Jayco Select Jay Series User manual

www.jayco.comwww.jayco.com
Camping Trailer
Owner’s Manual
Model Year 2007
Baja

Cunningham Campers, Inc.
5201 Highway 62
Jeffersonville, IN 47130
Visit Our Jayco Factory Direct Website. Help spread the word for us:
www.jaycofactorydirect.net
BUY FACTORY DIRECT ON THE INTERNET & SAVE THOUSANDS!
Online:
http://cunninghamcampers.com/parts/
Toll Free:
1-800-778-9411
Register At Our Online Camp Store
Receive a Coupon for 10% OFF your first purchase of
$10.00 or more! Just check your email after registering.
REGISTRATION IS FREE & SECURE!
Cunningham’s – Selling & Servicing Jayco RV’s for Nearly 35 Years!

WARNING: Read all instructions in this manual and component
I
manufacturer supplied information before using your RV.
This manual has been provided by Jayco, Inc. for the sole purpose of providing instructions
concerning the operation and maintenance of this vehicle and its components. Nothing in
this manual creates any warranty, either expressed or implied. The only warranty offered by
Jayco, Inc. is as set forth in the limited warranty applicable to this vehicle.
The owner’s failure to provide required service and/or maintenance could result in the loss
of warranty. The owner should review Jayco’s limited warranty and the limited warranties
that apply to specific components that are offered with this vehicle.
Instructions are included in the manual for operating various components which are
optional on some vehicles. In addition, the owner should refer to individual manufacturer’s
operating instructions contained in the owner’s packet.
WARNING:
I
,
Review the compatibility of your tow vehicle with the trailer you will be
towing. You, as the owner, are responsible for the safety and
compatibility of your tow vehicle and trailer selections.
,
You must not exceed the gross vehicle weight rating (GVWR) of the
trailer. Include all additions, cargo and tank fluids when calculating
the weight of your trailer.
,
Do not exceed the towing or cargo capacity of your tow vehicle. You
must clearly understand how your tow vehicle’s capacities are
calculated.
,
Do not load your trailer so that it is unbalanced from front to rear or
from side to side.
,
Know your loaded hitch weight and select a hitch that is adequate for
that weight. Consult your hitch and tow vehicle manufacturers with
any questions before you tow your trailer.
,
You are responsible for the maintenance of your tow vehicle and
trailer. Make sure your tow vehicle is mechanically sound for your
intended usage. Pay particular attention to suspension components,
tires and tire pressure.
,
We recommend the use of sway control devices and weight
distributing hitches with all Jayco towable products (excluding fifth
wheels, which use a different type of hitch).
,
Obey all traffic laws and use your seatbelts at all times. Many states
have lower speed limit requirements for tow vehicle/trailer
combinations. We recommend that you do not exceed 55 MPH when
towing a trailer.
Consult an expert for specific driver education when towing a trailer. There are private RV
driving schools, and some RV clubs, which offer driving seminars as part of their club
activities. Recreation vehicle publications and the Internet can be a source of information
regarding RV driver education, as well as many other topics to help you learn to safely use
your recreation vehicle.
