Jetting MJet V2 Instruction Manual

V2
Product Model V2
V2 USER GUIDE AND SAFETY MANUAL

Copyright © 2024 by Jetting AB
All rights reserved. No part of this publication may be reproduced, distributed, or
transmitted in any form or by any means, including photocopying, recording, or
other electronic or mechanical methods, without the prior written permission of
the publisher. For permission requests, write to the publisher, addressed ”Attention:
Permissions Coordinator,” at the address below.
Jetting AB, Murgatan 1, 522 30 Tidaholm, Sweden
jetting.se | [e-mail]
2

1. Claw Connector
2. Air Valve
3. Handle
4. Drive Belt Protection
5. Belt Clamping Lever
6. Drive Belts
7. Cable inlet
8. Easy Joystick Controller
9. Display
10. Power Button
11. Reset Button
12. Jetlogger socket
13. Battery Socket
14. Regulator
15. Security Stop
16. Oil Adjustment Screw
17. Oil Container Screw
18. Manometer for Motors
19. Pneumatic Motor
20. Pressure Sensor
21. Clamp bracket
22. Duct Clamps
23. Duct Release Air Valve
24. Manometer Duct
3
21
20
23
24
22
15
16 17
14
13
18
19
10
11
12
9
8
7
6
4
5
1
2
3

Important Safety Notice
Read and understand all procedures and safety instructions before using the V2 fiber blowing machine.
Please note all safety information on this page and take note of specific safety requirements outlined
in the procedures of this manual. Failure to follow these instructions may result in serious personal injury
or death.
Warning: The noise level will exceed 70 dB.
Manufacturer
Jetting AB
Murgatan 1
522 30 Tidaholm
Sweden
jetting.se
[e-mail]
[phone]
4

Table of Contents
General Information
Technical Information
Safety Regulations
Unpacking the Box/Case
Machine Setup
Cable Crash Test
Machine Operation
Maintenance
Repair & Service
Troubleshooting
Documentation and Recycling
EC Declaration
Notes
Section Page
1
2
3
4
5
6
7
8
9
10
11
12
13
6
7
8
11
11
13
14
18
20
20
20
21
22
5

6
1. General Information
The V2 is a unique device designed for the installation of fiber optic cables directly into ducts. The
V2 consists of a duct clamp and a belt drive system, which, when combined, installs a cable into an
airtight duct at speeds ranging from 0-200 m/min.
The V2 comes equipped with an LCD display as standard. The machine should be complemented with
specified duct clamps, cable seals, and cable guides depending on the dimensions of the duct and
cable for installation.
This user manual provides a comprehensive description of the V2, designed to feed fiber optic cable
through ducts. The duct must have been previously installed underground or above ground to receive
the fiber optic cable and must be suciently long at the outlet to be received by the machine. The
duct must be made of material with adequate pressure resistance to be tightly sealed in the machine’s
duct clamps. The duct should be airtight up to a pressure of 16 bar. Duct sizes range from 7 mm-50
mm, while fiber optic cables range from 2.4 mm-16 mm.
The V2 consists of a duct clamp manufactured in two halves that clamp around the duct. The duct
clamp holds a seal through which the fiber optic cable is fed before entering the duct. The duct
clamp and cable seals can be replaced to accommodate dierent duct and cable sizes. The duct is
mechanically clamped between the clamps, preventing movement in all directions. Seals fit around the
duct when clamped securely.
The fiber optic cable is fed through the duct with a combined pulling/pushing force. The pulling force
is achieved when pressurized air is fed into the duct clamp and forced into the duct, generating
resistance on the fiber cable from the airflow passing over it. The pushing force is created by engaging
the belt drive system. As the belt drive system feeds the fiber cable into the duct, pulling force is
generated by the airflow. The fiber optic cable floats inside the duct, minimizing resistance to being
pushed in by the belt drive.
The use of the V2 for operations other than those described in this manual is considered hazardous
and is discouraged. The manufacturer is relieved of any responsibility, civil or criminal, for the use of this
machine for purposes other than intended. The manufacturer’s responsibility ceases, and the warranty
becomes void when any of the following occur:
A. When the V2 is used for purposes other than described in this manual.
B. Modifications and/or alterations are made without written approval from the manufacturer.
C. Non-use of original manufacturer parts.
D. Poor maintenance.
E. Failure to use provided safety devices or equipment.
F. Connection of this device to machines and/or parts that have not been manufactured or
approved in writing by the manufacturer.
G. The V2 should not be used to install any cable other than fiber optic cable specified within the
range outlined in this user manual.
H. The V2 must not operate without oil in the oil reservoir, immediately voiding the warranty.
I. Check the oil level in the reservoir daily.
Jetting AB is not responsible for damages resulting from improper use of the V2.

