Jensen NAV101 User manual

Installation and Operation Manual
NAV101
[]
powered by
smart2go
,;
,/
,(
;=~~'
"
'c""J
'"~
"
)1

NAV101 ~
CONTENTS
Thank you for choosing aJensen product. We hope you will find the instructions in this owner's
manual clear and easy to follow. Ifyou take afew minutes to look through it, you'll learn how to
use all the features of your new Jensen NAV101 navigation system for maximum enjoyment.
Introduction 1
Safety Information 2
Installation 3
Getting Started 5
Main Features 6
Choosing and Finding Locations 8
Navigating 12
Planning aRoute 13
Managing your Address Book 14
Settings Menu.......... .. 16
Troubleshooting 21

~ NAV101
ii

NAV101 ~
INTRODUCTION
We hope that you enjoy using your new Jensen NAV101 navigation system. This manual is
designed to help you get the most out ofyour system. This navigation system leads you
straight to your destination.
You can navigate and plan your route with an easy-to-use and
intuitive interface, plan your trip
to suit your personal preferences and interests, and find and
save (bookmark) interesting destinations before you begin your trip.
Key Features
S.M.AR.T™ -(Smart Mapping Avoids Routine Traffic) enables you to navigate around
heavy traffic areas with ease.
(S.MAR.T. Route Guidance)
Powered
by gate5 /Nokia Smart2Go
Teleatlas Map Data
>4million POI (Point Of Interest)
Speed Sensitive Zoom
Enhanced Female TTS Voice Guidance Engine
Standard Male /Female Voice Guidance Engine
Turn by Turn Voice Guidance
Back-Up Data DVD
Specifications
Samsung S3C2440 (ARM9) 400MHz Processor
64MB SDRAM
32MB Nand Flash
Win CE 4.2
Storage -External SD Card Slot (2GB Card Included w/ Map Data)
Sirf
III 20 Channel GPS antenna
Operating Voltage -Received from Head Unit
(11 -16VDC, Negative Ground)
Parts List
NAV101 navigation module
SIRF III Antenna with magnetic mount
Left and right mounting brackets
Four rubber feet (to affix to the bottom ofthe
NAV101 in the recessed area near each
corner)
SmartBus cable (used to connect the
NAV101 to the Jensen navigation-ready radio)
Four 6mm (.25in) screws (to secure the left and right mounting brackets to the
NAV101
navigation module)
One 2Gigabyte SD Card pre loaded with map/navigation software
Two
11 mm (.4in) screws (for fastening the SmartBus cable to the radio and NAV1 01)
DVD with backup software for map data and navigation
1
About GPS and GNSS
The NAV101 is avehicle GPS (Global Positioning Satellite)-based navigation device which
utilizes digital map data to guide you from your selected location Ato location
B, using location
information obtained from aGlobal Navigation Satellite System (GNSS).
AGNSS consists of aset of satellites that transmit high-frequency radio signals containing
time, direction, and distance data that can
be picked up by areceiver, allowing users to
pinpoint their precise locations anywhere around the globe. Navigation Satellite Receivers
(GPS devices) use this transmitted information to calculate an exact location on the earth.
Every point on Earth can
be identified by latitude and longitude. The receiver uses the
information sent by at least three satellites and determines the coordinates of the receiving
device.
By comparing the time the signals were transmitted from the satellites and the time they were
recorded, the receiver calculates how far away each satellite
is. The distance of the receiver
from three or more satellites reflects its position
on the surface of the planet. Using these
distance measurements, the receiver might also
be able to calculate speed, bearing, trip time,
distance to destination, altitude, etc. The GPS position may be displayed as apoint on adigital
map (at least three satellites' signals must
be received) and as the GPS device moves the
corresponding trace is displayed as well.
Please keep
in mind that although the radio signals of navigation satellites will pass through
clouds, glass, plastic, and other lightweight materials, satellite-navigation receivers will not
work underground or
in some enclosed spaces.
Smart2Go Navigation / Tele Atlas Map Data
The NAV101 2GB SD card is pre-loaded with the Smart2Go navigation engine and Tele Atlas
map data. The map data covers the continental US, Canada, Alaska, Hawaii and Puerto Rico.

