JLG Skytrak 3013 Use and care manual

Operation & Safety
Manual
Original Instructions
Keep this manual with machine at all times.
An Oshkosh Corporation Company
Model
3013
PVC 1911
31211476
March 27, 2020 - Rev A

WARNING
Operating, servicing and maintaining this vehicle or equipment
can expose you to chemicals including engine exhaust, carbon
monoxide, phthalates, and lead, which are known to the State of
California to cause cancer and birth defects or other
reproductive harm. To minimize exposure, avoid breathing
exhaust, do not idle the engine except as necessary, service your
vehicle or equipment in a well-ventilated area and wear gloves
or wash your hands frequently when servicing. For more
information go to www.P65Warnings.ca.gov.

Revision Log
a
31211476
Re vis ion Log REVISION LOG
March 27, 2020 - A - Original Issue of Manual.

Read This First
b31211476
Re ad Th is Firs t
This manual is a very important tool! Keep it with the machine at all times.
The purpose of this manual is to provide owners, users, operators, lessors, and lessees
with the precautions and operating procedures essential for the safe and proper machine
operation for its intended purpose.
Due to continuous product improvements, JLG Industries, Inc. reserves the right to make
specification changes without prior notification. Contact JLG Industries, Inc. for updated
information.
Refer to www.JLG.com for Warranty, Product Registration, and other machine-related
documentation.
Operator Qualifications
The operator of the machine must not operate the machine until this manual has been
read, training is accomplished and operation of the machine has been completed under
the supervision of an experienced and qualified operator. Operation within the U.S.A.
requires training per OSHA 1910.178.
Operators of this equipment must possess a valid, applicable driver’s license, be in good
physical and mental condition, have normal reflexes and reaction time, good vision and
depth perception and normal hearing. Operator must not be using medication which
could impair abilities nor be under the influence of alcohol or any other intoxicant during
the work shift.
In addition, the operator must read, understand and comply with instructions contained
in the following material furnished with the telehandler:
• This Operation and Safety Manual
• Telehandler Safety Manual (ANSI only)
• All instructional decals and plates
• Any optional equipment instructions furnished
The operator must also read, understand and comply with all applicable Employer,
Industry and Governmental rules, standards and regulations.
Modifications
Modifications to this machine may affect compliance with Industry Standards
and/or Governmental Regulations. Any modification must be approved by JLG.

Read This First
c
31211476
This product must comply with all safety related bulletins. Contact JLG Industries, Inc. or
the local authorized JLG representative for information regarding safety-related bulletins
which may have been issued for this product.
JLG Industries, Inc. sends safety related bulletins to the owner of record of this machine.
Contact JLG Industries, Inc. to ensure that the current owner records are updated and
accurate.
JLG Industries, Inc. must be notified immediately in all instances where JLG products have
been involved in an accident involving bodily injury or death of personnel or when
damage has occurred to personal property or the JLG product.
FOR:
• Accident Reporting and Product Safety Publications
• Current Owner Updates
• Questions Regarding Product Applications and Safety
• Standards and Regulations Compliance Information
• Questions Regarding Product Modifications
CONTACT:
Product Safety and Reliability Department
JLG Industries, Inc.
13224 Fountainhead Plaza
Hagerstown, MD 21742
USA
or Your Local JLG Office
In USA:
Toll Free: 1-877-JLG-SAFE (1-877-554-7233)
Outside USA:
Phone: [phone]
E-mail:
[e-mail]

Read This First
d31211476
Other Publications Available
Service Manual.............................................................................................................................31211477
Parts Manual .................................................................................................................................31211478
Note: The following standards may be referenced in this manual:
ANSI is compliant to ANSI/ITSDF B56.6
AUS is compliant to AS 1418.19
CE is compliant to EN1459
Refer to the machine Serial Number Plate to identify the applicable compliance standard.

