jcb JCB-20OS Planning guide

POWER TOOL
INSTRUCTION & USER MANUAL
EN
JCB-20OS
Original Instructions
JCB-20OS-EN
Iss: 02/2020

2JCB-20OS
Instruction & User Manual
GENERAL WARNINGS & DISPOSAL
To reduce the risk of injury, the user must read the instruction manual.
The device must not be exposed to rain or immersed in water.
Do not allow any part of the device to come into contact with flames, or to
catch fire.
This symbol is used throughout this manual to warn the user about potential
risks. Please read & understand these sections before using the device.
Personal Protective Equipment (P.P.E.), such as ear defenders, eye protection,
safety gloves and a dust mask, must be worn during the operation of the
device.
This product has been marked with a symbol relating to removing electric and
electronic waste. The product should not be discarded with household waste
but must be returned to a collection system which conforms to the European
Directive 2012/19/EU. It will then be recycled or dismantled in order to
reduce the impact on the environment. Electric and electronic equipment can
be hazardous for the environment and for human health since they contain
hazardous substances.
Do not expose battery pack or tool to fire or excessive temperatures.
Do not dispose of batteries in household waste. Return exhausted batteries
to a local collection or recycling point.

WARNING: Lithium-ion batteries and products that contain lithium-ion batteries can expose you
to chemicals including cobalt lithium nickel oxide, and nickel, which are known to the State of
California to cause cancer and birth defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
WARNING: Drilling, sawing, sanding or machining wood products can expose you to wood
dust, a substance known to the State of California to cause cancer. Avoid inhaling wood dust or
use a dust mask or other safeguards for personal protection. For more information go to www.
P65Warnings.ca.gov/wood.
The month and year of manufacture can be found within the product serial number e.g.
MMYYPPPAXXXXX. Where production month (MM) and production year (YY) are included.
JCB-20OS Designation of the tool (20 - 20Vdc, OS - Orbital Sander)
3
JCB-20OS
Instruction & User Manual

4JCB-20OS
Instruction & User Manual
Contents
GENERAL POWER TOOL SAFETY WARNINGS 5
1. Work area safety 5
2. Electrical safety 5
3. Personal safety 5
4. Power tool use and care 6
5. Battery tool use and care 6
6. Service 7
SAFETY WARNINGS COMMON FOR SANDING 8
Additional Safety Rules For Orbital Sanders 8
Kickback and Related Warnings 9
CHARGER SAFETY 10
COMPONENT LIST 11
TOOL TECHNICAL DATA 12
BATTERY TECHNICAL DATA 12
CHARGER TECHNICAL DATA 12
NOISE INFORMATION 13
VIBRATION INFORMATION 14
OPERATING INSTRUCTIONS 15
Intended Use 15
ON/OFF SWITCH 15
Changing a Sanding Sheet 15
Dust Suction and Dust Extractor Pipe 15
Sanding Surfaces and Grade of Sandpaper 16
BATTERY AND CHARGER OPERATING INSTRUCTIONS 17
Overload Protection 18
MAINTENANCE 18
Transport and Storage 18
WARRANTY STATEMENT 21
GENERAL CERTIFICATE OF CONFORMITY 23

5
JCB-20OS
Instruction & User Manual
Read all safety warnings, instructions and
specifications provided with this power
tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or serious
injury. Save all warnings and instructions for
future reference.
WARNING!
The term “power tool” in the warnings refers to
your mains operated (corded) power tool or battery
operated (cordless) power tool.
1. Work area safety
m Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
m Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the dust or
fumes.
m Keep children and bystanders away while
operating a power tool. Distractions can
cause you to lose control.
2. Electrical safety
m Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric
shock.
m Avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There
is an increased risk of electric shock if your body
is earthed or grounded.
m Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
m Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep the cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of
electric shock.
m When operating a power tool outdoors,
use an extension cord suitable for
outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
m If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected supply.
Use of an RCD reduces the risk of electric shock.
3. Personal safety
m Stay alert, watch what you are doing
and use common sense when operating
a power tool. Do not use a power tool
while you are tired or under the influence
of drugs, alcohol or medication. A moment
of inattention while operating power tools may
result in serious personal injury.
m Use personal protective equipment.
Always wear eye protection. Protective
equipment such as a dust mask, non-skid safety
shoes, hard hat or hearing protection used for
appropriate conditions will reduce personal
injuries.
m Prevent unintentional starting. Ensure
the switch is in the off position before
connecting to power source and/or
battery pack, picking up or carrying the
tool. Carrying power tools with your finger on
the switch or energising power tools that have
the switch on invites accidents.
GENERAL POWER TOOL SAFETY WARNINGS

