Jin Ming Yuan LED300W User manual

Guangzhou Jin Ming Yuan stage lighting equipment Co., Ltd.
LED300W 3in1 Moving Head Beam Light
Instruction manual
(Please read the instructions carefully before use）

Precautions and installation
Maintenance
This lamp should be kept dry and avoid working in damp environment.
The intermittent use will effectively prolong the service life of this luminaire.
In order to obtain good ventilation effect and lighting effect, pay attention to frequent cleaning of fans and
fan nets and lenses.
Please do not use the organic solvents such as alcohol to wipe the shell of the lamp to avoid damage.
Statement
This product has good performance and complete package when it is released from factory. All users shall
strictly observe the warning and operation instructions stated above. Any damage caused by misuse is not within
the warranty of the company, and the failures and problems caused by neglecting the operating manual are not in
the responsibility of the distributor.
This manual is subject to technical changes without prior notice.
Notice of product
In order to ensure the service life of the product, the
product should not be placed in damp or leaking places,
and can not work in the environment with a temperature
above 60 degrees.
Do not place this product in loose or vibrant places.
To avoid danger of electric shock, please repair the product
for professional maintenance.
When the bulb is used, the supply voltage should not
exceed 10%. If the voltage is too high, the life of the bulb will
be shortened. If the voltage is too low, the light color of the
bulb will be affected.

After power failure, it will take 20 minutes to fully cool the
lamp before it can be energized again.
In order to ensure the normal use of this product, please
read the instructions carefully.
1. Product parameters:
LED 300W pattern head light
Light source: 300W LED imported high brightness white light module
Power: 600W
Power: AC90-240V 50-60Hz
Color temperature: 6800K
Lamp life: 50000 hours
Spot angle: 4 degree - 38 degrees
Control channel: 16/24 channel
Control mode: DMX512, master-slave, sound control, self walk
X/Y scan: level: 540 degrees, vertical: 270 degrees
Color: a color disc, 7 color plates + pure white light, a seven color color, can
make rainbow effect.
Pattern: two pattern plate with an effect pattern plate, rotating pattern disc 7
pluggable rotating glass pattern with 3D pattern effect, fixed pattern plate 7
patterns plus white light,
Dimming: 0-100% linear dimming,
Strobe: synchronous pulse stroboscopic, random pulse stroboscopic
Prism disc: 3 prism,
Display: color LCD display, display in Chinese and English, reversible display.
High efficiency heat pipe cooling system, no risk of lamp damage.

2. Signal line connection (DMX)
Use the RS-485 cable that meets the specifications: shielding,
120ohm characteristic impedance, 22-24 AWG, low capacitance
reactance. Do not use microphone cables or cables with different
characteristics. Terminals must be connected with 3 or 5 pin XLR
type male / female connectors. A 120ohm impedance matching
resistor (minimum 1 / 4 W) must be inserted between terminals
2 and 3 of the terminal plug.
Important note: lines can not be contacted or contacted with
metal shells.
Figure 1 DMX signal line connection diagram
3. Installation of lamps and lanterns
The lamps can be placed horizontally, slant and upside down.
It is necessary to pay attention to the installation method when it
is slant and upside down.
As shown in Figure 2, before positioning the lamp, to ensure
the stability of the installation location, when the reverse hanger
is installed, the lamp must be ensured not to fall down on the
support frame, and the safety rope needs to be hung through the

support frame and the lantern handle to ensure safety and
prevent the falling and sliding of the lamps.
When the luminaire is installed and tested, pedestrians are
prohibited from passing through it. Regular checks are made on
whether the safety ropes are worn out and whether the hook
screws are loose.
If the hanging installation is not stable, resulting in all the
consequences of the fall of lamps, I do not assume any
responsibility.
4. Display board menu operation instructions
1
DMX Address
001-512
DMX 地址设置
001-512
2
Sys set
DMX Mode
Simple mode 20CH
灯具设置
通道
简易通道模式 20 CH
Standard mode 24CH
标准通道模式 24 CH
Pan Inverse
No
水平反转
水平不反转
OFF
水平反转
Tilt Inverse
No
垂直反转
垂直不反转
OFF
垂直反转

