Jeti specbos 1211 Manual

Short Instructions
Spectroradiometer
specbos 1211
JETI Technische Instrumente GmbH
Tatzendpromenade 2
D-07745 Jena
Tel [phone]
Fax [phone]
e-mail: sales @ jeti com
Internet: www jeti com

Operating Instructions JETI – Spectroradiometer specbos 1211
- 2 -

Operating Instructions JETI – Spectroradiometer specbos 1211
License Agreement for JETI Technische Instrumente GmbH Software Products
IMPORTANT READ CAREFULLY BEFORE USING THE JETI SOFTWARE
JETI hereby grants to you a non-exclusive license to use one copy of the delivered JETI
software program (the "software") on a single computer according to the following items:
The software is in "use" on the computer when it is loaded into temporary memory (i e
RAM) or installed into permanent memory (e g hard disk, CD-ROM, or other storage
device) of the computer However, installation on a network server for the sole purpose of
distribution to one or more other computer(s) shall not constitute "use" for which a separate
license is required, provided you have separate license for each computer to which the
software is distributed
It is only allowed to use the software in connection with the JETI product (instrument,
spectrometer or OEM electronics), which was delivered with this software For additional
JETI products you need an extra software license
The software is owned by JETI or its suppliers and is protected by German copyright laws
and international treaty provisions and all other applicable national laws Therefore, you
must treat the software like any other copyrighted material (e g a book or musical
recording) except that if the software is not copy protected you may either
(a) make one copy of the software solely for backup or archival purposes, or
(b) transfer the software to a singlehard disk provided you keep the original solely for
backup or archival purposes You may not copy the user documentation provided with
the software and the connected JETI product
You may not:
(i) permit other individuals to use the software except under the terms listed above;
(ii) modify, translate, reverse engineer, decompile, disassemble (except to the extent that
this restriction is expressly prohibited by law) or create derivative works based upon
the software or documentation;
(iii) copy the software or documentation (except for back-up or archival purposes);
(iv) rent, lease, transfer, or otherwise transfer rights to the software or documentation;
(v) remove any proprietary notices or labels on the software or documentation
Any such forbidden use shall immediately terminate your license to the Software
(a) You agree that you shall only use the software and documentation in a manner that
complies with all applicable laws in the jurisdictions in which you use the software and
documentation, including, but not limited to, applicable restrictions concerning
copyright and other intellectual property rights
(b) You may not use the software in an attempt to, or in conjunction with, any device,
program or service designed to circumvent technological measures employed to
control access to, or the rights in, a content file or other work protected by the copyright
laws of any jurisdiction
(c) If you receive the first copy of the software electronically and a second copy on
physical media (e g , CD, diskette, etc ), the second copy may be used for archival
purposes only and may not be transferred to or used by any other person This license
does not grant you any right to any enhancement or update
The software may include certain external software components ("Add-Ons"), including the
Lab Windows user interface and drivers You may only call to or otherwise use such Add-
Ons through the use of the JETI applications Any direct use of Add-Ons through a non-JETI
proprietary application, including a custom or user-written application is prohibited by this
Agreement
If you have purchased JETI software in connection with a JETI product, you have the right
of purchasing a software update, if it is available, for a priority price
Title, ownership, rights, and intellectual property rights in and to the software and
documentation shall remain in JETI and/or its suppliers Title, ownership rights and
intellectual property rights in and to the content accessed through the software including the
content contained in the software media demonstration files shall be retained by the
applicable content owner and may be protected by applicable copyright or other law This
license gives you no rights to such content
For the JETI operating environment, the following terms apply:
- 3 -