Table of Contents
TABLE OF CONTENTS
31211476 1
Revision Log
Read This First
Operator Qualifications ........................................................................... b
Modifications............................................................................................... b
Other Publications Available ................................................................. d
Table of Contents
Section 1 - General Safety Practices
1.1 Hazard Classification System ....................................................................1-1
Safety Alert System and Safety Signal Words...............................1-1
1.2 General Precautions .....................................................................................1-1
1.3 Operation Safety............................................................................................1-2
Electrical Hazards....................................................................................1-2
Tip Over Hazard.......................................................................................1-4
Travel Hazard............................................................................................1-7
Load Falling Hazard ...............................................................................1-8
Lifting Personnel.....................................................................................1-9
Driving Hazards on Slopes................................................................1-10
Pinch Points and Crush Hazards.....................................................1-11
Fall Hazard..............................................................................................1-13
Chemical Hazards ................................................................................1-14
1.4 ClearSky (if equipped)............................................................................... 1-15
Federal Communications Commission (FCC) Information
for Users...................................................................................................1-15
Section 2 -Pre-Operation and Inspection
2.1 Preparation, Inspection and Maintenance...........................................2-1
2.2 Pre-Operation Check and Inspection.....................................................2-2
2.3 Safety Decals...................................................................................................2-4
ANSI (if equipped)...................................................................................2-4
2.4 Walk-Around Inspection.............................................................................2-8
2.5 Warm-Up and Operational Checks ......................................................2-10
Warm-Up Check ...................................................................................2-10
Operational Check............................................................................... 2-10
2.6 Operator Cab................................................................................................2-11
2.7 Windows........................................................................................................2-12
Cab Door Window (if equipped) .................................................... 2-12
Rear Window ......................................................................................... 2-13
Section 3 -Controls and Indicators
3.1 General..............................................................................................................3-1
3.2 Controls.............................................................................................................3-2
Park Brake..................................................................................................3-4
Table of Contents

Table of Contents
231211476
Parking Procedure..................................................................................3-4
Ignition.......................................................................................................3-5
Transmission Control Lever ................................................................3-6
Load Stability Indicator - LSI ...............................................................3-7
LSI Override Switch................................................................................3-9
Instrument Panel ................................................................................. 3-10
Joystick.................................................................................................... 3-12
Right Hand Console............................................................................ 3-13
Accessory Control Lever (if equipped)......................................... 3-14
3.3 Operator Seat .............................................................................................. 3-15
Adjustments .......................................................................................... 3-15
Operator Presence .............................................................................. 3-16
Seat Belt .................................................................................................. 3-17
Seat Belt Fastened............................................................................... 3-18
3.4 Boom Angle and Extension Indicators............................................... 3-19
Section 4 -Operation
4.1 Engine ...............................................................................................................4-1
Starting the Engine ................................................................................4-1
Cold Weather Starting ..........................................................................4-2
Battery Boosted Starting......................................................................4-3
Normal Engine Operation ...................................................................4-4
Shut-Down Procedure ..........................................................................4-4
4.2 Operating with a Non-Suspended Load...............................................4-5
Lift Load Safely ........................................................................................4-5
Before Picking Up a Load.....................................................................4-5
Transporting a Load ..............................................................................4-6
Leveling Procedure................................................................................4-6
Placing a Load..........................................................................................4-7
Disengaging a Load...............................................................................4-7
4.3 Operating with a Suspended Load.........................................................4-8
Lift Load Safely ........................................................................................4-8
Picking Up a Suspended Load ...........................................................4-8
Transporting a Suspended Load.......................................................4-9
Leveling Procedure................................................................................4-9
Placing a Suspended Load............................................................... 4-10
Disengaging a Suspended Load .................................................... 4-10
4.4 Loading and Securing for Transport ................................................... 4-11
Tiedown .................................................................................................. 4-11
Lifting....................................................................................................... 4-12
Section 5 -Attachments and Hitches
5.1 Approved Attachments ..............................................................................5-1
Coupler Mounted Attachments ........................................................5-1
JLG Supplied Fork Mounted Attachments ....................................5-1

Table of Contents
3
31211476
Non-OEM Fork Mounted Attachments...........................................5-1
5.2 Unapproved Attachments .........................................................................5-2
5.3 Fork Mounted Attachments ......................................................................5-3
General Requirements ..........................................................................5-3
Non-OEM Attachments.........................................................................5-4
5.4 Equivalent Load .............................................................................................5-5
Load Centers Beyond 24 Inches ........................................................5-5
Fork Mounted Attachments Equivalent Load ..............................5-6
5.5 JLG Supplied Attachments.........................................................................5-7
5.6 Telehandler/Attachment/Fork Capacity...............................................5-8
5.7 Use of the Capacity Chart...........................................................................5-9
Capacity Indicator Locations ..............................................................5-9
Sample Capacity Chart....................................................................... 5-10
Example...................................................................................................5-11
5.8 Attachment Installation ...........................................................................5-12
Mechanical Standard Quick Attach............................................... 5-12
Hydraulic Universal Quick Attach (UQC) ..................................... 5-14
5.9 Hydraulic Operated Attachment ..........................................................5-16
5.10 Adjusting/Moving Forks ..........................................................................5-17
5.11 Attachment Operation............................................................................. 5-18
Carriage with Forks .............................................................................5-19
Side Shift Carriage ............................................................................... 5-20
Bucket ...................................................................................................... 5-22
5.12 Hitches............................................................................................................ 5-24
Retrieval Hitch....................................................................................... 5-24
Ball Hitch - 2" (50 mm)........................................................................5-25
Section 6 -Emergency Procedures
6.1 Towing a Disabled Product........................................................................6-1
Moving Short Distances .......................................................................6-1
Moving Longer Distances....................................................................6-1
6.2 Emergency Lowering of Boom.................................................................6-2
6.3 Emergency Exit from Enclosed Cab........................................................6-3
Inside Cab ..................................................................................................6-3
Outside Cab (if equipped)....................................................................6-3
Section 7 - Lubrication and Maintenance
7.1 Introduction ....................................................................................................7-1
Clothing and Safety Gear.....................................................................7-1
7.2 General Maintenance Instructions..........................................................7-2
7.3 Maintenance Schedules..............................................................................7-3
Every 8 Hours............................................................................................7-3
First 50 Hours............................................................................................7-3
Every 50 Hours .........................................................................................7-4
Every 200 Hours.......................................................................................7-4

