JD Williams Ltd. CK247 User manual

Page 1 of 10
CK247 JDW STEAM MOP
Instruction Manual

Page 2 of 10
Plug Wiring (UK)
This appliance is fitted with a BS1363 13 amp plug. If you have to replace the
fuse, only those that are BSI approved to BS1362 and with a rated current of 13
amps should be used. Spares fuses are available from electrical stores. If the
plug outlets in your home are not suitable for the plug of this product, the plug
must be removed and disposed of safely as insertion of the plug into a socket is
likely to cause electric hazard.
A replacement plug should be wired according to the following instructions.
If in doubt, contact a qualified electrician.
This appliance must be earthed. The wires in the cord set are coloured in the
following way: BLUE-NEUTRAL. BROWN-LIVE, GREEN&YELLOW-EARTH
The wire that is coloured blue must be connected to the terminal that is
marked with the letter N.
The wire that is coloured brown must be connected to the terminal that is
marked with the letter L.
The wire that is coloured green & yellow must be connected to the terminal
in the plug that is marked with the letter E or marked with symbol.
If the supply cord is damaged a qualified person must replace it in order to
avoid a hazard.
Environment
The "crossed-out wheeled bin" symbol indicates that this product can be
recycled. Do not dispose of with household waste. Please take the Steam
Mop to your local refuse/collection site centre. If you are unsure of where
you local refuse centre is please contact your local authority.

Page 3 of 10
Safety instructions
SAFETY GUIDELINES-DEFINITIONS
It is important for you to read and understand this manual. The information it contains
relates to protecting YOUR SAFETY and PREVENTING PROBLEMS. The symbols
below are used to help you recognize this information.
DANGER：Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING：Indicates a potentially hazardous situation which, if not avoided, could result
in death or serious injury.
CAUTION：Indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury.
NOTICE：Used without the safety alert symbol indicates a potentially hazardous situation
which, if not avoided, may result in property damage.
Residual risks：
Additional residual risks may arise when using the tool which may not be included in the
enclosed safety warnings. These risks can arise from misuse, prolonged use, etc.
Even with the application of the relevant safety regulations and the implementation of safety
devices, certain residual risks cannot be avoided. These include:
Injuries caused by touching any moving parts.
Injuries caused by touching any hot parts.
Injuries caused when changing any parts or accessories.
Injuries caused by prolonged use of the appliance. When using any appliance for
prolonged periods ensure you take regular breaks.
WARNING：Read all safety warnings and all instructions. Failure to follow the warnings
and instructions listed below may result in electric shock, fire and/or serious injury.
Warning: When using electrical appliances, basic safety precautions, including the
following, should always be followed to reduce the risk of fire, electric shock, personal
injury and material damage.
Read all of this manual carefully before using the appliance.
The intended use is described in this manual. The use of any accessory or attachment
or the performance of any operation with this appliance other than those
recommended in this instruction manual may present a risk of personal injury.
Retain this manual for future reference.

Page 4 of 10
Using your appliance
For Household use only.
Do not direct steam at people, animals, electrical appliances or electrical outlets.
Do not expose to rain.
Store indoors.
Do not immerse the appliance in the water.
Do not leave the appliance unattended. Keep children away from unit while in use.
Do not leave the appliance connected to an electrical outlet when not in use.
Never pull the power cord to disconnect the appliance from the socket. Keep the
appliance cord away from heat, oil and sharp edges.
Do not handle steam cleaner with wet hands.
Do not pull or carry by cord, use cord as a handle, close door on cord, pull cord around
sharp corners or expose cord to heated surfaces.
Do not use appliance in an enclosed space filled with vapor given off by oil-based
paint thinner, some moth-proofing substances, flammable dust, or other explosive or
toxic vapors.
Do not use on leather, wax polished furniture or floors, synthetic fabrics, velvet or other
delicate, steam-sensitive materials.
Do not use on any unsealed hard floor surfaces. Additionally, on surfaces that have
been treated with wax or some no-wax floors, the sheen may be removed by the heat
and steam action. It is always recommended to test an isolated area of the
surface to be cleaned before proceeding. We also recommend that you check the
use and care instructions from the floor manufacturer.
Never put de-scaling, aromatic, alcoholic or detergent products into the steam mop, as
this may damage it or make it unsafe for use.
Do not operate the appliance with a damaged cord or plug or after the appliance
malfunctions, or has been damaged in any manner.
The mops tank should only be with cool/cold water and when the appliance is
disconnected from the power supply..
Use a funnel or measuring jug when filling to avoid any spills..
Never fill the tank with hot water, and do not over fill
If the circuit breaker activates while using the steam function, discontinue product use
immediately and contact the customer support center. (Beware of the risk of electrical
shock.)
The appliance emits very hot steam to sanitize the area of use. This means that the
steam head and cleaning pads get very hot during use.
NEVER LEAVE THE STEAM MOP OPERATING AND STATIONAR AS A
PERMANENT WITNESS MARK MAY RESULT ON YOUR FLOORING.
Do not use for any purpose other than described in this manual.
Caution: Always wear suitable shoes when using your steam mop and when changing
the accessories on your steam mop. Do not wear slippers or open-toed footwear.
Care should be taken when using this appliance. DO NOT touch any parts which may
become hot during use.