6JCB-20OS
Instruction & User Manual
m Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a rotating part of
the power tool may result in personal injury.
m Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the power tool in unexpected
situations.
m Dress properly. Do not wear loose
clothing or jewellery. Keep your hair and
clothing away from moving parts. Loose
clothes, jewellery or long hair can be caught in
moving parts.
m If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce dust-
related hazards.
m Do not let familiarity gained from
frequent use of tools allow you to become
complacent and ignore tool safety
principles. A careless action can cause severe
injury within a fraction of a second.
4. Power tool use and care
m Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job better
and safer at the rate for which it was designed.
m Do not use the power tool if the switch
does not turn it on and off. Any power
tool that cannot be controlled with the switch is
dangerous and must be repaired.
m Disconnect the plug from the power
source and/or remove the battery pack,
if detachable, from the power tool before
making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
m Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands of
untrained users.
m Maintain power tools and accessories.
Check for misalignment or binding of
moving parts, breakage of parts and any
other condition that may affect the power
tool’s operation. If damaged, have the
power tool repaired before use. Many
accidents are caused by poorly maintained power
tools.
m Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier
to control.
m Use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to
be performed. Use of the power tool for
operations different from those intended could
result in a hazardous situation.
m Keep handles and grasping surfaces
dry, clean and free from oil and grease.
Slippery handles and grasping surfaces do not
allow for safe handling and control of the tool in
unexpected situations.
5. Battery tool use and care
m Recharge only with the charger specified
by the manufacturer. A charger that is suitable
for one type of battery pack may create a risk of
fire when used with another battery pack.
m Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury and fire.

7
JCB-20OS
Instruction & User Manual
m When the battery pack is not in use, keep
it away from other metal objects, like
paper clips, coins, keys, nails, screws or
other small metal objects that can make a
connection from one terminal to another.
Shorting the battery terminals together may
cause burns or a fire.
m Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritation or burns.
m Do not use a battery pack or tool that is
damaged or modified. Damaged or modified
batteries may exhibit unpredictable behaviour
resulting in fire, an explosion or risk of injury.
m Do not expose a battery pack or tool to
fire or excessive temperature. Exposure
to fire or temperature above 130 °C may cause
explosion.
m Follow all charging instructions and do
not charge the battery pack or tool
outside the temperature range specified
in the instructions. Charging improperly or
at temperatures outside the specified range may
damage the battery and increase the risk of fire.
6. Service
m Have your power tool serviced by a
qualified repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
m Never service damaged battery packs.
Service of battery packs should only be
performed by the manufacturer or authorized
service providers.

8JCB-20OS
Instruction & User Manual
This power tool is intended to
function as a sander. Read all safety
warnings, instructions, illustrations and
specifications provided with this power
tool. Failure to follow all instructions may result
in electric shock, fire and/or serious injury.
Operations such as grinding, wire
brushing or cutting-off are not
recommended to be performed with
this power tool. Operations for which the
power tool was not designed may create a
hazard and cause personal injury.
m Proper safety gloves are also recommended.
m Use the tool for dry sanding only.
m Use clamps or a vice to secure your work
whenever possible.
m Use perforated hook-and-loop sandpaper
with the prescribed dimensions.
m A sanding sheet that has been used for metal
should not be used on other materials.
m Do not run the machine with any part of the
casing missing or damaged.
m Never switch on the sander under load and
place it down only after the head has come
to a complete stop.
m Vibrations can injure the nerves in hands &
arms. Keep exposure to vibrations as short
as possible.
m When carrying out work, always ensure that
you have a stable standing position.
m Wear ear protectors. Exposure to noise
can cause hearing loss.
m Wear eye protection. Wear goggles
to prevent eyes from exposure to flying
particles.
m Wear suitable gloves to protect
hands. Use of the power tool may expose
the operator’s hands to hazards including
cuts, abrasions and heat
m Wear a dust mask. Take protective
measures against inhalation of dust. Some
materials can contain toxic materials. Also
work with dust/ chip extraction when
connectable.
Additional Safety Rules For
Orbital Sanders
m Hold the power tool by insulated
gripping surfaces, when performing
an operation where the cutting
accessory may contact hidden wiring.
Cutting accessory contacting a “live”
wire may make exposed metal parts of
the power tool “live” and could give the
operator an electric shock.
m Do not use accessories which
are not specifically designed
and recommended by the tool
manufacturer. Just because the accessory
can be attached to your power tool, it does
not assure safe operation.
m The rated speed of the accessory
must be at least equal to the
maximum speed marked on the
power tool. Accessories running faster
than their rated speed can break and fly
apart.
m The outside diameter and the
thickness of your accessory must be
within the capacity rating of your
power tool. Incorrectly sized accessories
cannot be adequately guarded or controlled.
SAFETY WARNINGS COMMON FOR
SANDING