Table of Contents
431211476
Every 400 Hours ......................................................................................7-5
Every 600 Hours ......................................................................................7-5
Every 1000 Hours....................................................................................7-6
Every 1500 Hours....................................................................................7-6
7.4 Lubrication Schedules.................................................................................7-7
50 Hour Lubrication Schedule ...........................................................7-7
7.5 Operator Maintenance Instructions.......................................................7-8
Fuel System...............................................................................................7-8
Engine Oil ............................................................................................... 7-10
Hydraulic Oil.......................................................................................... 7-11
Tires .......................................................................................................... 7-12
Air Intake System................................................................................. 7-14
Engine Cooling System ..................................................................... 7-16
Battery ..................................................................................................... 7-17
Brake System......................................................................................... 7-18
Windshield Washer System (if equipped)................................... 7-19
Section 8 -Additional Checks
8.1 General..............................................................................................................8-1
8.2 Load Stability Indicator System ...............................................................8-1
Section 9 -Specifications
9.1 Product Specifications.................................................................................9-1
Fluids...........................................................................................................9-1
Capacities ..................................................................................................9-2
Tires .............................................................................................................9-3
Performance.............................................................................................9-4
Dimensions...............................................................................................9-5
Machine Towing Capacity...................................................................9-6
Index
Inspection, Maintenance and Repair Log

Section 1- General Safety Practices
1-1
31211476
SECTION 1 - GENERAL SAFETY PRACTICES
1.1 HAZARD CLASSIFICATION SYSTEM
Safety Alert System and Safety Signal Words
1.2 GENERAL PRECAUTIONS
• Hydraulic cylinders are subject to thermal expansion and contraction. This may result
in changes to the boom and/or attachment position while the machine is stationary.
Factors affecting thermal movement can include the length of time machine is
stationary, hydraulic oil temperature, ambient air temperature and boom and/or
attachment position.
• Precautions to avoid all hazards in the work area must be taken by the user before and
during operation of the machine.
DANGER
DANGER indicates an imminently hazardous situation which, if not avoided, will result
in death or serious injury.
WARNING
WARNING indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION
CAUTION indicates a potentiality hazardous situation which, if not avoided, may result
in minor or moderate injury.
WARNING
Before operation, read and understand this manual. Failure to comply with the safety
precautions listed in this manual could result in machine damage, property damage,
personal injury or death.

Section 1- General Safety Practices
1-231211476
1.3 OPERATION SAFETY
Note: The manufacturer has no direct control over machine application and operation.
Therefore, safety issues listed in this manual are non-exhaustive. The user and operator are
responsible for conforming with good safety practices.
Electrical Hazards
• This machine is not insulated and does not provide protection from contact or being
near electrical current.
• Always check for power lines before raising the boom.
• Maintain distance from electrical lines, apparatus, or any energized (exposed or
insulated) parts according to the Minimum Approach Distance (MAD).
Note: This requirement shall apply except where employer, local or governmental
regulations are more stringent.
• Allow for machine movement and electrical line swaying.
• Maintain a clearance of at least 10 ft (3m) between any part of the machine and its
occupants, their tools and their equipment from any electrical line or apparatus
carrying up to 50,000 volts. One foot additional clearance is required for every
additional 30,000 volts or less.
Voltage Range
(Phase to Phase)
Minimum Approach Distance
(MAD)
0 to 50 KV 10 ft (3 m)
Over 50KV to 200 KV 15 ft (5 m)
Over 200 KV to 350 KV 20 ft (6 m)
Over 350 KV to 500 KV 25 ft (8 m)
Over 500 KV to 750 KV 35 ft (11 m)
Over 750 KV to 1000 KV 45 ft (14 m)
O 0891D
10 ft
(3m)

Section 1- General Safety Practices
1-3
31211476
• The minimum approach distance may be reduced if insulating barriers are installed to
prevent contact, and the barriers are rated for the voltage of the line being guarded.
These barriers shall not be part of (or attached to) the machine. The minimum
approach distance shall be reduced to a distance within the designed working
dimensions of the insulating barrier. This determination shall be made by a qualified
person in accordance with the employer, local, or governmental requirements for
work practices near energized equipment.
DANGER
Do not maneuver machine or personnel inside prohibited zone (MAD). Assume all
electrical parts and wiring are energized unless known otherwise.