Page 5 of 10
Do not use when micro-fiber cleaning pad is not installed correctly.
Safety of others：
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning the use of the appliances
by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
STANDARD FEATURES
A Handle
B Handle Tube 1
C Handle Tube 2
D Measuring Cup
E Cleaning Tool
F Main Body
G Steam Head
H Microfiber Pad x 2
I Carpet Glider
Product Components
1 Handle
2 Cord Hook
3 Handle Socket
4 Handle Tube 1
5 Tube Connector
6 Handle Tube 2
7 Power Switch
8 Water Tank Release Catch
9 Water Tank
10 Water Tank Filler Cap
11 Power Cord
12 Swivel Head
A
B
C
D
E
F
G
H
I
1
2
3
4
5
6
2
7
8
9
10
11
12

Page 6 of 10
Features and Specifications
Features
Removable water tank；
Continuous steam output (up to 5 minutes continuous working):- 26g/min (avg.)
Steam output time：14 minutes (full water tank)
Red (warm-up) and blue (working) indicator light
Pressure relief protection, maintaining constant pressure
Wide range of angular movement and rotation of head

Specification
Rated voltage：230V
Rated frequency：50Hz
Output power：1300W (+5%,-10%)
Water Tank Capacity：350mL
Waterproof level：IPX4
ASSEMBLY –refer to Product Component Diagram for Part Numbers
NOTE: Each steam mop is 100% tested in the factory to ensure product performance and
safety. When assembling your new steam mop for the first time you may notice water residue
inside of the unit.
WARNING: Before attempting any of the following operations, make sure that the
appliance is switched off and unplugged and that the appliance is cold and contains
minimal or no water.
Attaching the handle
Slide the Handle Tube 4 into the Handle 1 until it clicks into place;
Slide the Handle Tube 6 into the Tube Connector 5 until it clicks into place;
Slide the Handle Tube 6 with Handle installed into the socket on top of the main body, until it
clicks into place;
The handle assembly can be removed from the steam mop body for easy storage by pressing
the Handle Tube button on the rear of the socket on the Main Body.

Page 7 of 10
Attaching the steam head
Slide the stem on the bottom of the main body into the
socket on the Steam Head 12 until the Steam Head
clicks into place.
The Steam Head can be removed from the Main Body
by pressing the button on the back of the Steam Head.
Attaching a cleaning pad
The Steam Head has a series of hooks on the
underside. Place the Micro-fiber Cleaning Pad on the
floor and press the Steam Head down onto it –they
will bond tightly.
To remove the pad, place the toe of your shoe onto the
Cleaning Pad removal tab and hold while lifting the
Steam Mop up.
Attaching Carpet Gilder
Press the Steam Mop, with Microfiber Cleaning Pad
fitted to Steam Head, down onto the Carpet Glider until
it clicks into place.
Place the toe of your shoe onto the Cleaning Pad
removal tab and lift the Steam Mop to remove the
Carpet Glider.
OPERATION
1. Filling the water tank
Remove the Water Tank 9 from the Main Body by
pressing the Release Catch 8. Unscrew the Water
Tank Filler Cap 10, and using the Measuring Cup add
350mL water to the tank. Replace the Filler Cap and
tighten.
Install the Water Tank back onto the Main Body until it
clicks into place.
2. Plug in the appliance into a grounded outlet.
When the appliance is switched on, the indicator light will turn red; this indicates preheating
mode.If the light does not illuminate, please check the "Troubleshooting" section for
assistance.
The Steam Mop has a warm-up time of 30 seconds. After the completion of the warm-up, the
indicator color turns blue. The Steam mop is ready for use.

