pneumatic bidirectional.
Reel Drive........................Independent direct drive motor.
Traction Drive...................Independent drive motor with two
synchronous polyurethane belts.
Traction Reduction Ratio..15.15:1
Mowing speed..................0 - 3.4 m.p.h. (5.31 km/h)
Differential........................Full automotive type, housed in
traction drum
Rear Drive Drum..............Machined aluminum alloy
2 Section, 7-3/4 (O.D.) x 10-31/32
2.4 WEIGHTS ________________________________________________________________
Gen Set Mowers
Weights: Without Grass Catcher Lbs. (kg)
63334 – Eclipse 2 118 11 Blade s................. 214 (97.1)
63335 – Eclipse 2 118 15 Blade s................. 217 (98.4)
63336 – Eclipse 2 118F 11 Blade s............... 254 (115.2)
63337 – Eclipse 2 118F 15 Blade s............... 257 (116.6)
63338 – Eclipse 2 122 11 Blade l.................. 221 (100.2)
63339 – Eclipse 2 122 15 Blade l................. 224 (101.6)
63340 – Eclipse 2 122F 11 Blade l............... 265 (120.2)
63341 – Eclipse 2 122F 15 Blade l............... 268 (121.6)
63342 – Eclipse 2 126 n................................ 243 (110.2)
Battery Pack Mowers
Weights: Without Grass Catcher Lbs. (kg)
63343 – Eclipse 2 118 11 Blade s................. 234 (106.1)
63344 – Eclipse 2 118 15 Blade s................. 237 (107.5)
63345 – Eclipse 2 118F 11 Blade s............... 274 (124.3)
63346 – Eclipse 2 118F 15 Blade s............... 277 (125.6)
63347 – Eclipse 2 122 11 Blade l................. 241 (109.3)
63348 – Eclipse 2 122 15 Blade l................. 244 (110.7)
63349 – Eclipse 2 122F 11 Blade l............... 285 (129.3)
63350 – Eclipse 2 122F 15 Blade l............... 288 (130.6)
63351 – Eclipse 2 126 l................................ 263 (119.3)
s With Steel Grooved Roller 68618
l With Machined Aluminum Grooved Roller 68614
n With Machined Aluminum Grooved Roller 68617
2.5 GEN-SET POWER MODULE _________________________________________________
Engine..............................Honda GX-120 K1Q JG2 4-Cycle,
4HP (2.98 kW) at 4000 RPM
Speed...............................Engine speed set at factory for
generator to produce 59.8 volts
with no load. (2750 to 3250 rpm)
Fuel..................................Regular Grade (Unleaded)
Fuel Tank .........................0.66 Gallon (2.5 liter)
Use clean, fresh, regular unleaded gasoline, 85 octane
minimum. Refer to the engine’s operator manual for fuel
recommendations when using blended fuel.

2 SPECIFICATIONS
en-8
2.6 BATTERY POWER MODULE ________________________________________________
To ensure the longest battery life possible, the batteries
are not shipped with the power module and must be
ordered separately. For optimum range and performance
use batteries that equal or exceed the Amp-hour rating
listed.
System Voltage............. 48 Volt DC
Batteries ...................... (4) 12 volt, valve regulated,
non-spillable sealed lead acid
batteries.
Charger......................... 5 Amp, 48 Volt DC, dual input
voltage 115/230 Volt AC, 50/60
Hz.
Recommended Battery:
CSB battery is the Jacobsen recommended battery for
use in the Eclipse mower.
CSB batteries can be ordered from these CSB
distributors, or from any local battery dealer.
Electronic Distributing
920 Brookstown Ave
Winston Salem, NC 27101
Phone Number - 800-777-1096
Fax Number - 336-723-1098
E-Mail - [e-mail] (E-Mail)
Contact Name - Bill Turner
URS Electronics
123 N.E. 7th
Portland, OR 97232
Phone Number - 800-955-4877
Fax Number - 503-232-3373
E-Mail - [e-mail]
Contact Name - Mark Twietmeyer
Alternate Batteries:
These alternate batteries are also currently available.
These batteries have the same dimensions and amp-
hour ratings, but have not been tested by Jacobsen, and
no recommendation is stated or should be implied.
Contact your local battery dealer or the manufacturer for
sourcing on these batteries.
(USE ONLY 12 VOLT SLA BATTERIES)
Battery Brand Battery Part Number
CSB EVX12200
Length
in. (mm) Width in. (mm) Height in. (mm) Weight lbs. (kg) Rating Amp-Hr Volts Qty Req’d
7-1/8
(181) 3 (76) 6-9/16 (167) 14.7 (6.7) 20 12 4
Battery Brand Battery
Part Number
Yuasa Enersys NPX 80
Panasonic LC-X1220AP
Panasonic LC-X1220P
Discover D12200
Power Sonic PSH-12180
B.B. Battery EB20-12

SPECIFICATIONS 2
en-9
2.7 ACCESSORIES & SUPPORT LITERATURE_____________________________________
Contact your area Jacobsen Dealer for a complete listing of accessories and attachments.