7
2. Technical Information
2.1. User Conditions
1. Temperature: -15°C to +40°C
2. Humidity: 20% to 90%
3. Relevant weather conditions for working conditions. Do not operate in heavy rain or/and lightning.
4. Natural and/or artificial workplace lighting: >200 lux
2.2. Air Compressor Requirements
1. Air Pressure: 16 bar max
2. Air Flow: 0.14-11 m3/min
3. Couplings: 3/4” Claw Connector
4. Max Pressure to Motors: 6 bar
5. Air Conditions: Dry, clean, and oil-free
2.3. Operational Capacity
1. Pushing Force: 550 N max
2. Installation Speed: 200 m/min max
3. Cable Sizes: 2.4 mm to 16 mm
4. Duct Sizes: 7-50 mm
2.4. Electrical Requirements
1. Counter Power Supply: 9 V Alkaline battery
2. Power Consumption: Approx. 15 hours of operation
3. Power Connection: Battery holder
2.5. Physical Specifications
1. Height: 230 mm
2. Depth: 450 mm
3. Width: 420 mm
4. Weight: 11 kg
2.6. Belt Drive
1. Max Clamping Force: 2000 N
2. Constant cable center design
3. Forward and reverse drive
4. One motor per belt drive
5. Clamping protection in stainless steel
2.7. Duct Clamps
1. Max 16 bar
2. Must withstand vibrations and shocks
3. Must have an exact fit
4. Duct should be cut at a 90-degree angle, and the cut surface should be smooth
5. Duct must be placed inside the O-ring but outside the air channel

3. Safety Regulations
Read and understand all procedures and safety instructions before using the V2. Please note all
safety information on this page and take note of specific safety requirements explained by procedures
outlined in this manual. Failure to follow these instructions may result in serious personal injury, proper-
ty damage, or death. The equipment must only be handled by trained and authorized personnel who
have read and understood all documentation. In the event of mishaps or breakdown, see section 3.1.
The machine is delivered in a custom hard case. When transported, the machine shall be placed in the
hard case. The hard case must be locked, and when transported by car, the locked case should be
strapped in a safe way, preventing it from overturning if the car brakes hard.
3.2. Workplace Safety
1. Wear personal protective equipment: ear protection, hard hat, safety glasses, steel reinforced safe-
ty shoes, and light leather work gloves (OSHA-approved or Personal Protective Equipment Directive
89/686/EEC-compliant).
2. The operator is responsible that no children or unauthorized persons are close to the machine while
in operation.
3. Do not operate this equipment with guards removed or damaged.
4. It’s strictly forbidden to wear loose fitted clothing and jewelry when operating the machine.
5. Check machine before starting for worn or damaged parts, loose nuts and bolts etc.
6. If machine is left unattended, ensure that unauthorized use is prevented.
7. Keep long hair securely tied back.
8. The safe use of this equipment requires operators to stand on stable ground.
9. Be careful when handling cables and live wires
10. Be careful when handling pressurized lines and hoses.
11. Stay clear of cables or lines under tension.
12. Use the machine only for its intended purpose.
13. Do not place cable drums too close to the unit. Position the drum minimum 2 meters from machine.
14. Keep hands away from drive wheels and moving parts during operation.
15. Beware of hot and cold surfaces, machine uses compressed air.
16. The machine is equipped with a handle; use this when lifting or handling the machine. The machi-
ne weighs more than 11 kg (24 lb). When lifting, be careful and avoid personal injury and machine
damage.
17. Beware of exposed electrical contacts. Do not touch, or allow metal objects to come into contact.
18. Machine may cause additional fire hazard if involved in an existing fire due to compressed air.
19. No personnel are to be in manholes or ducts when the Fiber Blowing Machine is being operated
20. Ensure no personnel are in the manhole at the far end of the cable run. Severe personal injury may
result.
21. The machine must be operated on firm ground.
22. Only use the machine for its intended purpose, do not use the belt drive without the air chamber to
push or to retrieve cable, blow air in the far end to help cable recovery.
8
3.1. Machine Safety Shutdown
1. Activate the Emergency Stop by turning the red knob clockwise.
2. Close the air valve.
3. Turn o the compressor.
4. Open the duct air release valve.
5. Disassemble the unpressurized air hose from the Machine.
Turn the red knob counterclockwise to deactivate the emergency stop.

