Jefferson JEFFOG45-230 User manual
User Manual
v.1.1
JEFFOG45-230
DISENFECTANT
SPRAY FOGGER
2
USER MANUAL v1.1
JEFFOG45-230
4.5L 1100W DISINFECTANT SPRAY FOGGER
www.jeffersontools.com
CONTENTS
Contents 2
About This Document 2
Introduction 3
Specications 3
Safety Guidelines 4
Operation 5
Maintenance 6
Troubleshooting 6
Parts List & Diagram 7
Environmental Protection 8
WEEE (Waste Electrical and Electronic Equipment) STATEMENT 8
Limited Warranty Statement 9
EU Declaration Of Conformity 11
ABOUT THIS DOCUMENT
This manual has been compiled by Jefferson Tools and is an integrated part of the product with which it's enclosed
and should be kept with it for future reference. Please read all of the information supplied in this User Manual before
operating this product.
This manual describes the purpose for which the product has been designed and contains all the necessary
information to ensure its correct and safe use. We recommend that you read the information supplied before carrying
out any maintenance or repair. By following all the general safety instructions contained in this manual you will help
to ensure operator safety and extend the potential life span of the equipment.
All photographs and drawings in this manual are supplied by Jefferson Tools to help illustrate the operation of the
product. Whilst every effort has been made to ensure accuracy of information contained in this manual our policy of
continuous improvement determines the right to make modifications without prior warning.
The information contained in this Instruction Manual is designed to assist you in the safe operation and maintenance
of the equipment Some illustrations in this Instruction Manual may show details or attachments that differ from those
on your own model. Contact your nearest Jefferson Dealer if you are unsure about any information included in this
manual or require any additional information about the safe use, operation maintenance, or repair of this equipment.
3
USER MANUAL v1.1
JEFFOG45-230
4.5L 1100W DISINFECTANT SPRAY FOGGER
www.jeffersontools.com
INTRODUCTION
• Chemical sprayer / fogger designed to sanitise large areas quickly and efficiently
• Suitable for disinfection, sterilisation, insecticidal and other spraying applications
• Portable & easy to use with accurate spray orientation
• Adjustable spray volume & particle size with rapid diffusion
• Powerful 1100W motor and 5M power cable with 13A UK Plug
• Compatible with oil & water based disinfectants between 0-35°C
• Ideal for sterilising offices, schools, waiting rooms, shops, hospitals, hotels, restaurants, vehicles, industrial work
places etc.
SPECIFICATIONS
Model Number: JEFFOG45-230
Input Supply: 230V ~ 50Hz
Power Cable / Plug: 5M / 13A
Rated Power: 1100W
Tank Capacity: 4.5L
Spray Volume: 150-260 ml/min
Spray Range: 8-10M
Particle Size: 10-150 Microns
Fluid Temperature Range: 0-35°C
Rated Runtime: 20 Minutes
Dimensions: 405 x 260 x 415 mm
Weight: 3.5kg
1. Spray Nozzle
2. Spray Regulation Valve
3. Sprayer Housing
4. ON (I) / OFF (O) Switch
5. Carry Handle
6. Motor Enclosure
7. Filter & Air Inlet
8. Angle Adjustment Knob
9. Screw Cap
10. Fluid Reservoir
11. Fluid Pipe
1
2
3
4
5
6
8
9
10
11
7
4
USER MANUAL v1.1
JEFFOG45-230
4.5L 1100W DISINFECTANT SPRAY FOGGER
www.jeffersontools.com
SAFETY GUIDELINES
Please read and ensure that you understand all of the operating instructions, safety
precautions and warnings in this Instruction Manual before operating or maintaining this
equipment. An accident can often be avoided by recognizing a potentially hazardous
situation before it occurs, and by observing the appropriate safety procedures. Never use
this equipment or modify it in any way that has not been specically recommended by the
manufacturer. Contact a qualied electrician for advice on any issues relating to electrical
safety in your working environment.
GENERAL EQUIPMENT SAFETY
• Inspect the equipment for damage and ensure all connections are secure before connecting this equipment to
the power supply. Do not use the equipment if damage is detected. When not in use, ensure that the equipment
is turned off and disconnect the plug from the mains power supply.
• Do not operate near children or animals or direct spray toward others.
• Do not operate the equipment if under the inuence of drugs or alcohol.
• This equipment should only be operated by fully trained and competent individuals.
