JAYDEN CREATION TVSBSD0453 User manual

NOTE:
ITEM NO. TVSBSD0453
This brochure contains IMPORTANT safty info. Please read and keep for
future reference.
1/16

MAINTAINANCE
AND WARNING
Keep furniture away from heat.
Do not clean furniture with harsh cleansers
or polish. Do not use detergents, Solvents,
abrasives, spray packs or leather cleaner. Use
non-color mild soap with warm water clean
spills(Mix 1:10 soap to water)
Do not place furniture under direct sunlight,
material will possibly fade over time.
Do not use on site dry Cleaning machine.
Children should not climb or jump on the
furniture.
Do not write on furniture without a padded
barrier to protect the surface.
Not for commercial use, For residential use
only.
Weight Limitation
80LBS
6

PARTS
LIST
6

Explosive View
6

HARDWARE
LIST
Be sure to check all packing material carefully for
small parts, which may have come loose inside the
carton during shipment.
6
SPARE
96 20
W

6 16
ASSEMBLY
IN STRUCTIO N S
A*2
D*2
A*2
D*2
B*4
O*4
A
D
Prepare the part 4, 5 and middle leg.
1)Assemble the middle leg. Align the hole in part 16 and the screw hole in part 15,
screw in and tighten the screw K by allenkey P.
2)Align the hole in part 4, 5, insert the wooden dowel D into the hole by hand;
screw in and tighten the cam bolt A by screwdriver W
Connect part 3 to the part 4 and 5.
1)Align the hole in part 3, insert the wooden dowel D into the hole by hand;
2)Insert the nut B into the hole in part 3, Align the hole in part 3, insert the part D and cam
bolt A in part 4 and 5 into the hole in part 3, screw in and tighten the nut B by screwdriver W.
3)Cover the nut by part O.
D*2

6
Q
Q
7
D*6
C*2
C
P
Connect the part 6 to the finished part in step 2.
1) Insert the wooden dowel D into the part 4, 5 and 6 by hand.
2) Align the hole in part 6, insert the wooden dowel D in part 3 into the part 6, then screw in
and tighten the screw C by allenkey P.
Connect the part 9 to the finished part in step 3.
1) Insert the part Q into part 9.
2)Slide part 9 into the groove of 3, 4, 5 and 6.
4
4
3

6
A*6
4
6
B*6
O*6
Prepare the part 1 and part 17.
1) Align the hole in part 1, screw in and tighten the cam bolt A
by screwdriver W.
2) Align the hole in U to the hole in part 17, screw in and tighten the
screw E by screwdriver W.
3) Align the hole in part 17 to the hole in part G, screw in and tighten the
screw H by screwdriver W.
4) Align the hole in part N to the hole in part 17, screw in and
tighten the screw E by screwdriver W.
B
Attach the part 1 to the finished part in step 4.
1) Insert the nut B into the hole in part 4, 5 and 6 as the picture show.
2) Align the hole in part 4, 5 and 6 to the cam bolt A in part 1, insert
wooden dowel D and cam bolt A at same time, then tighten nut B
by screwdriver W.
3) Cover the nut by part O.

9 16
U*3
A*4
D*8
D*4
D
A
Prepare the part 3.
1) Turn over the finished part in step 6.
2) Align the hole in part 3, 4 and 5 and insert the wooden dowel D into the
hole by hand as the picture show.
3) Align the hole in part 3, screw in and tighten the cam bolt A by screwdriver W.
4) Align the hole in part U ,screw in and tighten the screw E by screwdriver W
as the picture show.
Attach the part 7 and 8 to the finished part in step 7.
1) Insert the nut B into part 7 and 8 as the picture show.
2) Align the hole in part 7, 8 to the wooden dowel D and cam bolt A in part 3, insert the
part D and A into part 7 and 8 at the same time, then tighten the nut B by screwdriver W.
3) Cover the nut by part O.

16
7
8
C*8
Slide the part 10 and 11 into the groove in part 3,4,5,7 and 8.
Attach the part 2 to the finished part in step 9.
1）Insert the wooden dowel D in part 4,5,7,and 8 into
part 2, then
2）Align the hole in part 2 to the hole in part 4,5,7,
and 8, screw in and tighten the screw C by
allenkey P.
7
8
3

11 6
24
J*12
I*4
Attach the leg frame.
1) Align the hole in part 12 and 13 to the hole
in part 2, screw in and tighten the screw J
by allenkey P. DO NOT FULLY TIGHTEN!
2) Align the hole in part 16 to the hole in
part 12, screw in and tighten the screw I
by allenkey P. DO NOT FULLY TIGHTEN!
Assemble the part V to the leg frame.
1) Insert the edge of part V into the space in part 12 and 13
2) Align the hole in part V to the hole in part 12 and 13, screw
in and tighten the screw E by screwdriver W. DO NOT FULLY TIGHTEN!

12 6
14
14
14
14
V
14
Q
6
24 20
E*20
F*20
Assemble the legs.
1) Align the hole in part 14 to the
hole in part V, screw in and
tighten the screw L by allenkey P.
2) After check the all screw in right
position, fully tighten the screws I,
J E in sequence.
Assemble the part F and part R
(hook of anti-collapse) as the picture show.
1) Insert the part F into the space between
the part 1,2, 3, 4,5,6, 7, 8 screw in
screw E and tighten by screwdriver W.
2) Align the hole in part R to the part 1,
screw in and tighten the screw E by
screwdriver W

13
15
17
17
17
5
8
4
U*3
18
18
2
Attach the part 17 to the finished part in step 14.
1) Assemble the part U in the part 2 as the picture show.
2) Align the hole in part N to the part 4, 5 and 8, screw in and tighten the screw E by
screwdriver W as the picture show.
N

Use the adjustable nail to keep the cabinet level in case the
cabinet is wabbling.
Now your cabinet is ready to use.
16
14/16

17
1. Mark the position on the wall, this should be same as the position of R
where are on the back of panel 1; Drilled and insert the expandable screw
T by hammer;
2.Assemble the part R on the wall. Align the hole in the part R to the
expandable screw T, screw in and tighten by screwdriver;
3.let the plastic belt S go through the both R and pull to tighten.
M
M
T
T
M
15/16