3.3. Pneumatic Devices
The V2 is a pneumatic device that utilizes compressed air to install cables at high speeds.
Please observe the following precautions when using the machine:
1. Compressed air generates flying debris. Always wear personal protective equipment.
2. Serious personal injuries can occur. Always wear personal protective equipment.
3. Never open the air chamber when pressurised.
⚠
Do not open until the air pressure gauge read zero.
4. Only AUTHORIZED, fully trained personnel should operate the air compressor.
3.4. Electrical Devices
The control unit and the digital display are electrical devices. There are risks of electrical shocks that
can lead to serious personal injury or death. Please note the following precautions to avoid electrical
hazards:
1. Do not place the unit on a wet surface.
2. Do not use when there is thunder, lightning, or extreme weather conditions. A grounding rod driven
into the ground as an additional protection is recommended if there is any risk of extreme weather
conditions.
3. Do not remove the cover of the digital display. There are no user-serviceable parts inside.
Leave servicing to qualified service personnel.
4. The machine has electrical monitoring and safety circuits. Observe the following precautions to
avoid electrical hazards:
• Do not operate in or near water.
• Do not expose the machine to rain.
3.5. Working in Darkness
1. The operator must provide portable lighting that achieves a light intensity of at least
200 lux (lumen/m^2).
Improper use voids the warranty
9
23. Do not tamper with pressure relief valves or pressure reducing valves.
24. The compressed air supply must not be allowed to enter the air chamber or duct before the belts
have been closed on to the cable. Do not turn the air on until a reasonable length of cable 100 m
(300 ft) has been installed into the duct.
FAILURE TO DO SO MAY RESULT IN PERSONAL INJURY, AS THE CABLE COULD BE EJECTED FROM THE
FIBER BLOWING MACHINE WITH HIGH FORCE AND VELOCITY.
25. Ensure the cable drum rotates freely on its stand; the cable should leave from the top of the drum.
26. The cable should enter the machine in a clean and dry condition. In damp, dusty atmospheres, the
cable should be cleaned continuously as it enters the machine.
2 7. Do not open the air chamber until all the air has been exhausted and the air pressure gauge reads
zero.
28. The machine must not be operated without belt protection covers.

CRITICAL POINTS THAT DRAMATICALLY AFFECT THE OPERATION OF THE FIBER BLOWING MACHINE
• Pressure on the cable should be set as per the instructions.
• Belts to be closed at all times when cable is installed into the machine.
• Cord seals in the air chamber in good condition and correctly fitted to provide good sealing.
• Correct cable seal fitted.
• Duct/inner-duct fully connected and pressure tested.
• Duct and connecting fittings are suitable for operating at 232 psi (16 bar) air pressure.
• Duct clamp securely tightened.
• Compressor capacity suitable for the diameter of inner-duct being used up to 232 psi (16 bar)
(higher pressure gives better performance).
• Cable drum must be located in line and minimum 2 meters from the blowing machine.
• Air chamber, drive belts and pulleys, cable guides must be clean and free from debris, sludge, dirt,
water, and lubricant.
• The cable must be hand-guided into the blowing machine through a dry, clean cloth by the
operator wearing work gloves.
• Ensure the compressed air supply is not applied to the cable until approximately 300’ (100 meters)
of cable have been installed.
• Check the duct, duct clamp, cable and cable seals before starting the installation.
DISCLAIMER
Jetting takes care in the design of its products to help ensure that the cable is protected during instal-
lation. Due to the variety and dierent methods of cable manufacture, the responsibility of checking
the cable compatibility with the equipment lies with the operator. Therefore, Jetting cannot accept
liability for any damage to the cable.
10