9
JCB-20OS
Instruction & User Manual
m Do not use a damaged accessory.
Before each use inspect the accessory
such as abrasive wheels for chips
and cracks, backing pad for cracks,
tear or excess wear, wire brush for
loose or cracked wires. If the power
tool or accessory is dropped, inspect
for damage or install an undamaged
accessory.
m After inspecting and installing an
accessory, position yourself and
bystanders away from the plane of
the rotating accessory and run the
power tool at maximum no-load
speed for one minute. Damaged
accessories will normally break apart during
this test time.
Kickback and Related Warnings
m Kickback is a sudden reaction to a pinched
or snagged rotating wheel, backing pad,
brush or any other accessory. Pinching
or snagging causes rapid stalling of the
rotating accessory which in turn causes the
uncontrolled power tool to be forced in
the opposite direction of the accessory’s
rotation at the point of the binding.
m For example, if an abrasive wheel is snagged
or pinched by the workpiece, the edge of
the wheel that is entering into the pinch
point can dig into the surface of the material,
causing the wheel to climb or kick out. The
wheel may either jump toward or away
from the operator, depending on direction
of the wheel’s movement at the point of
pinching. Abrasive wheels may also break
under these conditions.
m Kickback is the result of power tool misuse
and/or incorrect operating procedures or
conditions and can be avoided by taking
proper precautions as given below.
m Maintain a firm grip on the power
tool and position your body and
arm to resist kickback forces. Never
place your hand near the rotating
accessory. Accessory may kickback over
your hand.
m Do not position your body in the
area where power tool will move if
kickback occurs. Kickback will propel the
tool in direction opposite to the wheel’s
movement at the point of snagging.
m Use special care when working
corners, sharp edges etc. Avoid
bouncing and snagging the accessory.
Corners, sharp edges or bouncing have a
tendency to snag the rotating accessory and
cause loss of control or kickback.

10 JCB-20OS
Instruction & User Manual
CHARGER SAFETY
m To reduce risk of injury, only charge
JCB rechargable batteries. The
charger and battery packs are specifically
designed to work together. Other types of
batteries may burst causing fire and personal
injury.
m Do not allow any liquid to get inside
the charger. Electric shock may result.
m Do not expose the charger to rain or
snow.
m Under certain conditions with the
charger plugged into the power
supply, the exposed charging contacts
inside the charger can be shorted by
foreign materials. Foreign materials of a
conductive nature such as, but not limited
to, steel, wool, aluminium foil or any buildup
of metallic particles should be kept away
from charger cavities.
m Always unplug the charger from
the power supply when there is no
battery in the cavity.
m Unplug the charger from the power
supply before attempting to clean.
m Do not operate the charger with a
damaged cord or plug. Have them
replaced immediately.
m JCB chargers are designed to
operate on standard household
supply voltages. Check the rating
plate of the charger matches your
local supply voltage. (Note: the dual
charger can additionally operate
on worldwide 120 V AC 60Hz input
voltage). Do not attempt to use the
chargers on any other supply voltage.
m This appliance can be used by
children aged from 8 years and above
and persons with reduced physical,
sensory or mental capabilities or
lack of experience and knowledge
if they have been given supervision
or instruction concerning use of
the appliance in a safe way and
understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be
performed by children without supervision.
m If the supply cord is damaged, it can
only be replaced by the manufacturer
or an authorised service agent to
avoid a potential hazard.
Read all safety warnings, instructions
and specifications provided with the
charger. Failure to follow all instructions
listed below may result in electric shock, fire
and/or serious injury. Save all warnings
and instructions for future reference.
WARNING!