Operating Instructions JETI – Spectroradiometer specbos 1211
JETI warrants that for a period of ninety (90) days from the date of acquisition the software,
if operated as directed, will substantially achieve the functionality described in the
documentation JETI does not warrant however that your use of the software will be
uninterrupted or that the operation of the software will be error-free or secure JETI also
warrants that the media containing the software, if provided by JETI, is free from defects in
material and workmanship and will so remain for ninety (90) days from the date you acquire
the software
To the maximum extend permitted by applicable law JETI and its suppliers disclaim all other
warranties either express or implied including but not limited to implied warranties of
merchantability and fitness for a particular purpose with regard to the software, the
accompanying written materials and any accompanying hardware
If the media is subjected to accident abuse or improper use during the warranty period; or if
you violate the terms of this License Agreement, this warranty shall immediately terminate
This warranty shall not apply if the software is used on or in conjunction with hardware or
software other than the unmodified version of hardware and software with which the
software was designed to be used as described in the documentation
This limited warranty gives you specific legal rights
Your remedies:
JETI's sole liability for a breach of this warranty shall be in JETI's sole discretion:
(i) to replace your defective media; or
(ii) to advise you how to achieve substantially the same functionality with the software as
described in the documentation through a procedure different from that set forth in the
documentation; or
(iii) if the above remedies are impracticable, to refund the license fee, if any, you paid for
the software Repaired, corrected or replaced software and documentation shall be
covered by this limited warranty for the period remaining under the warranty that
covered the original software or if longer for thirty (30) days after the date JETI either
shipped to you the repaired or replaced software or advised you as to how to operate
the software so as to achieve the functionality described in the documentation,
whichever is applicable Only if you inform JETI of the problem with the software
during the applicable warranty period and provide evidence of the date you acquired
the software will JETI be obligated to honor this warranty
Under no circumstances and under no legal theory whether in tort contract or otherwise
shall JETI or its suppliers or resellers be liable to you or any other person for any indirect,
special, incidental or consequential damages of any character including without limitation
damages for loss of goodwill, work stoppage, computer failure or malfunction or any and all
other commercial damages or losses even if JETI shall have been informed of the possibility
of such damages or for any claim by any other party Further, in no event shall JETI´s
liability under any provision of this agreement exceed the license fee paid to JETI for the
software and documentation
This software is intended for use only with properly licensed media, content, and content
creation tools It is your responsibility to ascertain whether any copyright, patent or other
licenses are necessary and to obtain any such licenses to serve and/or create, compress or
download such media and content You agree to record, play back and download only those
materials for which you have the necessary patent, copyright and other permissions,
licenses, and/or clearances You agree to hold harmless, indemnify and defend JETI, its
officers, directors and employees, from and against any losses, damages, fines and
expenses (including attorneys' fees and costs) arising out of or relating to any claims that
you have
(a) viewed, downloaded, encoded, compressed, copied or transmitted any materials (other
than materials provided by JETI) in connection with the software in violation of another
party's rights or in violation of any law, or
(b) violated any terms of this License Agreement
This License Agreement will automatically terminate if you fail to comply with any term
hereof No notice shall be required from JETI to effect such termination
- 4 -

Operating Instructions JETI – Spectroradiometer specbos 1211
Technical support for the software, as made available by JETI, is given directly from the
JETI office in Jena, Germany
This License Agreement shall constitute the complete and exclusive agreement between
JETI, it’s resellers and the end user, notwithstanding any variance with any purchase order
or other written instrument submitted by you, whether formally rejected by JETI or not The
acceptance of any purchase order you place is expressly made conditional on your consent
to the terms set forth herein The terms and conditions contained in this License Agreement
may not be modified except in a writing duly signed by you and an authorized representative
of JETI If any provision of this License Agreement is held to be unenforceable for any
reason, such provision shall be reformed only to the extent necessary to make it
enforceable, and such decision shall not affect the enforceability of such provision under
other circumstances, or of the remaining provisions hereof under all circumstances This
License Agreement shall be governed by the laws of Germany, without regard to conflicts of
law provisions, and you hereby consent to the exclusive jurisdiction of the provincial and
federal courts sitting in Germany Any and all unresolved disputes relating in any way to, or
arising out of, the software, your use of the software or this License Agreement shall be
submitted to arbitration in Germany; except that, to the extent that you have breached or
have indicated your intention to breach this License Agreement in any manner which
violates or may violate JETI's intellectual property rights, or may cause continuing or
irreparable harm to JETI (including, but not limited to, any breach that may impact JETI's
intellectual property rights, or a breach by reverse engineering), JETI may seek injunctive
relief, or any other appropriate relief, in any court of competent jurisdiction
Copyright (c) 2012 JETI Technische Instrumente GmbH and/or its suppliers
JETI Technische Instrumente GmH, Tatzendpromenade 2, 07745 Jena, Germany All rights
reserved
- 5 -

