Jensen JE4021S User manual

Please observe all safety precautions when using this product.
Please read this manual carefu.
IMPORTANT
JE4021S

2
4
4
5
6
11
12
19
20
21
22Specifications

WARNING IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire or electric shock,do not expose
this product to rain or moisture.
This symbol is intended to alert the user to the
presence of uninsulated “ dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
This symbol is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
This product utillizes tin-lead solder, and fluorescent lamp
containing a small amount of mercury. Disposal of these
materials may be regulated due to environmental consid-
erations. For disposal or recycling information,please
contact your local authorities or the Electronic Industries
Alliance: www.eia.org.
FCC STATEMENT
FCC CAUTION:
WARNING
This product has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This product generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference
to radio communications.Operation of this equipment in a
residential area is likely to cause harmful interference
in which case the user will be required to correct the
interference at his own expense.
Pursuant to 47CFR, Part 15.21 of the FCC rules, any
changes or modifications to this monitor not expressly
approved by the manufacturer could cause harmful
interference and would void the user’s authority to
operate this device.
This is a CLASS B product. In a domestic encironment,
this product may cause radio interference, in which cause
the user may be required to take adequate measures to
counter interference
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this product near water.
Apparatus should not be exposed to dripping or
splashing and no objects filled with liquids, such
as vases, should be placed on the product.
6) Clean only with a dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer’s instrutions.
8) Do not install near any heat sources
such as radiators, heat registers,
stoves, or other apparatus(including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your safety.
If the provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10) Protect the power cord from being walked on or
pinched, particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11) Only use attachments / accessories specified by
the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer or sold with
the apparatus.
when a cart is used, use caution when
moving the cart / apparatus combination
to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms
or when unused for long periods of time.
14) Refer all servicing to qualified service
personnel.Servicing is required when the
product has been damaged in any way, such as
power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the
product, the product has been exposed to rain
or moisture, does not operate normally, or has
been dropped.
15) Where the mains plug or an appliance coupler is
used as the disconnect device, the disconnect
device shall remain readily operable.
２

Before using your TV, please read these instructions
completely, and keep this manual for future reference,
Carefully observe and comply with all warnings,
cautions and instructions placed on the unit or
described in the operating instructions or service
manual.
WARNING
Power Sources
Grounding or Polarization
Overloading
Power
Sound
Power Cord
Ventilation
Heat sources
For the unit with a polarlzed AC power cord plug
For the unit with a DC power connector
Wall outlet
Wiring
Electric shock
Cleaning
To guard against injury, the following basic safety
precautions should be observed in the installation,
use and servicing of the unit.
This unit should be operated only from the type of
power source indicated on the information label.
If you are not sure of the type of electrical power
supplied to your home, consult your dealer or local
power company.
This unit is equipped with a polarized AC power cord
plug (a plug having one blade wider than the other), or
a DC power connection, for use in a vehicle. Follow
the instructions below:
This plug will fit into the power outlet
only one way.This is a safety feature.
If you are unable to insert the plug fully
into the outlet, try reversing the plug.If the plug still fails
to fit, contact your electrician to have a suitable outlet
installed. Do not defeat the safety purpose of the
polarized plug by forcing it in.
For installation in a vehicle, connect the red wire to the
12V accessory line and the black wire to ground terminal.
Do not use a poor fitting outlet.
Insert the plug fully into the outlet. If it is loose, if may
cause arcing and result in fire. Contact your electrician
to have the outlet changed.
For your safety, unplug the power cord when wiring
cables.
Do not touch the AC power cord or the unit with a wet
hand. If you plug / unplug the AC power cord from the
unit with a wet hand, it may cause electric shock.
Never attempt to move the unit unless the AC power
cord is disconnected.
Clean the power plug regularly.
If the plug is covered with dust and it picks
up moisture, its insulation may deteriorate
and result in fire.
Unplug the power plug and clean it regularly.
Unplug the power cord when cleaning this unit. If not,
it may result in electric shock.
Clean the cabinet of the TV with a dry soft cloth. To
remove dust from the screen, wipe it with a soft cloth.
Stubborn stains may be removed with a cloth slightly
dampened with a solution of mild soap and warm water.
Never use strong solvents such as thinner or benzine for
cleaning.
If using a chemically pre-treated cloth, please follow the
instructions provided on the package.
Always turn the unit off when it is not being used.
When the unit is left unattended and unused for long periods
of time, unplug it from the wall outlet as a precaution against
the possibility of an internal malfunction that could create a fire
hazard.
Do not overload wall outlets, extension cords or convenience
receptacles beyond their capacity, since this can result in fire
or electric shock.
If a snapping or popping sound from the TV is continuous or
frequent while the TV is operating, unplug the TV and consult
your dealer or service technician. It is normal for TV’s to make
occasional snapping or popping sounds, particularly when
being turned on or off.
If you damage the power cord, it may result in fire or electric
shock.
Do not pinch, bend, or twist the cord excessively.The core
lines may be bared and cut and cause short-circuit, resulting
in fire or electric shock.
Do not convert or damage the power cord.
Do not put anything heavy on the power cord.
Do not pull the power cord.
Keep the power cord away from heat sources.
Be sure to grasp the plug when disconnecting the power
cord.
If the power cord is damaged, stop using it and replace
with a new one.
The slots and openings in the TV are provided for necessary
ventilation. To ensure reliable operation of the unit, and to
protect it from overheating, these slots and openings must
never be blocked or covered. Unless proper Yentilation is
provided, the unit may gather dust and get dirty. For proper
ventilation, observe the following:
Do not install the unit turned backward or sideways.
Do not install the unit turned over or upside down.
Never cover the slots and openings with a cloth or other
materials.
Never block the slots and openings by placing the unit on a
bed, sofa, rug or other similar surface.
Never place the unit in a confined space, such as a bookcase
or built-in cabinet, unless proper ventilation is provided.
Leave some space around the unit. Otherwise, adequate
air-circulation may be blocked, causing overheating, and
may cause fire or damage the unit.
Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
３