11
JCB-20OS
Instruction & User Manual
COMPONENT LIST
1. ABRASIVE SHEET (SANDPAPER)
2. SANDING DISC
3. ON/ OFF SWITCH
4. DUST EXTRACTOR PIPE
5. CHARGER* - refer to page 12 for further
information
6
7
8
Battery size shown for
illustrative purposes only
Standard JCB-18VFC charger illustrated,
additional chargers available.
1
2
3
9
4
5
6. BATTERY PACK*- refer to page 12 for further
information.
7. BATTERY TEST BUTTON AND
CHARGE INDICATOR*
8. BATTERY RELEASE BUTTON
9. DUST COLLECTOR BAG
*If applicable

12 JCB-20OS
Instruction & User Manual
TECHNICAL DATA
Input Voltage 20V dc (from attached battery)
Speed 0-10000/min
Sanding Disc Diameter 125mm
Pad Fixing Type Hook and Loop Fastening System
Motor Type Brushed
Motor Protection Automatic over-current cut-off
Product Weight (body only) 0.98kg
LITHIUM ION BATTERY TECHNICAL DATA
Battery
Code
Battery
Size
Number
of cells Voltage Battery Capacity
Charge Time
(Fast Charger:
JCB-20VFC)
Charge Time
(Super Fast Charger:
JCB-20VSFC)
Charge Time
(Dual Charger:
JCB-20DC)
JCB-20-15LI Small 5 20V 1.5Ah 30 mins 20 mins 25 mins
JCB-20-20LI Small 5 20V 2.0Ah 45 mins 30 mins 35 mins
JCB-20-30LI Large 10 20V 3.0Ah 65 mins 40 mins 45 mins
JCB-20-40LI Large 10 20V 4.0Ah 90 mins 55 mins 60 mins
JCB-20-50LI Large 10 20V 5.0Ah 110 mins 65 mins 75 mins
Charger Fuse Rating: T2.4A T3.15A T5A
Times given as a guide only. Battery charge and discharge times dependant on age, usage and condition.
Charger Code Input Data Output Data
JCB-20VFC AC 120 V, 60Hz, 70W 14.4 -20V d.c. 2.4A
JCB-20VSFC AC 120 V, 60Hz, 105W 14.4 -20V d.c. 4.0A
JCB-20DC AC 120 V, 60Hz, 200W 20.5V d.c. 2 x 3.5A
CHARGER TECHNICAL DATA

13
JCB-20OS
Instruction & User Manual
Wear hearing protection.
The effects of noise can cause a loss of
hearing. The above-mentioned noise
emission values were measured in
accordance with a standardised test
procedure and can be used to compare one
power tool with another.
The above-mentioned noise emission
values can also be used for the preliminary
assessment of exposure.
WARNING!
The noise emissions during the actual use of
the power tool may differ from the above-
mentioned values depending on the power
tool being used, in particular on the type of
workpiece being processed.
Try to keep emissions as low as possible, for
example by limiting your working time. In
this regard, all the operational cycle phases
must be taken into consideration (such as
the times when the tool is switched off or
running idle).
WARNING!
NOISE INFORMATION
A-Weighted Sound Pressure (LpA)76 dB(A)
A-Weighted Sound Power (LwA)87 dB(A)
KpA & KwA 3 dB(A)
Wear ear protection when sound pressure is over 80 dB(A)
Total noise values determined according to IEC 62841-2-4.

14 JCB-20OS
Instruction & User Manual
The vibration emission value of the power
tool is tested under IEC 62841-1 and IEC
62841-2-4, and can vary during operation
depending on the following usage conditions:
WARNING!
m How the power tool is used and the
materials being cut, sanded or drilled.
m The power tool being in good condition and
well maintained.
m Using the correct accessory for the power
tool and ensuring it is sharp and in good
condition.
m The tightness of the grip on the handles and
if any anti-vibration accessories are used.
m The power tool being used as intended by
its design and these instructions.
m The declared vibration total value may also
be used in a preliminary assessment of
exposure.
THIS POWER TOOL MAY CAUSE
HAND-ARM VIBRATION SYNDROME
(HAVS) IF USAGE IS NOT
ADEQUATELY MANAGED.
To be accurate, an estimation of exposure
level in the actual conditions of use should
also take account of all parts of the operating
cycle. These include times when the power
tool is switched off and when it is running
idle but not actually doing work. This may
significantly reduce the total exposure level
over the working period, helping to minimize
your vibration exposure risk.
WARNING!
m ALWAYS use sharp and undamaged
accessories, bits, chisels, drills and blades.
m Maintain this power tool in accordance with
these instructions and keep well lubricated
(where appropriate).
m If the power tool is to be used regularly then
invest in anti-vibration accessories.
m Avoid using power tool in temperatures of
10°C or less.
m Plan your work schedule to spread any high
vibration power tool use across a number
of days.
VIBRATION INFORMATION
Vibration total values (triax vector sum) determined according to IEC 62841-1
and IEC 62841-2-4
Sanding Vibration Emission
Value (ah,DS)9.5 m/s2
Uncertainty (K) 1.5 m/s2

