Jefferson JEFVACWD090-230 User manual

JEFVACWD090-230 • JEFVACWD090-110
90L Wet & Dry Vacuum Cleaner
1
www.jeffersontools.com
User Manual
v.1.1
JEFVACWD090-230 • JEFVACWD090-110
Wet & Dry Vacuum Cleaner
90L

JEFVACWD090-230 • JEFVACWD090-110
90L Wet & Dry Vacuum Cleaner
2
www.jeffersontools.com

JEFVACWD090-230 • JEFVACWD090-110
90L Wet & Dry Vacuum Cleaner
3
www.jeffersontools.com
Contents:
Important: This manual is an essential part of this Jefferson product and should be kept safe with the product for future reference.
This manual outlines the purpose for which the product has been designed and contains important information to ensure its
correct and safe use. It is essential that you read and understand the information in this manual before operating this equipment.
General Safety
Specications
Standard Accessories
Parts Identication
Operation
Limited Warranty Statement
EC Declaration of Conformity
4
5
5
6
7
8
11

JEFVACWD090-230 • JEFVACWD090-110
90L Wet & Dry Vacuum Cleaner
4
www.jeffersontools.com
General Safety
1.
This equipment should only be operated by qualified
and responsible individuals who have read and
understood the information and guidelines described
in this document. In particular, the following safety
instructions should be followed to reduce the risk of
injury to the operator and members of the public.
1. Familiarise yourself with this equipment and its
operation before use - read this user manual
carefully before use. Save for future reference.
2. Ensure that all bystanders are kept at a safe
distance and that animals and children are kept from
the work area.
3. Never use this equipment if any part or accessory
is damaged or malfunctioning.
4. Always shut the equipment off completely when
not in use, if left unattended or for cleaning &
maintenance.
5. Ensure that the power supply is compatible with
the voltage and frequency stated on the specifica-
tion plate on the equipment. Be sure to carry out a
risk assessment before carrying out any work with
this equipment. Follow all relevant health and safety
guidelines and ensure electrical safety procedures are
implemented before use.
6. Only Jefferson approved engineers should carry
out repairs and maintenance on this equipment.
Only use Jefferson-approved replacement parts to
repair this equipment. Never modify the equipment
in anyway. Ensure that the equipment is kept in good
working order and cleaned and serviced regularly.
Regularly check external nuts and fixings to ensure
that they have not loosened from vibration during use.
7. Store in a clean dry environment.
Electrical Safety
In order to avoid accidents and injuries from
electric shocks:
• Ensure that the mains cable is not damaged by
being pulled over sharp edges, by jamming, or by
pulling on the cable.
• Before each use, check the power supply lead and
the extension cable for damage and ageing. Do not
use the equipment if the cable is damaged or
worn. Danger of electric shock hazard.
• If the power cable damaged, it must be replaced by
a Jefferson approved engineer or similarly qualied
person.
• Switch the machine off and disconnect
the mains plug:
- when the machine is not in use,
- before the machine is opened up,
- for all maintenance and cleaning work,
- if the connecting cable is damaged or tangled up.
• Do not use the cable to pull the plug out of the
socket. Protect the cable from heat, oil, and sharp
edges.
• Make sure that the mains voltage corresponds
with the information on the rating plate.
• The device must only be connected to
a mains socket via a residual-current
circuit breaker (RCD).
injury.to.people.can.be.avoided:
• Ensure that the machine is correctly assembled
and the lters are in the correct position for the
application before use.

JEFVACWD090-230 • JEFVACWD090-110
90L Wet & Dry Vacuum Cleaner
5
www.jeffersontools.com
General Safety Specications
2.
Important: After unpacking, inspect the equipment carefully and ensure that the product is in perfect condition without any
defects or no damaged or worn parts. Please dispose of all the packaging materials appropriately, recycling all materials where
facilities are available.
TANK CAPACITY 90L
POWER 2000W
VOLTAGE 230V (50Hz)
HEIGHT 92CM
TANK DIAMETER 44CM
AIR FLOW RATE 120L/S
VACUUM SUCTION 250mbar
CABLE LENGTH 8m
HOSE DIAMETER 40MM
INSULATION CLASS IPX4
Standard Accessories
3.
12
HT90-2
Principal Machine:

JEFVACWD090-230 • JEFVACWD090-110
90L Wet & Dry Vacuum Cleaner
6
www.jeffersontools.com
Parts Identication
4.
12
HT90-2
Principal Machine:

JEFVACWD090-230 • JEFVACWD090-110
90L Wet & Dry Vacuum Cleaner
7
www.jeffersontools.com
Parts Identication Operation
5.
Application:
The appliance is intended for wet and dry vacuuming in industrial and domestic environments.
This is equipment is not suitable for vacuuming ammable or explosive materials or those which might
endanger health.
The manufacturer cannot be held responsible for injuries resulting from use which does not comply with the
directions, or from incorrect use.
Before Use:
1. Make sure that the power supply is compatible with the equipment
2. Assemble the suction hose and connect to the tank connector on the vacuum cleaner
3. Connect the suction hose
Dry Vacuum Instructions:
1. Ensure that the dust bag is installed before use.
2. Empty any existing dust from the tank before cleaning.
3. Do not attempt to vacuum any liquids when equipment is set up for dry vacuuming.
Wet Vacuum Instructions:
1. Remove the dust lter before using the equipment to vacuum liquids.
2. Ensure that a suitable anti-foaming agent is added to the tank to prevent foam build up and damage to the
motor
Cleaning and Maintenance:
1. Clean the tank after use to prevent dirt accumulating inside
2. Clean the dust bags with warm water after use and dry for future use
3. Replace the dust bag every 1-2 years or as required

JEFVACWD090-230 • JEFVACWD090-110
90L Wet & Dry Vacuum Cleaner
8
www.jeffersontools.com
Limited Warranty Statement
Jefferson Professional Tools & Equipment, or hereafter "Jefferson" warrants its customers that its products will
be free of defects in workmanship or material. Jefferson shall, upon suitable notication, correct any defects,
by repair or replacement, of any parts or components of this product that are determined by Jefferson to be
faulty or defective.
This warranty is void if the equipment has been subjected to improper installation, storage, alteration, abnormal
operations, improper care, unauthorised service or repair.
Warranty Period
Jefferson will assume both the parts and labour expense of correcting defects during the stated warranty
periods below.
All warranty periods start from the date of purchase from an authorised Jefferson dealer. If proof of purchase is
unavailable from the end user, then the date of purchase will be deemed to be 3 months after the initial sale to
the distributor.
1 Year
•All Jefferson Wet & Dry Vacuum Cleaners
90 Days
• All replacement parts purchased outside of the warranty period
Important: All parts used in the repair or replacement of warranty covered equipment will be subject to a
minimum of 90 days cover or the remaining duration of the warranty period from the original date of purchase.
Warranty Registration / Activation
You can register and activate your warranty by visiting the Jefferson Tools website using the following address:
www.jeffersontools.com/warranty and completing the online form. Online warranty registration is
recommended as it eliminates the need to provide proof of purchase should a warranty claim be necessary.
Warranty Repair
Should Jefferson confirm the existence of any defect covered by this warranty the defect will be corrected by
repair or replacement at an authorized Jefferson dealer or repair centre.
Packaging & Freight Costs
The customer is responsible for the packaging of the equipment and making it ready for collection. Jefferson
will arrange collection and transportation of any equipment returned under warranty. Upon inspection of the
equipment, if no defect can be found or the equipment is not covered under the terms of the Jefferson
warranty, the customer will be liable for any labour and return transportation costs incurred.
These costs will be agreed with the customer before the machine is returned.
* Jefferson reserve the right to void any warranty for damages identified as being caused through misuse