Run mode
DMX
运行模式
DMX
Auto
自动
Backlight
60S
显示模式
60 秒
Always
常亮
Save
保存
Exit
退出
3
Manual
Pan
0-255
手动设置
水平
0-255
Pan Fine
0-255
水平微调
0-255
Tilt
0-255
垂直
0-255
Tilt Fine
0-255
垂直微调
0-255
Pan Tilt Speed
0-255
水平垂直速度
0-255
function
0-255
功能
0-255
Shutter
0-255
Stroboscopic
0-255
Dimmer
0-255
调光
0-255
Color
0-255
颜色
0-255
Color Fine
0-255
颜色微调
0-255
Static Gobo1
0-255
固图 1
0-255
Static Gobo2
0-255
固图 2
0-255
Gobo 3
0-255
旋转图案
0-255
Prism
0-255
棱镜盘 1
0-255
Prism Rot
0-255
棱镜 1 自转
0-255
Focus
0-255
调焦
0-255
Focus Fine
0-255
调焦微调
0-255
Zoom
0-255
enlarge
0-255
Frost
0-255
雾化
0-255
7Colors
0-255
七彩
0-255
Exit
退出
4
Infor
灯具信息
5
Factory
Passwords 158
工厂设置
密码 158
6
Reset
Reset pan&Tilt
灯具复位
水平垂直复位
Reset Effect
效果复位
Reset All
全部复位
EXIT
退出
7
Display
Language
Chinese
显示设置
语言设置
中文
English
英文
Disolay flip
YES
显示翻转
是
NO
否
touch calibration
触摸校准
EXIT
退出
5．Channel parameters

标准模式
（24 通
道）
精简模
式（20
通道）
DMX 值
通道功能
Standard
mode
Simple
mode
DMX Value
Function
1
1
0－255
Pan
X 轴
2
2
0－255
Pan Low
X 轴微调
3
3
0－255
Tilt
Y 轴
4
4
0－255
Tilt Low
Y 轴微调
5
5
0－255
P/T Speed
X Y 轴调速
6
6
Macro function
宏功能
0－19
Empty
空
20－24
Empty
空
25-29
Empty
空
30-99
Empty
空
100－120
Empty
空
130－150
X Y axis reset
X Y 轴复位
160－180
Effect reduction
效果复位
190－210
Reset of lamps and lanterns
灯具复位

220－240
Empty
空
241－255
Empty
空
7
7
Shutter
频闪
0-3
Closed
闭光
4-103
SLOW - FAST
频闪由慢到快
104-107
Open
开光
108-207
FAST STROBE-SLOW STROBE
脉冲频闪由慢到快
208-212
Open
开光
213-251
RANDOM SLOW - FAST
随机频闪，频率由慢
到快
252-255
Open
开光
8
8
Dimmer
调光
0－255
Linear Dimmer
线性调光
9
9
Macro Colour
颜色宏
0-9
white
白光
10-19
Colour 1
颜色 1
20-29
Colour 2
颜色 2

30-39
Colour 3
颜色 3
40-49
Colour 4
颜色 4
50-59
Colour 5
颜色 5
60-69
Colour 6
颜色 6
70-79
Colour 7
颜色 7
80-89
Colour 8
颜色 8
90-99
Colour 9
颜色 9
100-109
Colour 10
颜色 10
110-119
Colour 11
颜色 11
120-129
Colour 12
颜色 12
130-139
Colour 13
颜色 13
140-149
Colour 14
颜色 14
150-159
Colour 15
颜色 15
160-169
Colour 16
颜色 16
170-255
FAST ROTATION - SLOW
ROTATION
顺时针流水慢到快
10
*
Color Fine
颜色微调

