Jefferson OLYMPUS User manual

OLYMPUS
OLYMPUS
User Manual
v.1.2
2.8kVA Recoil Start With Electronic Ignition & AVR
JEFGENPET22

2
USER MANUAL
2.8kVA Petrol Generator
JEFGENPET22
www.jeffersontools.com
2. Parts Identification
1. Contents
1. Contents
2. Parts Identification
3. Safety Information
4. Checking the Generator Prior to Use
5. Starting the Generator
6. Connecting Consumers to the Generator
7. Stopping the Generator
8. Transportation and Storage
9. Operation Environment
10. Maintenance
11. Troubleshooting
12. Parts List & Diagram
13. Circuit Diagram
Limited Warranty Statement
EC Declaration of Conformity
2
2
3
4
4
5
5
5
5
6
7
8
10
11
12
1. Fuel cap
2. Engine On / Off
3. Power light
4. Circuit breaker
5. DC reset
6. AC Output
7. Earth connection
8. Voltage Meter
9. Recoil Handle
10. Engine
11. Air lter
12. Fuel tank

3
USER MANUAL
2.8kVA Petrol Generator
JEFGENPET22
www.jeffersontools.com
1. The exhaust gas is poisonous, never use a generator indoors or in an attached garage. Always run your
generator outdoors in a well-ventilated area. Keep the generator at least 1 meter (3 feet) away from buildings and
other equipment during operation.
2. Place generator on level ground to operate.
3. The load must be kept within rating stated on generator rating plate, overloading will damage the unit or shorten
its life.
4. Running the engine at excessive speeds is dangerous and will damage the engine.
5. Do not tamper with parts, which may increase or decrease the governed speed.
6. When using extension cords, please make sure they are grounded with sufcient wire gauge for the application.
Heavy-duty outdoor rated cords will handle household appliance loads.
7. The exhaust system gets hot enough to ignite some materials. Do not operate the engine near combustible
materials.
8. Do not store fuel indoors or try to refuel a generator while it is still running. Clean up any spilled fuel before
restarting the engine.
9. The mufer becomes very hot during operation and remains hot for a while after stopping the engine. Be careful
not to touch the mufer while it is hot. Let the engine cool before storing the generator indoors.
10. Turn off all equipment powered by the generator before shutting down your generator.
11. To prevent electric shock or re, never use the machine in rain or snow or connect the generator to a live circuit.
12. Do not connect the generator to another power supply outlet.
13. Protection against electrical shock depends on circuit breakers specically matched to the generating set. If the
circuit breakers require replacement they must be replaced with a circuit breaker having identical ratings and
performance characteristics.
14. Ensure the generator does not have any damaged hoses, loose or missing clamps, damaged tank or cap before
use. All defects should be corrected before use.
15. To prevent surging that may possibly damage equipment, do not allow the engine to run out of fuel when
electrical loads are applied.
16. Before transporting the generator ensure that all the fuel is drained to prevent leakage.
17. Unit must meet operating speed before electrical loads are connected. Always disconnect any loads before
turning off the generator.
18. Keep children and pets away from the generator at all times.
19. The installation and major repair of the generator should only be carried out by trained and fully qualied
engineers.
20. Ensure appropriate ear protection is worn when working in close proximity to the generator.
21. When using extension cables or mobile electric net use the following guidelines:
3. Safety Information
Cable Diameter Maximum Length
1.5 60m
2.5 100m
WARNING:
• Do not cover the unit when in use.
• The unit should be earthed using 4mm diameter grounding wire.
• Do not use the generator in wet or damp conditions.
• Store the generator in well-ventilated area with an empty fuel tank.