JEFVACWD090-230 • JEFVACWD090-110
90L Wet & Dry Vacuum Cleaner
9
www.jeffersontools.com
Warranty Limitations
Jefferson will not accept responsibility or liability for repairs made by unauthorised technicians or engineers.
Jefferson's liability under this warranty will not exceed the cost of correcting the defect of the Jefferson
products.
Jefferson will not be liable for incidental or consequential damages (such as loss of business or hire of
substitute equipment etc.) caused by the defect or the time involved to correct the defect. This written warranty
is the only express warranty provided by Jefferson with respect to its products.
Any warranties of merchantability are limited to the duration of this limited warranty for the equipment involved.
Jefferson is not responsible for cable wear due to flexing and abrasion. The end user is responsible for routine
inspection of cables for possible wear and to correct any issues prior to cable failure.
Claiming Warranty Coverage
The end user must contact Jefferson Professional Tools & Equipment (Tel: [phone]) or their
nearest authorised Jefferson dealer where final determination of the warranty coverage can be ascertained.
Step 1 - Reporting the Defect
Online Method:
• Visit our website www.jeffersontools.com/warranty and complete the Warranty Returns form. You can
complete the form online and submit it to us directly or download the form to print out and return by post.
Telephone Method:
Contact your Jefferson dealer or sales representative with the following information:
• Model number
• Serial number (usually located on the specification plate)
• Date of purchase
A Warranty Returns form will be sent to you for completion and return by post or fax, together with details of
your nearest authorised Jefferson repair centre. On receipt of this form Jefferson will arrange to collect the
equipment from you at the earliest convenience.
Step 2 - Returning the Equipment
It is the customer's responsibility to ensure that the equipment is appropriately and securely packaged for
collection. Please ensure that you include a copy of your proof of purchase. Please note that Jefferson cannot
assume any responsibility for any damage incurred to equipment during transit. Any claims against a third party
courier will be dealt with under the terms & conditions of their road haulage association directives.
Step 3 - Assessment and Repair
On receipt, the equipment will be assessed by an authorised Jefferson engineer and it will be determined if
the equipment is defective and in need of repair and any repairs needed are covered by the warranty policy. In
order to qualify for warranty cover all equipment presented must have been used, serviced and maintained as
instructed in the user manual.

JEFVACWD090-230 • JEFVACWD090-110
90L Wet & Dry Vacuum Cleaner
10
www.jeffersontools.com
Where repair is not covered by the warranty a quotation for repair, labour costs and return delivery will be sent
to the customer (normally within 7 working days).
Note: If the repair quotation is not accepted Jefferson Professional Tools & Equipment will invoice 1 hour
labour time at £30 per hour plus return carriage costs (plus VAT).
In cases where no fault can be found with the equipment, or, if incorrect operation of the equipment is
identified as the cause of the problem, a minimum of 1 hour labour at £30 per hour plus carriage costs will be
required before the equipment will be despatched back to the customer.
Any equipment repaired or replaced under warranty will normally be ready for shipment back to the customer
within 7 working days upon receipt of the equipment at an authorised Jefferson Repair centre (subject to part
availability). Where parts are not immediately available Jefferson will contact you with a revised date for
completion of the repair.
General Warranty Enquiries
For any further information relating to Jefferson warranty cover please call [phone] or send your
enquiry via email to [email protected].
Disclaimer:
The information in this document is to the best of our knowledge true and accurate, but all recommendations or suggestions are
made without guarantee. Since the conditions of use are beyond their control, Jefferson Tools® disclaim any liability for loss or
damage suffered from the use of this data or suggestions. Furthermore, no liability is accepted if use of any product in accordance
with this data or suggestions infringes any patent. Jefferson Tools® reserve the right to change product specifications and
warranty statements without further notification. All images are for illustration purposes only.
Parts & Servicing
For Jefferson approved replacement parts contact your
nearest dealer or contact Jefferson tools
Telephone: [phone]
Fax: [phone]
Email: [email protected]

JEFVACWD090-230 • JEFVACWD090-110
90L Wet & Dry Vacuum Cleaner
11
www.jeffersontools.com
EC Declaration of Conformity
We, Jefferson Professional Tools & Equipment, as the authorised European
Community representative of the manufacturer, declare that the following equipment
conforms to the requirements of the following Directives:
2004/108/EC (as amended) Electromagnetic Compatibility (EMC)
2006/95/EC (as amended) Low Voltage Directive
Equipment Category: Wet and Dry Vacuum Cleaner
A copy of this certificate has been submitted to the European Commission and to the
EU Member State, United Kingdom
Signed by: Stephen McIntyre
Position in the company: Operations Director
Date: 3rd December 2015
This technical document is held by: Jimmy Hemphill
Technical file holder's address as shown below
Name and address of manufacturer or authorised representative:
Jefferson Tools, Herons Way, Chester Business Park, Chester, United Kingdom, CH4 9QR
Telephone: [phone] Fax: [phone] Email: [email protected]
www.jeffersontools.com

Jefferson Tools, Herons Way, Chester Business Park, Chester, United Kingdom, CH4 9QR
Tel. [phone]
Email: [email protected]
IMPORTANT! SAFETY FIRST!
Before attempting to use this product please read
all the safety precautions and operating instructions
outlined in this manual to reduce the risk of fire,
electric shock or personal injury.
www.jeffersontools.com