0－255
Linear
线性
11
10
Gobo 1
固图
0-9
white
白光
10-19
Gobo1
图案 1
20-29
Gobo2
图案 2
30-39
Gobo3
图案 3
40-49
Gobo4
图案 4
50-59
Gobo5
图案 5
60-69
Gobo6
图案 6
70-79
Gobo7
图案 7
80-89
Gobo8
图案 8
90-112
FAST ROTATION - SLOW
ROTATION
顺时针流水快到慢
113-120
STOP
停止
121-143
SLOW ROTATION - FAST
ROTATION
逆时针流水慢到快
144-157
Gobo 1 Jitter
图案 1 抖动
158-171
Gobo 2 Jitter
图案 2 抖动

172-185
Gobo 3 Jitter
图案 3 抖动
186-199
Gobo 4 Jitter
图案 4 抖动
200-213
Gobo 5 Jitter
图案 5 抖动
214-227
Gobo 6 Jitter
图案 6 抖动
228-241
Gobo 7 Jitter
图案 7 抖动
242-255
Gobo 8 Jitter
图案 8 抖动
EFF Gobo
效果图案盘
12
11
0-4
white
白光
5-84
Gobo1-Gobo3
线性
85-89
white
白光
90-119
Gobo 1 Jitter
图案 1 抖动
120-149
Gobo 2 Jitter
图案 2 抖动
150-179
Gobo 3 Jitter
图案 3 抖动
180-214
FAST ROTATION - SLOW
ROTATION
顺时针流水快到慢
215-220
STOP
停止
221-255
SLOW ROTATION - FAST
ROTATION
逆时针流水慢到快

13
12
Gobo 2
旋转图案
0-9
white
白光
10-19
Gobo 1
图案 1
20-29
Gobo 2
图案 2
30-39
Gobo 3
图案 3
40-49
Gobo 4
图案 4
50-59
Gobo 5
图案 5
60-69
Gobo 6
图案 6
70-79
Gobo 7
图案 7
80-129
FAST ROTATION - SLOW
ROTATION
顺时针流水快到慢
130-135
STOP
停止
136-185
SLOW ROTATION - FAST
ROTATION
逆时针流水慢到快
186-195
Gobo 1 Jitter
图案 1 抖动
196-205
Gobo 2 Jitter
图案 2 抖动
206-215
Gobo 3 Jitter
图案 3 抖动
216-225
Gobo 4 Jitter
图案 4 抖动

226-235
Gobo 5 Jitter
图案 5 抖动
236-245
Gobo 6 Jitter
图案 6 抖动
246-255
Gobo 7 Jitter
图案 7 抖动
14
13
Gobo2/Rot
图案自转
0-63
Rotation
索引定位
64-126
FAST ROTATION - SLOW
ROTATION
逆时针由快到慢流水
127-128
STOP
停止
129-191
SLOW ROTATION - FAST
ROTATION
顺时针由慢到快流水
192-193
STOP
停止
194-255
SLOW ROTATION /FAST ROTATION
正反转由慢到快
15
*
0-255
Gobo2/Rot Fine
图案 2 自转微调
16
14
Prism
棱镜
0-127
Reserve
无棱镜
128-255
prism1
棱镜
17
15
Prism-1 Rot
棱镜自转
0－63
Rotation
索引

64－126
FAST ROTATION - SLOW
ROTATION
逆时针由快到慢流水
127－128
STOP
停止
129－191
SLOW ROTATION - FAST
ROTATION
顺时针由慢到快流水
192－193
STOP
停止
194－255
SLOW ROTATION - FAST
ROTATION
正反转由慢到快
18
*
Prism Rotation Fine
棱镜盘自转微调
0－255
Linear
线性
19
16
Iris
光圈
0-134
Linear
线性
135-164
FAST ROTATION - SLOW
ROTATION
快开慢关
165-194
SLOW ROTATION - FAST
ROTATION
快关慢开
195-224
EFF1
雨滴效果
225-255
EFF2
随机雨滴
20
17
Frost
雾化
0-127
white
白光
128-255
Frost
雾化