4
USER MANUAL
2.8kVA Petrol Generator
JEFGENPET22
www.jeffersontools.com
4. Checking the Generator Prior to Use
•Check the fuel level and top up with unleaded petrol if necessary. Do not overll the fuel tank (there should be no
fuel in the ller neck).
• After refuelling make sure the tank cap is closed properly and securely. Be careful not to spill fuel when refuelling
and clean up any spilled or excess fuel. Spilled fuel or fuel vapour can ignite when the engine
is started.
• The generator has a maximum fuel capacity of 15 Litres
• Do not fill above the fuel filter top.
• Check the engine oil level and top up if necessary as shown in Fig.1.
Fig.1
5. Starting the Generator
WARNING:
• Make sure there is no air in the fuel pipe when using the unit for the rst time, starting the
unit or refuelling an empty tank. You can drain away air by loosening the connection
between the injection pump and pipeline then drain the air until the fuel comes out.
• Do not loosen or adjust either the engine speed limit bolt or fuel injection limit bolt. These
have been set to their optimum settings before leaving the factory.
• Never pull out the start handle when the engine is running. This is dangerous and can
damage the engine.
1. Warm up the engine without the load for about 3 minutes.
2. Open the Fuel Cock.
3. Put the starting switch into the "Run" position.
4. Hold the starting/recoil handle loosely and pull the cord out it until
you feel resistance - then return it slowly.
6. Hold the starting/recoil handle rmly - then pull the cord hard and
fast as far as it will go. Use two hands if necessary. Repeat the
process until the engine starts.
Note: To make it easier to start the generator in cold temperatures
remove the oil plug and add 2cc of engine oil before starting.

5
USER MANUAL
2.8kVA Petrol Generator
JEFGENPET22
www.jeffersontools.com
7. Stopping the Generator
1. Before stopping the generator, allow it to run for approximately 3 minutes with no consumers so that it can "cool
down".
2. Turn off the circuit breaker.
3. Turn the key/ignition switch to the "OFF" position.
4. Turn the fuel cock lever to the "CLOSED" position.
8. Transportation and Storage
• When transporting the generator, ensure the starting switch is set to the "OFF" position and that the fuel valve is
set to the "Closed" position.
• Keep the generator level to prevent fuel spillage. Fuel vapour or spilled fuel may ignite. Touching a hot engine can
cause serious burns or res.
• Let the engine cool before transporting or storing the generator.
• Make sure not to drop or strike the generator when transporting. Do not place heavy objects on top of the
generator during transit, storage or operation.
6. Connecting Consumers to the Generator
1. Connect the machine you want to use to the AC socket. Note: Do not exceed the specied load limit of the
specied maximum AC output.
2. Do not connect the generator to the household network as this may result in damage to the generator itself or to
other electrical appliances in your home.
9. Operation Environment
• This unit can generate rated output under the following conditions:
• The Generator should work in low output under the following conditions:
Altitude Ambient Temperature Relative Humidty
0m +20º 60%
Altitude Ambient Temperature Relative Humidty
>1000m >40º90%

6
USER MANUAL
2.8kVA Petrol Generator
JEFGENPET22
www.jeffersontools.com
9. Maintenance
Daily 20 Hours Usage 50 Hours Usage 100 Hours Usage 300 Hours Usage
Engine oil check ○
Replace engine oil ○ ○
Check air cleaner ○
Wash the air cleaner ○
Oil filter cup ○
Oil filter ○
Spark plug ○
Valve clearance ○
Clean cylinder cover wash
Fuel tank wash Wash regularly replace every three years
Check the battery and
electrolyte levels Before use
The chart below indicates the maintenance checks you should make on your generator parts and the frequency that
these checks should generally be carried out. Note: You can contact your nearest Jefferson dealer for help and
advice and a full list of replacement parts.
Check
Frequency
Notes:
• Checking and the engine oil: With generator on level ground: remove the oil ller cap and dipstick clean with a
clean cloth. Insert the dipstick back into the oil lter hole without turning - remove and check that the oil level is
between the minimum and maximum indicators. If level is low rell to the maximum level mark.
●Checking the fuel level: With generator on level ground: open the fuel tank cap. Check the fuel level. If level is low
refuel up to the red marker on the fuel lter. Put the fuel cap back on.
WARNING:
• Ensure that any electrical equipment is disconnected from the generator before carrying
out any maintenance work on the generator.
• The circuit breaker should be in the "OFF" position before maintenance.
• The unit should be eatherd at all times.