Accessories
Lapping Compound (180 grit)................................... 554598
Orange Touch-up Paint (12 oz. spray)...................... 554598
18 in. Fixed Head Grass Catcher................................ 68122
18 in. Floating Head Grass Catcher........................ 4174683
22 in. Fixed Head Grass Catcher................................ 68123
22 in. Floating Head Grass Catcher.........................4114788
26 in. Fixed Head Grass Catcher................................ 68124
22 in. Push Brush (Fixed Head Units)..........................68611
22 in. Front Roller Brush (Fixed Head Units).............. 68610
22 in. Front Roller Brush (Floating Head Units).......... 68536
LED Light Kit............................................................... 63307
Battery Charger........................................................... 68661
Removable Battery Pack (u) ....................................... 63316
Mower Caddy Battery Pack Mounting Kit ................... 68660
Transport Tires............................................................ 62293
Mower Caddy..........................................................63321
Eclipse 2 Mower Caddy Mounting Kit .....................63354
22 in. Turf Groomer®(H).........................................67966
Fixed Head Turf Groomer®Adapter Kit...................67965
MAGKnife Kits
122F Super Tournament MAGKnife Kit................... 4188500
122F Tournament MAGKnife Kit............................. 4158083
122 Super Tournament MAGKnife Kit..................... 4158082
uDoes not included batteries
HFixed Head Units require 67965 to install Turf Groomer
Solid Rollers
18 in. with Scraper.......................................................68626
22 in. with Scraper.......................................................68530
26 in. with Scraper.......................................................68627
Grooved Rollers
18 in. Machined Steel ..................................................68616
22 in. Assembled Disc.................................................68527
22 in. Machined Aluminum ..........................................68614
22 in. Machined Steel ..................................................68613
22 in. Segmented Roller..............................................68673
26 in. Machined Aluminum ..........................................68617
26 in. Machined Steel ..................................................68628
Floating Head Reels
22 in. 11 Blade Reel.....................................................63308
22 in. 15 Blade Reel ....................................................63333
18 in. 11 Blade Reel.....................................................63309
18 in. 15 Blade Reel ....................................................62824
Right Hand Reel Conversion Kit..............................4172485
Left Hand Reel Conversion Kit ................................4172441
Additional Power Modules
Gen-Set Power Module ...............................................63305
Battery Power Module (u)............................................63306
Support Literature
Technical Manual.....................................................4260472
Operator Training DVD Video..................................4260475
Fixed Head Repair Manual......................................4262932
Floating Head Repair Manual..................................4262930
CAUTION
Use of other than Jacobsen authorized parts and accessories may cause personal injury or damage to the
equipment.
!

2 SPECIFICATIONS
en-10
DECLARATION OF CONFORMITY ƒȾȿɄɅȺɊȺɐɂə ɁȺ ɋɔɈɌȼȿɌɋɌȼɂȿ ƒPROHLÁŠENÍ O SHODċƒ
OVERENSSTEMMELSESERKLÆRING ƒCONFORMITEITSVERKLARING ƒVASTAVUSDEKLARATSIOON ƒ
VAATIMUSTENMUKAISUUSVAKUUTUS ƒDECLARATION DE CONFORMITE ƒKONFORMITÄTSERKLÄRUNG ƒ
ǻǾȁȍȈǾ ȈȊȂȂȅȇĭȍȈǾȈ ƒMEGFELELėSÉGI NYILATKOZAT ƒDICHIARAZIONE DI CONFORMITÀ ƒATBILSTƮBAS
DEKLARƖCIJA ƒATITIKTIES DEKLARACIJA ƒDIKJARAZZJONI TAL-KONFORMITÀ ƒDEKLARACJA ZGODNOĝCI ƒ
DECLARAÇÃO DE CONFORMIDADE ƒDECLARAğIE DE CONFORMITATE ƒVYHLÁSENIE O ZHODE ƒIZJAVA O
SKLADNOSTI ƒDECLARACIÓN DE CONFORMIDAD ƒDEKLARATION OM ÖVERENSSTÄMMELSE
Business name and full address of the manufacturer ƒɌɴɪɝɨɜɫɤɨ ɢɦɟ ɢɩɴɥɟɧ ɚɞɪɟɫ ɧɚ ɩɪɨɢɡɜɨɞɢɬɟɥɹ ƒObchodní jméno a plná adresa výrobce ƒ
Producentens firmanavn og fulde adresse ƒBedrijfsnaam en volledig adres van de fabrikant ƒTootja ärinimi ja täielik aadress ƒ
Valmistajan toiminimi ja täydellinen osoite ƒNom commercial et adresse complète du fabricant ƒFirmenname und vollständige Adresse des Herstellers ƒ
ǼʌȦȞȣȝȓĮ țĮȚ IJĮȤȣįȡȠȝȚțȒ įȚİȪșȣȞıȘ țĮIJĮıțİȣĮıIJȒ ƒA gyártó üzleti neve és teljes címe ƒRagione sociale e indirizzo completo del fabbricante ƒ
UzƼƝmuma nosaukums un pilna ražotƗja adrese ƒVerslo pavadinimas ir pilnas gamintojo adresas ƒIsem kummerƛjali u indirizz sƫiƫtal-fabbrikant ƒ
Nazwa firmy i peány adres producenta ƒNome da empresa e endereço completo do fabricante ƒDenumirea comercialăúi adresa completăa
producătorului ƒObchodný názov a úplná adresa výrobcu ƒNaziv podjetja in polni naslov proizvajalca ƒNombre de la empresa y dirección completa del