Page 8 of 10
NOTICE: If power is turned off in the middle of the warm-up, or after the warm-up is
complete, the product may repeat the above warm-up operation, depending on how
long the power has been off.
The Steam Head has a wide range of motion –it can clean into corners, and also under low
objects.
CLEANING AND MAINTENANCE
WARNING: BE SURE THAT THE UNIT IS DISCONNECTED FROM THE ROWER
OUTLET WHEN PERFORMING CLEANING
Drain the remaining water in the tank and clean the tank after every use.
How to decalcify the Water Tank interior:
To clean calcium deposits that build up inside the Water Tank , add one or two tablespoons of
white vinegar to a full Water Tank close the Water Tank Cap and then shake the contents.
DO NOT TURN THE STEAMER ON.
Cleaning procedure to remove lime scale:
If your steam mop begins to produce steam more slowly than usual or stops producing steam,
you may need to remove lime scale. Lime scale can develop over time on the metal parts
and greatly affect mop performance.
It is necessary to remove lime scale on regular basis every 25-50 times you use a full tank of
water or at least once a month, especially in areas with hard water.
The frequency of lime scale removal depends upon the hardness of your tap water and how
often you use the steam mop.
Follow this procedure to remove lime
By the use of cleaning tool
1. Check to ensure that the power supply is disconnected
before beginning.
2. Use the cleaning tool to remove the scale, as shown.
3. Move and rotate the cleaning tool to clean the vents.
Continue until all scale is removed from the outlet holes.
By using cleaning solution
1. Prepare a solution of 1/3 white vinegar and 2/3 tap water and add to the water tank.
2. Secure and position the unit to ensure that the steam released is aimed away from the

Page 9 of 10
floor or surrounding objects and surfaces.
3. Plug the unit in, turn the unit ON by pressing the power switch, and allow the unit to
produce steam unit the vinegar/water solution in used up.
4. Repeat the above procedure as many times as necessary until a normal steam flow
rate is achieved.
5. Fill the water tank with fresh water and rinse out.
6. Refill the water tank with fresh water, attach to the unit and release steam through the
system unit the water tank is empty.
WARNING:Don't leave the steamer unattended during the lime scale removal
process and/or while in use.
NOTICE: Perform a test cleaning on a suitable isolated area after each lime scale removal to
ensure that there is no debris left in the system.
This product contains no serviceable parts. Do not try to repair it yourself. Any servicing that
requires disassembly other than cleaning must be performed by a qualified appliance repair
technician.
ALL servicing should be done by an authorized service representative.
If the supply cord is damaged, it shall be replaced by the manufacturer or its
service agent or similarly qualified person in order to avoid a hazard.
Cleaning Microfiber Pad
Machine washable on "warm" setting. Always use a mild detergent.
For best care results, lay flat to dry.
IMPORTANT ：Allow the steamer to fully cool down before performing any
maintenance or troubleshooting checks.
IMPORTANT：Never use bleach or fabric softener when washing the Microfiber
Cleaning Pad.
STORAGE
NOTICE：After use, take out the water tank and, before turning off the power, let the product
work for a while until there is no steam emitted. Once it stops steaming it is ready to be stored.
After the Steamer is used, turn power off and then unplug the power cord.
Empty any residual water in the tank and clean the external surface with a dry cloth.
Once the Steam Mop cools down fully, wipe it over with a dry cloth.
Remove the cleaning pad and wash it so that it will be ready for next use.
Store the Steam Mop in a protected, dry area. Retain water funnel and measuring cup
for future use. Store the cord by winding it loosely around the cord hooks on the side of
the handle.
Keep out of reach of children.

Page 10 of 10
TROUBLESHOOTING
Use this troubleshooting guide as a first step to resolve any problems you may be
experiencing.
All servicing should be done by an authorized service representative.
WARNING: TO REDUCE RISK OF PERSONAL INJURY UNPLUG STEAMER BEFORE
SERVICING AND ALLOW TO COOL
PROBLEM
POSSIBLE REASON
POSSIBLE SOLUTION
Reduced steam or no steam
Water tank may be empty
Fill water tank
Steam nozzle may be
blocked
Clean steam nozzle
There is no power to the unit
Make sure unit is plugged in
Not switched on
Press power button
Unit will not turn on
Blown fuse or breaker
Replace fuse or reset breaker
in home
Power cord not plugged in
Plug cord into a working
circuit
Internal fuse is blown
Contact customer services
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
