Jiso N200414 Jelly XL User manual

www.jisoiluminacion.com 1/4
Min.Bending
Diameter
D120mm
24V
DC
Side View
Neon
UVResistant
Beam Angle
o
120
Cuttable
10CM 3
waterproof
IP67
Protection
Installation Instructions N200414 // Jelly XL
*

Product parameters:
www.jisoiluminacion.com 2/4
Parameter Mark Rated Value Unit
Forward Current
Power
CRI
Luminous Flux
Width
Min.Bending Diameter
VF
IF
PD
Ra
Φ
W
T
R
IP
24VDC
625
14.4
2700K 320LM
3000K 320LM
4000K 360LM
11
IP67
V
mA/M
W/M
/
Lm（1M）
mm
mm
mm
/
20
90+
≥120
100mm
200mm
11mm
1000mm
24VDC
Drawing:
Thickness 20mm
Installation Instructions N200414 // Jelly XL
( * ):The IP67 will be reach only when connectors are correctly sealed with neutral silicone material.
*

www.jisoiluminacion.com 3/4
Installation
1. IP65 Neon flex,side view version,dimension:11x20mm .
2. Material:silicon tube.
3. Low voltage 24VDC.
4. Single color.
5. High light efficiency.
Product Features
First, fix the clips onto the wall. Second, push the neon light all the
way down to the clips.
Third, check the polarity and connect
the cables to the power supply.
①ＨＣＮ０４－Ｆ０１
①
Accessories
End cap
HCN04-T01
End cap with cables
HCN04-C02
End cap with side cables
HCN04-C04
Jumper connector
HCN04-C03
Splice connector
HCN04-C01
Installation Instructions N200414 // Jelly XL
All dimensions in mm
HCN04-C02 HCN04-C01 HCN04-C03 HCN04-T01

A right-angle
Neon LED Strip instruction and caution
Straighten the LED strip
parallelly during normal service.
Bend the LED Strip inward or
outward around the curve.
(Attention: keep the curved
radian≥120mm)
Once need a turing, lateral
bending around the curve is
allowed only. Don't twist the
light-emitting area.
(Attention: keep the curved
radian≥120mm)
During normal service, do not
bend LED strips with its back
side up and front side down.
The LED strip cannot be distorted
during normal service.
During normal service,once need
a turning,must keep the curved
radian ≥120mm and couldn’t be
a right-angle.
Distortion
Parallelly R≥120mm
R≥120mm
www.jisoiluminacion.com 4/4
Installation Instructions N200414 // Jelly XL
