Grizzly G0566 User manual

-52- G0566/G0568/G0669 Industrial Bandsaw
93
121
124
126
128
125
129
130
127
58
136
57
59
57
75
240
76
74
136
131
123
132134A
134A
111
133
143
144
145
142A
140
137
139
138
30
288
146
100
99
102
103
104
105
106
101
31
122
107
108
109
110
113
120
119
115
116
117
114
118
98A
112
97
205
152
96
95
96
94
14
15
60
52 53 85
65
68
66
67
73
70
72 71
150
56
54 63
6261
64
228
88
81
82
69
77
78
79
80
153
154
87
85
84
83
86
32
27
39
35 38
37
36
28
29
151
289
290A
34
148
149
33
40 42
41
44
45
43
25
26
19
20
23
24
17 21
16
18
11
12
13
22
10
46
292
291A
51
49
48
50
47
7
8
5
6
4
9
92
90
89
91
2
3
1
23-2
23-1 23-3
23-4
23-7
23-5
23-6
G0566 Parts Breakdown

G0566/G0568/G0569 Industrial Bandsaw -53-
169
165
167
166
168
162
164
163
180
155
158
160
159
161
156
147
157
171
170
172
176
175
174
173
178
177
179
182
184
183
181
G0566 Parts Breakdown

-54- G0566/G0568/G0669 Industrial Bandsaw
230
217
187
189
287
190
188
191
246
209
213
211A
210
212
244
243
216
214
215
206
208
207
245
237
239 238
242 241
231
233
232
203
192
195
185
186
193
194
196
199
202
200
201
197
198
223
221
219
218
220
204
222
226
225
224
141
227
235
234
236
229
G0566 Parts Breakdown

G0566/G0568/G0569 Industrial Bandsaw -55-
253A
254
255
257
256A
258
251
252
249
250
247
248
55
293
294
301
296
298
299
297
300
295
276275
273
279A 274
261
262A
263A273 274
264A
277275 276 265
267A
260A
261 266
280
262A
264A
263A
260A
261
277 261
259A
G0566 Parts Breakdown

-56- G0566/G0568/G0669 Industrial Bandsaw
G0566 Parts List
REF PART # DESCRIPTIONREF PART # DESCRIPTION
33 PSB31M CAP SCREW M8-1.25 X 25
34 PSB06M CAP SCREW M6-1 X 25
35 PLW03M LOCK WASHER 6MM
36 P0566036 BRAKE PAD
37 P0566037 BUSHING
38 P0566038 BRAKE LEVER
39 PSB01M CAP SCREW M6-1 X 16
40 PSB01M CAP SCREW M6-1 X 16
41 PLW03M LOCK WASHER 6MM
42 P0566042 BRAKE STEP PLATE
43 P0566043 SPRING
44 PN01M HEX NUT M6-1
45 PSB01M CAP SCREW M6-1 X 16
46 PHTEK4M TAP SCREW M4 X 8
47 P0566047 CORD CLAMP 5/8”
48 P0566048 STEP CORD
49 PB41M HEX BOLT M4-.7 X 30
50 P0566050 LIMIT SWITCH KL7141
51 PN04M HEX NUT M4-.7
52 P0566052 UPPER WHEEL COVER
53 PN04M HEX NUT M4-.7
54 PW05M FLAT WASHER 4MM
55 PLN03M LOCK NUT M6-1
56 PS38M PHLP HD SCR M4-.7 X 10
57 PSB04M CAP SCREW M6-1 X 10
58 P0566058 LOWER WHEEL COVER
59 P0566059 SAW BLADE 4190X25.4X0.9mm
60 P0566060 UPPER WHEEL SLIDING BRACKET
61 P0566061 SPRING
62 PRP61M PIN 3 X 12
63 P0566063 MOVING PLATE
64 PHTEK15M TAP SCREW M4 X 10
65 P0566065 FIX PLATE
66 P0566066 TENSION POINTER
67 PHTEK6M TAP SCREW M4 X 16
68 P0566068 TENSION SCALE
69 P0566069 CONNECTING CORD
70 P0566070 SWITCH CORD
71 P0566071 SWITCH PLATE
1 P0566001 HANDLE KNOB M16-1.5
2 P0566002 HANDLE SHAFT
3 PN05M NUT M16-1.5
4 P0566004 ECCENTRIC SHAFT
5 PSBS03M BUTTON HD CAP SCR M10-1.5 X 20
6 PLW06M LOCK WASHER 10MM
7 P0566007 KNOB SCREW M10-1.5 X 25
8 P0566008 LOCK HANDLE M10-1.5
9 P0566009 KNOB SCREW M10-1.5 X 25
10 P0566010 TRANSLUCENT PIECE
11 P0566011 RIVET 3.2 X 10
12 P0566012 LATCHING KNOB 6MM
13 PSB02M CAP SCREW M6-1 X 20
14 PB73M HEX BOLT M10-1.5 X 50
15 PN02M HEX NUT M10-1.5
16 P0566016 HEIGHT POINTER
17 PFS07M FLANGE SCREW M5-.8 X 10
18 PHTEK4M TAP SCREW M4 X 8
19 P0566019 STRAIN RELIEF M20
20 P0566020 PLATE
21 PHTEK4M TAP SCREW M4 X 8
22 P0566022 CORD CLAMP 1/2”
23 P0566023 MOTOR 3HP 220V 1PHASE
23-1 P0566023-1 FAN COVER
23-2 P0566023-2 FAN
23-3 P0566023-3 CAPACITOR COVER
23-4 P0566023-4 START CAPACITOR 250MFD/250V
23-5 P0566023-5 CAPACITOR COVER
23-6 PC20A CAPACITOR 20MFD/400V
23-7 P0566023-7 WIRING BOX
24 PSBS01M BUTTON HD CAP SCR M8-1.25 X 20
25 P0566025 COVER
26 PB01M HEX BOLT M10-1.5 X 30
27 PN02M HEX NUT M10-1.5
28 PSB02M CAP SCREW M6-1 X 20
29 P0566029 LATCHING KNOB 6MM
30 PW01M FLAT WASHER 8MM
31 PSB31M CAP SCREW M8-1.25 X 25
32 P0566032 BUSHING

