Jobsite CT5305 Operation instructions

Cannon Tools Limited
Address: 20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.
Read your owner’s manual carefully before you installation, assembly, operation or maintenance of the
generator start.protect yourself and others by you follow all safety instructions. error in compliance with the
following instructions can cause serious injury and/ or property damage.
CORDLESS SLIDING MITRE SAW
Model : CT5305
ORIGINAL MANUAL

EC DECLARATION OF CONFORMITY
WeCANNON TOOLS LTD
20 Station road, Rowley Regis, West Midlands,B65 0JU.U.K.
Declare that the following machine complies with the appropriate basic safety and health requirements of
the EC Directive based on its design and type, as brought into circulation by us.
In case of alteration of the machine, not agreed upon by us, this declaration will lose its validity.
Product description: &25'/(666/,',1*MITRE SAW
Model: CT
Applicable EC Directives:
EC Machinery Directive 2006/42/EC
EC Directive of Electromagnetic Compatibility 2014/30/EU
Harmonized standards：
EN ISO12100:2010, EN 61029-1:2009+A11, EN 61029-2-9:2009+A11,
EN 55014-1:2017, EN 55014-2:2015
20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.
Mr. Gurcharan Tony Singh Sanghera
Managing Director
CANNON TOOLS LTD
2020-08-25

Donotexposetorainorwater.
Donotburn.
Preventshortcircuitandenergydischarge.
Intelligentbatterypack.Donotblenduse.
ConformstoEuropeansafetystandards.
Neverplacedefectiveequipmentinyourhouseholdrefuse.
Caution: Laserradiation. Donotlookintothebeam!Laserclass2product!
Danger! -Readtheoperatinginstructionstoreducetheriskofinquiry
Caution!Wearear-muffs. Theimpactofnoisecancausedamagetohearing.
Caution!Wearabreathingmask.
Caution!Wearsafetygoggles.
Caution!Riskofinjury! Donotreachintotherunningsawblade.
SYMBOLS

KNOWYOURPRODUCT
PARTSLIST
1.Laserlight
2.Laserlighton/offswitch
3.Sawarm
4.Releaseknob
5.Operatinghandle
6.Upperfixedbladeguard
7. G”Clamp
8.Rotatingbladeguard
9.Guardretractionarm
10.Bladeboltcover
11.Dustbag
12.Bevellock
13.Bevelscale
14.Fence
15.6mmHexkey
16.Mitretable
17.Mitrescale
18.Tableinsert
19.Switchtrigger
20.Mitrelockknob
21.Mitrelatch
22.Spindlelock
23.Slidebars
24.Slidelock
25.Trenchingdepthadjustmentscrew
26.Trenchingstop
27.Trenchingdepthlocknut
28.45 Beveladjustmentscrew
29.0 Beveladjustmentscrew
30.Releaselatch
31.Sidesupportbars(x2)
32.Batterypack
33.Batterylock
34.Switchlocker
35.Attachfence

SPECIFICATIONS
TECHNICALDATA
CT5305
Voltage:18V
Batterycapacity: 4AhLi-ion
No-loadspeed:3ϯ00RPM
Sawblade: 210x1.8xϮϱϰŵŵx40T
Notalltheaccessoriesillustratedordescribedare
includedinstandarddelivery.
-Thatthedeclaredvibrationtotalvaluehasbeen
measuredinaccordancewithastandardtestmethod
andmaybeusedforcomparingonetoolwith
another;
-Thatthedeclaredvibrationtotalvaluemayalsobe
usedinapreliminaryassessmentofexposure.
-Thatthevibrationemissionduringactualuseofthe
powertoolcandifferfromthedeclaredtotalvalue
dependingonthewaysinwhichthetoolisused;and
-oftheneedtoidentifysafetymeasurestoprotect
theoperatorthatarebasedonanestimationof
exposureintheactualconditionsofuse(taking
accountofallpartsoftheoperatingcyclesuchas
thetimeswhenthetoolisswitchedoffandwhenitis
runningidleinadditiontothetriggertime).
CUTTINGCAPACITY
Mitretableangles:0°to45°totheleft&right
Bevelcuts:0°to45°totheleft
Straightcutat0°x0°:22x7cm
Mitrecutat0°x45°:15.5x7cm
Bevelcutat45°x0°:22x3.5cm
Compoundmitrecutat45°x45°:15.5x3.5cm
Netweight:9.8kgs
INTENDEDUSE
Thismitresawisintendedforcuttingwood
and analogue materials, The sawis not
designedforcuttingfirewood.
WARNING !Whenusingelectrictoolsbasic
safetyprecautionsshouldalwaysbefollowedto
reducetheriskoffire,electricshockandpersonal
injuryincludingthefollowing.
Readalltheseinstructionsbeforeattemptingto
operatethisproductandsavetheseinstructions.