7
USER MANUAL
2.8kVA Petrol Generator
JEFGENPET22
www.jeffersontools.com
10. Troubleshooting
Symptom Possible Cause Action
Engine won't start
Not enough fuel oil Add fuel - see section "4. Checking Generator Prior to
Use"
Fuel nozzle cannot inject fuel or there is not
enough fuel
Repair the fuel injector
The speed control lever is not in the "Run"
position
Move the lever to the "Run" position
Lubricant oil level is too low Check that the oil level is topped up and sits between the
upper and lower level markers
Not enough speed or force used on the
starter/recoil handle
See section "5. Starting the Generator"
The fuel nozzle is blocked or dirty Clean tthe fuel nozzle
Generator fault
Circuit breaker is not closed Turn the circuit breaker to the "On" position
Poor or faulty socket connection Adjust the socket feet
The rated generator speed cannot be obtained Adjust to rated speed
Carbon brush is faulty or worn Replace the carbon brush
AVR is depreciated Replace the AVR
11. Technical Specification
Noise Level Information
The figures quoted in this table are
emission (sound power) levels and are not
necessarily safe working levels.
Whilst there is a correlation between
the emission and exposure levels, this can
not be used reliably to determine whether
or not further precautions are required.
Factors that influence the actual level of
exposure to the work-force include the
characteristics of the work room, the
other sources of noise, the number of
machines and other adjacent processes,
and the length of time for which an
operator is exposed to the noise. Also
the permissible exposure level can vary
between regions.
This information, however, will allow the
user of the machine to make a better
evaluation of the hazard and risk.
FREQUENCY:
RATED OUTPUT:
MAX OUTPUT:
AC OUTPUT:
DC OUTPUT:
ENGINE MODEL:
ENGINE TYPE:
STARTING SYSTEM:
GUARANTEED NOISE LEVEL:
FUEL TANK:
DISPLACEMENT CAPACITY:
LUBRICATION OIL VOLUME:
LOW OIL SHUTDOWN:
50Hz
2.5 kVA / 2.0kW
2.8 kVA / 2.2kW
1 X 230V 16A / 1 X 110V 16A
12V / 8.3A
MACGEN 5.5HP / 3600RPM
OHV PETROL • AIR-COOLED • 4 STROKE
RECOIL START • ELECTRONIC IGNITION
95 dB Lwa
15L
163cc
0.65L
YES

8
USER MANUAL
2.8kVA Petrol Generator
JEFGENPET22
www.jeffersontools.com
# Code Description Qty
1 012030000035 Engine 1
2 029030200301 190 front end cover 1
3 062024220007 Rotor 1
4 062024230011 Stator 1
5 029030101501 Alternator guard board 1
6 029030430600 190 rear end cover 1
7 029030500101 Wire fasten connection 1
8 029910300201 Shock absorption 4
9 029030610401 AVR 1
10 029030700200 carbon brush 1
11 029030300314 190 rear end cover guard 1
12 029840200100 Mufler bracket 1
13 029840100101 Muffler 1
14 029049910200 Mufler gasket 1
15 029010300102 Fuel tank 1
16 029019900602 Fuel tank filter 1
17 029019901102 Fuel tank cap 1
18 029019930000 fuel marker assembly 1
19 029019910001 Shock absorption 4
20 029019900408 ø7 clamp 1
21 029019900100 ø 4.5mm fuel pipe 1
22 029019900401 ø 8 clamp 1
23 02901990070904 Fuel switch 1
24 022400500082 Frame 1
25 029021600037 Control panel 1
26 517050401204 Screw ST4.2X12 4
27 029940110001 Muffler protect side guard 1
28 029940101601 Muffler protect outside guard 1
12. Parts List and Parts Diagram
# Code Description Qty
29 512040800001 flange nut M8 15
30 513010800001 flat washer ø8 2
31 513020800002 spring washer ø8 2
32 510020802501 flange bolt M8X25 (with flat washer
&spring washer)
4
33 510050802501 flange bolt M8X20 4
34 510070821008 Bolt M5/16-210 1
35 510060613001 Bolt M6x130 4
36 513020600002 spring washer ø 6 1
37 513030500000 external tooth lock washer ø 5 2
38 513010500001 flat washer ø 5 10
39 513020500000 spring washer ø 5 6
40 511050501601 flange bolt M5X16 7
41 511140502000 full-thread bolt M5X20 4
42 512010500001 nut M5 8
43 511050501201 flange bolt M5X12 2
44 511050601201 flange bolt M6X12 8
45 511050803501 flange bolt M8X35 1
46 513010600001 flat washer ø 6 1
47 513030600000 external tooth lock washer ø 6 1
48 512040600001 flange nut M6 5
49 029930000801 grounding wire 1
50 511050601401 flange bolt M6X14 1

