With the AirBox Convertible Upgrade CA LE you will be able to remove the air out of the following
printhead cartridges:
CANON Lexmark
Europe North America Middle East All regions
Africa Latin America Asia
Oceania
G37 G37 G37 1 HC
G40 G40 G40 14
G50 G50 G50 14A
G510 G210 G810 15
G512 G210XL G810XL 15A
CL38 CL38 CL38 23
CL41 CL41 CL41 23A
CL51 CL51 CL51 24
CL52 CL52 CL52 24A
CL511 CL211 CL811 28
CL513 CL211XL CL811XL 28A
29
29A
31
32
33
34
35
36
36A
36XL
36XLA
37
37A
37XL
37XLA
40
41
42
To use the AirBox Convertible pgrade CA LE you need also the AirBox Convertible Basis
Part!
How to use the AirBox Convertible
What you need in addition:
1. a pump
2. refilled printhead cartridges
3. a lintless cloth

www.jero.de primabat
®
GmbH
Seite 2 von 2 Stand: 25.11.2011
Tel.: [phone] ax: [phone]
Alle von uns erstellten Produkte unterliegen Marken- und Schutzrechte deren Inhaber Jens Rogge ist.
Alle Preise verstehen sich netto zzgl. Mehrwertsteuer z.Zt. 16% exkl. Versandkosten. Es gelten ausnahmslos unsere allgemeinen
Geschäftsbedingungen der neusten assung. Powered by primabat® GmbH
•The upgrade for H has to be placed onto the AirBox Basis art.
•On the back side of the upgrade you can see 4 holes (2 at the upper edge and 2 at the lower
edge) for fixing the upgrade on the 4 center screws of the AirBox Basis art.
•Hold the upgrade that way in which you are able to read the markings and press it carefully
down between the valve banks of the Basis art.
•Take care that the Upgrade is centered on the 4 screws of the Basis art.
•Now mount the included tubes in the correct order:
a. thick U tube
b. tube connector
c. thin U tube
d. tube connector
e. silicone tube with yellow tube reduction
f. Luer-Lock tube connector
•Connect the U tube with your pump.
•Combine the white Luer-Lock connector with the valve bank you decided to work with.
•Make yourself familiar with the arrangement of valve banks and the numbers leading to the
seperate channels of the upgrade.
•Valve No. I opens channel no. I, valve no. II opens channel no. II and so on.
•Switch on the pump.
•Every valve has 3 levers. If the valve is open the mid-lever points to the connected tube. If
the valve is closed the mid-lever points at the opposite direction or upwards.
•Insert the selected cartridge into the upgrade's notch - printhead facing up. The cartridge's
ventilation holes fit exactly on the air channels of the upgrade.
•lease start with the darkest ink. rocess the lightest color at last!
•Open the desired tube slowly and keep the lintless cloth at hand.
•ress the cartridge into the upgrade's rubber slightly with one finger.
•Tap slightly onto the number near the opened valve to control the air flow to the
ink chamber.
•When ink is coming out of the printhead wipe it off carefully with the lintless cloth.
•lease wipe only from back to front - just like the direction the nozzles are arranged in the
printhead.
•rocess this until you can see a constant ink flow without breaks.
•If the result is satisfying interrupt the air flow to the ink chamber by closing the valve.
•After that you can process the other ink chambers of the cartridge.
•Make a testprint.
•If the printout is perfect you have removed all bubbles.
•If the printout is streaky, start at the beginning. You only have to process the colors which
cause the white lines in your testprint.