fabricante ƒTillverkarens företagsnamn och kompletta adress
Jacobsen, A Textron Company
11524 Wilmar Blvd.
Charlotte, NC 28273, USA
Product Code ƒɄɨɞ ɧɚ ɩɪɨɞɭɤɬɚ ƒKód výrobku ƒProduktkode ƒProductcode ƒToote kood ƒTuotekoodi ƒCode produit ƒProduktcode ƒȀȦįȚțȩȢ ʌȡȠȧȩȞIJȠȢ
ƒTermékkód ƒCodice prodotto ƒProdukta kods ƒProdukto kodas ƒKodiƛi tal-Prodott ƒKod produktu ƒCódigo do Produto ƒCod produs ƒKód výrobku ƒ
Oznaka proizvoda ƒCódigo de producto ƒProduktkod
63334
63335
63336
63337
63338
63339
63340
63341
63342
63343
63344
63345
63346
63347
63348
63349
63350
63351
Machine Name ƒɇɚɢɦɟɧɨɜɚɧɢɟ ɧɚ ɦɚɲɢɧɚɬɚ ƒNázev stroje ƒMaskinnavn ƒMachinenaam ƒMasina nimi ƒLaitteen nimi ƒNom de la machine ƒ
Maschinenbezeichnung ƒȅȞȠȝĮıȓĮ ȝȘȤĮȞȒȝĮIJȠȢ ƒGépnév ƒDenominazione della macchina ƒIekƗrtas nosaukums ƒMašinos pavadinimas ƒIsem tal-
Magna ƒNazwa urządzenia ƒNome da Máquina ƒNumele echipamentului ƒNázov stroja ƒNaziv stroja ƒNombre de la máquina ƒMaskinens namn
Eclipse
®2 118 Hybrid 11 Blade
Eclipse®2 118 Hybrid 15 Blade
Eclipse®2 118F Hybrid 11 Blade
Eclipse®2 118F Hybrid 15 Blade
Eclipse®2 122 Hybrid 11 Blade
Eclipse®2 122 Hybrid 15 Blade
Eclipse®2 122F Hybrid 11 Blade
Eclipse®2 122F Hybrid 15 Blade
Eclipse®2 126 Hybrid 7 Blade
Eclipse®2 118 Battery 11 Blade
Eclipse®2 118 Battery 15 Blade
Eclipse®2 118F Battery 11 Blade
Eclipse®2 118F Battery 15 Blade
Eclipse®2 122 Battery 11 Blade
Eclipse®2 122 Battery 15 Blade
Eclipse®2 122F Battery 11 Blade
Eclipse®2 122F Battery 15 Blade
Eclipse®2 126 Battery 7 Blade
Designation ƒɉɪɟɞɧɚɡɧɚɱɟɧɢɟ ƒOznaþení ƒBetegnelse ƒBenaming ƒNimetus ƒTyyppimerkintä ƒPažymơjimas ƒBezeichnung ƒȋĮȡĮțIJȘȡȚıȝȩȢ ƒ
Megnevezés ƒFunzione ƒApzƯmƝjums ƒLithuanian ƒDenominazzjoni ƒOznaczenie ƒDesignação ƒSpecificaĠie ƒOznaþenie ƒNamen stroja ƒDescripción
ƒBeteckning
Lawnmower, Article 12, Item 32
Serial Number ƒɋɟɪɢɟɧ ɧɨɦɟɪ ƒSériové þíslo ƒSerienummer ƒSerienummer ƒSeerianumber ƒValmistusnumero ƒNuméro de série ƒSeriennummer ƒ
ȈİȚȡȚĮțȩȢ ĮȡȚșȝȩȢ ƒSorozatszám ƒNumero di serie ƒSƝrijas numurs ƒSerijos numeris ƒNumru Serjali ƒNumer seryjny ƒNúmero de Série ƒNumăr de
serie ƒSériové þíslo ƒSerijska številka ƒNúmero de serie ƒSerienummer
6333401651-6333404500
6333501651-6330104500
6333601651-6330204500
6333701651-6330304500
6333801651-6330404500
6333901651-6331104500
6334001651-6331204500
6334101651-6334304500
6334201651-6331404500
6334301651-6331504500
6334401651-6332504500
6334501651-6332604500
6334601651-6333504500
6334701651-6332804500
6334801651-6332904500
6334901651-6333004500
6335001651-6333104500
6335101651-6333204500
Engine ƒȾɜɢɝɚɬɟɥ ƒMotor ƒMotor ƒMotor ƒMootor ƒMoottori ƒMoteur ƒMotor ƒȂȘȤĮȞȒ ƒModulnév ƒMotore ƒDzinƝjs ƒVariklis ƒSaƫƫa Netta Installata ƒ
Silnik ƒMotor ƒMotor ƒMotor ƒMotor ƒMotor ƒMotor
Hybrid Models
Honda GX-120 Gas
Battery Models
Aspen Motor 48V Brushless DC
Net Installed Power ƒɇɟɬɧɚ ɢɧɫɬɚɥɢɪɚɧɚ ɦɨɳɧɨɫɬ ƒýistý instalovaný výkon ƒInstalleret nettoeffekt ƒNetto geïnstalleerd vermogen ƒInstalleeritud
netovõimsus ƒAsennettu nettoteho ƒPuissance nominale nette ƒInstallierte Nettoleistung ƒȀĮșĮȡȒ İȖțĮIJİıIJȘȝȑȞȘ ȚıȤȪȢ ƒNettó beépített teljesítmény ƒ
Potenza netta installata ƒParedzƝtƗtƯkla jauda ƒGrynoji galia ƒWisa’ tal-QtugƫƒMoc zainstalowana netto ƒPotência instalada ƒPuterea instalatănetăƒ
ýistý inštalovaný výkon ƒNeto vgrajena moþƒPotencia instalada neta ƒNettoeffekt
Hybrid Models
2,98 kW @ 3000 RPM
Battery Models
1,3 kW @ 2200 RPM
2.8 DECLARATION OF CONFORMITY____________________________________________

SPECIFICATIONS 2
en-11
Cutting Width ƒɒɢɪɨɱɢɧɚ ɧɚ ɪɹɡɚɧɟ ƒŠíĜka Ĝezu ƒSkærebredde ƒMaaibreedte ƒLõikelaius ƒLeikkuuleveys ƒLargeur de coupe ƒSchnittbreite ƒ
ȂȒțȠȢ ȝȚıȚȞȑȗĮȢ ƒVágási szélesség ƒLarghezza di taglio ƒGriešanas platums ƒPjovimo plotis ƒTikkonforma mad-Direttivi ƒSzerokoĞü ciĊcia ƒ
Largura de Corte ƒLăĠimea de tăiere ƒŠírka záberu ƒŠirina reza ƒAnchura de corte ƒKlippbredd
118, 118F - 45,7 cm
122, 122F - 55,9 cm
126 - 66,1 cm
Conforms to Directives ƒȼɫɴɨɬɜɟɬɫɬɜɢɟ ɫɞɢɪɟɤɬɢɜɢɬɟ ƒSplĖuje podmínky smČrnic ƒEr i overensstemmelse med direktiver ƒVoldoet aan de richtlijnen ƒ
