JETWAY LCD Monitor Series User manual

All Information in this manual may change from time to time without prior notice.
LCD Monitor Series
17.0 TFT Active Matrix LCD Panel
User’s Manual

17.0TFTActiveMatrixLCDPanelUserManual
English 2
TableofContent
Table of Content...................................................................................…2
Safety Instructions ..............................................................................…3
View of Monitor ....................................................................................... 4
Unpacking ............................................................................................... 6
Warning ................................................................................................... 6
Optional TV Tuner................................................................................... 7
Remote Control (Option) ...................................................................... 7
Cleaning Notes........................................................................................ 8
Precaution ............................................................................................... 8
Features................................................................................................... 8
Hardware Installation ............................................................................. 9
Hardware Installation Step by Step..................................................... 10
Hardware Installation TV Tuner (Option) ............................................ 11
Angle of Inclination .............................................................................. 14
Monitor Setup Button ........................................................................... 15
Troubleshooting.................................................................................... 16
OSD (On-Screen Display) Menu Mode (PC Mode) ............................. 16
Display Mode......................................................................................... 23
Specification ......................................................................................... 24

17.0TFTActiveMatrixLCDPanelUserManual
English 3
SafetyInstructions
1. Please read these safety instructions carefully.
2. Please keep this User‘s Manual for later reference.
3. Please disconnect this equipment from connecter before cleaning. Don‘t use
liquid or sprayed detergent for cleaning. Use moisture sheet or cloth for
cleaning.
4. Make sure the voltage of the power source when you try to connect the
equipment to the power outlet.
5. All cautions and warnings on the equipment should be noted.
6. Never pour any liquid into opening, this could cause fire or electrical shock.
7. Never open the equipment. For safety reason, the equipment should only be
opened by qualified service personnel.
8. If one of the following situations arises, get the equipment checked by a service
personnel :
a. Liquid has penetrated into the equipment.
b. The equipment has been exposed to moisture.
c. The equipment has not work well or you can not get it work according to
user‘s manual.
d. The equipment has dropped and damaged.
d. If the equipment has obvious sign of breakage.
9. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT
UNCONDITIONED, STORAGE TEMPERATURE ABOVE 40°C, IT MAY
DAMAGE THE EQUIPMENT.
10. Adaptor source :
a. Channel Well Technology, MODEL PAA050F.
b. Linearity Electronics co. LTD,MODEL LAD6019AB4

17.0TFTActiveMatrixLCDPanelUserManual
English 4
ViewofMonitor
Front View (1)
Back View (2)

17.0TFTActiveMatrixLCDPanelUserManual
English 5
ViewofMonitor
SideView(3)
15°

17.0TFTActiveMatrixLCDPanelUserManual
English 6
Unpacking
Thank you for your purchase. Please first check the following package content of
the 17” LCD monitor. Contact your dealer or store where you purchased the LCD
monitor if anything is missing.
17” TFT LCD Monitor
External Univ15 pin
D-sub
(RGB Analog) input
signal cable
*DVI. and Video are
optional*
Power Cord
AD / DC Adpter
External Universal
(DC 12V, 50 / 60Hz)
(AC 100-240V)
Audio Cable
with
Stereo Phone Jack
CD User’s Manual
Quick Start Guide
Warning
1. Make sure that the system power is turned off.
2. Plug the signal cable to the signal connector at the rear of PC.
3. Plug adapter output cable to the jack at the rear of LCD monitor and the
power cord to the adapter.
4. Connect the power cord to power source.
5. Turn on the computer and the monitor.
6. For the best display quality, we suggest that you set the resolution as
shown page 21 (Display Mode).

17.0TFTActiveMatrixLCDPanelUserManual
English 7
OptionalTVTuner
The 17” LCD monitor optionally supports TV tuner function with the following
accessories . It can be purchased separately. Contact your dealer for detail.
Optional TV Tuner
S-Video Cable Composite Cable
Europ PAL System
I to I Dungle
U.S. NTSC System
PH to F Dungle
RCA to Phone Jack
Cable
Remote Control
RemoteControl(Option)
Use the remote control by point toward the IR sensor window.
Notice: 1. The remote may not work properly during the low battery condition.
2. Do not place the remote under direct sunlight or area with high humidity.
If the remote control fails to operation, replace the battery in the remote control.
Notice: Insert battery (Lithium battery) with its terminals corresponding to the <+>
and <-> indications in the battery compartment.