• Before carrying out any maintenance work on the machine, switch off the machine and disconnect the plug from
the mains power supply.
• Do not alter the sprayer for any other purpose other than that which it was designed.
• The rated operation time is 20 minutes. Allow the motor to cool down after each cycle to prevent damage.
• Ensure that the working environment is clear from clutter and tripping hazards.
• Avoid spraying in wet or windy conditions. Do not use in dusty environments or locations near volatile or
inammable materials
• Always wear suitable protective equipment for the products you are spraying, check the manufacturers
guidelines and Safety Data Sheets (SDS) to ensure Personal Protective Equipment (PPE) is correctly rated to
protect against any harmful chemicals in use. Typical protection equipment may include spray suits, overalls,
masks, respirators, goggles, boots and gloves.
• Store the equipment in a dry safe location, away from children after use.
• Ensure that the sprayer and reservoir are cleaned and ushed after use.
• Ensure any remaining chemical detergents are disposed of in a safe manner, according to local regulations to
avoid contaminating the environment.
• Remove and wash all protective equipment immediately after you have nished spraying and wash hands
thoroughly before eating, drinking etc to avoid any chemical contamination.
• Contact Jefferson Tools for further advice on the safe use, maintenance, repair and compatible replacement
parts for this equipment.
WARNING:
No responsibility is accepted for incorrect use of this equipment. Incorrect use can result in damage to the equipment
and danger to the user. Warranty will be void in the event of incorrect use. The warnings, cautions and instructions
discussed in this instruction manual cannot cover all possible conditions and situations that may occur. It must be
understood by the operator that common sense and caution are factors which cannot be built into this product, but must
be supplied by the operator.
5
USER MANUAL v1.1
JEFFOG45-230
4.5L 1100W DISINFECTANT SPRAY FOGGER
www.jeffersontools.com
ELECTRICAL SAFETY
Ensure that you check the equipment thoroughly to ensure it is safe and t for purpose before each
use. It is important that you inspect all plugs, sockets, power cables and electrical ttings for wear
and damage and repair or replace any defective components. The risk of electric shock can be
minimised by the correct use of the appropriate electrical safety devices.
• We recommend that you t a Residual Current Circuit Breaker (RCCB) in
the main distribution board and that a Residual Current Device (RCD) is
used when operating this equipment.
• The Electricity at Work Act 1989 includes legislation that places legal
implications on employers to ensure the safety of electrical devices in the
workplace. The regulations dictate that all portable equipment must be
inspected regularly and tested to ensure that it is safe for use. 'Portable
equipment' means any electrical item that can be moved and this is often
referred to as Portable Appliance Testing (PAT). PAT testing should be
carried out regularly on this equipment by trained, authorised personnel, as
required by the legislation.
• The Health and Safety at Work Act 1974 states that it is the responsibility of the owner of electrical appliances to
ensure that both the equipment and working environments are maintained to ensure safe operation at all times.
• Check that all equipment cables are secure, correctly insulated, free from damage, and protected against short
circuit and overload before connecting to the power supply. Do not use worn or damaged cables, plugs, sockets
or other ttings.
• Ensure that the power supply matches voltage requirements specied on the equipment and that the plug is
wired correctly and tted with the correct fuse.
• If the electrical fuse blows, ensure it is replaced by an identical type of fuse with the same rating.
• Never pull or manoeuvre this equipment into position using the power cable.
• Ensure the power cable is kept away from heat, oil and sharp edges.
• We recommend that the equipment is connected directly to the power supply without the use of extension leads
as the resulting voltage drop can reduce motor performance.
• Always disconnect the equipment from the power source before servicing, inspecting, maintaining, cleaning,
replacing or checking any parts.
OPERATION GUIDE
Note: Please refer to the diagram shown on Page 4 for reference.
1. Add required proportions of spray product and water (if required) to the uid reservoir by unscrewing the cap and
pouring carefully (use a funnel if necessary). Clean up any spillage from the equipment and local surfaces before
proceeding. Ensure that the liquid temperature range is between 0-35°C.
2. Check the Safety Data Sheet (SDS) for the uid product and take any precautions recommended by the
manufacturer to ensure safe use of the equipment. Carry out a risk assessment of the working environment and take
any steps necessary to ensure safe working practices and applications.
3. Enure that you and any bystanders in the working environment are wearing correctly rated Personal Protection
Equipment for the application (check the manufacturers SDS to conrm required equipment and ratings).