~ NAV101
SAFETY INFORMATION
When the Jensen NAV101 is first turned on, the following message appears:
You must agree to the above notice before operating the NAV101.
The following safety rules must be followed to prevent accidents that can result in injury or
death to yourself or others:
The driver should operate the device only when the vehicle is stopped. Only avehicle
passenger should operate the device while the vehicle is moving. When driving, the need
to view the display is minimal. Voice prompts will guide you to your destinations.
It is your responsibility to comply with all traffic laws.
The
NAV101 is designed to assist you in the process of reaching your destination. It is not
asubstitute for attentiveness and good judgement. It is your responsibility to disregard
any unsafe, hazardous, or illegal route suggestions.
The device does not include, analyze, process, consider, or reflect any
of the following:
a. Legal restrictions (such as vehicular type, weight, height, width, load and speed
restrictions
);
b. Road slope or grade, bridge height, width, weight, or other limits;
c. Population density;
d. Neighborhood quality or safety;
e. Availability or proximity of law enforcement, emergency rescue, medical, or other
assistance;
f. Construction work zones or hazards;
g. Road or lane closures;
h. Road, traffic, or traffic facilities' safety or condition;
i. Weather conditions;
j. Pavement characteristics
or conditions;
k. Special events;
I. Traffic congestion.
While every attempt is made to ensure that the database is accurate, roadways, points of
interest, and business and service locations may change over time.
Do not use the
NAV101 to navigate to apolice station, hospital, etc. in an emergency. Call
911 for assistance.
2
Laws in some states prohibit wearing stereo headphones or may prohibit use or
placement of anavigation device while operating amotor vehicle. Please contact your
state's Department of Motor Vehicles for information.

NAV101 @!E>
1,,11 __
INSTALLATION
The NAV101 can be used with aJensen navigation-ready DVD unit (VM9412, VM9512,
VM9022).
Warnings
Do not install components in areas which are susceptible to rain, moisture, directsunlight,
extreme heat
or cold, excessive dust, dirt or humidity.
Do not install the NAV101 where it will obstruct the driver's view
or interfere with the
vehicle's operating system or safety features (air bags, hazard light buttons, etc.).
Use only installation parts and hardware provided with the unit.
Use of other parts can
cause malfunction and possible
damage to your navigation system.
This product should only be installed in vehicles with a12-volt battery with negative
grounding. Check the battery voltage
of your vehicle before installation.
To avoid shorts in the electrical system, be sure to disconnect the negative (-) battery
cable before beginning installation.
NAV10l Placement
The NAV101 should be installed under the back or front seat. It can also be installed in the
trunk, if necessary. Do not install the NAV1
01 where it will come in contact with water or direct
sunlight. Mount the supplied brackets to the NAV101 using the
4mm (.25in) screws provided.
Antenna Placement
Since the NAV101 uses GPS technology for navigation, proper antenna placement is crucial
for optimal performance
of the GPS receiver. When using GPS antennas, the antenna plane
should be parallel to the geographic horizon. There should be nothing between the antenna
and
the sky to ensure adirect line-of-sight between the antenna and available satellites.
The preferred antenna location is on the top of the car on the roof or trunk area. When placed
on
the dashboard, performance may be reduced due to obstruction caused by the window or
roof.
NOTE: 00 not cut the GPS antenna cable to shorten or lengthen it.
q,-'"
o
. ~ ..
Q
.... - .....
••• <>
I®
r;i)
@00 b~ ....
..•
.....~
"
..
.......... J0
NOTE: Be sure to install the NAV101 in such away that the SO card slot is accessible
after install, allowing for the removal/insertion of the SO card for future changes to map
data
or upgrades.
WARNING!
Be sure to secure all wires/cables safely awayfrom the steering wheel, shift
lever, and gas or brakepedal.
3

