ROKKER®XXR Series
7.25” Fairing Speaker
Upgrade Kit for 1998-2013
Harley®Roadglide
#HRRK-7252GTM-RXX
Installation
Instructions

Thank you for the condence you have shown in J&M Corporation by
purchasing one of our innovative products.
If you have any question or comments about this product, you may
contact us at USA 1-520-624-7000 Monday thru Friday, 8:00AM thru
5:00PM Mountain Standard Time.
1415 S. Cherry Avenue
Tucson, AZ 85713 U.S.A.
Tel [phone]
Website: http://www.jmcorp.com
E-mail: [email protected]
Installation and Instructions
1. Remove the outer fairing clamshell completely.
2. Unplug the spade wire connectors on the back of each of the
stock speakers.
3. Remove the grill/speaker assembly (all together) by unscrew-
ing the three attachment screws and one nut, on each side of the
fairing.
4. Place the assemblies on your work bench and remove the
speakers themselves from the plastic grill assemblies. Note: Save
the speaker attachment screws. They will be re-used to attach
the J&M 7.25” speaker adapters.
5. Peel off the factory grill from the front of each plastic speaker
adapter and replace this fabric grill with the new J&M plastic grill
with mounted mid-range and tweeter, positioned so that the mid
and tweeter connection wires are located in the exit groove of the
new grill. (for 1998-2005 RoadGlide updated speaker plate adapt-
ers will be needed at this step, J&M part# RRPA-RGSPA or Harley
part#’s 77021-98B & 77022-98B).
6. Re-install both left and right grill assemblies back into the fair-
ing using the original hardware.
7. Using the 5/8” long screws provided, install a J&M speaker
adapter with the side of the adapter marked “TOP” positioned
upward on both the left and right grill assemblies already installed
in the fairing. (Fig. A)
8. Using the original speaker attachment screws saved from
step 4, install a J&M 7.25” speaker with the speaker’s crossover
assembly and spade terminals pointing INWARD, onto both the
left and right J&M speaker adapters. (Fig. A)
9. Connect the wires from the grill mounted mid-range speaker
and tweeter to the correct terminals of the crossover assembly
mounted on the back of the 7.25” speaker. (Fig. B)
10. Then connect the terminals from the speaker wires of your
audio system to the correct spade terminals on the back of the
J&M speaker. (Fig. B)
11. Test each speaker for the proper operation before reassem-
bling the fairing, realizing that full sound quality and delity will
NOT be heard until the outer fairing shell is completely re-installed.
“TOP”
Fig. A
Fig. B
TW
MR
Tweeter
Midrange
TW
MR
Tweeter
Midrange
Speaker
Wiring
Important Note: 2012-2013 CVO RoadGlides come from Harley with smaller 5X7” stock speakers installed. Therefore to install the custom
J&M ROKKER XXR series 7.25” speakers into the fairing, you will need to obtain from Harley, the replacement speaker/grill adapters, Harley
part# 77021-98B (right side) & 77022-98B (left side), along with J&M speaker spade wire adapter kit, J&M part# HSWA-2301, for a clean
no-modication install.