Operating Instructions JETI – Spectroradiometer specbos 1211
- 6 -

Operating Instructions JETI – Spectroradiometer specbos 1211
Table of Contents
1. Introduction 9
2. Installation of Driver Software 11
2 1 Installation of Driver Software 11
2 1 1 Installation under Windows XP 11
2 1 2 Installation under Windows Vista and Windows 7 and
8 11
2 2 PC- Software 12
2 2 1 Installation under Windows 12
3. Operation of Device 13
3 1 specbos 1211 13
3 2 specbos 1211-BT 13
4. Installation of Hardware 15
4 1 Installation of USB Device 15
4 2 Installation of Bluetooth Device (specbos 1211 BT)15
4 3 Installation of RS Device (specbos 1211 RS) 19
4 4 Network settings for specbos 1211 LAN 19
4 5 Installing RealPort Driver 21
5. Start the Software 24
6. Measurement 26
6 1 Procedure 26
6 1 1 Measurement with specbos 1211-BT 27
6 1 2 Finishing the Program 29
7. Software Settings 30
7 1 Measurement Settings 30
7 1 1 Integration Time 30
7 1 2 Continuous measurement 31
7 1 3 Change measurement name 31
7 1 4 Delete Measurements 32
7 1 5 Calculation Range 33
7 2 Display Settings 33
7 2 1 Zoom 33
7 2 2 Diagram Options 34
7 2 3 Snap-to-Point Cursor 38
7 2 4 Screen Mode 38
7 3 Special Calculations 38
- 7 -

Operating Instructions JETI – Spectroradiometer specbos 1211
7 4 Snapshot 39
8. Data Storage 40
8 1 Data Transfer 40
8 2 Data Export 42
9. Shortcut Keys 44
10. Trigger Functions 45
11. Maintenance and Error Messages 46
12. Technical Data 47
12 1 Mechanical Dimensions 48
12 2 Battery charging (only specbos 1211-BT) 48
13. CE – Declaration of Conformity 50
14. Certificate of Warranty 51
15. Service 53
- 8 -

Operating Instructions JETI – Spectroradiometer specbos 1211
1. Introduction
specbos 1211 is an easy to use spectroradiometer for various
applications Its miniaturized shape makes it suitable for laboratory
as well as industrial use The spectroradiometer specbos 1211 can
measure luminance/ radiance as well as illuminance/ irradiance
Furthermore colorimetric data (CCT, chromaticity, color purity,
dominant wavelength, CRI) are calculated from the spectral data
Therefore it is suited for the test of light sources as CRT screens, for
the measurement of projectors and of room illuminance
specbos 1211 covers the wavelength range of 350 … 1000 nm and
is suitable for low light measurements due to its high sensivity
The version specbos 1211 UV extends the wavelength range to 250
nm
The indication of the measuring spot on the target in case of
luminance/ radiance measurements will be proceeded with a pilot
laser circle Irradiance measurements are done with a cosine
corrector head-piece The software switches automatically to the
appropriate measuring mode depending from the attached
measuring head
Acquisition and analysis of data is done by the PC software JETI
LiMeS The connection to the PC is via USB interface (virtual COM
port) It is also possible to communicate directly with the instrument
without the PC program Virtual Instruments for LabView are
contained on the CD as well as radiometric and spectrometric DLLs
Detailed helping information for both applications is included
Furthermore the instrument can be driven by the SCPI compatible
firmware commands The command list is also available on the CD
specbos 1211 is available with additional interfaces:
Serial interface specbos 1211 RS232
Bluetooth interface specbos 1211 BT
PC requirements:
•Pentium 4 / AMD Athlon XP or higher, min 512 MB RAM
•Graphic resolution: 1024*768, 16 bit color depth
recommended
•Windows XP (SP3); Vista or Windows 7, Windows 8; Excel
2000 (for data transfer)
- 9 -

