JLab Audio BLOCK PARTY User manual

We love that you are rocking JLab Audio!
We take pride in our products and fully stand behind them.
BLOCK PARTY
SPEAKER
L
I
M
I
T
E
D
T
W
O
Y
E
A
R
Once connected, a voice prompt
of “Bluetooth connected” and
solid blue logo will be indicated.
You are ready to play music.
CONNECT YOUR BLUETOOTH DEVICE
1Power the speaker ON
2Once Power is ON:
4Turn on the Bluetooth in your device settings. Search for “JLab Block Party” in your Bluetooth device settings and connect.
3
If you see the blue pulsing logo the speaker is already in Bluetooth Mode.
Follow Step 3.
If you see the white rotating ring Quick Press the Bluetooth / Receive Toggle Button
Blue pulsing logo will indicate Bluetooth Mode.
Follow Step 3.
Press and hold for 3 seconds the Bluetooth / Receive Toggle Button to enter pairing mode.
Notes:
•Bluetooth is a wireless radio technology, which means it is sensitive to objects between the speaker and the connected device.
The speaker is designed to be used within 33 feet (10 meters) of a connected device, with no major objects in between (walls, etc.).
•Once successfully connected, the speaker will memorize your device and automatically pair when turned on in the future.
Only one device may be connected at a time. To pair a different device, first unpair the current one through its Bluetooth settings.
•If for any reason Bluetooth connection is lost, manually reconnect your Bluetooth device.
Bluetooth
JLab Block Party
Settings
Bluetooth
Settings
YOUR SATISFACTION IS GUARANTEED
You may exchange or return merchandise within 30 days of the purchase date.
Learn more at jlabaudio.com/guarantee
YOUR WARRANTY
You may register your product at jlabaudio.com/register. All warranty claims are subject to JLab Audio
authorization and at our sole discretion. Retain your proof of purchase to ensure warranty coverage.
CONTACT US

AUX IN USB OUTDC IN
ACCESSORIES
SPEAKER PORTS /BUTTONS
POWER /
STAND BY
SHARE MODE /
RECEIVE MODE /
PLAY / PAUSE
USB
CHARGE
OUT
DC
INPUT
AUX
INPUT
BLUETOOTH /
RECEIVE TOGGLE
VOL –VOL +
REMOVABLE
HANDLE
DC POWER
ADAPTOR
REMOVABLE
HANDLE
EQ CHANGE
LONG PRESS SIMULTANEOUSLY
BATTERY LEVEL
SHORT PRESS SIMULTANEOUSLY
CHARGING
1Before charging, it is recommended you turn off the speaker.
2 Open the silicone cover on the back of the speaker and
connect the speaker to your computer or wall outlet using
the provided DC Power Adaptor.
3The indicator light on the front of the speaker will blink
purple one time to indicate charging is in progress.
Allow about 6 hours to fully charge.
Note: For optimum performance, charge overnight with DC Power Adaptor prior to using.
RE-PAIR BLUETOOTH (OR PAIR NEW DEVICES)
1When Power is ON:
Note: If you have multiple Bluetooth devices connecting and want to connect a specific device, make sure you turn
the Bluetooth OFF on your other devices so the speaker can connect to your desired device.
2
3
If you see the blue pulsing logo the speaker is already in Bluetooth Mode.
Follow Step 2.
If you see the white rotating ring Quick Press the Bluetooth / Receive Toggle Button
Blue pulsing logo will indicate Bluetooth Mode.
Follow Step 2.
Press and hold for 3 seconds the Bluetooth / Receive Toggle Button to enter pairing mode.
Blue pulsing logo will indicate Bluetooth Re-Pairing.
Search for “JLab Block Party” in your Bluetooth device settings and connect.
POWER ON /OFF
Power ON: Press and hold for 2 seconds.
Power OFF: Press and hold for 4 seconds.
Stand By: When power is ON, press and hold for 2 seconds (See Stand By instructions for details)
PLAY /PAUSE
Quick press to Play / Pause