Vastab direktiividele ƒDirektiivien mukainen ƒConforme aux directives ƒEntspricht Richtlinien ƒǹțȠȜȠȣșȒıIJİ ʌȚıIJȐIJȚȢ ȅįȘȖȓİȢ ƒMegfelel az irányelveknek
ƒConforme alle Direttive ƒAtbilst direktƯvƗm ƒAtitinka direktyvǐreikalavimus ƒValutazzjoni tal-Konformità ƒDyrektywy związane ƒCumpre as Directivas ƒ
RespectăDirectivele ƒJe v súlade so smernicami ƒSkladnost z direktivami ƒCumple con las Directivas ƒUppfyller direktiv
2004/108/EC
2006/42/EC
2000/14/EC, 2005/88/EC
2006/66/EC
Conformity Assessment ƒɈɰɟɧɤɚ ɡɚ ɫɴɨɬɜɟɬɫɬɜɢɟ ƒHodnocení plnČní podmínek ƒOverensstemmelsesvurdering ƒConformiteitsbeoordeling ƒ
Vastavushindamine ƒVaatimustenmukaisuuden arviointi ƒEvaluation de conformité ƒKonformitätsbeurteilung ƒǻȚĮʌȓıIJȦıȘ ȈȣȝȝȩȡijȦıȘȢ ƒ
MegfelelĘség-értékelés ƒValutazione della conformità ƒAtbilstƯbas novƝrtƝjums ƒAtitikties Ƴvertinimas ƒLivell tal-Qawwa tal-ƪoss Imkejjel ƒOcena
zgodnoĞci ƒAvaliação de Conformidade ƒEvaluarea conformităĠii ƒVyhodnotenie zhodnosti ƒOcena skladnosti ƒEvaluación de conformidad ƒ
Bedömning av överensstämmelse
2006/42/EC Annex VIII
Measured Sound Power Level ƒɂɡɦɟɪɟɧɨ ɧɢɜɨ ɧɚ ɡɜɭɤɨɜɚ ɦɨɳɧɨɫɬ ƒNamČĜený akustický výkon ƒMålte lydstyrkeniveau ƒGemeten geluidsniveau ƒ
Mõõdetud helivõimsuse tase ƒMitattu äänitehotaso ƒNiveau de puissance sonore mesuré ƒGemessener Schalldruckpegel ƒ
ȈIJĮșȝȚıȝȑȞȠ İʌȓʌİįȠ ȘȤȘIJȚțȒȢ ȚıȤȪȠȢ ƒMért hangteljesítményszint ƒLivello di potenza sonora misurato ƒIzmƝrƯtais skaƼas jaudas lƯmenis ƒ
Išmatuotas garso stiprumo lygis ƒLivell tal-Qawwa tal-ƪoss Iggarantit ƒMoc akustyczna mierzona ƒNível sonoro medido ƒNivelul măsurat al puterii
acustice ƒNameraná hladina akustického výkonu ƒIzmerjena raven zvoþne moþi ƒNivel de potencia sonora medido ƒUppmätt ljudeffektsnivå
Hybrid Models - 96 dB(A) LWA
Battery Models - 86 dB(A) LWA
Guaranteed Sound Power Level ƒȽɚɪɚɧɬɢɪɚɧɨ ɧɢɜɨ ɧɚ ɡɜɭɤɨɜɚ ɦɨɳɧɨɫɬ ƒGarantovaný akustický výkon ƒGaranteret lydstyrkeniveau ƒ
Gegarandeerd geluidsniveau ƒGaranteeritud helivõimsuse tase ƒTaattu äänitehotaso ƒNiveau de puissance sonore garanti ƒGarantierter
Schalldruckpegel ƒǼȖȖȣȘȝȑȞȠ İʌȓʌİįȠ ȘȤȘIJȚțȒȢ ȚıȤȪȠȢ ƒSzavatolt hangteljesítményszint ƒLivello di potenza sonora garantito ƒGarantƝtais skaƼas
jaudas lƯmenis ƒGarantuotas garso stiprumo lygis ƒLivell tal-Qawwa tal-ƪoss Iggarantit ƒMoc akustyczna gwarantowana ƒNível sonoro farantido ƒ
Nivelul garantat al puterii acustice ƒGarantovaná hladina akustického výkonu ƒZajamþena raven zvoþne moþi ƒNivel de potencia sonora garantizado ƒ
Garanterad ljudeffektsnivå
Hybrid Models - 95 dB(A) LWA
Battery Models - 85 dB(A) LWA
Conformity Assessment Procedure (Noise) ƒɈɰɟɧɤɚ ɡɚ ɫɴɨɬɜɟɬɫɬɜɢɟ ɧɚ ɩɪɨɰɟɞɭɪɚɬɚ (ɒɭɦ) ƒPostup hodnocení plnČní podmínek (hluk) ƒ
Procedure for overensstemmelsesvurdering (Støj) ƒProcedure van de conformiteitsbeoordeling (geluid) ƒVastavushindamismenetlus (müra) ƒ
Vaatimustenmukaisuuden arviointimenettely (Melu) ƒProcédure d’évaluation de conformité (bruit) ƒKonformitätsbeurteilungsverfahren (Geräusch) ƒ
ǻȚĮįȚțĮıȓĮ ǹȟȚȠȜȩȖȘıȘȢ ȈȣȝȝȩȡijȦıȘȢ (ĬȩȡȣȕȠȢ) ƒMegfelelĘség-értékelési eljárás (Zaj) ƒProcedura di valutazione della conformità (rumore) ƒ
AtbilstƯbas novƝrtƝjuma procednjra (troksnis) ƒAtitikties Ƴvertinimo procednjra (garsas) ƒProƛedura tal-Valutazzjoni tal-Konformità (ƪoss) ƒ
Procedura oceny zgodnoĞci (poziom haáasu) ƒProcesso de avaliação de conformidade (nível sonoro) Procedura de evaluare a conformităĠii (zgomot) ƒ
Postup vyhodnocovania zhodnosti (hluk) ƒPostopek za ugotavljanje skladnosti (hrup) ƒProcedimiento de evaluación de conformidad (ruido) ƒ
Procedur för bedömning av överensstämmelse (buller)
2000/14/EC Annex VI, Part 1
UK Notified Body for 2000/14/EC ƒɇɨɬɢɮɢɰɢɪɚɧ ɨɪɝɚɧ ɜɈɛɟɞɢɧɟɧɨɬɨ ɤɪɚɥɫɬɜɨ ɡɚ 2000/14/ȿɈ ƒÚĜad certifikovaný podle smČrnice þ. 2000/14/EC ƒ
Det britiske bemyndigede organ for 2001/14/EF ƒEngels adviesorgaan voor 2000/14/EG ƒÜhendkuningriigi teavitatud asutus direktiivi 2000/14/EÜ
mõistes ƒDirektiivin 2000/14/EY mukainen ilmoitettu tarkastuslaitos Isossa-Britanniassa ƒOrganisme notifié concernant la directive 2000/14/CE ƒ
Britische benannte Stelle für 2000/14/EG ƒȀȠȚȞȠʌȠȚȘȝȑȞȠȢ ȅȡȖĮȞȚıȝȩȢ ǾȞȦȝȑȞȠȣ ǺĮıȚȜİȓȠȣ ȖȚĮ 2000/14/ǼȀ ƒ