Allpersonswhouseandservicethemachinehave
tobeacquaintedwiththisManualandmustbe
informedaboutitspotentialhazards.Childrenand
infirmpeoplemustnotusethistool.Childrenshould
besupervisedatalltimesiftheyareintheareain
whichthetoolisbeingused.Itisalsoimperativethat
youobservetheaccidentpreventionregulationsin
forceinyourarea.Thesameappliesforgeneral
rulesofoccupationalhealthandsafety
Evenwhenthetoolisusedasprescribeditisnot
possibletoeliminateallresidualriskfactors.The
followinghazardsmayariseinconnectionwiththe
tool’sconstructionanddesign:
·Contactwiththeblade.
·Kickbackofworkpieceandpartsofworkpiece.
·Bladefracture.
·Catapultingofbladepieces.
·Damagetohearingifeffectiveearmuffsarenot
worn.
·Harmfulemissionsofsawdustwhenthemachine
isusedinclosedrooms.Alwaysuse
supplementarydustextractionwherepossible.
·Donotusebladesthataredeformedorcracked.
·Alwaysremovetheplugfromthemainssocket
beforemakinganyadjustmentsormaintenance,
includingchangingtheblade.Toensuresafe
operationofthemitresawyoumustfollowthese
guidelines:
·Selectthecorrectbladeforthematerialtobecut.
·Donotusethesawtocutmaterialsotherthan
thoserecommendedbythemanufacturer.
Themitresawcanbesafelycarriedbythemain

handlebutonlyonceithasbeenremovedfromthe
mainspowerandsecuredinthelockeddown
position.
·Donotusethesawwithouttheguardsin
position,ingoodworkingorderandproperly
maintained.
·Ensurethatthearmisproperlysecurewhen
beveling.
·Keepthefloorareaaroundthemachinelevel,well
maintainedandfreeofloosematerials.
·Provideadequatelighting.
·Ensurethatyouaretrainedintheuse,adjustment
andoperationofthemachine.
·Usecorrectlysharpenedbladesandobservethe
maximumspeedmarkedontheblade.
·Donotremoveanycut-offsfromthecuttingarea
untiltheguardisfullylockedinplaceandthe
bladehascometorest.
·Ensurethatthemitresawisfixedtoawork
benchwhereverpossible.
·Whencuttinglongpieceswhichextendwellover
thetablewidthensurethattheendsare
adequatelysupportedatthesameheightasthe
sawtabletop.Supportsshouldbepositionedin
suchawaytoensurethattheworkpiecedoesnot
falltotheground.oncethecuthasbeenmade.A
numberofsupportsatregularintervalsmaybe
requirediftheworkpieceisextremelylong.
NOTINTENDEDUSE
Ifnotintendedusetheriskoffire,electricshockand
personalinjurymaybefurtherand
-Theprovisionscontainedinthis guarantee arenot
intendedtolimit,modify,takeawayfrom,disclaimor
excludeanystatutory guarantee setforthinany
applicableprovincialorfederallegislation.
RESIDUALRISKS
Even if you use this electric power tool in
accordancewithinstructions,certainresidualrisks
cannotberulesout.Thefollowinghazardsmay
arise in connection with the equipment s
constructionandlayout:
1.Lungdamageifnosuitableprotectivedustmaskis
used.
2.Damagetohearingifnosuitableearprotectionis
used.
3.Healthdamagecausedbyhand-armvibrationsifthe
equipmentisusedoveraprolongedperiodorisnot
properlyguidedandmaintained.
GENERALSAFETYINSTRUCTIONS
WARNING !Whenusingelectrictoolsbasic
safetyprecautionsshouldalwaysbefollowedto
reducetheriskoffire,electricshockandpersonal
injuryincludingthefollowing.
Readalltheseinstructionsbeforeattemptingto
operatethisproductandsavetheseinstructions.
1-Keepworkareaclear
-Clutteredareasandbenchesinviteinjuries.
2-Considerworkareaenvironment
-Donotexposetoolstorain.
-Donotusetoolsindamporwetlocations.
-Keepworkareawelllit.
-Donotusetoolsinthepresenceofflammable
liquidsorgases.
3-Guardagainstelectricshock
-Avoidbodycontactwithearthedorgrounded
surfaces(e.g.pipes,radiators,ranges,
refrigerators).
4-Keepotherpersonsaway
-Donotletpersons,especiallychildren,notinvolved
intheworktouchthetoolortheextensioncordand
keepthemawayfromtheworkarea.
5-Storeidletools
-Whennotinuse,toolsshouldbestoredinadry
locked-upplace,outofreachofchildren.
6-Donotforcethetool
-Itwilldothejobbetterandsaferattheratefor
whichitwasintended.
7-Usetherighttool
-Donotforcesmalltoolstodothejobofaheavy
dutytool.
-Donotusetoolsforpurposesnotintended;for
exampledonotusecircularsawstocuttree
limbsorlogs.
8-Dressproperly
-Donotwearlooseclothingorjewellery,theycanbe
caughtinmovingparts.
-Non-skidfootwearisrecommendedwhenworking
outdoors.
-Wearprotectivehaircoveringtocontainlonghair.
9-Useprotectiveequipment
-Usesafetyglasses.
-Usefaceordustmaskifworkingoperationscreate
dust.
10-Connectdustextractionequipment
-Ifthetoolisprovidedfortheconnectionofdust
extractionandcollectingequipment,
ensuretheseareconnectedandproperlyused.