©2006 Jayco, Inc. LITHO USA 04/06**07-1 Part #0181064.2007

TABLE OF CONTENTS
1
WARRANTY &SERVICE
ABOUT THIS MANUAL.................................1
CHANGE OF ADDRESS OR OWNERSHIP.......4
CUSTOMER RELATIONS..............................4
CUSTOMER RESPONSIBILITY ......................2
DEALER RESPONSIBILITY ...........................3
EXTENDED TRANSFERABLE LIMITED
WARRANTY...........................................11
GOODIE BAG .............................................1
JAYCO CUSTOMER FIRST EMERGENCY
ROADSIDE ASSISTANCE ..........................6
JAYPLUS EXTENDED SERVICE CONTRACT ..7
LIMITED WARRANTY TRANSFER
APPLICATION ........................................13
MANUFACTURING PROCESS.......................2
OBTAINING EMERGENCY WARRANTY
REPAIR...................................................6
OBTAINING SERVICE AT JAYCO...................7
OBTAINING SERVICE FOR SEPARATELY
WARRANTED ITEMS.................................7
OWNER’S INFORMATION.............................5
REPLACEMENT PARTS ...............................7
REPORTING SAFETY DEFECTS ...................1
SAFETY ALERTS ........................................1
SUGGESTIONS FOR OBTAINING SERVICE ....3
THE JAYCO TRAVEL CLUB..........................6
TOWABLE LIMITED WARRANTY ...................8
OCCUPANT SAFETY
CARBON MONOXIDE ALARM .....................17
EGRESS EXIT WINDOW ............................16
FIRE EXTINGUISHER.................................17
FIRE SAFETY INFORMATION......................16
OTHER FIRE SAFETY INFORMATION..........17
PROPANE (LP) GAS ALARM......................18
SEVERE WEATHER INFORMATION.............15
ELECTRICAL SYSTEMS
120-VOLT AC SYSTEM.............................21
120-VOLT CIRCUIT BREAKERS..................22
12-VOLT DC SYSTEM...............................24
12-VOLT FUSE PANEL ..............................26
30-AMP POWER CORD .............................22
AUXILIARY BATTERY
(CUSTOMERSUPPLIED) .........................25
BATTERY ISOLATOR FOR YOUR TOW
VEHICLE (CUSTOMER INSTALLED)..........26
CALCULATING ELECTRICAL LOAD .............24
CONVERTER............................................23
ELECTRICAL SYSTEM PRECAUTIONS.........21
GFCI RECEPTACLE OUTLET.....................24
IN CASE OF AN ELECTRICAL FIRE.............21
PROPANE SYSTEM
CALCULATING PROPANE USAGE...............33
DOT PROPANE CYLINDER .......................28
HOSES,PIPES,TUBES &FITTINGS ...........32
HOW TO LEAK TEST THE PROPANE
SYSTEM ...............................................28
INSTALLING PROPANE CYLINDERS............30
PROPANE REGULATOR ............................32
PROPANE SAFETY PRECAUTIONS.............27
TRAVELING WITH PROPANE......................33
USING THE PROPANE SYSTEM .................32
PLUMBING SYSTEM
12-VOLT WATER PUMP &SWITCH ............36
BATHROOM SHOWER (IF SO EQUIPPED)...39
BLACK &GREY TANK DRAINS ..................42
BLACK/GREY WATER HOLDING TANKS
(IF SO EQUIPPED).................................43
BLACK/GREY WATER SYSTEM
(IF SO EQUIPPED).................................42
CASSETTE TOILET (IF SO EQUIPPED) .......44
DRAINING THE FRESH WATER SYSTEM.....40
FAUCETS.................................................38
FRESH WATER CONNECTIONS .................35
FRESH WATER HOLDING TANK.................35
OUTSIDE SHOWER (IF SO EQUIPPED).......38
SANITIZING THE PLUMBING SYSTEM .........40
THE FRESH WATER SYSTEM....................35
WATER HEATER ......................................37
WATER PRESSURE REGULATOR
(CUSTOMER SUPPLIED) ........................36
WATER PURIFICATION SYSTEM
(IF SO EQUIPPED).................................39
WINTERIZING THE PLUMBING SYSTEM......41
PRE-TRAVEL INFORMATION
E-Z LUBE AXLE .......................................51
FIRST SHORT TRIP...................................55
FRONT DECK (BAJA MODELS)..................50
HITCH (CUSTOMER SUPPLIED).................46
HITCH HEIGHT &HITCH BALL...................47
LOADING YOUR RV..................................53
ROOF......................................................49
RV BRAKE SYSTEM .................................48
RV TIRE INFORMATION ............................51
SEASONING THE NEW TENT CANVAS........50
SWAY CONTROL (CUSTOMER SUPPLIED)..47
TOW VEHICLE..........................................45
TRAILER FRAME.......................................49
VEHICLE IDENTIFICATION NUMBER (VIN)
EXPLAINED...........................................46
VEHICLE LABELS......................................46

TABLE OF CONTENTS
2
PRE-TRAVEL INFORMATION,CONT.