LAN
Accessories
The configuration of the components may look different from the following illustration.
Remote ControlBattery 1.5V(AAA X2)
POWER

Mounting on a Desktop
Wall Mounting
Using the Stand
Installation Precautions
1 1
1
1
1
Your LED TV can be mounted on a desktop with the base installed.
This is not a floor-standing unit.
Please refer to diagrams A and B.
Please ensure enough space for safe use.
Installation of the LED TV in an improperly ventilated location can cause damage to the LED TV
due to increased temperature.
(Mounting on a wall)
(Using the Stand)
Contact your dealer to purchase the Adjustable-angle wall mount required for wall-mounted installation.
Do not install on an unstable location with a support area smaller than the LED TV.
Please refer to the desktop stand user＇
s manual for details of installation.

1、Installation Guide
①Show the Installation Guide page after booting up for the first time
Press the [Up and Down] button to switch the OSD Language and press [OK] button to enter the
next setting page.
②Data collection and firmware updates notice page
Press the [Up and Down] button on the remote control to switch the options, and the [OK] button
to confirm the selection. It is recommended to select [ACCEPT].
Items Method Directions
[VIEW ADDITIONAL DETAILS] [OK] button See more detailed firmware/software
network download updateinstructions.
[ACCEPT] [OK] button Accept all agreements and agree to the
firmware/software network to
６

automatically download updates
③If you press [OK] key in the [VIEW ADDITIONAL DETAILS] box，it will go to the data
collection and firmware updates notice view additional details page. Default focus text section,
[Up and Down] key pulls down the text to the bottom and press the [Down] key to switch to the []
DECLIN ALL box, press [OK] key to confirm the selection and go to the next setting page.
④The default country channel tuning settings page
Press the [Up and Down] button on the remote control to select the menu option, [OK] button to
confirm the selection and go to the next setting page.
Items Method Directions
[ACCEPT ALL] [OK] button Accept all agreements and agree to
the firmware/software network to
automatically download updates.
[ACCEPT AUTOMATIC UPDATES] [OK] button Accept all protocol parts and
manually select whether to agree to
the firmware/software network
download update if there is a
firmware/software update
[ACCEPT USAGE INFORMATION
COLLECTION]
[OK] button Accept the agreement and agree to
collect some non-personal user
information.
[DECLINE ALL] [OK] button Reject all protocols and disable
firmware/software network updates.
７

5The time zone setting page
Press the [Up and Down] button on the remote control to select the menu option, [OK] button to
confirm the selection and go to the next setting page.
6The daylight saving time setting page
Press the [Up and Down] button on the remote control to select the menu option, [OK] button to
confirm the selection and go to the next setting page.