11-Donotabusethecord
-Neveryankthecordtodisconnectitfromthe
socket.Keepthecordawayfromheat,oiland
sharpedges.
12-Securework

-Wherepossibleuseclampsoravicetoholdthe
workpieces.Itissaferthanusingyourhand.
13-Donotoverreach
-Keepproperfootingandbalanceatalltimes.
14-Maintaintoolswithcare
-Keepcuttingtoolssharpandcleanforbetterand
saferperformance.
-Followinstructionforlubricatingandchanging
accessories.
-Inspecttoolcordsperiodicallyandifdamagedhave
themrepairedbyanauthorizedservice
facility.
-Inspectextensioncordsperiodicallyandreplaceif
damaged.
-Keephandlesdry,cleanandfreefromoiland
grease.
15-Disconnecttools
-Whennotinuse,beforeservicingandwhen
changingaccessoriessuchasblades,bitsand
cutters,disconnecttoolsfromthepowersupply.
16-Removeadjustingkeysandwrenches
-Formthehabitofcheckingtoseethatkeysand
adjustingwrenchesareremovedfromthetoolbefore
turningiton.
17-Avoidunintentionalstarting
-Ensureswitchisin"off"positionwhenpluggingin.
18-Useoutdoorextensionleads
-Whenthetoolisusedoutdoors,useonlyextension
cordsintendedforoutdooruseandsomarked.
19-Stayalert
-Watchwhatyouaredoing,usecommonsenseand
donotoperatethetoolwhenyouaretired.
20-Checkdamagedparts
-Beforefurtheruseoftool,itshouldbecarefully
checkedtodeterminethatitwilloperate
properlyandperformitsintendedfunction.
-Checkforalignmentofmovingparts,bindingof
movingparts,breakageofparts,mountingandany
otherconditionsthatmayaffectitsoperation.
-Aguardorotherpartthatisdamagedshouldbe
properlyrepairedorreplacedbyanauthorized
servicecenterunlessotherwiseindicatedinthis
instructionmanual.
-Havedefectiveswitchesreplacedbyanauthorized
servicecenter.
-Donotusethetooliftheswitchdoesnotturniton
andoff.
21-Warning
-Theuseofanyaccessoryorattachmentotherthan
onerecommendedinthisinstruction
manualmaypresentariskofpersonalinjury.
22-Haveyourtoolrepairedbyaqualifiedperson
-Thiselectrictoolcomplieswiththerelevantsafety
rules.Repairsshouldonlybecarriedoutbyqualified
personsusingoriginalspareparts,otherwisethis
mayresultinconsiderabledangertotheuser.
IMPORTANTSAFETYINSTRUC-
TIONSFORALLBATTERYPACKS
Whenorderingreplacementbatterypacks,besureto
includethecatalognumberandvoltage.Consultthe
chartattheendofthismanualforcompatibilityof
chargersandbatterypacks.Thebatterypackisnot
fullychargedoutofthecarton.Beforeusingthe
batterypackandcharger,readthesafetyinstructions
belowandthenfollowchargingproceduresoutlined.
Donotchargeorusethebatterypackin
explosiveatmospheres,suchasinthepresenceof
flammableliquids,gasesordust. Insertingor
removingthebatterypackfromthechargermay
ignitethedustorfumes.
NEVERforcethebatterypackintothecharger.
DONOTmodifythebatterypackinanywaytofit
intoanon-compatiblechargerasbatterypackmay
rupturecausingseriouspersonalinjury. Consultthe
chartattheendofthismanualforcompatibilityof
batteriesandchargers.
•Chargethebatterypacksonlyindesignated
chargers.
DONOT splashorimmerseinwaterorother
liquids.
Donotstoreorusethetoolandbatterypackin
locationswherethetemperaturemayreachor
exceed104 °F(40 °C)(suchasoutsideshedsor
metalbuildingsinsummer). Forbestlifestore
batterypacksinacool,drylocation.
NOTE:Donotstorethebatterypacksinatool
withthetriggerswitchlockedon.
NevertapethetriggerswitchintheONposition.
WARNING: Firehazard.Neverattempttoopen
thebatterypackforanyreason.Ifthebatterypack
caseiscrackedordamaged,donotinsertintothe
charger.Donotcrush,dropordamagethebattery
pack.Donotuseabatterypackorchargerthathas
receivedasharpblow,beendropped,runoveror
damagedinanyway(e.g.,piercedwithanail,hit
withahammer,steppedon).Damagedbatterypacks
should be returned to the service center for
recycling.
WARNING:Firehazard.Donotstoreor
carrythebatterypacksothatmetalobjectscan
contactexposedbatteryterminals. Forexample,
donotplacethebatterypackinaprons,pockets,tool
boxes,productkitboxes,drawers,etc.,withloose

nails,screws,keys,etc. Transportingbatteriescan
possiblycausefiresifthebatteryterminals
inadvertentlycomeincontactwithconductive
materialssuchaskeys,coins,handtoolsandthe
like. The US Department of Transportation
HazardousMaterialRegulations(HMR)actually
prohibittransportingbatteriesincommerceoron
airplanes(e.g.,packedinsuitcasesandcarry-on
luggage)UNLESStheyareproperlyprotectedfrom
short circuits. So when transporting individual
batterypacks,makesurethatthebatteryterminals
areprotectedandwellinsulatedfrommaterialsthat
couldcontactthemandcauseashortcircuit.