4. Connect the equipment to the rated power supply as indicated in the equipment specications. Ensure the socket
is protected by a residual circuit breaker (RCD-RCCB).
5. Turn the equipment ON using the power switch #4 (ON (I) / OFF (O).
6. Adjust the ow of uid on the spray regulation valve (#2) as required.
7. Begin to spray in the area required using slow careful movements following the rotation of the gear plate. If the
rotation speed decreases check the nozzle for any debris and clean if required.
8. When you have nished spraying, close the spray regulation valve and move the power switch to the OFF (O)
position, carefully dispose of any unused solution in the reservoir and ush out the sprayer with a cleansing solution
for 2-3 minutes and allow to dry off before packing away.
Cable Grip
Neutral
Wire
(Blue)
Earth
Wire
(Brown)
Earth Wire
(Yellow
& Green) 13 Amp
Fuse
6
USER MANUAL v1.1
JEFFOG45-230
4.5L 1100W DISINFECTANT SPRAY FOGGER
www.jeffersontools.com
MAINTENANCE
Warning: Risk of electric shock. Always disconnect this equipment from the mains supply before carrying out any
cleaning or maintenance.
• Maintenance and repair must be performed by a qualied person. Do not carry out any maintenance work before
carefully reading the following instructions.
• While replacing electrical parts of the equipment, turn off the switch and remove the mains power supply.
• Faulty parts should be replaced only with approved components having the same specications as the original
ones.
• Before performing any maintenance work, turn off the machine and remove the mains power supply.
Maintenance work on electric parts of the equipment should be performed by a qualied technician only.
• Do not clean the machine or its peripheral devices without rst removing the mains power supply.
• This equipment should be cleaned with a clean moist cloth and ushed thoroughly with a suitable cleaning
solution after each use to remove any chemical residues. For stubborn dirt on the exterior housing use a moist
cloth with a mild detergent.
• Ensure the spray nozzle and uid reservoir are clean before use.
• Never immerse the appliance in water or cleaning solution or hold directly under running water.
• Allow the equipment to cool sufciently after use before cleaning it.
• Do not use aggressive, chemical or abrasive cleaning agents.
• Do not use solvents such as petrol, alcohol, ammonia water etc.
• Check the air inlet and lter and remove any dirt or debris as required to ensure a smooth and constant air ow.
TROUBLESHOOTING
Symptom Possible Causes Solution
Device will not function
or spray.
1. Air leak / insufcient pressure
2. No power supply or incorrect
power supply.
3. Blown fuse.
4. Damaged motor.
5. Spray regulation valve closed.
Blockage in the uid delivery pipe
or nozzle.
1. Check that the housing and air inlet is
completely sealed
2. Check the power is on and motor is running.
Check that the power supply matches the
specication shown in the technical data.
3. Replace the fuse with one matching the
required rating.
4. Repair or replace the motor. Contact Jefferson
Tools for advice on repair and replacement parts.
5. Check and ensure that the spray regulation
valve is opened as required. Check and remove
any debris or residue in the delivery pipe or nozzle
to allow liquid to ow.
7
USER MANUAL v1.1
JEFFOG45-230
4.5L 1100W DISINFECTANT SPRAY FOGGER
www.jeffersontools.com
PARTS LIST & DIAGRAM
# Description Qty # Description Qty
1Screw 8 14 Fluid Reservoir 1
2Nozzle Front Section 1 15 Nut 1
3Spray Regulation Valve 1 16 L-Type Internal Thread 1
4Nozzle Fan Blade 1 17 Connecting Pipe 2
5Rear Cover 1 18 Connecting Body Bolt 4
6O-Ring 1 19 Nut 6
7Switch 1 20 Net Cover 1
8Sprayer Enclosure 1 21 Seal Ring 2
9Seal Ring 1 22 Filter Screen 1
10 Motor 1 23 Effluent Filter 1
11 Hand Screw 2 24 Power Cable 1
12 Connecting Cover 1 25 Waterproof Joint 1
13 Water Inlet Cover 1 26 Spring 2
8
USER MANUAL v1.1
JEFFOG45-230
4.5L 1100W DISINFECTANT SPRAY FOGGER
www.jeffersontools.com
WEEE (Waste Electrical and Electronic Equipment) STATEMENT
Information on Disposal for Users of Waste Electrical & Electronic Equipment
This symbol on the product(s) and / or accompanying documents means that used electrical and
electronic products should not be mixed with general household waste. For proper treatment,
recovery and recycling, please take this product(s) to designated collection points where it will be
accepted free of charge.
