Jensen of Scandinavia Media:Link 9005 DUO User manual

9” DVD CAR KIT WITH DUAL PLAYERS
Please read this manual carefully before operation
Operating manual
Media:Link 9005 DUO

CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF FIRE AND ELEC-
TRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK)
OF THE UNIT. REFER SERVICING ONLY TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert
the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the pres-
ence of important operation and servicing instructions in the literature accompanying the
appliance.
To prevent fire or shock hazard, do not expose this device to rain or moisture. Dangerous high voltage is present inside the
enclosure. Do not open the cabinet.
CAUTION:
This Digital Video Disc player employs a laser system. To prevent direct exposure to the laser beam, do not try to open the
enclosure or defeat the safety interlocks. When open and the interlocks are defeated, visible laser radiation is present.
To prevent ele ctric shock, match wide blade of plug to wide slot of outlet and fully insert.
Use of controls, adjustments, or performance of procedures other than those specified herein may result in hazardous radiation
exposure. DO NOT STARE INTO THE BEAM.
NOTICE:
PRECAUTIONS
This product incorpora tes copyright pro tection technology that is prot ected by U.S. patents and other intellectual property
rights. Use of this copyright pro tection technology must be auth orized by Macrovision, and is intended for home and other
limited viewing u ses only unless otherwise authorized by Macro vision. Reverse engineering or disassembly is prohibited.
Do not make any changes or modifications to the equipment unless otherwise specified in
the manual. If such changes or modifications should be made, you could be required to stop
DivX Certified® device that plays DivX video. Visit divx.com for more information and software tools to convert your files into
DivX videos.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play purchased DivX Video-on-
Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to
vod.divx. com for more information on how to complete your registration.
WARNING:
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official
operation of the equipment.
2

IMPORTANT SAFETY INSTRUCTIONS
Read Instructions: All the safety and operating instructions should be read before the product 1.
is operated.
Retain Instructions: The safety and operating instructions should be retained for future refer-2.
ence.
Heed Warnings: All warnings on the product and in the operating instructions should be 3.
adhered to.
Follow Instructions: All operating and usage instructions should be follo wed.4.
Cleaning: Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners 5.
or aerosol cleaners. Use a damp cloth for cleaning.
Attachments: Use only attachments recommended by the manufacturer. Use of other attach-6.
ments may be hazardous.
Water and Moisture: Do not use this product near water (e.g., near a bath tub, washbowl, 7.
kitchen sink, laundry tub, in wet basements, or near a swimming pool and the like).
Accessories: Do not place this product on an unstable cart, stand, tri-8.
pod, bracket, or table. Use only with carts, stands, tripods, brackets,
or tables recommended by the manufacturer or sold with the prod-
uct. Any mounting of the product should follow the manufacturer’s
instructions and should use a mounting accessory recommended
by the manufacturer.
A product and cart combination should be moved with care. Quick 9.
stops, excessive force, and uneven surfaces may cause the product
and cart combination to overturn.
Ventilation: Slots and openings in the cabinet are provided for ventilation 10.
to ensure reliable operation of the product and to protect it from overheating. These openings
should never be blocked by placing the product on a bed, sofa, rug, or other similar surface.
This product should not be pla ced in a built-in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer instructions have been adhered to.
Power Sources: This product should be operated only from the type of power source indi-11.
cated on the rating label. If you are not sure of the type of power supply to your home, consult
your product dealer or local power company. For products intended to operat e from battery
power or other sources, refer to the operating instructions.
Power-Cord Protection: Power supply cords should be routed so that they are not likely to 12.
be walked on or pinched by items placed upon or against them, paying particular attention to
cords at plugs, convenience receptacles, and at the point which they exit from the product.
3