Operating Instructions JETI – Spectroradiometer specbos 1211
The specbos 1211 packages includes:
•Basic device specbos 1211 with protection cap
•Cosine corrector head-piece
•Operating instructions
•Tripod
•Transport box
•CD-ROM with PC software JETI LiMeS, DLLs, LabView Virtual
Instruments, operating instructions and firmware command list
•USB cable
•Trigger connector
additionally:
specbos 1211 BT
•Bluetooth antenna, bluetooth adapter and a rechargeable
lithium polymer battery EasyPack 3 7V (EZPack XL)
specbos 1211 RS
•serial cable
•Power supply 9V
specbos 1211 LAN
•Power supply 5V
- 10 -

Operating Instructions JETI – Spectroradiometer specbos 1211
2. Installation of Driver Software
2.1. Installation of Driver Software
Don't connect the device during driver installation.
Please note that you must have administrator privileges to
install the device driver!
This chapter describes the installation procedure of the USB driver
2.1.1 Installation under Windows XP
1 Insert CD-ROM delivered with your device into the
CD/DVD drive
2 If Autorun is enabled on your PC an installation program
starts automatically Please exit this program by pressing
Exit Install
3 Open directory 'Driver' on the installation CD-ROM
4 Run 'install bat' and follow the instructions
5 After finishing connect your device to an USB-port
6 A ‘New Hardware found’ wizard should appear If it asks to
connect to Windows Update answer with No
7 Select Install software automatically (recommended) and
press Next
8 Windows should complete the driver installation
automatically
If the driver couldn’t be installed successfully please read chapter
Fehler: Referenz nicht gefunden “Uninstall driver software” and try
again
2.1.2 Installation under Windows Vista and Windows 7 and 8
1 Insert CD-ROM delivered with your device into the
CD/DVD drive
2 If Autorun is enabled on your PC an installation program
starts automatically Please exit this program by pressing
Exit Install
3 Open directory 'Driver' on the installation CD-ROM
4 Run 'install bat' and follow the instructions
5 After finishing connect your device to an USB-port
6 Windows should complete the driver installation
automatically
- 11 -

Operating Instructions JETI – Spectroradiometer specbos 1211
If the driver couldn’t be installed successfully please read chapter
Fehler: Referenz nicht gefunden “Uninstall driver software” and try
again
- 12 -

Operating Instructions JETI – Spectroradiometer specbos 1211
2.2. PC Software
2.2.1 Installation under Windows
Please note that you must have administrator privileges to
install the device driver!
Execute the following steps on the PC to install the software JETI
LiMeS :
•Start Windows 7/ 8/ XP/ Vista
•Insert the CD in the CD-ROM drive
•The following window appears, if the autostart function of
Windows is activated
Otherwise press install exe in the Install folder of the CD ROM
•Click the Install JETILiMeS and follow the instructions to
install the program
- 13 -