SPECIFICSAFETYINSTRUCTIONSFOR
LITHIUMION(Li-Ion)
Donotincineratethebatterypackevenifitis
severelydamagedoriscompletelywornout. The
batterypackcanexplodeinafire.Toxicfumesand
materialsarecreatedwhenlithiumionbatterypacks
areburned.
Ifbatterycontentscomeintocontactwiththe
skin,immediatelywashareawithmildsoapand
water. Ifbatteryliquidgetsintotheeye,rinsewater
overtheopeneyefor15minutesoruntilirritation
ceases.Ifmedicalattentionisneeded,thebattery
electrolyteiscomposedofamixtureofliquid
organiccarbonatesandlithiumsalts.
Contentsofopenedbatterycellsmaycause
respiratory irritation. Provide fresh air. If
symptomspersist,seekmedicalattention.
WARNING: Burnhazard.Batteryliquidmaybe
flammableifexposedtosparkorflame.
SAFETYRULESFORLASERLIGHTS
WARNINGS. Beforeconnectingatooltoa
powersource(mainsswitchpowerpointreceptacle,
outlet,etc.)besurethatthevoltagesupplyisthe
sameasthatspecifiedonthenameplateofthetool.
Apowersourcewithavoltagegreaterthanthat
specifiedforthetoolcanresultinseriousinjurytothe
user,aswellasdamagetothetool.Ifindoubt,do
notpluginthetool.Usingapowersourcewitha
voltagelessthanthenameplateratingisharmfulto
themotor.Yourtoolisdoubleinsulatedforadditional
protectionagainstapossibleelectricalinsulation
failurewithinthetool.
ADDITIONALSAFETYRULESFOR
MITRE SAWS
WEARGOGGLES
WEAREARMUFFS
WEARABREATHINGMASK
WARNING! Foryourownsafetyreadinstruction
manualbeforeoperatingmitresaw.Weareye
protection.Keephandsoutofpathofsawblade.Do
notoperatesawwithoutguardsinplace.Donot
performanyoperationfreehand.Neverreacharound
sawblade.Turnofftoolandwaitforsawbladeto
stopbeforemovingworkpieceorchangingsettings.
Whenchangingtheblade,replaceandsecureall
guardingtoitsoriginalpositionandcorrectlybefore
startingtool.Disconnectpower(orunplugtoolas
applicable)beforechangingbladeorservicing.Donot
exposetorainoruseindamplocations.Toreducethe
riskofinjury,returncarriagetothefullrearposition
aftereachcrosscutoperation.
Thetoolmustbeusedonlyforitsprescribedpurpose.
AnyuseotherthanthosementionedinthisManualwill
beconsideredacaseofmisuse.Theuserandnotthe
manufacturershallbeliableforanydamageorinjury
resultingfromsuchcasesofmisuse.
Themanufacturershallnotbeliableforanychanges
madetothetoolnorforanydamageresultingfromsuch
changes.
Evenwhenthetoolisusedasprescribeditisnot
possibletoeliminateallresidualriskfactors.The
followinghazardsmayariseinconnectionwiththetool’s
constructionanddesign:
Damagetothelungsifaneffectivedustmaskisnot
worn.
Damagetohearingifeffectiveearmuffsarenot
worn.
·Whenoperatingthesaw,usesafetyequipment
includingsafetygogglesorshield,earprotection,
dustmaskandprotectiveclothingincludingsafety
gloves.
·Ensurethatthereisadequategeneralorlocalized
lighting.
·Donotusethesawunlesstheguardsarein
place.
·Donotusethesawtocutmetalormasonry.
·Donotletanyoneunder18yearsoperatethis
saw.
·Ensurethattheoperatorisadequatelytrainedin
theuse,adjustmentandoperationofthemachine.
·Donotusethissawtocutfirewood.
·Keeptheareafreeoftrippinghazards.
·Reportfaultsinthemachine,includingguards
andsawblades,assoonastheyarediscovered.

·Ensurethatthemachineisalwaysfixedtoa
workbench,wheneverpossible.
·Alwaysstandtoonesidewhenoperatingthe
saw.
·Neveruseadamagedordeformedsawblade.
·Whencuttingroundwood,useclampsthat
preventtheworkpiecefromturningonbothsidesof
theblade.
·Neveruseyourhandstoremovesawdust,chipsor
wasteclosebytheblade.
·Useonlybladesasrecommendedbythe
manufacturerandwhichconformtoEN847-1.
·DonotusebladesofHighSpeedSteel(HSS
blades).
·Ifthetableinsertisdamagedorworn,haveit
replacedbyanauthorizedservicecenter.
·Rags,cloths,cordandstringandthelikeshould
neverbeleftaroundtheworkarea.
·Avoidcuttingnails.Inspecttheworkpieceand
removeallnailsandotherforeignobjectsbefore
beginningsawing.