~ NAV101
GPSAntenna
<tENSER>
NAV101
Mobile Navigation
Connections
1. Insert one end ofthe Smartbus cable into the "DATA BUS" slot on the side ofthe NAV1 01
and secure it with a11mm (.4in) screw (provided). Connect the other end of the cable to
the
NAV101 input on the back of your Jensen navigation-ready head unit (VM9412,
VM9512, VM9022). If using aVM9412 or VM9512, secure the cable to the radio using a
11 mm (.4in) screw. The VM9022 has acable to cable connection and does not require an
anchor screw.
2. Attach the GPS Antenna to the "ANTENNA" jack on the side ofthe NAV101.
3. Insert SD card into the SD card slot and gently press the card in against the spring latch
until it stops, then release. The card will "lock" firmly into place inside the SD card slot.
~
//
0
(@0s
..
I §j
~=~
0I
ANTENNA RESET
DATA BUS
Secure Smartbus Cable
with 11mm (.4in) Screw
.o~~~~~_
ll1!ill ~
t
=
=
t
~
~
t
Jensen VM9022
o
t
=
=
O
D@
I~~~ @0
- 1(=)
8MB
Jensen VM9412NM9512
o
NAV Bus
4

NAV101 ~
GETTING STARTED
The initial GPS location lock is best established when your vehicle is parked. If the device is in
motion, the signal can take longer to initially connect. Once the initial coordinates are
established, the software will follow you as you move and navigate.
NOTE: It may take up to 5 minutes to establish the first connection. Subsequent
connections will be faster (30 seconds to 1minute), but if you have not used the unit for
several days or are very far away from the last location you used it, it may take up to 5
minutes again to find a strong signal.
Set time zone
Your NAV101 automatically determines the time through the GPS signal. However, you must
set your time zone.
Select your time zone from the list. You can change the time zone later (see "General
Settings" on page 16).
Press the confirmation icon.
View Safety Precautions
Next, ascreen with safety precautions will be shown.
1. Read the safety precautions.
2. Press "I Agree" to continue to the Main Menu.
5

~ NAV101
MAIN FEATURES
Main Menu
The main menu is your central point of access to all functions of your NAV1 01. It allows you to
set your destination, manage your favorites and control all settings of your device.
In Tracking mode, the map follows your actual position (GPS position), displaying information
about your geographic position, your speed, etc. The GPS position is indicated by agreen
arrow.
Zoom In
POI
Icons
-Zoom Out
GPS Signal Strength
Menu Button
Gr~Of) '"'OOd SI'va
on 8ay Cir
.. "
--
Business Icons
(Press for information)
-
,
.-
~b
.
~
- eXO"'n;, PI .:
513 Washington St
Cross hair --;;W::B:="'====------=.
... £8
Back Button
Use astylus or your finger to browse the map and enter Browsing mode. The selected position
will be identified by acrosshair cursor. The screen is highlighted
in orange when in Browsing
mode.
speed.'
Time .•
Geographic ; • .. ..
Information ;.
lClilOi(!)
The "Main Menu" consists of the following options:
View Map: Press to view your current location on the Tracking Map.
Drive
to ... :Choose your destination -either by searching for an address, choosing an
entry from the POI (point of interest) directory, selecting alocation from the map, or by
choosing adestination from asaved list of recently visited locations or favorites (see
"Choosing and Finding Locations"
on page 8).
Settings: Configure your navigation
to suit your needf:. Define general settings (e.g. time,
language, or system
of measurement), configure your map (e.g. 2D or 3D mode, day or
night mode, map complexity) or load amap of adifferent region, set the route options
(e.g. choose to avoid or allow toll roads or ferries, or change the volume (see "Settings
Menu"
on page 16).
Map Tracking and Browsing
The map is the core component of your NAV1 01. It will be centered on your current location by
default, provided you have aGPS connection. You can browse the map, display information
about the different locations shown
on it and choose them for routing and navigating. The map
knows two basic states, the Tracking and the Browsing mode.
Crosshair Location
6