Operating Instructions JETI – Spectroradiometer specbos 1211
3. Operation of Device
3.1. specbos 1211
The instrument is switched on automatically when the USB connection to
the PC is established
Attention: The USB driver must be installed at first without connected
instrument
Pressing the illuminated switch switches on the target marking if the
instrument is in Radiance mode Repeated pressing switches the target
marking off
3.2. specbos 1211 BT
The specbos 1211 BT will be powered by battery if the wireless
interface is used The battery will be charged when the instrument is
connected to the PC via USB Alternatively it can be charged with the
power supply
The switch on the rearside has the following functions:
•Pressing if instrument is switched off: Switch on the instrument
•Short pressing if the instrument is switched on: Switch on/ off
the target marking
•Long pressing if the instrument is switched on: Switch off the
instrument
•If the instrument is switched off and connected to power
supply or to PC by USB:
•Short flashing – battery will be charged
•Continuous illumination – battery is fully charged
•If the instrument is switched on:
•Continuous illumination with short breaks – battery will be
charged
•Continuous illumination – battery is fully charged
Remark: The USB connection between PC and instrument needs to be
established if the battery shall be charged via USB
Automatic switch off:
- 14 -

Operating Instructions JETI – Spectroradiometer specbos 1211
The instrument will be switched off if there is no connection to the PC for
more than 15 min , e g if the operator forgot to switch it off If the
software LiMeS is running the instrument will be not switched off
automatically
The battery powered specbos 1211 BT will be automatically switched
off if the defined operating time of 15 min without any communication is
elapsed The device send in this case a enquire code (0x05)
Battery down:
If the battery charge is below the low value an enquire code (0x05) will
be sent, and a timer for time out starts (see chapter Measurement with
specbos 1211 BT)
After time out the device send again the enquire code and switched
power off
- 15 -

Operating Instructions JETI – Spectroradiometer specbos 1211
4. Installation of Hardware
4.1. Installation of USB Device
Unpack the spectroradiometer specbos 12x1 carefully and check the
delivered parts
trigger connector USB connector power supply
Attention: The USB driver must be installed at first without connected
instrument
Connect the device to an USB interface of a PC or laptop using the
enclosed USB cable
4.2. Installation of Bluetooth Device (specbos 1211 BT)
specbos 1211 BT can be used alternatively via bluetooth or USB
Press the rearside switch until it is shinning in blue
illuminated switch battery bluetooth adapter
trigger connector USB connector power supply
- 16 -

Operating Instructions JETI – Spectroradiometer specbos 1211
The package of the device includes the bluetooth antenna Please
connect it to the instrument as it is shown below
The bluetooth interface is often integrated into modern computers If
your computer is not equipped with it you need to use the bluetooth
dongle (included in the delivery)
The software guides you through the installation
•Click on the symbol
•Click Add a Device
- 17 -
bluetooth
antenna

Operating Instructions JETI – Spectroradiometer specbos 1211
•Click Continue and select JETI specbos 1211
•Click Enter the device's pairing code and Next
- 18 -

Operating Instructions JETI – Spectroradiometer specbos 1211
•Insert the device pairing code: 0000 and click Next
The next window finalizes the installation
- 19 -

Operating Instructions JETI – Spectroradiometer specbos 1211
4.3. Installation of RS Device (specbos 1211 RS)
Connect the device to a PC or laptop using the enclosed RS cable
and the power supply (9 V):
power supply RS232 connector
4.4. Network settings for specbos 1211 LAN
The specbos device and the controlling PC have to use the same
network address to communicate with the specbos 1211 LAN via a
network connection space
The default network setting of the specbos device is set to DHCP
(obtain network settings automatically) If a DHCP server is running
in your network the device will obtain an IP address from within the
local network address space, and no further steps are required
If no DHCP server is available (e g direct connection to a PC) or you
want to give the device a fixed IP address for some other reasons,
the network setting of the specbos device has to be changed by a
tool called "Digi Device Discovery", which is available on the
installation CD
Please note that you must have administrator privileges!
1 Connect specbos 1211 LAN to the power supply and to the LAN
(1:1 as well as crossed cables can be used)
2 Go to directory 'Tools\Device Discovery' on the installation CD
and run 'dgdiscvr bat
- 20 -
illuminated switch
mini USB connector power supply 5V
trigger connector