4. Unpacking the Box/Case
Components
Each V2 STD Kit includes the following items:
• V2 main unit
• Machine mounts x2 (1 unit omitted for shipments other
than wooden box)
• Jetting lubricant, Duct Lube, Micro Duct Lube
• Duct clamps (vary depending on order)
• Cable sealing kit (vary depending on order)
• Hex key
• Assortment box
• Clamp bracket
• O-ring cord
• Manual
• Grounding cable
• O-ring
5. Set Up the Machine
This user manual provides installation and operating instructions for the V2.
5.1. Determine Fiber Cable Size
1. Determine the size of the cable to be installed.
5.2. Select Cable Sealing and Duct
1. Choose the appropriate cable sealing and duct clamp for the specific application based on the
duct and cable size.
5.3. Install Cable Sealing & Fiber Cable in the Duct Clamp
1. Loosen the clamp bracket on the duct clamp. Open the duct clamp.
2. Install the appropriate cable sealing on the fiber. Ensure that the direction of the seal on the fiber
is correct so that it fits securely in the duct clamp. The sealing lip of the cable sealing should face
toward the end of the duct.
3. Once the cable sealing is correctly positioned on the cable, install the cable sealing into the lower
half of the appropriate duct clamp.
5.4. Install Duct
1. Place the duct securely in the lower duct clamp.
2. Ensure there is sucient length available on the duct to avoid unnecessary strain on the duct.
3. Once the duct is in place, close the duct clamp and tighten by screwing the clamp bracket.
It should be airtight.
5.5. Install Fiber in Belt Drive and Tighten
1. Thread the cable through the rear cable guide and between the belt drives to control mobility.
2. Tighten the upper and lower belt drive with the Belt Clamping Lever to ensure even pressure on the
cable.
3. Tighten without causing the belt drives to slip during the pressure force setting determined in the
crash test procedure. Do not overtighten.
Do not connect the air supply until the installation is complete.
The machine should be anchored in the machine fixture. The fixture should be mounted on
a stable, flat surface.
11

5.6. Connect to Air Compressor
Note: Ensure that the regulator is set to 0/o, and the Easy Joystick Control is in the STOP position
before connecting the air hose.
1. Connect the air hose to the air compressor.
2. Connect the air hose to the machine. The unit uses a Claw Connector.
5.7. Placement of Cable Drum
The cable drum should be positioned in line and at least 2 meters away from V2. The fiber should not
enter the V2 at an angle greater than 10 degrees from the intended direction of travel.
5.8. Connect battery to the Unit
Insert battery in the battery socket. Use a high-quality 9V battery.
5.9. Display
1. Activate the display by pressing the POWER button. Reset values by pressing RESET.
2. The V2 display shows the number of meters of blown fiber cable in the duct (m) and the current
speed (m/m meters/minute).
3. For the V2-JLP version, the connection to the JetLogger documentation system is displayed as
follows: Connected (LOGON)/Disconnected (LOGOF) & Low Battery (LOWB).
4. When the machine is not in operation, the display should be turned o to conserve battery power.
5. Switch between meters and feet/feet and meters. The machine must be turned o.
Hold down ’reset’ and then press ’power’. When the display starts, release ’reset’.
5.10. Connect Grounding Cable
Connect the machine to the grounding spike or directly to the drum holder.
Visit www.jetting.se for instructional videos.
Speed (m/m) Installed length in meters
Connection to JetLogger
(JLP variant)
Low Battery Voltage
12
Always use clean, oil-free, and dry air.
Route all hoses in a safety way to prevent tripping hazards.
To avoid creating tripping hazards, Place the air hose away from the work
area and secure it to a stable object.