For private households:
Dispose of this product at the end of its working life and in compliance with the EU Directive on Waste
Electrical and Electronic Equipment (WEEE). Contact your local solid waste authority for recycling information
for this equipment.
Disposing of this product correctly will help save valuable resources and prevent any potential negative effects on
human health and the environment, which could otherwise arise from inappropriate waste handling.
Please contact your local authority for further details of your nearest designated collection point.
Penalties may be applicable for incorrect disposal of this waste, in accordance with you national legislation.
For business users in the European Union:
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further
information.
Information on Disposal in other Countries outside the European Union:
This symbol is only valid in the European Union. If you wish to discard this product please contact your local
authorities or dealer and ask for the correct method of disposal.
ENVIRONMENTAL PROTECTION
Recycle any packaging and unwanted materials instead of disposing of them as waste. All tools,
accessories and packaging should be sorted, taken to a recycling centre and disposed of in
a manner which is compatible with the environment. When the product becomes completely
unserviceable, reaches the end of its working life and requires disposal, drain off any
uids (if applicable) into approved containers and dispose of the product and the uids according
to local regulations.
9
USER MANUAL v1.1
JEFFOG45-230
4.5L 1100W DISINFECTANT SPRAY FOGGER
www.jeffersontools.com
LIMITED WARRANTY STATEMENT
Jefferson Professional Tools & Equipment, or hereafter "Jefferson" warrants its customers that its products will be free of defects in workmanship
or material. Jefferson shall, upon suitable notication, correct any defects, by repair or replacement, of any parts or components of this product
that are determined by Jefferson to be faulty or defective.
This warranty is void if the equipment has been subjected to improper installation, storage, alteration, abnormal operations, improper care, service
or repair.
Warranty Period
Jefferson will assume both the parts and labour expense of correcting defects during the stated warranty periods below.
All warranty periods start from the date of purchase from an authorised Jefferson dealer. If proof of purchase is unavailable from the end user, then
the date of purchase will be deemed to be 3 months after the initial sale to the distributor.
1 Year
JEFFOG45-230 4.5L 1100W DISINFECTANT SPRAY FOGGER
90 Days
• All replacement parts purchased outside of the warranty period
Important: All parts used in the repair or replacement of warranty covered equipment will be subject to a minimum of 90 days cover or the
remaining duration of the warranty period from the original date of purchase.
Warranty Registration / Activation
You can register and activate your warranty by visiting the Jefferson Tools website using the following address:
www.jeffersontools.com/warranty and completing the online form. Online warranty registration is recommended as it eliminates the need to
provide proof of purchase should a warranty claim be necessary.
Warranty Repair
Should Jefferson confirm the existence of any defect covered by this warranty the defect will be corrected by repair or replacement at an
authorized Jefferson dealer or repair centre.
Packaging & Freight Costs
The customer is responsible for the packaging of the equipment and making it ready for collection. Jefferson will arrange collection and
transportation of any equipment returned under warranty. Upon inspection of the equipment, if no defect can be found or the equipment is not
covered under the terms of the Jefferson warranty, the customer will be liable for any labour and return transportation costs incurred. These costs
will be agreed with the customer before the machine is returned.
*Jefferson reserve the right to void any warranty for damages identified as being caused through misuse
Warranty Limitations
Jefferson will not accept responsibility or liability for repairs made by unauthorised technicians or engineers. Jefferson's liability under this
warranty will not exceed the cost of correcting the defect of the Jefferson products.
Jefferson will not be liable for incidental or consequential damages (such as loss of business or hire of substitute equipment etc.) caused by
the defect or the time involved to correct the defect. This written warranty is the only express warranty provided by Jefferson with respect to its
products.
Any warranties of merchantability are limited to the duration of this limited warranty for the equipment involved.
Jefferson is not responsible for cable wear due to flexing and abrasion. The end user is responsible for routine inspection of cables for possible
wear and to correct any issues prior to cable failure.
10
USER MANUAL v1.1
JEFFOG45-230
4.5L 1100W DISINFECTANT SPRAY FOGGER
www.jeffersontools.com
Claiming Warranty Coverage
The end user must contact Jefferson Professional Tools & Equipment (Tel: +44 (0) 1244 646 048) or their nearest authorised Jefferson dealer where
final determination of the warranty coverage can be ascertained.