9
USER MANUAL
2.8kVA Petrol Generator
JEFGENPET22
www.jeffersontools.com

10
USER MANUAL
2.8kVA Petrol Generator
JEFGENPET22
www.jeffersontools.com
13. Circuit Diagram
Ground
DC reset 9A
12V out
POWER lamp
purple
purple
AC 12V
generator
AC
230V
blue
AC breaker
230V 12A
1-ph socket
110V 16A
1-ph socket
230V 16A

11
USER MANUAL
2.8kVA Petrol Generator
JEFGENPET22
www.jeffersontools.com
Limited Warranty Statement
Jefferson Professional Tools & Equipment, or hereafter "Jefferson" warrants its customers that its products will be
free of defects in workmanship or material. Jefferson shall, upon suitable notication, correct any defects, by repair
or replacement, of any parts or components of this product that are determined by Jefferson to be faulty or defective.
This warranty is void if the equipment has been subjected to improper installation, storage, alteration, abnormal
operations, improper care, unauthorised service or repair.
Warranty Period
Jefferson will assume both the parts and labour expense of correcting defects during the stated warranty
periods below.
All warranty periods start from the date of purchase from an authorised Jefferson dealer. If proof of purchase is
unavailable from the end user, then the date of purchase will be deemed to be 3 months after the initial sale to the
distributor.
1 Year
• All Jefferson petrol and diesel generators
90 Days
• All replacement parts purchased outside of the warranty period
Important: All parts used in the repair or replacement of warranty covered equipment will be subject to a
minimum of 90 days cover or the remaining duration of the warranty period from the original date of purchase.
Warranty Registration / Activation
You can register and activate your warranty by visiting the Jefferson Tools website using the following address:
www.jeffersontools.com/warranty and completing the online form. Online warranty registration is recommended as it
eliminates the need to provide proof of purchase should a warranty claim be necessary.
Warranty Repair
Should Jefferson confirm the existence of any defect covered by this warranty the defect will be corrected by repair
or replacement at an authorized Jefferson dealer or repair centre.
Packaging & Freight Costs
The customer is responsible for the packaging of the equipment and making it ready for collection. Jefferson will
arrange collection and transportation of any equipment returned under warranty. Upon inspection of the equipment,
if no defect can be found or the equipment is not covered under the terms of the Jefferson warranty, the customer
will be liable for any labour and return transportation costs incurred.
These costs will be agreed with the customer before the machine is returned.
*Jefferson reserve the right to void any warranty for damages identified as being caused through misuse

12
USER MANUAL
2.8kVA Petrol Generator
JEFGENPET22
www.jeffersontools.com
Warranty Limitations
Jefferson will not accept responsibility or liability for repairs made by unauthorised technicians or engineers.
Jefferson's liability under this warranty will not exceed the cost of correcting the defect of the Jefferson products.
Jefferson will not be liable for incidental or consequential damages (such as loss of business or hire of
substitute equipment etc.) caused by the defect or the time involved to correct the defect. This written warranty is the
only express warranty provided by Jefferson with respect to its products.
Any warranties of merchantability are limited to the duration of this limited warranty for the equipment involved.
Jefferson is not responsible for cable wear due to flexing and abrasion. The end user is responsible for routine
inspection of cables for possible wear and to correct any issues prior to cable failure.
Claiming Warranty Coverage
The end user must contact Jefferson Professional Tools & Equipment (Tel: [phone]) or their
nearest authorised Jefferson dealer where final determination of the warranty coverage can be ascertained.
Step 1 - Reporting the Defect
Online Method:
• Visit our website www.jeffersontools.com/warranty and complete the Warranty Returns form. You can complete
the form online and submit it to us directly or download the form to print out and return by post.
Telephone Method:
Contact your Jefferson dealer or sales representative with the following information:
• Model number
• Serial number (usually located on the specification plate)
• Date of purchase
A Warranty Returns form will be sent to you for completion and return by post or fax, together with details of your
nearest authorised Jefferson repair centre. On receipt of this form Jefferson will arrange to collect the equipment
from you at the earliest convenience.
Step 2 - Returning the Equipment
It is the customer's responsibility to ensure that the equipment is appropriately and securely packaged for collection,
together with a copy of the original proof of purchase. Please note that Jefferson cannot assume any
responsibility for any damage incurred to equipment during transit. Any claims against a third party courier will be
dealt with under the terms & conditions of their road haulage association directives.
Please note: Jefferson will be unable to collect or process any warranty requests without a copy of the original proof
of purchase.
Step 3 - Assessment and Repair
On receipt, the equipment will be assessed by an authorised Jefferson engineer and it will be determined if the
equipment is defective and in need of repair and any repairs needed are covered by the warranty policy. In order to
qualify for warranty cover all equipment presented must have been used, serviced and maintained as instructed in
the user manual.