Lightning: For added protection for this product, unplug it from the wall outlet and disconnect 13.
the antenna or cable system during a lightning storm or when it is left unattended and unused
for long periods of time. This will prevent damage to the product due to lightning or power-line
surges.
Overloading: Do not overload wall outlets, extension cords, or integral convenience recep-14.
tacles as this can result in a risk of fire or electric shock.
Object and Liquid Entry: Never push objects of any kind into this product through openings 15.
as they may touch dangerous voltage points or shout-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the product.
Servicing: Do not attempt to service this product yourself as opening or removing covers may 16.
expose you to dangerous voltag e or other hazards. Refer all servicing to qualified service
personnel.
Damage Requiring Service: Unplug this product from the wall outlet and refer servicing to
qualified service personnel under the following conditions: a) when the power-supply or plug
is damaged; b) if liquid has been spilled or if objects have fallen into the product; c) if the
product has been exposed to rain or water; d) if the product does not operate normally by fol-
lowing the operating instructions. Adjust only those controls that are covered by the operating
instructions as improper adjustment of other controls may result in damage and will often
require extensive work by a qualified technician to restore the product to its normal operation;
e) if the product has been dropped or damaged in any way; f) when the product exhi bits a
distinct change in performance—this indicates a need for service.
IMPORTANT SAFETY INSTRUCTIONS
Replacement Parts: When replacement parts are required, be sure that your service techni-18.
cian has used replacement parts specified by the manufacturer or have the same charac-
teristics as the original part. Unauthorized substitutions may result in fire, electric shock, or
other hazards.
Heat: The product should be situated away from heat sources such as radiators, heat regis-19.
ters, stoves, or other products (including amplifiers) that produce heat.
Battery shall not be exposed to excessive heat such as the sunshine, fire or the like. Dan-20.
ger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent
type.
WARNING: Excessive sound pressure from earphones and headphones can cause he aring 21.
loss.
WARNING: The mains plug (or direct plug in adaptor) is used as disconnect device, the 22.
disconnect device shall remain readily operable.
17.
4

TABLE OF CONTENTS
PRECAUTIONS ...............................................................................................................................2
IMPORTANT SAFETY INSTRUCTIONS .........................................................................................3
TABLE OF CONTENTS ...................................................................................................................5
PACKAGE CONTENTS ...................................................................................................................7
ABOUT OPTICAL DISCS ................................................................................................................8
Disc Requirements................................................................................................................... 8
Disc Care and Maintenance .................................................................................................... 8
Handling a Disc ............................................................................................................... 8
Cleaning a Disc ............................................................................................................... 8
LOCATION OF CONTROLS ........................................................................................................... 9
Left View ................................................................................................................................. 9
Front View ............................................................................................................................... 9
Right View ............................................................................................................................... 9
Back View ..............................................................................................................................10
Remote Control ......................................................................................................................11
GETTING STARTED ......................................................................................................................12
Using the remote control.........................................................................................................12
Power Supply .........................................................................................................................12
Using Headphones/Earphones .............................................................................................18
USB/SD/MMC Card Connection ............................................................................................18
BASIC OPERATIONS ....................................................................................................................19
Basic Playback .......................................................................................................................19
Play/Pause/Stop ............................................................................................................19
Previous /Next (Skip) .....................................................................................................19
Forward/Reverse (Search) ............................................................................................19
Slow/Step .......................................................................................................................19
Menu Navigation ....................................................................................................................19
Numeric Keypad ....................................................................................................................20
Disc Error Messages ..............................................................................................................20
Power Management ...............................................................................................................20
FUNCTION BUTTONS ..................................................................................................................21
Display/Setup .........................................................................................................................21
Zoom ......................................................................................................................................21
Multi-Subtitle/Audio/Angle ......................................................................................................21
SUB ........................................................................................................................................21
Audio ..............................................................................................................................21
CONNECTIONS .............................................................................................................................15
Power, Audio and Video Output Connections ........................................................................15
Connecting to a wall outlet .............................................................................................15
Outputting AV signal from the main unit to the monitor by the DC car cord ...................15
Using the car plug ..........................................................................................................16
Outputting AV signal from the main unit to the monitor ..................................................16
Audio and Video Connectios ( external device) ....................................................................17
Rechargeable Battery Pack ...................................................................................................17
5

Angle ..............................................................................................................................21
Menu/Title ..............................................................................................................................21
Menu ..............................................................................................................................21
Title ................................................................................................................................21
Repeat A-B Mode ...................................................................................................................21
Repeat Playback Of Chapter/Title/All of a Disc.......................................................................22
LCD Mode Menu ....................................................................................................................22
To access the USB/SD mode .................................................................................................22
SETUP ...........................................................................................................................................23
Language Setup .....................................................................................................................23
Video Setup ............................................................................................................................23
Audio Setup ............................................................................................................................24
Misc ........................................................................................................................................24
SPECIFICATIONS ..........................................................................................................................25
TROUBLESHOOTING ...................................................................................................................26
TABLE OF CONTENTS
6
Declaration of confirmity..................................................................................................................28

Please make sure the following items are included in the package. If any items are missing, please
contact your local dealer.
PACKAGE CONTENTS
2 x ML9005 2 x stereo
earphones
2 x 220V adapter
2x Car bracket
Menu
Title
VOL- VOL+
2x Remote control
with battery
AV cable12V car adapter
7