·Supporttheworkproperly.
·Refrainfromremovinganycut-offsorotherparts
oftheworkpiecefromthecuttingareawhilstthe
machineisrunningandthesawheadisnotinthe
restpositionorwhilstthemachineisrunningwithan
unguardedsawblade.
·Donotattempttofreeajammedbladebeforefirst
switchingoffthemachine.
·Donotsloworstopabladewithapieceofwood.
Letthebladecometorestnaturally.
·Ifyouareinterruptedwhenoperatingthesaw,
completetheprocessandswitchoffbeforelooking
up.
·Periodicallycheckthatallnuts,boltsandother
fixingsareproperlytightened.
·Donotstorematerialsorequipmentabovea
machineinsuchawaythattheycouldfallintoit.
·Alwaysholdthesawonpartsthatareinsulated.If
youaccidentallycutintohiddenwiringorthesaw s
owncable,themetalpartsofthesawwillbecome
“live”.Switchoffatthemainsandremovetheplug
immediately.
·Neversawnearcombustibleliquidsorgases.
·Notethedirectionofrotationofthemotorandthe
blade.
·Donotlockthemovableguardintheopenposition
andalwaysensurethatitisworkingproperly,freely
rotatingandreturningtofullycovertheteethofthe
blade.
·Connectthesawtoadustcollectiondeviseand
ensurethatitisoperatedproperly.Astheoperatorof
thesaw,pleasemakesurethatyouunderstand
factorsthatinfluenceexposuretodust,includingthe
typeofmaterialtobemachined,theimportanceof
localextractionandtheproperadjustmentof
hoods/baffles/shootsofyourdustextractionsystem.
Werecommendthatyoualwayswearadustmask
whenoperatingthissaw.
·Weargloveswhenhandlingsawbladesand
roughmaterials.
·Sawbladesshallbecarriedinaholderwherever
possible.
·Selectsawbladesinrelationtothematerialbeing
cut.
·Usecorrectlysharpenedsawbladesandobserve
themaximumspeedmarkedontheblade.Ensure
thespeedmarkedonthesawbladeisatleastequal
tothespeedmarkedonthesaw
·Takeadditionalcarewhentrenching(slotting).
·Themitresawcanbesafelycarriedbythe
carryinghandlebutonlyonceithasbeenremoved
fromthemainspowerandsecuredinthelocked
downposition. Warning!Neverusetheguardas
theliftingandtransportationpurpose!
·Ensurethatthearmisproperlysecurewhen
beveling.
·Keepthefloorareaaroundthemachinelevel,well
maintainedandfreeofloosematerials.
·Ensurethatyouaretrainedintheuse,adjustment
andoperationofthemachine.
·Donotremoveanycut-offsfromthecuttingarea
untiltheguardisfullylockedinplacedandtheblade
hascometorest.
·Wherepossibleuseclampsoravicetoholdthe
workpieces.Itissaferthanusingyourhand.
·beforeeachcut,makesurethatthemachineis
stable.
·Whencuttinglongpieceswhichextendwellover
thetablewidth,ensurethattheendsareadequately
supportedatthesameheightasthesawtabletop.
Supportsshouldbepositionedinsuchawayto
ensurethattheworkpiecedoesnotfalltotheground
oncethecuthasbeenmade.Anumberofsupports
atregularintervalsmayberequirediftheworkpiece
isextremelylong.
Duringslidecutting,alwaysensurethatthesaw
bladeispushedawayfromtheoperator.
Alwaysusestandstoprovidesupportforlongwork
piecesthatoverhangtheturntable.
Feedworkintoabladeorcutteragainstthedirection
ofrotationofthebladeorcutteronly.
Beforemakingcompoundmitrecuts,ensurethatthe
workheadissecurelyfixedinthedesiredposition.
Neverreachoverthebladetoremovewasteoroff
cuts.

OPERATINGINSTRUCTIONS
ACCESSORIES
TheCompoundMitreSawissuppliedwiththefollowing
accessoriesasstandard:
Sawblade(fitted)
6mmhexkey
Dustbag
Instructionmanual
Batterycapacity: 4AhLi-ion(#)
Charger (#)
(#)Notalltheaccessoriesillustratedordescribedare
includedinstandarddelivery.
TRANSPORTATION
Liftthemitresawonlywhenthesawarmislockedinthe
downposition,thesawisswitchedoffandthebatteryis
removedfromthepowertool.
Onlyliftthesawbytheoperatinghandle (5) orouter
castings.Donotliftthesawusingtheguards.
BENCHMOUNTING
Thesawbasehasholesineachcornertofacilitatebench
mounting.
1. Placethesawonalevel,horizontalbenchorwork
tableusingbolts(notsupplied)andfixthesawtothe
benchusing4bolts.
2. Ifdesired,youcanmountthesawtoapieceof1/2”
(13mm)orthickerplywoodwhichcanthenbeclamped
toyourworksupportormovedtootherjobsitesand
re-clamped.
CAUTION. Makesurethatthemountingsurfaceisnot
warpedasanunevensurfacecancausebindingand
inaccuratesawing.
