Jameson JS-8500 User manual

MP3 PLAYER / RECEIVER
USB /SD /MMC/AUX SLOT
INSTALLATION
PRECAUTIONS
Choose the mounting location where the unit will not interfere with the normal
the driver.
driving function of
Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up
properly and the unit and the system work properly.
Use only the parts included with the unit to ensure proper installation. The use
of unauthorized
parts can cause malfunctions.
Consult with your nearest dealer if installation requires the drilling of holes or other modifications of
the vehicle.
Install the unit where it does not get in the driver's way and cannot injure the passenger if there is
a sudden stop. Like an emergency stop.
Avoid installing the unit where it would be subject to high temperature, such as from direct
sunlight, or from hot air, form the heater, or where it would be subject to dust, dirt or excessive
vibration.
INSTALLATION
GENERAL OPERATIONS
FRONT PANEL LAYOUT
03
52120
18
18
17
1
2
3
15 8 79
12
14 6
19
4
10
13
11
Power/MOD Button
Volume/Sel Button
Display/Mute Button
LCD Display
Reset Button
Band switch/ID3 select
Tune Seek & Track forward Button
Tune Seek & Track reverse Button
Automatically memory storing
Play/pause & Preset Button 1
Intro & Preset Button 2
Repeat & Preset Button 3
Random & Preset Button 4
Preset Button 5
Preset Button 6
Release Button
Remote Control sensor
AUX IN JACK
USB connecter
21
20
19
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
18
SD/MMC slot
Flashing LED
16
GENERAL OPERATIONS
EQ OFF/ON
Select “EQ ON ” POP CLASS ROCK EQ OFF menu male.
GENERAL OPERATIONS
SOUND ADJUSTMENT
Turn on (2) can adjust the desired volume quality.
Press SEL button (2) will change in the following order.
Option:
VOLUME
Adjust volume level by using (2) knob. Turn the VOL knob to left to decrease
the sound level, turn the VOL knob to right to increase the sound level.
VOL/SEL
Note: The unit is initially set to volume mode.
VOL BAS TRE BAL FAD
(Volume) ( Bass) ( Treble) ( Balance)(Fader)
Press VOL/SEL button shortly and turn VOL button to right or left to select different
mode.
menu
BASS
Press VOL/SEL button(2) one time. Adjust bass level by using VOL/SEL(2) Knob.
TREBLE
Press VOL/SEL button(2) two times. Adjust treble level by using VOL/SEL(2) Knob .
BALANCE
Press VOL/SEL button(2) three times. Adjust sound balance between left and right
speakers by using VOL/SEL(2)Knob .
FADER (optional)
Press SEL button(2) four times. Adjust sound balance between front and rear speakers
by using VOL/SEL(2)Knob.
SELECT MENU
Press VOL/SEL button for several seconds, selecting menu is activated as cyclical mode
of following function for use's selection:
BAS
VOL TRE BAL EQ LOUD OFF/ON
STEREO/MONO DX/LOC
FAD
04
POWER /MOD conversion
2.Under power off status,short press is power on,
Under power on status,short press is switching mode,long press is power off.
LOUD EQ
02
DIN FRONT-MOUNT (Method A)
1.Frame
2. Insert fingers into the groove in the front of frame and pull out to remove t he frame. (When
reattaching the frame,point the side with a groove downwards and attach It.)
3.Lever
Insert the levers supplied with the unit into the grooves at both sides of the unit and shown in
figure until they click. Pulling the levers makes possible to remove the unit from the dashboard.
2
13
Remov ing th e unit
Fastening the unit to the factory radio mounting bracket:
1. Select a position where the screw holes of the bracket and the screw holes of the main unit
become aligned (are fitted), and tighten the screws at 2 places on each side. Use either truss
screws (5 x 5mm) .
2. Screw
3. Dashboard or Console.
DIN REAR-MOUNT (Method B)
Installation using the screw holes on the sides of the unit.
3
2
2
INPUT THE SD CARD
The SD oblique angle keeps Rightward exposure, put into the SD slot and press it again to eject.
3/ R PT
6/ + 10
BAND A MS
AUX
MODE
DISP /
JS-8500
3 / RP T
1/
5 / - 10
4 / RD M
2 / IN T
6 / + 10
BA ND A MS
AU X
/MO DE
DI SP /
3/ R PT
1/
5/ - 10
4/ R DM
2/ I NT
6/ + 10
BAND A MS
AUX
/MODE
DISP /

REMOTE CONTROL LAYOUT
1Power Button
Pause/play/ uttonPreset B 1
Intro/Preset Button2
Repeat Playing/Preset Button3
Random/Preset Button4
Preset Button5
Preset Button6
Mute Button
Volume Control
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Mode Switch
ST/MO Button
Loudness Button
Scan Button
Display Button
APS/AMS Button
LOC/DX Button
Band Switch
Tuning/Selecting Tracks/ F.F / F.R
Select Button
19
Remote Control Optional
Replacing the Battery
When the operational range of the remote control becomes short or non functions while operating.