ABOUT OPTICAL DISCS
Disc Requirements
This DVD player supports playback of the following discs.
Type Disc Mark Content Type Disc Size Max. Playback Time
DVD-Video Discs Audio + Video
(moving picture) 12 cm
133 min (SS-SL)
242 min (SS-DL)
266 min (DS-SL)
484 min (DS-DL)
Audio Compact Discs (CDs) Audio 12 cm 74 min
JPEG CDs -- Still Picture 12 cm
above are not supported by this unit (eg, PC CD-ROM, CD-Extra, CD-G, CD-I, etc.)
Disc Care and Maintenance
Optical discs (DVDs, CDs) contain high-density compressed data and need proper handling.
Handling a Disc
Hold a DVD/CD by its edges. Avoid touching •
the recorded side of the disc. To remove a
DVD/CD from its storage case, press down on
the center retention mechanism of the case
and lift the disc out.
Do not subject discs to prolonged exposure to direct sunlight, high humidity, or high tem-•
peratures.
Do not bend or press discs. •
To reduce the risk of scratches, always put discs back in their case after use. Store discs •
vertically in a cabinet.
Do not place stickers or labels on either side of a disc.•
Cleaning a Disc
Use a dry, soft cloth to wipe off any fingerprints and dusts from the playing surface of the disc.
Wipe in a straight line radially from the center to the outside edge of the disc. Small dust particles
and light stains will not affect playback quality.
Never use chemicals such as record sprays, anti-static sprays, benzene, or thinners to clean •
a disc. Doing so will damage the surface of the disc permanently.
MPEG4 Audio + Video 12 cm 600 min
MP3 -- Audio 12 cm
(DivX and Xvid only)
600 min
This unit can play back CD-R and CD-RW discs that contain JPEG picture files. Discs not listed
---
8

LOCATION OF CONTROLS
Left View Right View
Front View
For your reference:
1. Place a disc with the label side facing up in the CD compartment.
2. To start playback, press the OK (Play/Pause/Enter) button. (Some discs will start playback automatically).
3. To stop playback, press the STOP button.
4. To play next / previous track, press the NEXT/PREVIOUS button.
5. To fast forward/reverse, repeatedly press and hold the NEXT/PREVIOUS button.
6. To slow-reverse/forward through the disc, press the Up/Down direction but ton.
Audio/Video in/out switch
LCD Mode/USB button
Increase volume
Decrease volume
Stop/Setup button
Earphone Jack
Audio/Video Jack
DC 9V IN
Power Switch
USB Port
SD/MMC
USB Port
SD/MMC Card Slot
DC 9V IN
Connect to the supplied AC Adapter
or the DC Car Cord for power supply.
Power Switch
Set the power on/off.
Audio/Video Jack
Input/Output the audio/video signal.
Earphone Jack
Connect to the earphone.
Audio/Video in/out switch
S. eelct whether the Audio/Video Jack
LCD Mode/ USB button
Press this button to display the LCD
setting menu or enter USB menu.
Stop/Setup button
Press to stop og enter Setup menu.
Increase volume
Press this to increase volume
Decrease volume
Press this to decrease volume
Left View Right View
To connect a USB flash drive.
To connect a SD/MMC card.
Previous / Fast Reverse
Next/Fast Forward
Charging Indicator
Power on Indicator
Enter
Remote Sensor
Down/Forward
Up/Reverse
operates in OUT or IN modem.
9

MADE IN CHINA
Support ID place here
LOCATION OF CONTROLS
Back View
Using the Stand
1. Lift up the stand from the groove.
2. Support the unit agaist the stand.
LOCATION OF CONTROLS
Bracket holes
Ventilation Slots
10

Menu
Title
VOL- VOL+
LOCATION OF CONTROLS
Remote Control
Display/Setup
Standby
Previous
Fast Reverse
Play/Pause
Numeric Buttons
LCD Mode/USB/SD
Zoom
Subtitle
Repeat A-B
Repeat All
Menu
Audio
Angle
Title
Next
Fast Forward
Direction Buttons
LOCATION OF CONTROLS
Enter menu
Volume +
Volume -
11

GETTING STARTED
Using the Remote Control
To load a battery in the remote:
Pull in the direction of the arrow.1.
Slide the compartment out.2.
Place the battery in the compartment with the positive side ( + ) facing up.3.
Push the compartment in to close.4.
Point the remote at the remote sensor of the Portable media player at a distance of no more
than 15 feet and at an angle no greater than 60 degrees.
•
Batteries will last for about one year under typical usage. •
Replace the batteries if the remote is no longer working.•
Do not spill water on the remote control.•
Do not use the remote control for other equipment at the same time.•
Remove the batteries if the remote control will not be in use for an extended period of time.•
12