6. Cable Crash Test
Cable crash testing is a rapid and simple step that should be completed before attempting to install
fiber cable with the V2. This test is necessary to set the regulator’s position for the motors under the
breakpoint (pressure force) where the V2 can cause fiber cable damage due to over-pressurization or
encountering an obstacle in the duct system. Each fiber cable has dierent pressure values based on size
and design.
IMPORTANT
Use the same size of cable and duct that will be used for the job.
Jetting cannot be responsible for any cable damage.
Crash Test: For all cable types > 3 mm diameter
Set the pressure between the belt drives and fiber cable at the lowest possible setting that allows a
desirable installation speed.
1. Insert the fiber cable and seal into the duct as it would be for the actual installation.
2. Install a 2-3 m test length of duct in the V2 clamp and secure the clamp.
3. Block the end of the test length of duct.
4. Tighten the belt drives against the fiber cable with the belt drive engaged in the forward direction until
the fiber begins to be installed.
5. Insert the fiber cable into the blocked end of the duct.
6. Belt drive slippage should occur on the fiber before the fiber bends.
7. Tighten the belt drives against the fiber cable half a turn.
8. Repeat steps 6-7 until the fiber cable bends. This is your pressure force slip limit.
9. Loosen the belt drives on the fiber cable a quarter turn and perform the test again to confirm that no
bending has occurred. MAINTAIN THIS SETTING FOR THE FIBER CABLE FOR ACTUAL INSTALLATION!
10. Replace the test length of duct with the actual installation duct and proceed to section 7. Machine
Operation of V2.
13
Always wear protective equipment: a safety helmet,
safety glasses, steel-reinforced safety shoes, and
work gloves.

7.3. Activate Air Pressure
Slowly open the ball valve to allow airflow to the duct clamp. Do not apply maximum air pressure and
flow on the initial air insertion. Do not open the air supply until the desired speed slows down (about
100 m). Then gradually increase the air pressure in steps of about 10-20% at a time. Follow the speed of
the cable installation and balance air pressure gently against belt drive speed. Too much air can slow
down or stop the installation.
7.4. Adjust Speed
Use the regulator to adjust the belt drive speed in combination with the Easy Joystick Controller to ensure
smooth installation and match the amount of air pressure used so that the forces cooperate.
7.5. Install Cable
The cable must be dry and clean of dirt.
7.6. Stop Belt Drive
To stop the belt drive, reduce the air pressure on the regulator or move the Easy Joystick Controller to the
STOP position. The emergency stop is activated by turning it clockwise.
14
Do not exceed 16 bars when using the device. Compressed
air generates flying debris. Always wear personal protective
equipment.
7. Machine Operation
7.1. Verify Adjustable Pressure Force
Verify that the adjustable pressure force is set to the established crash test value, and the speed is at a
minimum. Turn the regulator to 0 bar by lifting and rotating the ring fully counterclockwise. Ensure that
the Easy Joystick Controller is in the STOP position.
7.2. Connect Belt Drive
The belt drive can be maneuvered forward and backward with the Easy Joystick Controller. For instal-
lation, connect the belt drives by first increasing the regulator to the desired air pressure for the motors,
e.g., 1-6 bars. For forward drive, move the Easy Joystick Controller to the forward position. This operates
continuously and also controls the speed. Install the cable in the duct with motor power only until the
speed starts to slow down (about 100 m). Then, compressed air is added.

7.7. Check Oil Level
Check the pneumatic oil container to ensure continuous oil mist lubrication to the motors.
The oil level must always be above the hose in the oil container.
Max
Min
7.8. Refill Oil
Oil can be filled into the container in two dierent ways. Use only Jetting Pneumatic oil 32.
Alternative 1. Loosen the oil container screw and fill.
Alternative 2. Unscrew the entire container by hand counterclockwise
and pour the oil directly into the container.
Do not run motors with an empty or
malfunctioning oil container!
15

7.9. Calibration of mist lubrication
1. Start the process by activate Machine Safety Shutdown (see 3.1).
2. Turn the adjustment screw clockwise to the bottom.
3. Rotate the adjustment screw counterclockwise to ’3’.
4. Place the Easy Joystick Controller controller in stop position.
5. Deactivate the emergency stop by turning it counterclockwise.
6. Turn the regulator to 0.2 MPa.
7. Position the Easy Joystick Controller controller to ’Forward’.
8. Count the number of drops from the tap inside the adjustment screw.
The correct amount should be 1 drop every 30 seconds.
9. If necessary, turn the adjustment screw counterclockwise to increase or clockwise to decrease the
amount of oil.
2.1.
7. 8. 9.
3.
4. 5. 6.
16