7The network type setting page
Press the [Up and Down] button on the remote control to select the menu option, [OK] button to
confirm the selection and go to the next setting page.
Items Method Directions
Wi-Fi Network [OK] button Go to the wireless network connection page
(automatically search for attachment wifi)
Wired Network [OK] button Go to the wired network connection page
Skip [OK] button Skip the network settings and go to the next
level settings page.
8If you do not need to connect to the network, select the“Skip”option, press [OK] button to
confirm, and you will be taken to skip the network settings page.
９

Items Method Directions
Set up network [OK] button Go back to the network settings page
Skip[OK] button Confirm to skipthe network settings
and enter input source setting page.
Items Method Directions
Start Netflix [OK] button Start Netflix takes you to Netflix app
Skip [OK] button Skip takes you to Input Source
9The input source setting page
IF you set up network the next screen is
Press the [Up and Down] button on the remote control to select the menu option, Press the [OK]
button to confirm the selection and go to the next setting page. Pressing the [DOWN] button all
the way willturn the page to the USB source.
Items Method Directions
TV [OK] button Go to the channel tuning page
AV HDMI1 HDMI2...USB [OK] button Switch the source channel

10 The channel tuning page
The UI default focus the “Skip” option, Press the [OK] button to skip the DTV channel tuning
then enter the ATV channel tuning.
2、HOME
Press the [Home] button to display the homepage,Press the [Up and Down] button to switch
between the Apps, NETFLIX, Input souce, and Settings options, Press the [Left and Right]
button to select the corresponding sub-option and press the [OK] button to confirm

3、Main Menu
Press the [ ] button to display the main menu. Press the [Up and Down] but ton to switch
between the options of Picture, Sound, Setting, Lock, PVR Option, Programm, Network, About.
Press the [Right] button to jump to the sub-option on the right.
3.1 Picture
Function Description：
Items Directions
Apps All APPS：Netflix、YouTube、、Facebook 、TwitterVudu 、Smart TV Apps、
Youtube Kids、Screencast、Browser、There may be some custom differences Apps.
NETFLIX Netflix account recommendation information
Input All input source：TV、AV、HDMI1/2/3、USB
Setting All menu settings：Picture、Sound、Setting、Lock、
Programme、
Network、About

Items Adjustable mode Directions
Picture Mode Standard->Movie->User->Power Saving->
Dynamic
Picture mode
adjustment
Contrast Picture Mode is adjustable in User mode 0-100 Contrast adjustment
Brightness Picture Mode is adjustable in User mode 0-100 Brightness adjustment
Color Picture Mode is adjustable in User mode 0-100 Color adjustment
Sharpness Picture Mode is adjustable in User mode 0-100 Sharpnessadjustment
Tint Picture Mode is adjustable in ATV NTSC mode Tint adjustment
Backlight tnemtsujdathgilkcaB001-0
Color Temperature Standard -> Warm -> Cool Color adjustment
AspectRatio Standard->Wide->Wide Zoom->Zoom Aspect Ratio
Noise Reduction Low->Middle->High-> Auto->Off Noise Reduction
adjustment
3.2 Sound
Function Description：
Items Adjustable mode Directions
Sound Mode Standard ->Music -> Movie ->
Sport -> User Sound Mode adjustment
Equalizer
(on show only
when the
Sound Mode is
user mode)
120Hz 0-100
120Hz frequency range
sound amplitude gain
adjustment.
500Hz 0-100 500Hz requency range sound
amplitude gain adjustment.
1.5KHz0-100
1.5KHz requency range
sound amplitude gain
adjustment.

5KHz 0-100 5KHz requency range sound
amplitude gain adjustment.
10KHz 0-100 10KHz requency range sound
amplitude gain adjustment.
Balance (-)50—tnemtsujdaecnalabemuloV05
Auto Volume Limit Off->On Auto Volume Limit
adjustment
tnemtsujdadnuoSdnuorruSffO/nOdnuoSdnuorruS
Digital output type Auto->Dolby DD Dolby DD+>
-
-
>PCM
SPDIF port output mode
adjustment
Audio
Delay
SPDIF Delay 0-250 SPDIF volume delay time
adjustment
Speaker Delay 0-250 Speaker volume delay time
adjustment
HDMI ARC
Delay 0-250
0-100
ARC volume delay time
adjustment
Video Description Off->On(on show only for DTV
channel)
Video Description adjustment
Video Volume adjustment
Audio Languages English->French->Spanish Audio Languages adjustment
VD Volume
3.3 Setting
Function Description ：
Items Adjustable mode Directions
Language OSD
Language English- -> French>Spanish OSD menu language selection adjustment
OSD Time Always->5 Seconds->10
Seconds ->15 Seconds OSD menu display time adjustment