13
GETTING STARTED
1
23
Connecting the car bracket

GETTING STARTED
14
DC 9V IN
To the Cigarette
Lighter Socket
DC 9V IN
4

CONNECTIONS
Using the car plug
DC 9V IN
To the Cigarette
Lighter Socket
DC 9V IN
Note: Not for use in 24V vehicles.
WARNING: Disconnect this car power adaptor when not in use.
Do not use in 24V systems
Whatch same movie on both units
A
Movie A Movie A
1This way you can see the same movie on both units.
15

CONNECTIONS
Whatch same movie on both units
2
Audio/Video Audio/Video
3
Audio/Video Audio/Video
Set to AV OUT Set to AV IN
Movie A Movie A
16

CONNECTIONSCONNECTIONS
Rechargeable Battery Pack
For new or exhausted rechargeable battery pack, we recommend it be recharged for 4 hours.•
To charge the battery, just connect the AC adaptor. •
If the battery does not work to your expectation, please consult the service center.Do not attempt to •
replace or repair the battery by yourself.
The battery can be recharged about 300 times without obvious performance drop. •
Note:
Only use the provided charger to charge the battery.•
Never dispose off in fire or expose to heat.•
Do not use in high temperature or near heat sources . •
Do not open the cover. Refer servicing only to qualified service personnel. •
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.•
Low Battery Detection
The unit will automatically go into STANDBY mode when the battery is low.•
Audio and Video Connections (external device)
Refer to the owner’s manual of the external device as well.1.
Before connecting the power source, 2. ensure that all the connections are properly done.
If the player will not be used for a long period of time, disconnect the power and remove the battery from 3.
the remote control.
Audio / Video input Audio / Video output
Set switch to OUTSet switch to IN
17

CONNECTIONS
Using Headphones / Earphones
HEADPHONE VOLUME WARNING
Connect earphones with the volume set low and increase it if required. Prolonged listening through some
earphones at high volume settings can result in hearing damage. When headphones/earphones are
connected, no sound will be emitted from the unit’s speaker.
Caution: Avoid listening to sound at levels which may be harmful to your ears.
Continuous use of earphones at high volume can dam age the user’s hearing.
USB/SD/MMC Card Connection
Insert a USB or card into the corresponding slot.
Press the USB/SD button to display DISC/ SD/USB menu.1.
Press the Up/Down direction buttons to select USB or SD and press the OK (Play/Pause/Enter) 2.
button to start playback.
It takes a short while for the unit’s reading data. After the device is detected, the screen will 3.
display the working menu, press the direction buttons to select the desired file from the menu
and press OK (Play/Pause/Enter) button to start playback
18

BASIC OPERATIONS
Prepare the connections and power supply.
Load a disc.
Press the Open button to open the disc compartment lid. Load a disc with the label-side facing up. Close
the lid manually. If a single-sided disc is loaded upside-down, the player will display “BAD DISC”.
Start playback.
Press Play/Pause button to start playback (some discs may start playing automatically).
Play/Pause/Stop
Press • to play the disc for the first time.
Press • during playback to pause. Press again to resume playback.
Press • during playback to stop the disc (“Pre-Stop”). Press to resume playback.
Press • when the disc is “Pre-Stopped” to stop playback completely. (When is pressed, the
disc will start playing from the beginning.)
Next/Previous (Skip)
Press • to skip forward one track (DVD, CD, MP3, etc).
Press • to skip back one track (DVD, CD, MP3, etc).
Forward/Reverse (Search)
Press / for a while to fast-forward / reverse through the disc.
Each successive press of • / will change the rate of fast-forward / reverse playback.
Slow
To slow-reverse/forward through the disc, press the UP/DOWN direction button.
Each successive press of DOWN/UP direction button will change the rate of slow-motion •
playback.
Press • to resume normal playback.
19

BASIC OPERATIONS
Adjusting the Volume
Use the Volume + or - button to adjust volume level.•
Disc Error Messages
The following messages will be displayed on-screen if there is a problem with the format of the loaded disc.
WRONG REGIONAL DISC. • The region code of the disc does not match the player’s region code (Region
4).
BAD DISC. T• he player is equipped with automatic disc quality detection software. If the player detects
a disc that is da maged or has a format problem, it may play the disc at a lower quality or stop play
completely, depending on how damaged the disc is.
Note:
DVD disc production quality may vary; some discs may deviate from the industry standard.
Some incorrectly-formatted discs may still play, however, the playback and operational quality of the disc may
be substandard.
Power Management
If the player will not be in use for a long period of time, set the Power Switch to the OFF position and unplug
the player.
20