2000/14/EK – egyesült királyságbeli bejelentett szervezet ƒOrganismo Notificato in GB per 2000/14/CE ƒ2000/14/EK AK reƧistrƝtƗorganizƗcija ƒ
JK notifikuotosios Ƴstaigos 2000/14/EC ƒKorp Notifikat tar-Renju Unit gƫal 2000/14/KE ƒDopuszczona jednostka badawcza w Wielkiej Brytanii wg 2000/
14/WE ƒEntidade notificada no Reino Unido para 2000/14/CE ƒOrganism notificat în Marea Britanie pentru 2000/14/CE ƒ
Notifikovaný orgán Spojeného kráĐovstva pre smernicu 2000/14/ES ƒBritanski priglašeni organ za 2000/14/ES ƒ
Cuerpo notificado en el Reino Unido para 2000/14/CE ƒAnmält organ för 2000/14/EG i Storbritannien
Number: 1088
Sound Research Laboratories Limited
Holbrook House, Little Waldingfield
Sudbury, Suffolk CO10 0TH
Operator Ear Noise Level ƒɈɩɟɪɚɬɨɪ ɧɚ ɧɢɜɨɬɨ ɧɚ ɞɨɥɨɜɢɦ ɨɬ ɭɯɨɬɨ ɲɭɦ ƒHladina hluku v oblasti uší operátora ƒStøjniveau i førers ørehøjde ƒ
Geluidsniveau oor bestuurder ƒMüratase operaatori kõrvas ƒMelutaso käyttäjän korvan kohdalla ƒNiveau de bruit à hauteur des oreilles de l’opérateur ƒ
Schallpegel am Bedienerohr ƒǼʌȓʌİįȠ șȠȡȪȕȠȣ ıİ ȜİȚIJȠȣȡȖȓĮ ƒA kezelĘfülénél mért zajszint ƒLivello di potenza sonora all’orecchio dell’operatore ƒ
TrokšƼa lƯmenis pie operatora auss ƒDirbanþiojo su mašina patiriamo triukšmo lygis ƒLivell tal-ƪoss fil-Widna tal-Operatur ƒ
Dopuszczalny poziom haáasu dla operatora ƒNível sonoro nos ouvidos do operador ƒNivelul zgomotului la urechea operatorului ƒ
Hladina hluku pôsobiaca na sluch operátora ƒRaven hrupa pri ušesu upravljavca ƒNivel sonoro en el oído del operador ƒLjudnivå vid förarens öra
Hybrid Models
82 dB(a) Leq (2006/42/EC)
Battert Models
70 dB(a) Leq (2006/42/EC)
Harmonised standards used ƒɂɡɩɨɥɡɜɚɧɢ ɯɚɪɦɨɧɢɡɢɪɚɧɢ ɫɬɚɧɞɚɪɬɢ ƒPoužité harmonizované normy ƒBrugte harmoniserede standarder ƒ
Gebruikte geharmoniseerde standaards ƒKasutatud ühtlustatud standardid ƒKäytetyt yhdenmukaistetut standardit ƒNormes harmonisées utilisées ƒ
Angewandte harmonisierte Normen ƒǼȞĮȡȝȠȞȚıȝȑȞĮ ʌȡȩIJȣʌĮ ʌȠȣ ȤȡȘıȚȝȠʌȠȚȒșȘțĮȞ ƒHarmonizált szabványok ƒStandard armonizzati applicati ƒ
Izmantotie saskaƼotie standarti ƒPanaudoti suderinti standartai ƒStandards armonizzati uĪati ƒNormy spójne powiązane ƒNormas harmonizadas usadas
ƒStandardele armonizate utilizate ƒPoužité harmonizované normy ƒUporabljeni usklajeni standardi ƒEstándares armonizados utilizados ƒ
Harmoniserade standarder som används
BS EN ISO 20643
BS EN ISO 5349-1
BS EN ISO 5349-2
BS EN 836
Technical standards and specifications used ƒɂɡɩɨɥɡɜɚɧɢ ɬɟɯɧɢɱɟɫɤɢ ɫɬɚɧɞɚɪɬɢ ɢɫɩɟɰɢɮɢɤɚɰɢɢ ƒPoužité technické normy a specifikace ƒ
Brugte tekniske standarder og specifikationer ƒGebruikte technische standaards en specificaties ƒKasutatud tehnilised standardid ja spetsifikatsioonid ƒ
Käytetyt tekniset standardit ja eritelmät ƒSpécifications et normes techniques utilisées ƒAngewandte technische Normen und Spezifikationen ƒ
ȉİȤȞȚțȐ ʌȡȩIJȣʌĮ țĮȚ ʌȡȠįȚĮȖȡĮijȑȢ ʌȠȣ ȤȡȘıȚȝȠʌȠȚȒșȘțĮȞ ƒMĦszaki szabványok és specifikációk ƒStandard tecnici e specifiche applicati ƒ
Izmantotie tehniskie standarti un specifikƗcijas ƒPanaudoti techniniai standartai ir techninơinformacija ƒStandards u speƛifikazzjonijiet tekniƛi uĪati ƒ
Normy i specyfikacje techniczne powiązane ƒNormas técnicas e especificações usadas ƒStandardele tehnice úi specificaĠiile utilizate ƒ
Použité technické normy a špecifikácie ƒUporabljeni tehniþni standardi in specifikacije ƒEstándares y especificaciones técnicas utilizadas ƒ
Tekniska standarder och specifikationer som används
B71.4
ISO 2631-1
The place and date of the declaration ƒɆɹɫɬɨ ɢɞɚɬɚ ɧɚ ɞɟɤɥɚɪɚɰɢɹɬɚ ƒMísto a datum prohlášení ƒSted og dato for erklæringen ƒ
Plaats en datum van de verklaring ƒDeklaratsiooni väljastamise koht ja kuupäev ƒVakuutuksen paikka ja päivämäärä ƒLieu et date de la déclaration ƒ
Ort und Datum der Erklärung ƒȉȩʌȠȢ țĮȚ ȘȝİȡȠȝȘȞȓĮ įȒȜȦıȘȢ ƒA nyilatkozat kelte (hely és idĘ) ƒLuogo e data della dichiarazione ƒ
DeklarƗcijas vieta un datums ƒDeklaracijos vieta ir data ƒIl-post u d-data tad-dikjarazzjoni ƒMiejsce i data wystawienia deklaracji ƒLocal e data da
declaração ƒLocul úi data declaraĠiei ƒMiesto a dátum vyhlásenia ƒKraj in datum izjave ƒLugar y fecha de la declaración ƒPlats och datum för