WEIGHING YOUR TOW VEHICLE &RV ......54
WEIGHT DISTRIBUTING SYSTEM
(CUSTOMER SUPPLIED) ........................48
WEIGHT LABELS ......................................45
TOWING &HANDLING
BREAKAWAY SWITCH...............................59
CAMPING TRAILER HITCHING
PROCEDURE.........................................61
DRIVING &ALCOHOL................................59
EMERGENCY STOPPING...........................63
EMERGENCY TOWING ..............................66
RV DRIVING SCHOOLS &SEMINARS.........59
SAFETY CHAINS (TRAVEL TRAILER)..........60
STABILIZER JACKS...................................60
TOWING ..................................................61
WIRE HARNESS/CONNECTOR PLUG .........60
CAMPING &OPERATING
AIR CONDITIONER PREP (IF SO EQUIPPED)77
ATTIC FAN (IF SO EQUIPPED)...................77
BBQ GRILL (IF SO EQUIPPED)..................74
BBQ GRILL PREP ....................................74
BOOTH DINETTE (IF SO EQUIPPED)..........70
CANOPY (IF SO EQUIPPED)......................74
CONDENSATION.......................................76
COOKING WITH PROPANE........................71
DEPARTING CAMP CHECKLIST..................78
ENTRANCE DOOR WITH SCREEN DOOR....66
FURNACE (IF SO EQUIPPED) ....................78
HEATED BED MATS (IF SO EQUIPPED)......69
ICE BOX (IF SO EQUIPPED) ......................71
IN CASE OF A GREASE FIRE .....................73
J-STEEL SOFA (IF SO EQUIPPED).............70
KEYS.......................................................66
KITCHEN STOVE RANGE &OVEN
(IF SO EQUIPPED).................................72
LIGHTS....................................................71
MICROWAVE (IF SO EQUIPPED)................73
REFRIGERATOR (IF SO EQUIPPED)...........71
SCREEN ROOM (IF SO EQUIPPED)............76
SETTING UP THE FRONT &REAR BEDS ....67
SETTING UP YOUR CAMPSITE...................65
SLIDEOUT ROOM SYSTEM
(IF SO EQUIPPED).................................70
SOLAR PREP (BAJA MODELS ONLY,
IF SO EQUIPPED ...................................77
THERMOSTAT ..........................................77
STORAGE &MAINTENANCE
ABS PLASTIC..........................................81
COUNTERTOPS........................................82
CUSHIONS...............................................82
DOORS &LOCKS .....................................83
EXTERIOR FINISH ....................................83
FORMALDEHYDE......................................81
HARDWARE &SINK OR SHOWER
FIXTURES.............................................81
LIFTER SYSTEM.......................................83
MAINTENANCE CHECKLIST.......................86
PANELING ...............................................81
REAR BUMPER ........................................84
SEALANTS...............................................84
SHOWER CURTAIN LINER
(IF SO EQUIPPED).................................81
STORAGE CHECKLIST ..............................85
TENT CANVAS .........................................82
VINYL FLOOR ..........................................82
SPECIFICATIONS &GLOSSARY
APPROXIMATE ELECTRICAL LOAD
RATINGS ..............................................92
DC FUSE PANEL LAYOUT.........................90
GLOSSARY OF TERMS..............................93
OEM LIST ...............................................89
OEM WHEEL LUG TORQUE CHART ..........90
PROPANE CONSUMPTION CHART .............91
REPLACEMENT LIGHT BULBS ...................91

WARRANTY & SERVICE
Congratulations! Thank you for selecting the
2007 CAMPING TRAILER by Jayco. We are
excited to welcome you to our growing family.
Jayco is proud to be the largest, privately held
manufacturer in the RV industry and we invite
you to stop by our Visitors Center located in
Middlebury, Indiana. We offer regularly
scheduled guided tours of our manufacturing
facilities (closed holidays). If this is of interest,
please contact us at 1-800-RV-JAYCO.