NAV101 I,' \
NOTE: Pressing an icon on the map opens an overlay window with information about
the selected item.
To zoom in or out, press the +or -icons. After pressing one of the icons, the zoom slider
will appear, enabling smooth zooming.
With the compass icon
(in the bottom left hand corner) you may adjust the orientation.
If you want to return
to the tracking mode, press the
button.
Navigation Screen
The navigation screen displays your route (in blue) and your surroundings. Agreen arrow
identifies your current position. The
red arrow will indicate the direction of your next turn. The
upcoming maneuver
is also visualized in the upper left corner, along with the distance to that
turn. When you come
up to aturn, you will hear avoice command at the appropriate time.
Next Maneuver Next Turn/Junction/Exit Number
Lake Emma f
'«1 \.InS
~ Loop
speed __
Current Time/ ---------------..1-
Estimated Arrival Time ~
Distance to Destination ____
_ .+
-
Distance to Next Maneuve
Next
Turn Current Position
On the left, additional information, including the current and estimated arrival time and the
distance
to your destination, is displayed.
For one-way streets, the transit direction
is indicated with ared arrow.
For more information about navigation, see "Navigating"
on page 12.
7

~ NAV101
CHOOSING AND FINDING LOCATIONS
This section describes the different ways offinding and choosing locations. You can search for
an Address, search POI (Point of Interest) directories and city guides, select arecent
destination or choose from your Address Book, or select alocation
on the Map.
NOTE:
If a route is in progress when you exit the NAV101 system, the unit will prompt
"Do you want to resume the last route?" when you resume operation.
Finding an Address
Find addresses through the Address search. Just enter information about the desired target,
select ahit from the results list and use the address found for different purposes, like showing
it on amap, planning your route, and navigating.
1. From the main menu, press Drive to ....
2. Press Address. The "Find Address" window will be displayed:
Your NAV101 offers aconvenient interactive look-ahead search function
to prevent
misspelling. Only keys that lead to asearch result can be pressed -all others are
greyed out.
8
After entering the second character, only letters that can be used to spell an existing
destination will
be available for selection of the third character, the fourth character,
and so on.
Continue entering characters until you have narrowed down the search to only one
result, or press the OK button to display alist of search results, from which
you can
choose.
If at any point
you want to backspace and delete characters, press the backspace
button
«0) on screen.
To add aspace, press the space bar ( _ ).
If you need to enter an apostrophe n, use the space key instead.
3. Select a State/Provo
a. Press the "State/Prov." data field to access the "Select State" screen.
b. Choose astate from the list by pressing to highlight it. Use the scroll bar on the right
of the screen
to view all of the choices.
C. Press the OK button to choose the highlighted State/Provo and return to the "Find
Address" screen.
4. Select aCity.
a. Press the "City" data field to access the "Enter ..... screen.
b. Use the on-screen keypad to enter the City name. If the first two characters are not
part
of an existing City name, "No entries found" appears on the screen.
C. Press the OK button to select the entered name or select from alist of matches
based
on the letters you entered.
d. Press the OK button to choose the highlighted City and return to the "Find Address"
screen.
5. Select aStreet.
a. Press the "Street" data field to access the "Enter ... "screen.
b. Use the on-screen keypad to enterthe Street name. If the first two characters are not
part
of an existing Street name, "No entries found" appears on the screen.
C. Press the OK button to select the entered name or select from alist of matches
based on the letters you entered.
d. Press the OK button to choose the highlighted Street and return to the "Find
Address" screen.
6. Select astreet No.

NAV101 I
a. Press the "No." data field to access the "Enter. .. "screen.
b. Use the on-screen keypad to enter the street Number.
c. Press the OK button to enter the street Number. If the Number you entered is not an
existing street Number, "House number not found. Street will
be used for
destination." appears
on the screen. You will automatically return to the "Find
Address" screen.
7. Press the MENU button to view the following screen:
To navigate to the location, select Navigate.
To use the location for planning aroute, select Waypoint.
To save the location as abookmark, select Save.
To view the location on the map, select On Map.
Searching for and Choosing a POI (Point Of Interest)
The POI finder allows you to quickly find points of interest, like gas stations and restaurants, in
adatabase of millions of POls. These places can be near your current position (the default) 01
at any other location.
Browse POls
1. From the main menu, press POI Search. The "POI Search" window will be displayed:
9
2. Select an area for the POI search. Although the text in the white "Where?" box shows
your current location, you must press the Where? button to set your current location for
the POI search or enter anew location.
NOTE: The
first time the POI search is used, the default location will be New York City.
You
must press the Where? button to choose your current location or specify another
location.
a. To search for aPOI in another location, press the "Where?" button. Ascreen with
navigation options appears.
b. Press the corresponding button to search for anew address using the "Enter ... "
screen (Find Address), My Address Book, or your current GPS Position.
To skip this
step and return to the "POI Search" screen press Back.
3. On the "POI Search" screen, select one of the following POI categories: Automotive,
Overnight, Dining, Sights, Shopping, Leisure, Service, Transport. Amenu with sub-
categories will be shown.

