Jaxpety HG61N0212 User manual

User Manual

1 2
You need
Hardware List
16PCS
A
1Tools required 21 persons is needed 3Take 30 minutes
30mins
A Phillips head scre
wdriver is required for
the assembly of this
product.（not included）
Power tools should
not be used to assemble
this product.
M8x50mm
2PCS
B
M6x60mm
18PCS
C
A ×8
M6x25mm
1PC
D
PRODUCT ASSEMBLY
STEP 1
Check the package contents before getting started !
USE SCREWS(A)TO ATTACH THE TABLE BODY(11)TO THE TABLE LEGS(7).
Do not screw all the screws when installing the table legs and stool legs.
Keep half-screw state until all installation adjustments are complete before
screwing the screws.
UESCRIPTION
LA DESCRIPTION
NO
NON
1 7
8
9
10
11
1
12 2
1
2
2
2
3
4
4
1
1
4
5
6
QUANTITY
QUANTITE
UESCRIPTION
LA DESCRIPTION
NO
NON
QUANTITY
QUANTITE
MIRROR TABLE LEGS
CUSHION
STOOL LEGS
BOARD
TABLE BODY
MIRROR FIXTURE
BOARD
BOARD
SMALL DRAWER
MAIN DRAWER
Technical Specifications
Size
Max
Brand
750X400X1430mm
330LBS
weight capacity
JAXPETY

4
3
PRODUCT ASSEMBLY
PRODUCT ASSEMBLY
STEP 2 STEP 4
STEP 3 STEP 5
C×3 C×3
C ×2
C ×4
C ×2
B ×2
C ×2
USE SCREWS(C)TO CONNECT BOARD(3)BOARD(4)AND BOARD(10)TOGETHER.
USE SCREWS C TO CONNECT THE TABLE BODY(11)AND THE THIRD
STEP OF THE ASSEMBLED PARTS.
USE SCREWS B TO CONNECT MIRROR FIXTURE(2)TO MIRROR(1).
USE SCREWS（C）TO CONNECT STEP2 WITH THE COMPLETED PART OF THE
SECOND STEP.

6
STEP 8
5
STEP 6
STEP 7
PRODUCT ASSEMBLY PRODUCT ASSEMBLY
A ×8
C ×2
Do not screw all the screws when
installing the table legs and stool legs.
Keep half-screw state until all installation
adjustments are complete before
screwing the screws.
PLEASE THE SMALL DRAWER IN THE POSITION SHOWN AND ATTACH
IT TO THE ASSEMBLED PART IN STEP 5 WITH THE SCREW(C).
USE SCREWS(A)TO CONNECT STOOL LEGS AND STOOL.