ABOUT THIS MANUAL
This manual is a guide to the operation and
maintenance of your RV. The CAMPING
TRAILER is available in several sizes and
models, so accessories and components may
differ. Some equipment described in this
manual may not apply to your RV. If you find
the components vary significantly from what is
described, please contact your dealer to
ensure you have the correct information.
Nothing in this manual creates any warranty,
either expressed or implied, nor does it cover
every possible detail of equipment, standard
or option, installed on or in your RV.
The information, illustrations and
specifications in this manual reflect the most
current available at the time of publication
approval, are subject to change and not
intended to indicate actual size.
GOODIE BAG
The Goodie Bag contains original equipment
manufacturer (OEM) operator's manuals,
warranty cards and/or registrations. It is
important you complete and mail the warranty
cards and registrations to each OEM within the
prescribed time limit to avoid loss of warranty
coverage. This Owner's Manual and the
Goodie Bag should be considered a
permanent part of the RV. If the RV is sold,
they should remain with the vehicle for the next
owner.
SAFETY ALERTS
Your safety, and the safety of others, is very
important. To help you make informed
decisions, we have provided operating
procedures and other information on safety
labels affixed to your RV and in this manual.
Please call your dealer or Jayco Customer
Service if you are unsure how to proceed.
Always use the appropriate safety gear when
servicing or maintaining your RV.
This is the safety alert symbol. It is
used to alert you to potential
personal injury hazards. Obey all
safety messages that follow this symbol to
avoid possible injury or death.
REPORTING SAFETY DEFECTS
In the United States
If you believe that your RV has an alleged
defect that could cause a crash or cause injury
or death, you should immediately inform the
National Highway Traffic Safety Administration
(NHTSA), in addition to notifying Jayco
1
SECTION 1
WARRANTY & SERVICE
DANGER
This indicates an imminently hazardous
situation which, if not avoided, will result in
death or serious injury.
WARNING
This indicates a potentially hazardous
situation which, if not avoided, will result in
death or serious injury.
CAUTION
This indicates a potentially hazardous
situation which, if not avoided, will result in
minor or moderate injury.
CAUTION
This indicates a potentially hazardous
situation which, if not avoided, may result in
property damage.

Customer Service. If NHTSA receives similar
complaints, it may open an investigation, and if
it finds that a safety defect exists in a group of
vehicles it may order a recall and remedy
campaign. However, NHTSA cannot become
involved in individual problems between you,
your dealer or Jayco. For additional
information, please refer to the NHTSA
website at www.safercar.gov.
To contact NHTSA by phone:
Call the DOT Vehicle Safety Hotline at
1-888-DASH-2-DOT (1-888-327-4236) and a
NHTSA representative will record your
complaint information. Or TTY: 1-800-424-
9153 or 1-202-484-5238
To contact NHTSA by mail:
U.S. Department of Transportation
National Highway Traffic Safety Administration
Office of Defects Investigation
NVS-210, 400 7th Street, SW
Washington, DC 20590
In Canada
If you believe your vehicle has an alleged
safety defect, you should contact Transport
Canada, in addition to contacting Jayco
Customer Service. Transport Canada prefers
to be called instead of posted mail or email as
it enables their investigators to confirm that
your information is correct, and to answer your
questions accurately. For additional
information, please refer to the Transport
Canada website at www.tc.gc.ca.
To contact Transport Canada by phone:
Call 1-800-333-0510 or [phone] if you
are calling from the Ottawa region and ask to
speak to a defect investigator.
To contact Transport Canada by mail:
Road Safety and Motor Vehicle
Regulation Directorate
Transport Canada
Tower C, Place de Ville
330 Sparks Street
Ottawa, Ontario K1A 0N5
MANUFACTURING PROCESS
Jayco recreational vehicles
are manufactured for use as
temporary living quarters for
recreation, camping and
travel uses, all as defined by
the bylaws of the
Recreational Vehicle
Industry Association (RVIA).
This recreation vehicle is
not intended for use as a
full-time residence or for
commercial use. Commercial use means
using the RV as a business asset such as a
mobile office or using the RV for lease or rental
purposes.
