7
ATTENTION
Qualified technicians installing the
machine are obliged to train the operators
about the machine utilization and
safety procedures to be followed. They
must provide a real “demonstration” and
verify that machine's instructions are
available to the operators.
Following warnings should be noted:
The dishwasher must be installed
in accordance with local codes, or in
the absence of local codes, installed
in accordance with the applicable
requirements in the National Electrical
Code, NFPA 70, Canadian Electrical Code
(CEC), Part 1, CSA C22.1, and Standard for
Ventilation Control and Fire Protection of
Commercial Cooking Operations, NFPA 96.
WARNING!
DO NOT OPEN THE DOOR QUICKLY IF
CYCLE HAS NOT ENDED.
DO NOT DIP BARE HANDS INTO THE
WASHING SOLUTION.
DO NOT REMOVE THE PANELS IF THE
MACHINE HAS NOT BEEN DISCONNECTED
FROM THE POWER AND WATER SUPPLY.
DO NOT BYPASS THE MACHINE'S
PROTECTION DEVICES (MICROSWITCHES,
PANELS, ETC) PROVIDED BY THE
MACHINE MANUFACTURER IF NOT IN THE
PRESENCE OF TRAINED TECHNICIAN THAT
CAN TAKE THE PROPER PRECAUTIONS.
DO NOT UTILISE THE MACHINE TO WASH
OBJECTSOF SHAPE, TYPE, SIZE, AND
MATERIAL NOT COMPATIBLE WITH THE
MACHINE.
DO NOT OPERATE THE MACHINE IF NOT
PROPERLY CONNECTED, ACCORDING TO
THE SPECIFICATIONS AND REQUIREMENTS
OF THE LOCAL LAW AND PRESCRIPTION OF
MANUFACTURER, MAKING SURE THAT ALL
SAFETY DEVICES ARE OPERATIVE.
ID/RATING/DATA PLATE
ID/Rating plate of the appliance contains
identification and technical data and is
located on front panel.
2A – WATER CONNECTION
N.B.
The shut-off valve must be a single
direction, spool, sphere, lid control type,
which can shut off the water supply
quickly and totally. The water pressure
and flow must conform to the data
diagram supplied with each machine.
1- Position the dishwasher and level the
appliance by turning the respective
height-adjustable feet. (Fig.4)
Fig. 4
2- Connect the solenoid valve, which feedsthe
machine, to the water shutoff valve,
using a flexible line. (Fig.5) Each
machine must have its own water
supply line.
Fig. 5
2A1 – WATER SUPPLY PRESSURE Check
that the dynamic water supply pressure,
measured between the appliance and the
mains, is between 29 and 58 psi. If the
pressure is too high, install a suitable
pressure reducer on the inlet pipe. If the
pressure is low, install an additional external
pressure pump. (par.1D – Technical Data)
-In case of new install or long term appliance
inactivity, drain the water line to eliminate air
bubbles and foreign bodies present in new or
unused water lines. Failure to do so could
damage the machine.
2A2 – WATER HARDNESS
If water hardness is higher than acceptable,
install a water softener of adequate size
before the feed solenoid valve. (par.1D –
Technical Data)
If there is a high concentration of
mineral residue in the water or high
conductivity, we recommend installing the
demineralization filter for 5/7° f.
INSTRUCTION FOR INSTALLER / MAINTENANCE