NAV101
Choosing a Location on the Map
1. From the "Main Menu", press View Map. The "Map -Tracking" window will be displayed,
indicating your last location:
4. Select asub-category from the POI Search list. Alist of POls will be shown.
POI Search: Automotive - car Rental
~
Wizard Auto Rental
0.4miE]
60 Hudson St, New York 10013
~
Performance car Rental
0.5mi
298 Mulberry St, New York 10012
~
NYC Exotic Car Rentals
0.8 mi
300 Mercer St, New York 10003
~
Money's Worth Car & Truck Rntl
0.8 mi
210 South St, New York 10002
~
Big Apple Rent-A-Car
0.8mi
575 Washington St, New York 10014
0.9mi If]
;:ol!
Action Car Rental
¢>
~
Use the scroll bar on the right side of the screen to see all of the choices.
••
..
: • 4 4 4 ~
.
lCl4"iW
Map -Tracking
--
on e.
yCir
"'Ii
-
To return to the previous category, press the button.
5. Press a POI to select it and display the following navigation options:
2. Press any part of the map area to enter browsing mode and navigate the map. During
browsing, the map screen borders will turn orange. Use the
+/- buttons to zoom in/out.
Point
the cursor at any location on the map to view location information in apop-up box.
3. Press the MENU button to view navigation options for the selected destination.
Exxon Mobil Corp
tilke Mary 32746
IIPhone:
407'323~703
Navigating to a Recent Location
1. From the "Main Menu", select Drive to ....
To navigate to the location, select Navigate.
To use the location for planning aroute, select Waypoint.
To save the location as abookmark, select Save.
To view the location on the map, select On Map.
Press
Description to view detailed information about the chosen POI, including
address and telephone number, when available.
Search
pals
1. To search for aPOI, return to the "POI Search" screen and press the ABC button. The
"Enter.
.. "screen will appear.
2. Enter the search keyword (at least three characters), and press the OK button. Alist of
POls beginning with the search keyword appears
on the screen. (If there are no POls
containing your search criteria, "No entries found." appears
on the screen.)
3. Press the POI to select it and view navigation options. Continue navigation as instructed
in the previous section.
10

tNAV101 I
2. From the "Drive to ... "menu, select Recents. Alist of recent locations will appear on the
screen:
3. Press to select arecent destination from the "Recents" list. (Use the scroll bar on the righl
side
of the screen to see all of the choices.) Ascreen with navigation options appears.
4. Continue navigation as instructed in the previous sections.
NOTE: The "Recents" list stores the last 15 addresses
or destinations. After 15 entries,
the oldest destination will be deleted and the newest entry added
to the top of the list.
Recent addresses cannot be deleted manually.
Choosing aLocation from your Address Book
1. From the "Main Menu", select Drive to ....
2. From the "Drive to ... "menu, select My Address Book. The "My Address Book" screen
will be displayed:
3. Select one of the following Address Book categories: Home and Work, Favorites, Trips.
The "Home and Work", "Favorites" or "Trips" screen will appear, depending
on your
selection.
4. Press abookmarked location to select it and display available navigation options.
11
5. Continue navigation as instructed in the previous sections.