15
JCB-20OS
Instruction & User Manual
OPERATING INSTRUCTIONS
Intended Use
This orbital sander is intended for dry sanding
of wood, plastic, metal and filler material as
well as painted surfaces.
The power tool must not be modified or used
for any other purposes than the ones described
in these instructions.
ON/OFF Switch (3)
m On: Shift the ON/OFF switch slider to “I”
position.
m Off: Shift the ON/OFF switch slider to “O”
position.
Changing a Sanding Sheet
The sanding sheet (1) and sanding pad (2) are
provided with a hook and loop attachment
system to allow quick and easy changing of
sanding and polishing sheets.
Ensure the hook and loop surfaces of the
sanding pad tool plate, and chosen sheet are
as clean as possible, and free from any large
debris prior to mounting the sheet.
NOTE
To attach a new sheet:
m Align the edge of the disc with the edge of
the pad, and ensure the sheet is centered in
the plate.
m Apply pressure to the disc, ensuring it is
securely fixed across the entire sanding pad.
To remove a disc:
m Lift one corner of the sheet and pull off from
the sanding pad tool plate.
Dust Suction
m Efficiency and durability of sandpaper are
much improved by dust suction through the
apertures in the disc and sandpaper.
m The dust collector bag (9) is a push fit onto
the dust extractor pipe (4).
m Dust collector bag must be emptied
regularly.
m Ensure waste from the dust bag is disposed
of as per local regulatory guidelines.
Dust Extractor Pipe (4)
m For sanding jobs that generate increased
levels of dust, use a vacuum cleaner.
m Disconnect the dust collector bag and
connect a pipe from your vacuum cleaner
instead.
Before using the power tool on metal
surfaces, always remove the dust bag from
the outlet. Sparks may ignite the dust or the
bag.
WARNING!
Prior to any assembly, adjustment or cleaning
operations, always disconnect the power
tool either from the power supply or
remove the battery as appropriate.
WARNING!

16 JCB-20OS
Instruction & User Manual
Sanding Surfaces
m Place the machine flat on the workpiece,
ensuring the entire anding disc makes even
contact.
m Power on the sander.
m Apply uniform sanding pressure.
m Adjust your pressure to suit the work as
required.
Less sanding pressure increases the sanding
capacity and protects the machine and the
sanding paper.
NOTE
The removal capacity and the sanding pat-
tern are determined mainly by the selection
of the Sand paper (grade), the speed of the
sanding pad and the application pressure.
NOTE
Rough Sanding
m Attach a sand paper with coarse grain.
m Apply only light sanding pressure to achieve
increased material removal.
For faster material removal, do not increase
pressure on the tool, instead use a coarser
sanding sheet.
NOTE
Fine Sanding
m Attach a sand paper with fine grain.
m With moderate pressure, move the
machine in a circular pattern or alternately
in lengthwise and crosswise directions over
the workpiece.
Do not tilt the machine during operation.
This will apply uneven pressure, and may
cause damage to the work piece (e.g. when
sanding veneer).
NOTE
To avoid marring the finished surface, switch
off the machine, and only lift it from the
workpiece when it has come to a stop.
NOTE
Orbital Sanding
m Guide your sander parallel to the working
surface and move it in circles or in a cross
pattern.
m The speed of the orbital motion of the
sanding pad is reduced as applied pressure
increases.
Selecting The Right Grade Of
Sandpaper
m Use coarse grits to sand down rough
finishes, medium grit to smooth the work
and fine grit to finish off.
m The higher the grade number, the finer the
grit.
m For rough work start with a low grade of
grit. (e.g. 60 grit) and change to a higher,
finer grade (e.g. 120 grit) for finishing.
m If you use a fine grade for rough surfaces the
sandpaper will clog and need changing more
frequently.
The correct grade for your application will
depend on sanding speed, material and pres-
sure applied. Always test on a scrap piece of
material if possible.
NOTE