Section 1- General Safety Practices
1-431211476
Tip Over Hazard
General
• For additional load requirements, refer to the appropriate capacity chart.
• Never use an attachment without the appropriate original equipment manufacturer
(OEM) approved capacity chart installed on the telehandler.
• Understand how to properly use the capacity charts located in cab.
•DO NOT exceed rated lift capacity.
• Be sure that the ground conditions are able to support the machine.
• Be aware of wind conditions. Wind may cause load swing and dangerous side loads.
• Keep the machine a minimum of 2 ft (0,6 m) from holes, drop-offs, obstructions,
debris, concealed holes and other potential hazards at ground level.
•DO NOT raise boom unless frame is level (0 degrees), unless otherwise noted on
capacity chart.
OW0050

Section 1- General Safety Practices
1-5
31211476
•MAINTAIN proper tire pressure at all times. If proper tire pressures are not
maintained, this machine could tip over.
• Refer to manufacturer’s specifications for proper fill ratio and pressure requirements
for tires equipped with ballast.
• Always wear seat belt.
• Keep head, arms, hands, legs and all other body parts inside operator’s cab at all times.
If telehandler starts to tip over:
•DO NOT JUMP
• BRACE YOURSELF and STAY WITH THE MACHINE
• KEEP YOUR SEAT BELT FASTENED
• HOLD ON FIRMLY
• LEAN AWAY FROM THE POINT OF IMPACT
OH2291
OH20911
OH2221

Section 1- General Safety Practices
1-631211476
Non-Suspended Load
•DO NOT drive with boom raised.
Suspended Load
• Tether suspended loads to restrict movement.
• Weight of all rigging (slings, etc.) must be included as part of load.
• Keep heavy part of load closest to attachment.
• Never drag the load; lift vertically.
When driving with a suspended load:
• Start, travel, turn and stop slowly to prevent load from swinging.
•DO NOT extend boom.
•DO NOT raise the load more than 300 mm (11.8 in) above ground surface or the
boom more than 45°.
•DO NOT exceed walking speed.
O 0901D
OW0150

Section 1- General Safety Practices
1-7
31211476
Travel Hazard
• Look out for and avoid other personnel, machinery and vehicles in the area. Use a
spotter if you DO NOT have a clear view.
• Ensure that adequate clearance is provided between both rear tailswing and front fork
swing.
• Before moving be sure of a clear path and sound horn.
• When driving, retract boom and keep boom/attachment as low as possible while
maintaining visibility of mirrors and maximum visibility of path of travel.
• Always look in the direction of travel.
• Always check boom clearances carefully before driving underneath overhead
obstructions. Position attachment/load to clear obstacles.
• Telehandlers equipped with solid or foam filled tires should not be used in
applications requiring excessive roading or driving extended distances. In the event
an application requires excessive roading or driving expanded distances, it is
recommended to use telehandlers not equipped with solid or foam filled tires.
O 0121W
2-WHEEL REAR STEER

Section 1- General Safety Practices
1-831211476
Load Falling Hazard
• Never suspend load from forks or other parts of carriage weldment. Use only
approved lift points.
•DO NOT burn or drill holes in fork(s).
• Forks must be centered under load and spaced apart as far as possible.
OW0130

Section 1- General Safety Practices
1-9
31211476
Lifting Personnel
• When lifting personnel, USE ONLY an approved personnel work platform, with proper
capacity chart displayed in the cab.
•DO NOT drive machine from cab when personnel are in platform.
O 0171W
O 0921D

Section 1- General Safety Practices
1-10 31211476
Driving Hazards on Slopes
To maintain sufficient traction and braking capabilities, travel on slopes as follows:
• When unloaded, drive with forks pointed downhill.
• When loaded, drive with the forks pointed uphill.
• For additional travel requirements, refer to the appropriate capacity chart.
• To avoid overspeeding the engine and drivetrain when driving down
slopes, use the service brake as necessary to maintain a slow speed. DO NOT shift
into neutral and coast downhill.
• Avoid excessively steep slopes or unstable surfaces. To avoid tip over DO NOT
drive across excessively steep slopes under any circumstances.
• Avoid turning on a slope. Never engage “inching” or shift to “Neutral” when
going downhill.
•DO NOT park on a slope.
OW0200