RELEASEKNOB
Thereleaseknob(4)isprovidedforholdingthecutting
headdownwhiletransportingorstoringthemitresaw.
Thesawmustneverbeusedwiththereleaseknob
lockingtheheaddown.
MITRETABLELOCKS
Themitretablelocks(20)areusedtolockthetableat
thedesiredmitreangle.
Themitresawcutsfrom0°to45°bothleftandright.To
adjustthemitreangleloosenthemitretablelocks(20)(21)
androtatethemitretabletothedesiredposition.
Themitretablefeaturespositiveclickstopsat0°,15°,
22.5°,30°and45°forquicksettingofcommonmitre
angles.
BEVELLOCK
Thebevellock(12)isusedtosetthebladeatthedesired
bevelangle.Themitresawbevelcutsfrom0°to45°to
theleft.Toadjustthebevelangleloosenthebevellock
andadjustthesawarmtothedesiredbevelangle.
SPINDLELOCKBUTTON
Thespindlelockbutton(22)preventsthebladeinthe
sawfromrotating.Depressandholdthespindlelock
buttonwhileinstalling,changing,orremovingtheblade.
ROTATINGLOWERBLADEGUARD
Therotatinglowerbladeguard(8)providesprotection
frombothsidesoftheblade.Itretractsovertheupper
bladeguard(6)asthesawisloweredintotheworkpiece.
TURNINGONANDOFF
1. Toturnthesawonpress switchlock(34)toleftand
depressandholdtheon/offtriggerswitch(19)
2. Toturnthesawoffreleasethe switchlock(34)and
on/offtriggerswitch(19).
DUSTEXTRACTION
1. Fitthedustbag(11)tothedustextractionport.
2. Avacuumdustextractiondevicecanbeconnectedto
thedustextractionport.Useasuitablevacuumadaptor
ifnecessary.Thedustextractionporthasaninternal
diameterof40mm.
SETTINGTHETABLESQUAREWITHTHEBLADE
1. Makesurethatthebatteryisremovedfromthepower
point.
2. Pushthesawarm(3)downtoitslowestpositionand
engagethereleaseknob(4)toholdthesawarminthe
transportposition.
3. Loosenthemitrelocks(20)andliftingupthemitre
latch(21).
4. Rotatethetable(16)untilthepointerispositionedat
0.
5. Releasemitrelatch(21)andtightenthemitrelocks
(20).
6. Loosenthebevellock(12)andsetthesawarm(3)at
0bevel(thebladeat90 tothemitretable).Tighten
thebevellock(12).
7. Placeasetsquareagainstthetable(16)andtheflat
partoftheblade.
8. Rotatethebladebyhandandchecktheblade-to-table

alignmentatseveralpoints.
9. Theedgeofthesetsquareandthesawbladeshould
beparallel.
10. Ifthesawbladeanglesawayfromthesetsquare,
adjustasfollows.
11. Usean10mmwrenchoradjustablewrenchto
loosenthelocknutsecuringthe0°beveladjustment
screw(29).Also,loosenthebevellock(12).
12. Adjustthe0°beveladjustmentscrew(29)usinga4
mmhexkeytobringthesawbladeintoalignmentwith
thesquare.
13. LoosenthePhillipsheadscrewholdingthepointerof
thebevelscale(13)andadjustthepositionofthepointer
sothatitaccuratelyindicateszeroonthescale.
Retightenthescrew.
14. Retightenthebevellock(12)andthelocknut
securingthe0°beveladjustmentscrew(29).
SETTINGTHEFENCESQUAREWITHTHETABLE
1. Makesurethatthebatteryisremovedfromthepower
point.
2. Pushthesawarm(3)downtoitslowestpositionand
engagethereleaseknob(4)toholdthesawarminthe
transportposition.
3. Loosenthemitrelocks(20)andliftingupthemitre
latch(21).
4. Rotatethetable(16)untilthepointerispositionedat
0.
5. Releasemitrelatch(21)andtightenthemitrelocks
(20).
6. Usinga5mmhexkey,loosenthetwoscrewssecuring
thefence(14)tothebase.
7. Placeasquareagainstthefence(14)andalongsidethe
blade.
8. Adjustthefence(14)untilitissquarewiththeblade.
9. Tightenthescrewssecuringthefence(14).
10. LoosenthePhillipsheadscrewholdingthepointerof
themitrescale(17)andadjustitsothatitaccurately
indicatesthezeropositiononthemitrescale.
11. Retightenthescrewsecuringthemitrescalepointer.
CHANGINGABLADE
1. Makesurethatthebatteryisremovedfromthepower
point.
2. Pushdownontheoperatinghandle(5)andpullthe
releaseknob(4)todisengagethesawarm(3).
3. Raisethesawarm(3)toitshighestposition.
4. Loosenthecoverplatescrewabout2turnswitha
Phillipsscrewdriver.Donotremovethisscrewfromthe
tool.
5. Pulltherotatingbladeguard(8)down.Whenthe
rotatingbladeguard(8)ispositionedovertheupper
fixedbladeguard(6)itispossibletoaccesstheblade
bolt.
6. Liftandholdupthelowerbladeguard(8)toexpose
thethreadedbladebolt.