13
USER MANUAL
2.8kVA Petrol Generator
JEFGENPET22
www.jeffersontools.com
Where repair is not covered by the warranty a quotation for repair, labour costs and return delivery will be sent to the
customer (normally within 7 working days).
Note: If the repair quotation is not accepted Jefferson Professional Tools & Equipment will invoice 1 hour labour
time at £30 per hour plus return carriage costs (plus VAT).
In cases where no fault can be found with the equipment, or, if incorrect operation of the equipment is
identified as the cause of the problem, a minimum of 1 hour labour at £30 per hour plus carriage costs will be
required before the equipment will be despatched back to the customer.
Any equipment repaired or replaced under warranty will normally be ready for shipment back to the customer within
7 working days upon receipt of the equipment at an authorised Jefferson Repair centre (subject to part availability).
Where parts are not immediately available Jefferson will contact you with a revised date for completion of the repair.
General Warranty Enquiries
For any further information relating to Jefferson warranty cover please call [phone] or send your enquiry
via email to [email protected]
Disclaimer:
The information in this document is to the best of our knowledge true and accurate, but all recommendations or suggestions are
made without guarantee. Since the conditions of use are beyond their control, Jefferson Tools® disclaim any liability for loss or
damage suffered from the use of this data or suggestions. Furthermore, no liability is accepted if use of any product in accordance
with this data or suggestions infringes any patent. Jefferson Tools® reserve the right to change product specifications and war-
ranty statements without further notification. All images are for illustration purposes only.
Parts & Servicing
For Jefferson approved replacement parts contact your
nearest dealer or contact Jefferson tools
Telephone: [phone]
Fax: [phone]
Email: [email protected]

14
USER MANUAL
2.8kVA Petrol Generator
JEFGENPET22
www.jeffersontools.com
EC Declaration of Conformity
We, Jefferson Professional Tools & Equipment, as the authorised European
Community representative of the manufacturer, declare that the following equipment
conforms to the requirements of the following Directives:
2000/14/EC (as amended) Noise Emission in the Environment by Equipment
for Use Outdoors
2004/108/EC (as amended) Electromagnetic Compatibility
2006/42/EC (as amended) Machinery Directive
97/68/EC (as amended) Non Road Mobile Machinery Directive
Equipment Category: Power Generator (Item 45)
Product Name/Model: JEFGENPET22EL 2.8kVA /2.2kW Petrol Generator
The conformity assessment procedure followed was in accordance with Annex VI of the Outdoor Noise Directive
Notified Body: SNCH Luxembourg GmbH. (No. 0499)
Measured Sound Power Level: 95dB
Guaranteed Sound Power Level: 95dB
A copy of this certificate has been submitted to the European Commission and to the
EU Member State, United Kingdom
Signed by: Stephen McIntyre
Position in the company: Operations Director
Date: 29 May 2014
This technical document is held by: Jimmy Hemphill
Technical file holder's address as shown below
Name and address of manufacturer or authorised representative:
Jefferson Tools, Herons Way, Chester Business Park, Chester, United Kingdom, CH4 9QR
Telephone: [phone] Fax: [phone] Email: [email protected]
www.jeffersontools.com

15
USER MANUAL
2.8kVA Petrol Generator
JEFGENPET22
www.jeffersontools.com
14. Notes

16
USER MANUAL
2.8kVA Petrol Generator
JEFGENPET22
www.jeffersontools.com
Jefferson Tools,
Herons Way,
Chester Business Park,
Chester,
United Kingdom,
CH4 9QR
Tel. [phone]
Email: [email protected]
IMPORTANT! SAFETY FIRST!
Before attempting to use this product please read
all the safety precautions and operating instructions
outlined in this manual to reduce the risk of fire,
electric shock or personal injury.
www.jeffersontools.com