17.0TFTActiveMatrixLCDPanelUserManual
English 8
CleaningNotes
1. Be gentle to clean the screen.
2. Never use any kind of corrosiveness chemical dissolvent to clean the
screen, it may hurt your screen surface.
3. We suggest that a camel hair brush or a soft, lint-free cloth be used to clean
the screen.
4. Don’t exert any pressure directly to the LCD screen.
Precaution
1. Do not expose the monitor to direct sunlight or heat.
2. Do not spill liquid on the monitor.
3. Do not attempt to open the monitor. You may be hurt by electric shock. For
service, call your place of purchase.
4. Do not use your monitor when magnets or electronic products are operating
nearby.
5. Do not use harsh chemicals or strong cleaning solvents to clean the
monitor screen. Wipe it with clean, soft clothes applied with mild solution.
6. Do not place anything on your monitor. Bad ventilation may elevate
temperature in the monitor.
7. Don’t use your fingers to touch the LCD screen, directly. Fingerprint
contains oil and may be difficult to clean.
Features
Power Saving:
The power management complies with VESA DPMS standard. When the system is
idle (Off Mode), the monitor automatically cut its power consumption to a level less
than 5w.
Auto Adjustment Key Function:
With “AUTO” key, you can automatically adjust the display for your best view.
Wide Viewing Angle:
The horizontal 150°and vertical 125° offer you great screen view.
Plug and play compatibility:
With DDC1/DDC2B compliance, the monitor is plug and play compatible to Windows
95/98/me/2000/XP.
Space Saving:
The monitor is designed with 280 mm indepth to provide you with more hand room for
desk working space.
Side-by-Side :
The monitor comes with 17.7 mm trimmed down frame to offer side-by-side operation

17.0TFTActiveMatrixLCDPanelUserManual
English 9
HardwareInstallation
Be careful to your LCD monitor. It’s very delicate and easy to break. Turn off LCD’s
and PC’s power before installation. Follow the installation step by step described
below.
Input
【1】DC-IN：This is for connecting the power cable
【2】AUDIO-IN：This can be connected to the audio-out connector of any sound resource.
【3】VGA-IN : This can be connected with the D-Sub 15 pin signal cable.
【4】VIDEO : This is for (RCA) composite video in from video source. *(option)
【
1
】
【
6
】
【
5
】
【
8
】
【
2
】
【
4
】
【
7
】
【
3
】

17.0TFTActiveMatrixLCDPanelUserManual
English 10
【5】S-IN：This can be connected with the S-Video signal cable. * (option)
【6】TV ：This can be connected with the TV signal cable. *(option)
【7】Audio Out：This is for connection of headphone or external speaker.
【8】DVI-D：This can be connected with the DVI-D compatible signal cable. *(option)

17.0TFTActiveMatrixLCDPanelUserManual
English 11
HardwareInstallationStepbyStep
1. Turn your monitor upside down carefully with panel facing you to locate all
connector port.
2. Plug in signal cable to VGA-IN of the monitor and the other side of the cable to
the computer.
3. Connect the audio cable to AUDIO-IN on the monitor, and the other side to
computer line out.

17.0TFTActiveMatrixLCDPanelUserManual
English 12
HardwareInstallationStepbyStep
4. Plug power cord onto DC adapter.
5. Plug the DC cable from power adapter onto the DC-IN on monitor.
6. Congratulations! You have just completed the hardware installation.
HardwareInstallationTVTuner(Option)
1. Hardware installation for optional TV tuner of the 17” TFT LCD monitor is
described below.

17.0TFTActiveMatrixLCDPanelUserManual
English 13
HardwareInstallationTVTuner(Option)
2. First, remove the plastic back cover by pushing clips in two sides .
3. Locate pin connector on the TV tuner and the pin connector on monitor
indicated.
4. Slide the TV tuner module into the right side of the spare space of the back of
monitor, and gently plug the optional TV tuner into the connector mentioned at
Step 3 .