~ NAV101
NAVIGATING
Browsing the Map During Navigation
You can browse the map while navigating without interrupting the current route -you will still
be guided through voice commands.
To browse during navigation, simply touch the "map" (the screen) and the Map Browsing
feature
is automatically activated. During browsing, the map screen borders will turn
orange until the Back button
is pressed to return to the guide.
The powerful navigation capabilities
of your NAV1 01 will guide you along the shortest or
quickest route from A
to B - with voice commands and in 3D (optional).
To begin navigation, select alocation using the Drive to... feature (see "Choosing and Finding
Locations"
on page 8).
Using the Guidance Menu
To view available menu options during navigation, press the MENU button. The "Guidance
Menu" appears
on the screen:
Alt. route
With this option, you can choose to block the calculated route for agiven distance (e.g., 0.5
mile) and force
an alternate route. Simply tap on the icon which shows the desired distance to
block. Your route will be recalculated, and the previous route will be discarded for the given
distance.
Turn by Turn
Opens the list of the waypoints (turns) along your route.
Save
Save your present position as afavorite.
Volume
Alter the volume of the voice commands.
Search (POI)
Redirect your route by adding apoint of interest (POI) stop, e.g., agas station.
Settings
Change the device settings as described in "Settings Menu" on page 16.
12
Press the
button to return to on-screen navigation.

(NAV101 I
PLANNING A ROUTE
This section describes the route planning feature. This feature allows you to plan your route in
advance, choosing multiple stopovers along yourjourney.
1. To begin navigation, select alocation using the Drive to ... feature (see "Choosing and
Finding Locations"
on page 8).
2Select Waypoint to view the "Destination List", where you will see the location you just
entered.
3. Press the +icon to add astopover to your route. The "Choose stopover" screen appears
4. Choose stopovers like your home or work addresses, afavorite, apoint of interest, a
recent location, or you can search for an address or pinpoint adestination on the map.
5. After adding stopovers, you can modify your trip using the following features:
Use the +icon
to choose additional stopovers.
To change the order of the stopovers, select astopover and then use the up and
down arrows
to move it up/down in the list.
Use the Trash icon to delete aselected stopover.
13
6. Once you have chosen your route, press the MENU button in the bottom right-hand
corner
of the screen. The following options are available:
To begin navigation, press Start Navi. The display will switch to the navigation map.
To simulate the planned route, press Simulate. The device will calculate the route
based
on auser entered destination, but not actually perform navigation guidance
based
on GPS signals. This setting is primarily used for preview or for checking
various routes and turns.
To calculate the route, press Routing. Once the route is calculated, the "Route
Summary" will
be displayed. Select an item from the "Route Summary" to display the
"Turn by Turn" list. When you press (highlight) aturn, the system will prompt "Do you
want to delete this waypoint?". Choose Yes or No. Press the button
to
view the route beginning with the highlighted turn.
To save the route as afavorite trip, press Save (see "Favorites" on page 15).
To return to the previous screen, select Back.
NOTE: When
planning aroute, you can select the Waypoints option to add or delete
stopovers on your trip. When adding a new beginning or ending point, the system will
not automtically eliminate stopovers. The unwanted stops must be manually removed
by selecting them and pressing the Trash can icon.

~ . NAV101
MANAGING YOUR ADDRESS BOOK
The Address Book allows you to save your home and work locations, as well as other frequent
destinations for easy recall. After entering an address or searching for aPOI, you can choose
the Save option to bookmark your selection, eliminating the need to perform repeated
searches.
To access your Address Book, select Drive to ... from the "Main Menu", and then select My
Address Book. The "My Address Book" screen will be displayed:
Home and Work
To access the "Home and Work" screen, press the Home and Work button.
If no home address has been set,
you are prompted to set one. You can choose it by searching
for
an address through your current GPS position or by choosing arecently visited 10cation.To
14
set the initial default address for work or home, press Home or Work and then choose one of
the following options:
To return to the previous screen, select Back.
Select
Address to open the "Find Address" screen and enter the address (see "Finding
an Address" on page 8).
Select GPS
Position to bookmark your current position as your Home or Work address.
Select Recent to choose your Home or Work address from alist
of recent locations.
If the address
is already set, press Home or Work to choose from the following options:
To navigate to the location, select Navigate.
To use the location for planning aroute, select Waypoint.
To change the bookmarked location, select Edit.
To view the location on the map, select On Map.
To return to the previous screen, select Back.
To erase the current saved location, select Delete.
To erase both Home and Work locations, select Delete all.
To modify or navigate to/from an address once it is saved, select the home or work address
and then press the MENU button
to select from available options.

