Janome Sit Down Table with Machine Front to Back User manual

1
Sit Down Table
with Machine
Front to Back

2
© 2015 Printed in the United States
First Print Feb 2015
Second Print June 2015

3
Step 1. Unpack the box your table and legs were
shipped in.
Step 2. With the main table in the box you can put
the legs on.
You will notice the main table legs have extrusions
on them for attaching the leaf support legs.
Two have short extrusions and two have long extru-
sions.
In gure 1 you see the location for the long and the
short extrusions.
Figure 2 short extrusion
Figure 3 long extrusion
Step 3 Lay out the legs according to Figure 1
Step 4 Now attach the legs as shown in gure 4,
5, and 6. You will be using a black bolt with washer.
Figure 4 shows the space for the leg.
Figure 5 shows the bolt in position
Figure 6 shows bolt tight and leg connected.
Long extrusion
Long extrusion
Short extrusion
Short extrusion
Figure 1
Figure 5Figure 4
Figure 3
Figure 2
Figure 6
Space for the leg is this
opening between the side
boards, not the triangle
opening.
Front of Table

4
Step 4. Once you have all four legs attached prop-
erly with the provided bolts. Turn the table over.
Figure 7 is showing the front of the table with the
cut out for changing the bobbin.
Figure 8 and 9 are showing the legs attached to the
main table with the extrusions
Figure 7 This is the front of the table the cut out
is for changing the bobbin
Figure 8 Figure 9
Connecting the side extension
support legs.
This table comes with extensions for both the right
and left side of the table. These are hinged exten-
sions that rest on support legs which are mounted
to the main table legs. These support legs will
swing at towards the extension fold down so that
you do not have to take them o when not useing
them.
Step 5. Open the box with the extension. There
is one extension in each box along with the legs to
support it.
Figure 10

5
Step 6. Pull the legs from the box and locate the
bolts and nuts for attaching the legs to the main
table legs.
Step 7. Using 1 bolt and nut per leg attach them to
the legs on the main table.
Figure 11 shows two of the legs and four of the
bolts
Figure 12 shows positioning the leg
Figure 13 shows leg attached with bolt and nut.
Note: Cut o part goes towards the back of the
extant to allow folding of the legs towards the table.
Step 8. Once you have the four legs on fold them
towards the table so that we can hang the exten-
sions in place.
Figure 14 shows the legs on and folded. Table
ready to hang the extension on.
Figure 12
Figure 11
Figure 13
Figure 14
Hinge points for Extension

6
Placing the machine on the ta-
ble.
With the table assembled you are ready to place the
machine on the table.
Step 11. Locate four small rubber pads that the
machine will rest on. These look like half circles.
Figure 19
Step 12. Place one in each corner of the machine
opening in the table.
Figure 20
Step 13. Place the machine into this opening with
the bobbin towards the cut out in the bottom.
Figure 21
Figure 19
Figure 21
Figure 20

7
Hanging the Extensions.
This table comes with extensions for both the right
and left side of the table. These are hinged exten-
sions that rest on support legs which are mounted
to the main table legs. These support legs will
swing at towards the extension fold down so that
you do not have to take them o when not useing
them.
Step 9. Remove the extension one at a time and
hang them on the side of the table. To Hang line up
the hinge part on the extension see gure 15 with
the henge part on the main table see gure 14 on
page 5.
Step 10. To use the extension lift extension and
unfold the support legs from the table. Once the
legs are all the way out you can lay the extension on
the support legs and your table is ready.
Figure 15
Figure 18Figure 17