Jayco reserves the right to discontinue or
change specifications or design at any time
without notice and without incurring any
obligation whatsoever. RVs built for sale in
Canada may differ to conform to Canadian
Codes.
CUSTOMER RESPONSIBILITY
It is important you read and understand the
information in this manual and your Goodie
Bag before using your RV. Familiarize yourself
with the applicable warranties. You are
responsible for ensuring the procedures for
obtaining warranty repairs are followed
properly.
As the owner of the RV, you are responsible for
regular and proper maintenance performed in
accordance with this manual and the OEM
operator's manuals. This will prevent
conditions arising from neglect that are not
covered by the Towable Limited Warranty. It is
your responsibility and obligation to return
your RV to your dealer for warranty service
repair.
As with your other personal belongings, it is
important that you protect yourself and others
with insurance coverage. Your insurance
agent can assist you in obtaining the
appropriate insurance coverage for personal
liability, theft, collision, property damage, etc.
Or your dealer may be of assistance in
2
SECTION 1
WARRANTY & SERVICE
MEMBER
T
R
R
U
E
L
C
I
K
A
R
C
T
A
M
G
P
N
I
E
P
R
M
•
A
F
C
O
G
L
D
I
N
TM
RVIA seal

obtaining a JayPlus Retail Insurance quote for
you. This insurance quote is offered to you
directly by GMAC Insurance (not Jayco, Inc.).
For more information, please contact your
dealer or call 1-800-252-2031 Savings Code:
GL 2A to contact GMAC insurance.
DEALER RESPONSIBILITY
At the time of sale of the new RV, your dealer is
expected to explain or provide the following:
0Deliver your RV in the best condition
possible and ensure that it passed the
pre-delivery inspection and all systems
tests.
0Provide orientation of the RV, its systems,
components and operation.
0Request that you read all warranty
information and explain any provision not
clearly understood.
0Ensure you receive the Goodie Bag. Your
dealer can assist you in completing the
component-manufacturer warranty cards
or registrations and locating any required
component model or serial numbers.
0Complete and return the Warranty
Registration and Customer Delivery Form
to Jayco within 10 days of delivery to
activate the applicable warranty coverage.
Please note that your Towable Limited
Warranty is activated only after Jayco receives
a signed Warranty Registration and Customer
Delivery Form from your selling dealer. If it has
been more than 60 days since the purchase of
your new RV and you have not received a
confirmation letter from Jayco, please contact
your selling dealer or Jayco Customer Service.
If you have mailed in a Limited Warranty
Transfer application you will receive a
response letter from Jayco confirming your
warranty status (please allow 6-8 weeks for
processing).
SUGGESTIONS
FOR OBTAINING SERVICE
The independent dealers who are authorized
to sell Jayco RVs are also there to provide
service after the sale. We work closely with
them in an effort to keep you satisfied. To help
ensure your dealer provides the level of
service you expect, here are some
suggestions we would like to make:
Contact your dealer at once… Don’t wait
until you are ready to use your RV. Your dealer
may not be able to service it immediately
and/or the repair may require parts be ordered.
The dealer’s service department is busiest on
Mondays and Fridays and before the holidays.
Prepare for the appointment… If you are
having warranty work performed, be sure to
have the right papers with you. Take your
warranty folder and have your vehicle
information available. Not all the work to be
performed may be covered by the warranty;
discuss additional charges with the dealer’s
service management.
Prepare a list… Provide your dealer with a
written list of specific repairs needed. It is
important that you provide any vehicle repair
history to the dealer’s service manager. Keep
a maintenance log of your RV’s service
history. This can often provide a clue to the
current issue.
Be reasonable with your requests… If you
leave a list with several items and you need
your RV returned back by a specific time,
discuss the situation with the dealer’s service
management and list your items in order of
priority. This may include making a second
appointment for work not completed or parts
that the dealer may need to order.
Don’t expect to look over the technician’s
shoulder… Please do not be offended if you
are told you cannot watch the work being
done. Some insurance requirements forbid
admission of customers to the service area.