(NAV101 I
Favorites
To access your list of favorites, press the Favorites button. The "Favorites" screen appears:
NOTE: Use
the scroll bar and arrows on the right side of the screen to move up and
down the list and view all entries.
Select an item and then press the MENU button
to choose from the following options:
To navigate to the location, select Navigate.
To use the location for planning aroute, select Waypoint.
Press
Sort to sort all entries into alphabetical order.
To view the location on the map, select On Map.
To return to the previous screen, select Back.
Select Rename to go to the "Change bookmark name" screen and rename the selected
bookmark.
To erase the current saved location, select Delete.
To erase all saved locations, select Delete all.
15
NOTE: All user information such as settings, bookmarks and recently visited locations
are stored on the SD memory card and not on the device.
Trips
To access your list of saved trips, press the Trips button. The "Trips" screen appears:
Select atrip and then press the MENU button
to choose from the following options.
To calculate the route for the selected trip, select Navigate.
To edit existing or add new stopovers to the selected trip, select Edit Stopovers.
Select Rename to go
to the "Change trip name" screen and rename the selected trip.
To erase the current saved trip, select Delete.
To return to the previous screen, select Back.
To erase all saved trips, select Delete all.

~ NAV101
SETTINGS MENU
When using the NAV101 for the first time, it is recommended that you customize the system
parameter settings. For example, regarding navigation, you can choose to avoid
or allow toll
roads or ferries or enable
S.MAR.T. routing. You can also edit display settings, including 20 or
3D mode, day or night mode, map complexity, etc.
To get started, choose Settings from the "Main Menu".
Press Set Time to select the appropriate time zone from the "Time zone" menu (use the
up/down arrows and scroll bar to view the entire list). Press the
OK button to confirm and
return
to the "General Settings" menu.
Press Miles/Kilometers
to change the system of measurement.
Press About to view information about the application.
You can always press the button to return to the previous screen.
Map Settings
Select Map Settings to modify the following options.
General Settings
Select General Settings to modify the following options.
Press Language to view the "Language" screen. Press the "USA" (English) icon and then
select one
of the following voice types for voice commands: English_US female (TIS),
US English Female, US English Male
16

NAV101 I
Calculate route
based
on the short-
est distance.
Do not use toll roads
when calculating
routes.
Try not to use high-
ways when calculat-
ing routes.
Do not include ferry
travel when calculat-
ing routes.
Disable Smart
Routing.
Use highways as
much as possible
when calculating
routes.
Use toll roads when
calculating routes.
Table 1: Route Settings
Calculate route
based on the fastest
time.
Use ferry travel
when calculating
routes.
Enable Smart
Routing (see
"Traffic Avoid-
ance Technology
(Smart Routing)"
on page 18.)
Route Settings
Select Route Settings to modify the following options
Press each button
to toggle between the options listed in Table 1.
Check the boxes of any category you want to have displayed on the map. Uncheck
those that should
be hidden. Note that this will NOT affect any searches that you
perform.
To apply your settings, press the OK button.
Repeatedly press the Day/Night/Automatic button
to toggle between day and night
modes. Choose Automatic to allow the mode
to be chosen automatically based on the
time of day.
To select which and how many icons are displayed on the map, press Display POI.
Select Maps to select the appropriate map (USA). If you have map data for different
regions on your memory card, select the name
of the current region. All available maps
on the memory card will be listed.
Press the
20/30 button to toggle between 2D and 3D display mode.
Press
to toggle the map display between Track Up and North Up.
Track Up: This mode will display the map with the vehicle direction always pointing
up. The map will rotate and move accordingly during navigation while the green
arrow representing the vehicle stays up and still.
North Up: This mode will display the map with North always pointing upward. The
map will not rotate during navigation. The green arrow representing the vehicle will
rotate and move according to the vehicle location on the map.
17