7. Holdtherotatingguard(8)upandpressthespindle
lockbutton(22).Rotatethebladeuntilthespindlelocks.
8. Usethe6mmhexkeyprovidedtoloosenandremove
thebladebolt.(Looseninaclockwisedirectionasthe
bladescrewhasalefthandthread).
9. Removetheflatwasher,outerbladewasherandthe
blade.
10. Wipeadropofoilontotheinnerbladewasherand
theouterbladewasherwheretheycontacttheblade.
11. Fitthenewbladeontothespindletakingcarethat
theinnerbladewashersitsbehindtheblade.
12. Replacetheouterbladewasher.
13. Depressthespindlelockbutton(22)andreplacethe
flatwasherandbladebolt.
14. Usethe6mmhexkeytotightenthebladebolt
securely(tighteninananti-clockwisedirection).
15. Lowerthebladeguard,holdtherotatinglowerblade
guard(8)andbladeboltcover(10)inpositionand
tightenthefixingscrewtosecurethebladeboltcoverin
position.
16. Checkthatthebladeguardoperatescorrectlyand
coversthebladeasthesawarmislowered.
17. Connectthesawtothepowersupplyandrunthe
bladetomakecertainthatitisoperatingcorrectly.
CROSSCUT
Ifpossible,alwaysuseaclampingdevicesuchasa‘G"
clamptosecureyourworkpiece.
Whencuttingyourworkpiece,keepyourhandswell
awayfromthebladearea.
Donotremoveacut-offpieceontheright-handsideof
thebladeusingyourlefthand.
Acrosscutismadebycuttingacrossthegrainofthe
workpiece.A90 crosscutismadewiththemitretable
setat0 .Mitrecrosscutsaremadewiththetablesetat
someangleotherthanzero.
1. Pullonthereleaseknob(4)andliftthesawarm(3)to
itsfullheight.
2. Loosenthemitrelocks(20)andliftingupthemitre
latch(21).
3. Rotatethemitretable(16)untilthepointeralignswith
thedesiredangle.
4. Releasemitrelatch(21)andretightenthemitrelocks
(20).

5. Placetheworkpieceflatonthetablewithoneedge
securelyagainstthefence(14).Iftheboardiswarped,
placetheconvexsideagainstthefence(14).Ifthe
concavesideisplacedagainstthefence,theboardcould
breakandjamtheblade.
6. Whencuttinglongpiecesoftimber,supportthe
oppositeendofthetimberwithsidesupportbars,a
rollerstandoraworksurfacethatislevelwiththesaw
table.
7. Beforeturningonthesaw,performadryrunofthe
cuttingoperationtocheckthattherearenoproblems
suchasaclampinterferingwiththecuttingaction.
8. Holdtheoperatinghandle(5)firmlyandsqueezethe
releaselatch(30).Allowthebladetoreachmaximum
speedandslowlylowerthebladeintoandthroughthe
workpiece.
9.Releasetheswitchtrigger(19)andallowthesawblade
tostoprotatingbeforeraisingthebladeoutofthe
workpiece.Waituntilthebladestopsbeforeremoving
theworkpiece.
BEVELCUT
Ifpossible,alwaysuseaclampingdevicesuchasa‘G"
clamptosecureyourworkpiece.
Whencuttingyourworkpiece,keepyourhandswell
awayfromthebladearea.
Donotremoveacut-offpieceontheright-handsideof
thebladeusingyourlefthand.
Abevelcutismadebycuttingacrossthegrainofthe
workpiecewiththebladeangledtothefenceandmitre
table.Themitretableissetatthezerodegreeposition
andthebladesetatananglebetween0 and45 .
1. Pullonthereleaseknob(4)andliftthesawarmtoits
fullheight.
2. Loosenthemitrelocks(20)andliftingupthemitre
latch(21).
3. Rotatethemitretable(16)untilthepointeralignswith
zeroonthemitrescale(17).
4. Releasemitrelatch(21)andretightenthemitrelocks
(20).
5. Loosenthebevellock(12)andmovethesawarm(3)
tothelefttothedesiredbevelangle(between0 and
45 ).Tightenthebevellock(12).
6. Placetheworkpieceflatonthetablewithoneedge
securelyagainstthefence(14).Iftheboardiswarped,
placetheconvexsideagainstthefence.Iftheconcave
sideisplacedagainstthefence,theboardcouldbreak
andjamtheblade.
7. Whencuttinglongpiecesoftimber,supportthe
oppositeendofthetimberwithsidesupportbars,a
rollerstandoraworksurfacethatislevelwiththesaw
table.
8. Beforeturningonthesaw,performadryrunofthe
cuttingoperationtocheckthattherearenoproblems
suchasaclampinterferingwiththecuttingaction.
9. Holdtheoperatinghandle(5)firmlyandsqueezethe
releaselatch (30).Allowthebladetoreachmaximum
speedandslowlylowerthebladeintoandthroughthe
workpiece.
10. Releasetheswitchtrigger(19)andallowthesaw
bladetostoprotatingbeforeraisingthebladeoutofthe
workpiece.Waituntilthebladestopsbeforeremoving
theworkpiece.