deklarationen
Jacobsen, A Textron Company
11524 Wilmar Blvd.
Charlotte, NC 28273, USA
November 1st, 2012

2 SPECIFICATIONS
en-12
Signature of the person empowered to draw up the declaration on behalf of the manufacturer, holds the technical documentation and is authorised to
compile the technical file, and who is established in the Community.
ɉɨɞɩɢɫ ɧɚ ɱɨɜɟɤɚ, ɭɩɴɥɧɨɦɨɳɟɧ ɞɚ ɫɴɫɬɚɜɢ ɞɟɤɥɚɪɚɰɢɹɬɚ ɨɬ ɢɦɟɬɨ ɧɚ ɩɪɨɢɡɜɨɞɢɬɟɥɹ, ɤɨɣɬɨ ɩɨɞɞɴɪɠɚɳ ɬɟɯɧɢɱɟɫɤɚɬɚ ɞɨɤɭɦɟɧɬɚɰɢɹ ɢɟ
ɨɬɨɪɢɡɢɪɚɧ ɞɚ ɢɡɝɨɬɜɢ ɬɟɯɧɢɱɟɫɤɢɹ ɮɚɣɥ ɢɟɪɟɝɢɫɬɪɢɪɚɧ ɜɨɛɳɧɨɫɬɬɚ.
Podpis osoby oprávnČné sestavit prohlášení jménem výrobce, držet technickou dokumentaci a osoby oprávnČné sestavit technické soubory a založené v
rámci Evropského spoleþenství.
Underskrift af personen, der har fuldmagt til at udarbejde erklæringen på vegne af producenten, der er indehaver af dokumentationen og er bemyndiget til
at udarbejde den tekniske journal, og som er baseret i nærområdet.
Handtekening van de persoon die bevoegd is de verklaring namens de fabrikant te tekenen, de technische documentatie bewaart en bevoegd is om het
technische bestand samen te stellen, en die is gevestigd in het Woongebied.
Ühenduse registrisse kantud isiku allkiri, kes on volitatud tootja nimel deklaratsiooni koostama, kes omab tehnilist dokumentatsiooni ja kellel on õigus
koostada tehniline toimik.
Sen henkilön allekirjoitus, jolla on valmistajan valtuutus vakuutuksen laadintaan, jolla on hallussaan tekniset asiakirjat, joka on valtuutettu laatimaan
tekniset asiakirjat ja joka on sijoittautunut yhteisöön.
Signature de la personne habilitée à rédiger la déclaration au nom du fabricant, à détenir la documentation technique, à compiler les fichiers techniques et
qui est implantée dans la Communauté.
Unterschrift der Person, die berechtigt ist, die Erklärung im Namen des Herstellers abzugeben, die die technischen Unterlagen aufbewahrt und berechtigt
ist, die technischen Unterlagen zusammenzustellen, und die in der Gemeinschaft niedergelassen ist.
ȊʌȠȖȡĮijȒ ĮIJȩȝȠȣ İȟȠȣıȚȠįȠIJȘȝȑȞȠȣ ȖȚĮ IJȘȞ ıȪȞIJĮȟȘ IJȘȢ įȒȜȦıȘȢ İț ȝȑȡȠȣȢ IJȠȣ țĮIJĮıțİȣĮıIJȒ, ȠȠʌȠȓȠȢ țĮIJȑȤİȚ IJȘȞ IJİȤȞȚțȒ ȑțșİıȘ țĮȚ ȑȤİȚ IJȘȞ
İȟȠȣıȚȠįȩIJȘıȘ ȞĮ IJĮȟȚȞȠȝȒıİȚ IJȠȞ IJİȤȞȚțȩ ijȐțİȜȠ țĮȚ ȠȠʌȠȓȠȢ İȓȞĮȚ įȚȠȡȚıȝȑȞȠȢ ıIJȘȞ ȀȠȚȞȩIJȘIJĮ.
A gyártó nevében meghatalmazott személy, akinek jogában áll módosítania a nyilatkozatot, a mĦszaki dokumentációt Ęrzi, engedéllyel rendelkezik a
mĦszaki fájl összeállításához, és aki a közösségben letelepedett személy.
Firma della persona autorizzata a redigere la dichiarazione a nome del fabbricante, in possesso Della documentazione tecnica ed autorizzata a costituire
il fascicolo tecnico, che deve essere stabilita nella Comunità.
TƗs personas paraksts, kura ir pilnvarota deklarƗcijas sastƗdƯšanai ražotƗja vƗrdƗ, kurai ir tehniskƗdokumentƗcija, kura ir pilnvarota sagatavot tehnisko
reƧistru un kura ir apstiprinƗta KopienƗ.
Asmuo, kuris yra gana žinomas, kuriam gamintojas suteikơƳgaliojimus sudaryti šiądeklaraciją, ir kuris jąpasirašơ, turi visątechninĊinformacijąir yra
Ƴgaliotas sudaryti techninơs informacijos dokumentą.
Il-firma tal-persuna awtorizzata li tfassal id-dikjarazzjoni f’isem il-fabbrikant, gƫandha d-dokumentazzjoni teknika u hija awtorizzata li tikkompila l-fajl
tekniku u li hija stabbilita fil-Komunità.
Podpis osoby upowaĪnionej do sporządzenia deklaracji w imieniu producenta, przechowującej dokumentacjĊtechniczną, upowaĪnionądo stworzenia
dokumentacji technicznej oraz wyznaczonej ds. wspólnotowych.
Assinatura da pessoa com poderes para emitir a declaração em nome do fabricante, que possui a documentação técnica, que está autorizada a compilar
o processo técnico e que está estabelecida na Comunidade.