Close
Caption Basic
Slection
Off->CC1->CC2->CC3->CC4->
Text1->Text2->Text3->Text4 CC channel adjustment
Advanced
Selection
Off->Service1->Service2->
Service3->Service4->Service
5->Service6
CC Service adjustment
Option CC font display effect adjustment page
Link
Setup
Link-CEC On/Off HDMI CECadjustment
HDMI ARC On/Off HDMI ARC adjustment
Auto Power On/Off
Whether the TV is automatically
turned on when the related DVD
device is turned on
Auto
Standby On/Off When the TV is turned off, the CEC device is turned off.
Time
Auto Sync On/Off System time setting switch
Clock System time display box, optional when Auto Sync is off, [Right]
key to enter the system time setting page
Sleep Timer
Off->10min->20min->30min
->60min->90min->120min->
180min->240min
Sleep time setting
Time Zone Time Zone adjustment
DST Off/On The daylight saving time setting
page
Reset Yes or No User reset
TTS
elbasiDroelbanESTTteSffO/nOelbanE
Verbosity Low->High TTS Verbosity adjustment
Rate Support Slow->Middle->Fast TTS Rate Support adjustment
Pitch
Support Low->Middle->High TTS Pitch Support adjustment
Speaker Betty Say->Anita Say TTS Speaker adjustment
3.4 Lock
CC MODE CC off->CC On Mute->CC On CC MODE adjustment

Function Description：
Items Adjustable mode Directions
Lock System On/Off Control Set Password, USA and Canada Tv
Rating Switch
Set
Password
Please Enter
Old Password
Default password
“0000”
Set the system password. Press the [number]
button on the remote control to set the new
system password. Please enter the password
before and after the New Password and
Confirm New Password. The inconsistency
will indicate that the Password not match
setting fails. After the setting is successful, it
will automatically return to the previous
layer.
Please Enter
New Password
Confirm New
Password
USA TV USA TV rating channel lock adjustment page
USA MPAA USA MPAA rating channel lock adjustment page
Canada English Canada English rating channel lock adjustment page
Canada French Canada French rating channel lock adjustment page
RRT Setting RRT Setting page(This feature is only available on special
channels.)
RRT Reset Reset RRT (This feature is only available on special channels.)
Block Unrated TV On/Off Block Unrated TV adjustment
3.6 Program
TV channel can be accessed by [Right] button.
１６

Function Description：
Items Adjustable mode Directions
Antenna Mode Air->Cable Antenna Mode adjustment
Auto Tuning Start auto tuning
Signal Information View channel signal strength (In the DTV channel can be focused)
3.6 Network
Function Description：
Items Adjustable mode Directions
Wi-Fi
AUTO Scan Automatically search for nearby wireless networks
Manual Input Manually enter the wifi that needs to be connected
IP Wireless network ip address prompt box
Netmask Wireless network subnet mask prompt box
Gateway Wireless network gateway prompt box
１７

DNS Wireless network DNS prompt box
Ethernet
Protocol IPv4->IPv6 Wired network protocol selection
Configuration DHCP->Static Wired network ip acquisition
method selection
IP Wired network ip address, Configuration is set to Static optional
Prefix The number of bits in the wired network subnet mask is set, and the
Configuration is set to Static.
Gateway Wired network gateway, Configuration is set to Static optional
DNS Wired network DNS, Configuration is set to Static optional
Connect Connect to a wired network
Wake On LAN On/Off Wired network wake up TV enable switch
Wake On WLAN On/Off wireless network wake up TV enable switch
3.7 About
Function Description：
Items Directions
NETFLIX
Netflix Deactive Clear Netflix login account
Terminate Netflix Exit Netflix
Netflix ESN Check out the View ESN key
Netflix Version Check out the Netflix version
View End-User License Agreement View End-User License Agreement
System information Check out the system information
NetReady Information Check out the NetReady Device ID information
Software Update(USB) USB Software Update
Internet Update Check Check out the Internet Update
１８

3、USB
Insert the USB flash drive and press the [OK] button in the USB menu of the input source page to
enter the Media menu.
Press the [Left and right] button Select the inserted USB flash device,press the [OK] button to
enter the following page
Press the [Left and right] buttons can be selected ALL, Photo, Music, Video options, press the
[OK] button to select the file type, "Return" box to press [OK] to return to the previous directory,
select a file press the [OK] button to enter the video file.
１９