17
JCB-20OS
Instruction & User Manual
BATTERY AND CHARGER OPERATING
INSTRUCTIONS
Battery
Make sure the ON/OFF Switch slider (3) is
not set to the ON position (I) when inserting
or removing the battery. Use only JCB
batteries: JCB-20-15LI, JCB-20-20LI, JCB-
20-30LI, JCB-20-40LI and
JCB-20-50LI.
NOTE
m Do not use excessive force when
inserting the JCB battery in the
power tool. An incorrectly connected
battery can damage the battery terminals or
the battery socket on the power tool.
m Use the button (7) on the battery to check
the charging status; 4 red LEDs indicates
fully charged, where 1 indicates low battery
charge status.
Charging The Battery
After charging for the first time, ensure the
battery is completely discharged before
placing on charge again. Repeat this charging
and discharging cycle 4 to 5 times to ensure
battery is correctly conditioned.
WARNING!
m Place the battery charger on a level and
stable surface. Plug the charger into a
suitable power point.
m Connect the battery pack to the charger so
that it clicks into place.
m Refer to the Battery Charge Level table
below for battery charger status as indicated
by LED lights.
m When the battery pack is fully charged,
unplug the battery charger from the power
supply and remove the battery pack from
the charger.
Battery Charge Level
Red
LED
Green
LED Battery Charge Status
Charger is connected to
mains power
Connected battery is
charging
Connected battery is fully
charged
Connected battery has a
charging fault
Charger is outside correct
operating temperature
range (<0˚C / >40˚C)
If the LEDs on the charger do not come on
when charging:
m Check that mains plug is properly connected
to the power supply and the supply is
switched on.
m Check that the battery is correctly inserted
in the charger.
Connecting the battery to the
power tool
m Connect the battery to the battery socket
on the power tool so that it clicks into place.
Removing the battery from the
power tool
m Press the battery release button (8) and
remove the battery from the power tool.

18 JCB-20OS
Instruction & User Manual
Overload protection
m When the power tool is overloaded
(abnormal high current), the integral
electronic control system will automatically
protect the motor by switching off the
power supply.
m Set the ON/OFF Switch slider to the OFF
(O) position and wait one or two seconds
for the electronics to reset, then restart the
power tool.
Do not hold the work piece with your
hands.
WARNING!
MAINTENANCE
Cleaning
Switch off the power tool and disconnect
the power (remove battery/unplug) before
cleaning and maintenance. This helps avoid
the risk of electric shocks and accidental
starting.
WARNING!
m Wipe the power tool with a dry or damp
cloth. Do not use a wet cloth. Do not
use detergent that contains solvent or
corrosive, abrasive additives. This risks
damaging the surfaces of the power tool.
m Clear the power tool vents and the blade
clamp assembly of dust and dirt after each
use. Do not clean ventilation holes by
inserting sharp objects in them, such
as screwdrivers and other similar
objects.
m Stubborn contamination in areas hard to
access can be removed with compressed air
(max 3. bar).
m Regularly check all fasteners, screws and
bolts to make sure that they are tight.
Tighten any loose screws immediately or
serious injury could occur.
Brush inspection
m Brush inspection and replacement should
only be performed by an authorised JCB
service centre.
Power tool lubrication
m JCB power tools are properly lubricated in
the factory and are ready for use.
Repairs and servicing
m Power tools should be subject to periodic
preventative maintenance to ensure
continued safe and reliable operation.
m If the power tool requires servicing or
repair (eg loss of power) do not continue to
operate the power tool.
m Please return the power tool to an
authorized JCB service agent or repair
centre for service and repair using factory
supplied identical replacement parts.
Never open the power tool. The power
tool has no internal parts that the user can
service or repair. Never try to repair the
power tool yourself. Take to an authorised
service centre.
WARNING!
Transport and Storage
m If the power tool will remain unused for any
length of time, it should be stored in the
original packaging.

19
JCB-20OS
Instruction & User Manual
m Store the power tool in a dry, frost-free,
well ventilated place with a temperature of
no more than 40°C.
m Keep all tools out of the reach of children.
m Always switch off the power tool and
disconnect it from the power supply
(remove the battery/unplug the power
cord) before transport.
m Always carry the power tool using the
purpose-designed handle.
m Ensure that the power tool is not at risk
of tipping over or exposed to excessive
vibration and shocks during transport,
especially if the tool will be transported by
car or other vehicle.

20 JCB-20OS
Instruction & User Manual