Replace a new CR2025 battery. Make sure the battery polarity before replacement.
3.Insert the Battery Holder into the Remote control
1.Pull out Battery Holder while pressing the stopper
2.Put the button type battery(+)mark upward into the Battery Holder.
07 08
SPECIFICATION
General
Power Supply Requirements:
Maximum Output Power:
Chassis Dimensions:
178 x 130x 50mm (W x D x H)
Tone Controls
Bass (at 100Hz): +10dB / -10dB
Treble (at 10K): +10dB / -10dB
Current Drain: 10A
USB/SD MUSIC Player
Signal to Noise Ratio: More than 60dB
Channel Separation:
More than 60dB
Frequency Response:
FM Radio
Frequency Coverage (MHz):
IF :
Sensitivity (S/N-30dB):
Stereo Separation:
20Hz - 20KHz
87.5 - 108MHz
10.7MHz
12dBu
>30dB
50W x 4(CH)
Load Impedance:4 ohms
Remarks:
Specifications subject to change without notice
DC 14.4V , Negative Ground
ADDITIONAL INFORMATION
GENERAL OPERATIONS
AREA SETUP
In Radio mode. Press SEL button for several seconds. LCD will be show from BEEP ON
AREA USA/EUR. At AREA USA/EUR. You can use VOL +/- to select the AREA
frequency.
RADIO OPERATIONS
BAND SELECTION
At tuner mode, press BAND button (6) to select the desired band. The
change in the following order:
reception band will
05
Note: On Remote Control
RESET
RESET button (5) is placed on the housing and must be activated with either a ball point
pen or thin metal object. (Do not use sharp object to avoid damaging the unit.) The RESET
button (5) is to be activated for the following reasons:
- Initial installation of the unit when all wiring is completed.
- All the function buttons do not operate.
- Error symbol on the display.
STATION SELECTION
STATION SELECTION
During radio mode, Press “SEEK ” or “SEEK ”buttons shortly to automatically
a station, Press “SEEK ” or “SEEK ” buttons more than 1 second is operated as
manual turning mode.
search
- Program Scanning
Press AMS(MP3) button (9) shortly to scan preset station. When the AMS mode is carry out,
“INT” appear on LCD display, the unit scan each stored station for 5 seconds, you also can press
the corresponding number button or AMS button. Your desired station will start playing.
And then 6 strongest stations are stored into the corresponding preset number button.
STATION STORING
Press preset button (11~16)
RADIO MODE.
M1 ~ M6
- PRESET MEMORY is loaded when key is pressed for less than 1 second.
- PRESET MEMORY is saved when key is pressed for longer than 1 sec.
RADIO OPERATIONS
06
SELECT TRACKS
During USB/SD operation, press SEEK " " button or " " button to move
to the previous track or the following track, Track number shows on display. During /,
hold SEEK " " (8) button or SEEK " " (7) to fast reverse or fast forward. Music play
starts from when you release the button.
Press preset button (15-16):
- MP3 MODE : 10 TRACK UP / DOWN is activated.
When the total track is 10 or less, KEY is inactivated.
(8) SEEK (7)
USB SD
RPT
Press preset button (12):Flash play mode : REPEAT ON / OFF is activated.
When REPEAT ON, RPT INDICATOR comes on and repeats the current music track.
RDM
During RANDOM ON, RDM INDICATOR is turned on
track of disc is played in ramdom instead of normal order.
Press preset button (13): and each
USB/SD FLASH MP3 Playing：
PLAY / PAUSE
Press button (10) pause function Music track play time
Press it again to resum palying, press it more than 1 second is TOP function.
is activated. INDICATOR flashes.
INT
Press button (11): During INTRO ON, INT indicator comes on and begins
Playing the first 10sec of each song, until the last song is played. It begins playing the entire
track from where INT started
USB/SD OPERATIONS
AUTOMATICALLY MEMORY STORING & PROGRAM SCANNING
- Automatically Memory Storing
Press AMS(MP3) button (9) for several seconds, the radio searches from the
frequency and checks the signal strength until one cycle search is finished.
current
Short press “DISP” button to turn on the mute, Press “DISP” again to turn
off the mute.
Long press “DISP”, LCD screen shows clock “00:00”. Short press “DISP”,
the hour flashes, rotate “VOL +/-“to adjust hour. Press “SEL” button, minute
flashes, rotate “VOL +/-“ to adjust the minute. If there is no operation within
5 seconds, the unit will memorize the current time and return to current mode.