17.0TFTActiveMatrixLCDPanelUserManual
English 14
HardwareInstallationTVTuner(Option)
5. Screw to fix TV tuner module on the supporting sheet metal and re-install the
color back panel.
6. Insert the RCA video signal cable into VIDEO port, and the other side to RCA
Video output on sources such as DVD player……….
7. Insert the S-Video signal cable into S-IN port, and the other side to S-Video
output on sources such as DVD player……….
8. Insert the TV signal cable into TV port, from the local cable TV system
provider……….
9. Congratulations again! You’ve done an incredible job and can start to enjoy it.

17.0TFTActiveMatrixLCDPanelUserManual
English 15
AngleofInclination
In normal condition
LCD lay back 0˚~ 15˚(positive and negative 2˚)

17.0TFTActiveMatrixLCDPanelUserManual
English 16
MonitorSetupButton
Menu control button
There 5 keys for user to set up the monitor, including “ Power”, “MENU “,
“AUTO”, ” <▼> Down”, ” <▲> Up”. Please refer to the introduction below.
1. “ Power”: Turn the LCD power on and off. When the power is on, the light
turns green, and standby in the color of orange.
2. “AUTO”: Exit and save the setting. Hot key for auto adjustment.
3. “MENU”: Press the button to display OSD main menu and select OSD
Option.
4. “<▲> Up”: Increase the value in the OSD option. Hot key for PC / Video / S-
Video / TV mode. You can use the button to switch between PC,
Video, S-Video, and TV mode screen.
5. “<▼> Down”: Decrease the value in the OSD option . Hot key for volume
adjustment.
Power UpDownOSD MenuAuto Adjust

17.0TFTActiveMatrixLCDPanelUserManual
English 17
Troubleshooting
If you encounter any trouble in using the monitor, make sure your monitor is
properly installed according to the following steps before you call for service.
˙There is no picture on the screen.
Check:
1. Power saving mode. Press any key and move the mouse to deactivate
the mode.
2. Signal Cable Connector Pins. If there are bent or missing pins, consult
your dealer or store where you purchased the monitor.
˙Characters look too dark or too bright
Check:
1. Using OSD Menu to adjust the Contrast.
˙When shall your monitor be adjusted?
Check:
1. After “ reset”
2. If the resolution of frequency is being changed.
. The text on the screen is unclear.
Check
1. Make sure the resolution matches with the display mode.
OSD (On-Screen Display) Menu Mode (PC Mode)
Option select
1. Press the MENU button to access menu.
2. Using MENU again for advanced adjustment selection.
3. Press Down and Up for choosing different OSD function.
4. Press MENU as enter to select the function you want.
Main Menu Setting
Main Menu Setting
Contrast：
Adjust the contrast ratio of the display.
CONTRAST

17.0TFTActiveMatrixLCDPanelUserManual
English 18
OSD (On-Screen Display) Menu Mode (PC Mode)
BRIGHTNESS:
Adjust the difference between light and
dark area.
BRIGHTNESS
COLOR ADJUST:
A
djust the RED, GREEN, and BLUE colors
o
f the display.Click “ENTER” to adjust the
R.G.B. color separately.
COLOR ADJUST
RED:
Adjust the RED color of the display.
RED
BLUE:
Adjust the BLUE color of the display.
BLUE

17.0TFTActiveMatrixLCDPanelUserManual
English 19
OSD (On-Screen Display) Menu Mode (PC Mode)
COLOR TEMP:
Adjust the color temperature of the
display.
COLOR TEMP
BACK :
Return to the Main Menu Screen
BACK
COLOCK:
Adjust the re-flash ratio of the vertical
scanning area.
CLOCK
PHASE:
Adjust the re-flash ratio of the horizontal
scanning area.
PHASE

17.0TFTActiveMatrixLCDPanelUserManual
English 20
OSD (On-Screen Display) Menu Mode (PC Mode)
AUTO ADJUST:
Automatically adjust the re-flash ratio of
both vertical and horizontal scanning
areas of the display.
AUTO ADJUST
H. POSITION:
Adjust the horizontal viewing area of the
display.
H. POSITION
V. POSITION:
Adjust the Vertical viewing area of the
display.
V. POSITION
BACK :
Return to the Main Menu Screen
BACK