3
SECTION 1
WARRANTY & SERVICE

Inspect the work performed… Finally,
check out the service or repair job when you
pick up your RV. Notify the dealer’s service
management immediately of any
dissatisfaction. If you cannot return your RV
immediately for repair, make an appointment
as soon as possible.
Please be aware that all service shops require
notification of any issues with their repairs
within a specified time limit. Make sure you are
familiar with their repair policies.
CUSTOMER RELATIONS
Jayco, Inc. has empowered its dealers to
make warranty and repair decisions. If a
special circumstance occurs that requires
information from Jayco, we have asked your
dealer’s service management to make the
contact on your behalf. This is why you
should always talk to your dealer’s service
management first.
Most issues arise from misunderstandings
about warranty or service needs. We
recognize that, on some occasions, you will
not be totally satisfied with a dealer’s decision
or actions. If this is the case, you should write
or call Jayco Customer Service. Our hours are
Monday – Friday, 8:00 a.m. – 5:00 p.m. (closed
holidays). Please provide the following
information:
0Your name, location and phone number.
0Your RV’s 17-digit vehicle identification
number (VIN).
0Date of purchase.
0Name of the dealership who sold the RV to
you.
0Name and address of the dealer servicing
your RV.
0A detailed description of the concern.
0If applicable, the component description,
serial number and model number.
Mailing address Shipping address
Jayco, Inc. Jayco, Inc.
Customer Service Customer Service
P.O. Box 460 100 Bontrager Drive
903 S. Main Street Bldg 42 Door 4220
Middlebury IN 46540 Middlebury IN 46540
Phone number: [phone]
Fax number: [phone]
Email: [email protected]
Website: www.jayco.com
California Lemon Law notice
If you have determined that your vehicle has
non-conformities under the California Lemon
Law, you must provide written notice of the
claimed defects directly to Jayco, Inc., and
permit Jayco to perform a final repair attempt.
An important note
about alterations and warranties
Installations or alterations to the original
equipment vehicle as distributed by Jayco, Inc.
are not covered by the Towable Limited
Warranty. The special body company,
assembler, equipment installer, or upfitter is
solely responsible for warranties on the body
or equipment and any alterations (or any effect
of the alterations) to any of the parts,
components, systems, or assemblies installed
by Jayco. Jayco, Inc. is not responsible for the
safety or quality of design features, materials
or workmanship of any alterations by such
suppliers.
CHANGE OF
ADDRESS OR OWNERSHIP
Help keep our records current so that if, in the
event of a recall, you are notified. Please notify
Jayco Customer Service of a change of
address or ownership. Mail the completed
form (located in the back of this manual) to
Jayco. If you have purchased your RV as
“used” include documentation showing your
proof of ownership (i.e., a copy of your bill of
sale, insurance policy, etc.).
4
SECTION 1
WARRANTY & SERVICE

OWNER’S INFORMATION
Complete the information below for ready
reference when maintenance or service is
needed. If you ever need to contact your
selling dealer or Jayco Customer Service, you
will need your 17-digit VIN and delivery date.
Owner Name ____________________________________________________________________
Address ________________________________________________________________________
City______________________________________ ST/Province ______ ZIP/Postal Code _____
VIN ____________________________________________________________________________
License Plate No. ____________________________________________ Delivery Date ________
Dealer Name ____________________________________________________________________
Address ________________________________________________________________________
City______________________________________ ST/Province ______ ZIP/Postal Code _____
Dealer's Phone No. _________________________ Fax No. ______________________________
Salesperson _____________________________________________________________________
Key Numbers
Entry Door Deadbolt ____________________________________________________________
Entry Door Lock________________________________________________________________
Other __________________________________ Other________________________________
Other __________________________________ Other________________________________
Insurance Company_______________________________________________________________
Policy Number ___________________________________________________________________
Agent's Phone No.__________________________ Fax No. ______________________________
Agent's Name____________________________________________________________________
5
SECTION 1
WARRANTY & SERVICE