SHARE MODE (LINK SPEAKERS)
JLab
Block Party
If you see the white rotating ring then you are already in Receive Mode.
Follow Step 3.
If you see the blue pulsing light Quick press the Bluetooth / Receive Toggle Button
White rotating ring will indicate Receive Mode.
Follow Step 3.
White blinking ring will indicate that it is set to receive. All receiving speakers must be blinking white to link
to Main/Sharing Speaker.
2Power ON the other House Party or Block Party speaker(s) to enter them in Receive Mode as follows:
3Press and hold 3 seconds the Share Mode / Receive Mode button
1Power ON chosen Main/Sharing speaker.
Connect the speaker to your Bluetooth device.
Once connected, set this speaker aside until step 4.
(Follow the Connect Your Bluetooth Device instructions
if speaker is not connected to your device)
CHECK BATTERY LEVEL
Press both volume buttons simultaneously. (Short Press)
VOLUME CONTROL
CHANGE EQ SETTINGS
The House Party is pre-loaded with 2 EQ settings (outside or inside). To change settings, hold both volume buttons for 3 seconds. (Long Press)
Volume Down Volume Up
Green lights on ring will indicate volume level on speaker.
Note: Volume on the speaker works independently from your Bluetooth
device. Adjust the volume on both the speaker and your device accordingly.
Purple lights on ring will indicate battery level on speaker.
The logo will flash green for outside and flash blue for inside.

Press and hold for 3 seconds the Share Mode Button
Share Mode will flash blue indicating it is searching for Receiving speakers
Receiving Receiving
Main/Sharing
4Return to Main/Sharing speaker that is connected to your Bluetooth device.
USE STAND BY MODE WHEN SPEAKERS ARE LINKED
Main/Sharing speaker
will turn solid blue
Receiving speaker(s)
will turn solid white
Note: To change the Main/Sharing speaker to a different speaker, disconnect your device and follow the same 5 step process.
All speakers will turn to red logo
to indicate Stand By Mode is activated
Receiving Receiving
Main/Sharing
Receiving Receiving
Main/Sharing
Receiving Receiving
Main/Sharing
ABOUT STAND BY MODE
Stand By Mode has the capability to turn On, Off, and reconnect ALL Receiving speakers that are connected to the Main/Sharing speaker.
This capability works when all speakers are plugged into an AC outlet and when Share Mode has already been set up.
1When speakers are linked/shared, press and hold 2 seconds on the Power button of the Main/Sharing speaker
5Once the speakers are linked:

Press and hold 2 seconds on the Power button of the Main/Sharing speaker.
This will turn the speaker back on and wake the Receiving speakers.
Receiving Receiving
Main/Sharing
The logo will pulse blue and auto-connect
to your Bluetooth device.
Receiving Receiving
Main/Sharing
2
Press and hold the Share Mode button for 3 seconds.
Blue pulsing ring will initiate the speakers to reconnect.
All Receiving speakers will wake and reestablish connection.
Receiving Receiving
Main/Sharing
Receiving Receiving
Main/Sharing
3
JLABAUDIO.COM
CAUTIONS
• Listen to music at a suitable volume for enjoyment in order
to not cause damage to your hearing and/or speaker system.
• Store in a well ventilated area.
• To reduce the risk of fire or electric shock, do not expose this
speaker or the accessories to rain, water drops or moisture.
• Keep the unit away from an open flame such as fire, candle, etc.
• Avoid extreme heat, cold and humidity.
•Only use attachments/accessories specified by the manufacturer.
• Do not drop any objects into the unit through the openings.
• Do not place anything heavy on the unit.
• To ensure proper ventilation and proper operation, never cover
or block the slots and opening with a cloth or other materials.
• The maximum working temperature is 95ºF/35ºC.
• Lithium batteries (like all rechargeable batteries) are recyclable
and should NOT be recycled or disposed of in normal household
waste. Contact your local government for disposal or recycling
practices in your area.
WARM-UP YOUR SPEAKERS
Optional: Burn-in is the process for exercising new audio equipment. We recommend 40 hours of burn-in time for most speakers to reach
optimal performance. The main purpose of the process is to loosen the diaphragm of a newly crafted speaker and to stress the speaker driver.
Normal, everyday use can also burn-in the speakers though JLab’s proprietary burn-in provides an ideal mix of sounds and frequency
sweeps to achieve this.
Burn-in your audio equipment with the JLab Audio app available on the App Store and Google Play.
Or access the burn-in method at: jlabaudio.com/burnin