Step 1 - Reporting the Defect
Online Method:
• Visit our website www.jeffersontools.com/warranty and complete the Warranty Returns form. You can complete the form online and submit it
to us directly or download the form to print out and return by post.
Telephone Method:
Contact your Jefferson dealer or sales representative with the following information:
• Model number
• Serial number (usually located on the specification plate)
• Date of purchase
A Warranty Returns form will be sent to you for completion and return by post or fax, together with details of your nearest authorised Jefferson
repair centre. On receipt of this form Jefferson will arrange to collect the equipment from you at the earliest convenience.
Step 2 - Returning the Equipment
It is the customer's responsibility to ensure that the equipment is appropriately and securely packaged for collection, together with a copy of
the original proof of purchase. Please note that Jefferson cannot assume any responsibility for any damage incurred to equipment during
transit. Any claims against a third party courier will be dealt with under the terms & conditions of their road haulage association directives.
NOTE: Jefferson will be unable to collect or process any warranty requests without a copy of the original proof of purchase.
Step 3 - Assessment and Repair
On receipt, the equipment will be assessed by an authorised Jefferson engineer and it will be determined if the equipment is defective and in need
of repair and any repairs needed are covered by the warranty policy. In order to qualify for warranty cover all equipment presented must have been
used, serviced and maintained as instructed in the user manual.
Where repair is not covered by the warranty a quotation for repair, labour costs and return delivery will be sent to the customer (normally within 7
working days).
NOTE: If the repair quotation is not accepted Jefferson Professional Tools & Equipment will invoice 1 hour labour time at £30 per hour plus
return carriage costs (plus VAT).
In cases where no fault can be found with the equipment, or, if incorrect operation of the equipment is identified as the cause of the problem, a
minimum of 1 hour labour at £30 per hour plus carriage costs will be required before the equipment will be despatched back to the customer.
Any equipment repaired or replaced under warranty will normally be ready for shipment back to the customer within 7 working days upon receipt
of the equipment at an authorised Jefferson Repair centre (subject to part availability). Where parts are not immediately available Jefferson will
contact you with a revised date for completion of the repair.
General Warranty Enquiries
For any further information relating to Jefferson warranty cover please call +44 (0) 1244 646 048 or send your enquiry
Disclaimer:
The information in this document is to the best of our knowledge true and accurate, but all recommendations or suggestions are made without
guarantee. Since the conditions of use are beyond their control, Jefferson Tools® disclaim any liability for loss or damage suffered from the use of
this data or suggestions. Furthermore, no liability is accepted if use of any product in accordance with this data or suggestions infringes any patent.
Jefferson Tools® reserve the right to change product specifications and warranty statements without further notification. All images are for
illustration purposes only.
11
USER MANUAL v1.1
JEFFOG45-230
4.5L 1100W DISINFECTANT SPRAY FOGGER
www.jeffersontools.com
EU DECLARATION OF CONFORMITY
We, Jefferson Professional Tools & Equipment, as the authorised European Community representative of the manufacturer, declare
that the following equipment conforms to the requirements of the following:
Directive / Standard / Regulation Description:
2014/35/EU (as amended) Low Voltage Directive (LVD)
2014/30/EU (as amended) Electromagnetic Compatibility Directive (EMC)
Equipment Category: Chemical Sprayer / Fogger
Model Number(s): JEFFOG45-230 4.5L 1100W DISINFECTANT SPRAY FOGGER
Signed by: Stephen McIntyre
Position in the company: Operations Director
Date: 18 November 2020
Technical file holder's address as shown below
Name and address of manufacturer
or authorised representative:
Jefferson Tools, Herons Way, Chester Business Park,
Chester, United Kingdom, CH4 9QR
Telephone: +44 (0)1244 646 048 Fax: +44 (0)1244 241 191
Email: [email protected]
Jefferson Tools,
Herons Way,
Chester Business Park,
Chester,
United Kingdom,
CH4 9QR
Tel. +44 (0)1244 646 048
Email: [email protected]
IMPORTANT! SAFETY FIRST!
Before attempting to use this product please read
all the safety precautions and operating instructions
outlined in this manual to reduce the risk of fire,
electric shock or personal injury.
www.jeffersontools.com
Table of contents
Other Jefferson Paint Sprayer manuals