Semnătura persoanei împuternicite săelaboreze declaraĠia în numele producătorului, care deĠine documentaĠia tehnică, este autorizatăsăcompileze
dosarul tehnic úi este stabilităîn Comunitate.
Podpis osoby poverenej vystavením vyhlásenia v mene výrobcu, ktorá má technickú dokumentáciu a je oprávnená spracovaĢtechnické podklady a ktorá
je umiestnená v Spoloþenstve.
Podpis osebe, pooblašþene za izdelavo izjave v imenu proizvajalca, ki ima tehniþno dokumentacijo in lahko sestavlja spis tehniþne dokumentacije, ter ima
sedež v Skupnosti.
Firma de la persona responsable de la declaración en nombre del fabricante, que posee la documentación técnica y está autorizada para recopilar el
archivo técnico y que está establecido en la Comunidad.
Undertecknas av den som bemyndigad att upprätta deklarationen å tillverkarens vägnar, innehar den tekniska dokumentationen och är bemyndigad att
sammanställa den tekniska informationen och som är etablerad i gemenskapen.
2006/42/EC Annex II 1.A.2
Tim Lansdell
Technical Director
Ransomes Jacobsen Limited
West Road, Ransomes Europark,
Ipswich, IP3 9TT, England
2006/42/EC Annex II 1.A.10
Vasant Godhalekar
VP of Engineering
Jacobsen, A Textron Company
11524 Wilmar Blvd,
Charlotte, NC 28273, USA
Certificate Number ƒɇɨɦɟɪ ɧɚ ɫɟɪɬɢɮɢɤɚɬ ƒýíslo osvČdþení ƒCertifikatnummer ƒCertificaatnummer ƒSertifikaadi number ƒHyväksyntänumero ƒ
Numéro de certificat ƒBescheinigungsnummer ƒǹȡȚșȝȩȢ ȆȚıIJȠʌȠȚȘIJȚțȠȪ ƒHitelesítési szám ƒNumero del certificato ƒSertifikƗta numurs ƒ
Sertifikato numeris ƒNumru taƛ-ƚertifikat ƒNumer certyfikatu ƒNúmero do Certificado ƒNumăr certificat ƒýíslo osvedþenia ƒŠtevilka certifikata ƒ
Número de certificado ƒCertifikatsnummer
4260472 Rev B

DECALS 3
en-13
3 DECALS
3.1 DECALS _________________________________________________________________
Familiarize yourself with the following decals. They are critical to the safe operation of the
mower. REPLACE DAMAGED DECALS IMMEDIATELY.
4170001
STOP
4127335
4169840 REV A
DANGER
To prevent injury, disengage all
drives, engage parking brake, turn
off key switch and disconnect
power connector before working on
machine or emptying grass
catchers.
DANGER
Keep hands and feet
away from the cutting
unit to prevent serious
injury.
DANGER
1. Keep a safe distance from the machine. Keep
bystanders away.
2. Properly dispose of components from this
machine. Refer to local regulations for waste
disposal and recycling.
3. Refer to the manual for maintenance and
service procedures.
4. Do not spray water at electrical connectors,
motors or controllers. Do not use high pressure
when to clean mower.
4170321
Read the manual before
adjusting engine throttle
lever.

3 DECALS
en-14
Familiarize yourself with the following decals. They are critical to the safe operation of the
mower. REPLACE DAMAGED DECALS IMMEDIATELY.
4265170
4265171
4172240
Read the manual before adjusting
front roller weight.
Disengaged Parking Engaged
Brake
Reel Switch
OFF
On
4265172
Key Switch
Off Position
Run Position
Energize Unit

DECALS 3
en-15
To Engage Traction.
1. Slide bail to the left.
2. Squeeze bail to handle.

4 CONTROLS
en-16
4 CONTROLS
4.1 ICONS___________________________________________________________________
4.2 HANDLE CONTROLS ______________________________________________________
A. Parking Brake – Used whenever the mower is left
unattended or as a service brake while transporting.
Always use transport tires when transporting up or
down hills.
B. Speed Paddle – Sets maximum traction drive
speed when O.P.C. Bail is engaged. Push (+) side
of lever to increase speed. Push (-) side of lever to
decrease speed.
C. O.P.C. Bail – Slide bail slightly to the left and
squeeze bail to start traction motor. Traction motor
speed is increased as the bail moves towards the
handle. Release bail to stop unit.
D. Key Switch - The power switch turns the power on
and off. It has three positions OFF, RUN, and
START. Key switch must be in RUN position to start
units equipped with Gen-Set power module.
E. Reel Switch - The reel switch is used to start and
stop the reel.
F. LCD Controls - Used to navigate through menus.
G. LCD Display - Used to display operating conditions.
Figure 4A
WARNING
Never attempt to operate the machine unless you have read the Safety and Operation
Manual, the Parts and Maintenance Manual and know how to operate all controls correctly.
Familiarize yourself with the icons shown above and what they represent. Learn the
location and purpose of all the controls before operating this mower.
Engaged Disengaged
Parking Brake
O.P.C. Traction
Drive
Squeeze bail to handle
Power On
Fast Slow
Throttle
Power Up
Slide Bail Left
Power Off
!
WARNING
To prevent injury, always use transport tires when
transporting unit up or down hills.
!
DANGER
Keep hands and feet away from the cutting unit to
prevent serious injury.
A
B
C
D
E
F
G
!

CONTROLS 4
en-17
4.3 LCD DISPLAY_____________________________________________________________
The LCD displays current functional values for the
operation of the Eclipse 2 mower and sounds one of
three types of audible alerts. The LCD operates in one of
two modes, Operator Mode (Default), and Maintenance
Mode. Use of Maintenance mode requires a four digit pin
number.
Press either of the orange buttons (K or L) to change
screen display or change values. Push the right orange
button (K) to go forward in the display list or increase
setting value, and push the left orange button (L) to go
back in the display list or decrease setting value. The
black button (J) is used to select, reset, or change
values.
Figure 4B
Audible Alerts indicate one of three conditions detected
by the LCD Display and a corresponding message would
show on the display. A solid tone indicates low system
voltage. A fast beeping (2 per second) alert indicates an
over voltage condition. A slow beeping (1 every 3
seconds) alert indicates mower is in backlap mode.