7.10. Motor Lubrication for machines not in use
⚠
Must be done if the machine is not in use for 2/3 days or longer.
1. Start the process by activate Machine Safety Shutdown (see 3.1).
2. Place V2 upside down and let it rest on the black handle. The quick connectors on the motor are now
easily accessible.
3. Disconnect the hose from the quick coupling and pour 10 ml of oil into the coupling. Reattach.
4. Perform the same procedure with hose number two.
5. Turn the machine back and rotate the upper and lower drive belts by hand. Rotate a full turn to ensure
full lubrication of the motor.
7.11. Additional
Do not exceed air pressure more than 6 bars to the motors. Micro cables up to 5 mm should never
exceed 3 bars of air pressure to the motors.
1. 2.
3. 4.
5.
17

8. Maintenance
Clean all units and components thoroughly
with a dry cloth.
✔
✔
✔
✔
✔
✔
Inspect hoses, cables, connections,
fastening elements, couplings and screws
for any signs of damage or looseness.
Inspect the duct seals (O-rings).
Verify the operation of the mist lubricator
(See section 7.9)
Check the oil level. The oil level should never
be completely empty.
(See section 7.7-7.8)
Always use clean, dry, and oil-free air. Use a compressor with a water separator/dryer.
Belt Replacement
Motor Lubrication for machines not in use.
(See section 7.10)
Every 50 kilometers unless excessive wear occurs.
⚠
Must be done if the machine is not in use for 2/3 days or longer.
Every 10 kilometers unless excessive wear occurs.
Replacement of Cable Seals
Inspect the belt drives. Replace them if
excessive wear has occurred. Excessive
wear is evident when the belt drives can no
longer grip the fiber optic cable eectively.
Procedure Daily Weekly Monthly 60 days 90 days
Disconnect the air supply and vent any air pressure before servicing any component on the V2.
Avoid handling leaking connections, valve seals, or inadequately sealed duct clamps.
DANGER! Risk of compressed air penetrating the skin causing air embolism. In case of
suspicion, immediately contact emergency medical care.
18

Check the wear of the belts. Inspect the tension of the belts.
Properly tensioned belts are checked by folding the belt
approximately 45 degrees. Ensure that the slide rails are clean
and lubricated. WD40 or 5-56 lubricant can be used.
Adjustment of the upper belt. To adjust - loosen the 4 screws at
the back that secure the upper pulley.
Adjust the screw for the upper drive belt.
To adjust the belt tension: tighten the adjustment screw clockwise
to tighten the belts or counterclockwise to reduce tension. Once
the correct tension on the belts is achieved, tighten the 4 screws.
Reassemble the adjustment screw to secure the lock.
For adjustment - loosen
the 4 screws at the
back that secure the
upper pulley.
Adjustment screw
4 screws
To access the
bracket, use a 3
mm Allen key.
8.1. Belt Tension Inspection
8.2. Adjustment of the upper belt
8.3. Adjustment of the lower belt.
To acess the adjustment screw to the
lower belt
Disconnect the air supply and release any air pressure before
inspecting or servicing the V2.
19

10. Troubleshooting
The cable is stuck in the hose.
Drive Belts not feeding fiber cable
Diculty Restarting Cable Installation
after Air System Shutdown
Drive Belt Feeding System Not Starting
1. Notify the people at the other end of the duct that an
issue has occurred, and the operator will shut down the
system.
2. Turn o the pneumatic air supply using the air control
valve to reduce air pressure from the duct and duct
clamp.
3. Use the cable counter or measure the cable to determi-
ne the location of the blockage.
4. Inform the supervisor of the problem and collaborate on
a solution accordingly.
1. Assist the cable drum by pulling the cable towards the
machine.
1. The operation can be restarted after the air pressure has
increased and stabilized.
1. Emergency stop may still be engaged. Reset the emer-
gency stop by turning it counterclockwise after turning
the regulator counterclockwise to zero and ensuring that
the Easy Joystick Controller is in the STOP position.
2. Check the oil container.
11. Documentation and Recycling
Order Documentation
For documentation, user manuals, and technical information, please visit www.jetting.se. Alternatively,
contact your local distributor for assistance.
Feedback on Documentation
Comments regarding our product documentation can be sent to [e-mail].
We appreciate all feedback.
Disposal
Adhere to the regulations of your country regarding the recycling and disposal of the product.
9. Repair & Service
Repair & Service should be performed by Authorized Jetting Service Center or Jetting AB.
See Authorized Jetting Service Center at www.jetting.se.
20
