Jasper Connect User manual

Installation Instructions
Unit Assembly
Recommended Tools
Package Contents
Step 1
Attach the legs to the bottom of the uphol-
stered unit using 1 inch long large wood
screws. The base will have pilot holes to locate
the screws.
Page 1 of 2CONNECT
Legs
Upholstered Unit
1-1/4”Wood Screw
1”Zinc Wood Screw
Hardware Used
Linking Hook & Latch
1” Long Screws
#2 & #3 Phillips Head Bits
#2 & #3 Phillips Screw Drivers
Screw Gun
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-CT001
5/1/16

Installation Instructions
Page 2 of 2
Unit Assembly
(continued)
CONNECT
Step 2
Attach the two (2) linking latches and two
(2) linking hooks using 1-1/4” long black
wood screws as shown. There will be a
predrilled hole for each piece of hard-
ware for the first screw. Line up hardware
perpendicular to the base and drive in the
second screw to secure in place.
Linking
Latch
Linking
Hook
Step 3
To create the 3-piece media group,
the center section will have both
linking latches and hooks, while the
right unit will have only the latches
on the corresponding side, and the
left unit will only have the hooks on
the corresponding side as shown.
No Latches No Hooks
Step 4
Make sure to level the units so that
the bases are flush and there are
no gaps between the headrests.
1-1/4” Screws 1-1/4” Screws
Flush
No Gaps
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