ATTACHFENCE
1.Forcuttingsafetyalwaysusetwoattachfence.
2.Ifusebevelcut,dragouttheattachfence.The
attachfencedistancemovingpartsabout3-8mmat
anytimes.
COMPOUNDMITRECUT
Ifpossible,alwaysuseaclampingdevicesuchasa‘G"
clamptosecureyourworkpiece.
Whencuttingyourworkpiece,keepyourhandswell
awayfromthebladearea.
Donotremoveacut-offpieceontheright-handsideof
thebladeusingyourlefthand.
Acompoundmitrecutinvolvesusingamitreangleanda
bevelangleatthesametime.Itisusedinmakingpicture
frames,tocutmouldings,makingboxeswithsloping
sidesandforroofframing.Alwaysmakeatestcutona
pieceofscrapwoodbeforecuttingintothegood
material.
1. Pullonthereleaseknob(4)andliftthesawarmtoits
fullheight.
2. Loosenthemitrelocks(20)andliftingupthemitre
latch(21)..
3. Rotatethemitretable(16)untilthepointeralignswith
thedesiredangleonthemitrescale(17).
4. Releasemitrelatch(21)andretightenthemitrelocks
(20).
5. Loosenthebevellock(12)andmovethesawarm(3)
tothelefttothedesiredbevelangle(between0 and
45 ).Tightenthebevellock(12).
6. Placetheworkpieceflatonthetablewithoneedge
securelyagainstthefence(14).Iftheboardiswarped,
placetheconvexsideagainstthefence.Iftheconcave
sideisplacedagainstthefence,theboardcouldbreak
andjamtheblade.
7. Whencuttinglongpiecesoftimber,supportthe
oppositeendofthetimberwiththesidesupportbars,a

rollerstandoraworksurfacethatislevelwiththesaw
table.
8. Beforeturningonthesaw,performadryrunofthe
cuttingoperationtocheckthattherearenoproblems
suchasaclampinterferingwiththecuttingaction.
9. Holdtheoperatinghandle(5)andfirmlyandsqueeze
the releaselatch (30).Allowthebladetoreach
maximumspeedandslowlylowerthebladeintoand
throughtheworkpiece.
10. Releasetheswitchtrigger(19)andallowthesaw
bladetostoprotatingbeforeraisingthebladeoutofthe
workpiece.Waituntilthebladestopsbeforeremoving
theworkpiece.
ToSlideCutWideBoards
Toslidecutwideboards, Unlocktheslidelockknob(24)
andallowthecuttingheadassemblytomovefreely.
SETTINGCUTTINGDEPTH
Thedepthofcutcanbepresetforevenandrepetitive
shallowcuts.
1. Slidethestopplate (24) towardsthefrontposition.
2. Loosenthelocknut (25) tofreethelockknob (23),
turnthestopknobuntilthecuttingheaddownuntilthe
teethofthebladeareatthedesireddepth.
3. Whileholdingtheupperarminthatposition,tighten
thelocknuttosecuredthestopknob.
4. Recheckthebladedepthbymovingthecuttinghead
fronttobackthroughthefullmotionoftypicalcut
alongthecontrolarm.
TO REMOVE OR INSTAL BATTERY
PACK
WARNING: Neveroutletthebatterypackwhile
thetoolisworking.
Depressthebatterypacklockbuttontorelease
andslidethebatterypackoutfromyourtool.
Afterrecharge,slideitbackintoyourtool.A
simplepushandslightpressurewillbe
sufficient.
CHARGINGTHEBATTERYPACK
1.Thebatterychargesuppliedismatchedtothe
batteryinstalledinthemachine.Donotuse
anotherbatterycharger.
2.Thebatterypackisprotectedagainstdeep
discharging.Whenthebatterypackisempty,the
machineisswitchedoffbymeansofa
protectivecircuit.
3.Connectthechargertothepowersupplyandthe
poweronLEDindicatorlightswillshowing.Slide
thebatterypackintothechargertomakethe
connections.
BATTERYPOWERCHECK
Beforeworking,pressthe ON buttonwhichisat
batterysurface,itwillactivebatteryand
showingbatterypowerseveralseconds.
MAINTENANCE
1. Storethetool,instructionmanualandaccessoriesina
secureplace.Inthiswayyouwillalwayshaveallthe
informationandpartsonhand.
2. Keepthetool’sairventsuncloggedandcleanatall
times.
3. Removedustanddirtregularly.Cleaningisbestdone
withcompressedairorarag.
4. Neverusecausticagentstocleanplasticparts.
GENERALINSPECTION
1. Regularlycheckthatallthefixingscrewsaretight.
Theymayvibratelooseovertime.
SERVICE
Toolservicemustbeperformedonlybyqualified
repairpersonnel.Serviceormaintenanceperformedby
unqualifiedpersonnelcouldresultinariskofinjury.
Whenservicingatool,useonlyidenticalreplacement
parts.FollowinstructionsintheMaintenancesectionof
thismanual.Useofunauthorizedpartsorfailureto
followMaintenanceInstructionsmaycreateariskof
electricshockorinjury.