21
18
7 Colour
七彩
0-255
7 Colour
七彩，线性
22
19
Foucs
调焦
0-255
Foucs
调焦，线性
23
*
Foucs Fine
调焦微调
0-255
Foucs Fine
调焦微调，线性
24
20
Zoom
放大
0-127
Reserve
无放大
128-255
Zoom
放大
6. Common failures and attention to use
1. common troubleshooting
The lamps and lanterns contain specialized
components such as PCB, high voltage power
and so on. For your safety and product life, non
professionals should not disassemble the lamps
and accessories without authorization.
1. light bulbs are not bright
Possible cause: the bulb is not completely cooled
or the bulb reaches its life.

Because of abnormal operation, the light bulb is
not completely cooled, the lamp body should be
cooled for more than 10 minutes, so that the
interior of the lamp is fully restored to normal,
and then the power supply can be restarted
again.
To check whether the bulb reaches service life,
new bulbs should be replaced.
Check whether the line of bulb and lamp is leak,
fall off or contact poorly.
Change the new lighting device.
The 2. beams are dim
Possible reasons: light bulbs are used for a long
time or the light path is not clean.
To check whether the bulb reaches service life,
new bulbs should be replaced.
Check whether the optical components or light
bulbs are clean, and whether there is dust on the
light bulbs and other optical devices, it is
necessary to regularly clean and maintain the
light bulb and the components in the lamps and
lanterns.

3. pattern projection blur
Check whether the value of the electronic focus
channel is suitable for the projection distance
now.
4. the lamps and lanterns work intermittently
The reason is: the internal line is protected.
Check whether the fan operates normally or
whether it is dirty or not, causing the interior
temperature of the luminaire to rise.
Check whether the internal temperature control
switch is closed.
Check whether the bulb is in service life and
replace the new bulb.
5. control table is not controlled after normal
reset
Possible reasons: signal line failure or lamp
parameter settings are abnormal.
Check the initial address code and check the
connection of the DMX signal line (whether the
signal wire and cable are intact, and whether
the connection is loose).
Add signal amplifier, plus 120 ohmic terminal

resistance;
6. light fixtures can not start
The reason is that the power supply line is bad.
Check whether the fuse on the power input
socket is fusible and replace the insurance.
Lamps cause poor contact in long distance
transportation due to vibration.
Check the input power supply, computer board
and other plug - in devices。
1. use of attention
Check whether the local power supply meets the rated voltage requirements of the product, and the leakage
protector and overcurrent protector meet the load requirements.
Please do not use insulated conductor which has been damaged.
The lamps and lanterns use strong wind refrigeration, easy to accumulate dust, it must be cleaned once a
month, especially the heat dissipation tuyere, otherwise the dust will be blocked, resulting in bad heat
dissipation and abnormal luminaires.
When fixing the luminaire, the fastening screws must be fastened and equipped with safety cables and
checked regularly.
In the installation and positioning of the lamps and lanterns, any point on the surface of the lamp and any
easy to burn explosive, keep the minimum distance of 10 meters and the distance of 2.5 meters from the
illuminant, please do not install the lamp directly on the surface of the combustible material.
The continuous working time of lamps and lanterns should not be more than 10 hours, the interval of
continuous starting lamps should not be less than 10 minutes, otherwise it will not be triggered normally
because of the protection of the light bulb.
The closing time of using on-off valve should not exceed 5 minutes. If you need to shut down the light for a
long time, you should use the console (light control channel) to turn off the light bulb.
In order to ensure that many lamps and lanterns comply with the effect of the scene better, the lamps should
not always be in the unfinished scene, that is, start the next scene action, it is best not more than 3 minutes
to ensure that multiple lamps can run synchronously.
During the process of use, if lamps and lanterns are abnormal, they should stop using lamps in time to
prevent other faults.