Alert Displays: In addition to the standard displays for each mode, there are six displays that are used to alert the
operator/mechanic of a problem the needs to be corrected.
G
J
K
L
Alert Display Alert Description
Low Voltage display is shown when system voltage drops below 42 Volts DC on Battery
powered mowers or 38 Volts DC on Gen-Set powered mowers, for 30 seconds and a solid tone
alarm will sound. Press the black button (J) to silence the alarm. Return mower to storage area
or install a fully charged battery pack. Reel motor will not operate with low voltage on the display.
Overvoltage/Check Voltage display is shown when system voltage is above 60 Volts DC and a
fast (2 per second) beeping alarm will sound. If not corrected, controller will shut down after 60
seconds. Check generator output before restarting system. [See Section 11.4].
Traction Motor Controller Fault display is shown when a problem is detected in the traction
motor controller. Traction motor will not operate until the problem is resolved. Return mower to
maintenance area for repair.
Traction Motor Fault display is shown when a traction motor short circuit is detected or the
traction motor current draw exceeds 30 Amps for one second. Traction motor will not operate
until the problem is resolved. Return mower to maintenance area for repair.
Reel Motor Controller Fault display is shown when a problem is detected in the reel motor
controller. Reel motor will not operate until the problem is resolved. Return mower to
maintenance area for repair.
Reel Motor Fault display is shown when a reel motor short circuit is detected or the reel motor
current draw exceeds 30 Amps for one second. Reel motor will not operate until the problem is
resolved. Return mower to maintenance area for repair.
WARNING
Turn reel switch off, release bail, turn key to off position, and disconnect battery connector before checking for
obstructions in reel.
!

4 CONTROLS
en-18
Operator Mode is used by the operator for system voltage information, travel speed, FOC setting, reel speed, and total
hours on mower. Press the orange buttons (K and L) on the front handle cover to toggle between the different displays.
Operator Mode is view only, only screen illumination mode can be changed.
Display Description
Start-Up Screen - Displays for up to five seconds when system is started.
System Voltage - Displays system voltage between 42 and 59 volts. Screen will be replaced
with alert screen when system voltage drops below 42 volts or rises above 60 volts.
FOC Setting - Displays FOC (Frequency of Clip) setting. When FOC is set to 0, reel will operate
at the fixed reel speed.
Fixed Reel Speed - Displays fixed reel speed setting with FOC set to 0. Fixed reel speed setting
is not used for any FOC other than 0.
Hour Meter - Displays total hours unit has been operated.
Daytime Illumination - When selected, LCD displays dark pixels on a light background. Press
the black button (J) to toggle between daytime and nighttime illumination.
Nighttime Illumination - When selected, LCD displays light pixels on a dark background. Press
the black button (J) to toggle between daytime and nighttime illumination.
Maintenance Mode PIN - Used to enter Maintenance Mode. Maintenance Mode pin is required.
See Maintenance Mode.

CONTROLS 4
en-19
Maintenance Mode is used to set and adjust all functional values for the Eclipse 2 Mower. LCD displays available in
Maintenance Mode are, maintenance hours, backlap, system voltage, travel speed, set FOC, reel speed, traction
motor current draw, reel motor current draw, total motor current draw, set mow speed, set reel speed, set power
source, set number of reel blades, calibrate speed paddle, calibrate bail lever, set display units, and factory reset.
Figure 4C
See Operator Mode for descriptions of Daytime/
Nighttime Illumination, System Voltage, and Fixed Reel
Speed screens.

4 CONTROLS
en-20
Display Description
To enter Maintenance Mode, press either orange buttons (K or L) until Maintenance Mode PIN
screen is on the display and press black button (J). Use the orange buttons (K or L) to select and
the black button (J) to enter the digits for the Mechanic Mode pin.
NOTE: The default PIN for Maintenance Mode is 6789. The Maintenance Mode PIN can be
customized to a setting of your choice. Please contact your Jacobsen Dealer or Jacobsen
Technical Support (1800-848-1636 Option 2) for complete instructions.
Maintenance Hours - System can track up to 999.9 hours for maintenance purposes.
To reset maintenance hours, press either of the orange buttons (K or L) on the front cover until
the maintenance hours screen is on the LCD display. Press the black button (J) to move to the
confirm reset screen. Press the right orange button (K) to confirm reset, or press left orange
button (L) to cancel reset.
Backlap Select - Used to switch mower to backlap mode. See Section 12.4 for backlap screen
descriptions.
Set FOC - To set the fixed FOC, press either of the orange buttons (K or L) on the front cover
until the FOC set screen is on the LCD display. Press the black button (J) to enter set mode. Use
the orange buttons to raise (K) or lower (L) the FOC value to the desired setting. press the black
button to set speed.
Fixed FOC setting must be 0 or between 0.087 and 0.178 in. (2.2 and 4.5 mm). [See Section
4.4].
Traction Motor Current - Displays current draw of traction drum motor. Fault will be displayed if
current draw is greater than 30 Amps for one second.
Reel Motor Current - Displays current draw of reel motor. Fault will be displayed if current draw
is greater than 30 Amps for one second.
Total Motor Current - Displays total current draw of traction drum motor and reel motor.
Maximum Mow Speed - To set the maximum mow speed, press either of the orange buttons (K
or L) on the front cover until the set max mow speed screen is on the LCD display. Press the
black button (J) to enter set mode. Use the orange buttons to raise (K) or lower (L) the maximum
mow speed to the desired speed. press the black button to set speed.
Maximum mow speed must be between 2.0 and 3.8 MPH (3.2 and 6.1 kph).
Fixed Reel Speed: To set the fixed reel speed, the FOC setting must be set to 0, then press
either of the orange buttons (K or L) on the front cover until the set reel speed screen is on the
LCD display. Press the black button (J) to enter set mode. Use the orange buttons to raise (K) or
lower (L) the reel speed to the desired setting.
Fixed reel speed must be set between 1800 and 2200 rpm.
The Maximum Mow Speed and the Fixed Reel Speed are used to determine the FOC
(Frequency of Cut) [See Section 4.4].