G0566/G0568/G0569 Industrial Bandsaw -57-
G0566 Parts List
REF PART # DESCRIPTIONREF PART # DESCRIPTION
110 P0566110 HANDWHEEL
111 PSB06M CAP SCREW M6-1 X 25
112 P0566112 SQUARE SHAFT
113 PW01M FLAT WASHER 8MM
114 PSB14M CAP SCREW M8-1 X 20
115 P0566115 UPPER WHEEL HINGE ASSY
116 PSS75M SET SCREW M10-1.5 X 16
117 P0566117 GUIDE BLOCK
118 P0566118 UPPER WHEEL SHAFT
119 P6205 BALL BEARING 6205LLU
120 PR26M INT RETAINING RING 52MM
121 P0566121 BUSHING
122 P0566122 UPPER WHEEL Ø21”
123 PW01M FLAT WASHER 8MM
124 PLW04M LOCK WASHER 8MM
125 PSB14M CAP SCREW M8-1 X 20
126 PSB14M CAP SCREW M8-1 X 20
127 PLW04M LOCK WASHER 8MM
128 PW01M FLAT WASHER 8MM
129 P6205 BALL BEARING 6205LLU
130 P0566130 LOWER WHEEL Ø21”
131 P0566131 BUSHING
132 PR26M INT RETAINING RING 52MM
133 P0566133 PULLEY
134A PSS04M SET SCREW M6-1 X 12
136 P0566136 TIRE
137 PSB14M CAP SCREW M8-1.25 X 20
138 P0566138 PULLEY
139 P0566139 LOWER SHAFT
140 PSBS01M BUTTN HD CAP SCR M8-1.25 X 20
141 PW03M FLAT WASHER 6MM
142A PVA30 V-BELT A-30 4L300
143 P0566143 BRUSH
144 PLN03M LOCK NUT M6-1
145 PW03M FLAT WASHER 6MM
146 PSB02M CAP SCREW M6-1 X 20
147 P0566147 NYLON PIECE
148 PW01M FLAT WASHER 8MM
72 PHTEK15M TAP SCREW M4 X 10
73 P0566073 KEY SWITCH Ø22
74 P0566074 STOP SWITCH Ø22
75 P0566075 START SWITCH Ø22
76 P0566076 CONNECTING CORD
77 PFS09M FLANGE SCREW M5-.8 X 50
78 P0566078 TERMINAL BOX
79 P0566079 TERMINAL HOUSE
80 P0566080 POWER CORD
81 P0566081 STRAIN RELIEF M20
82 P0566082 MAGNETIC SWITCH MPE-18 22A
83 PN04M HEX NUT M4-.7
84 PW05M FLAT WASHER 4MM
85 P0566085 DOOR LATCH SWITCH ADZ-S11
86 PFS10M FLANGE SCREW M4-.7 X 35
87 P0566087 MACHINE BODY
88 PFS07M FLANGE SCREW M5-.8 X 10
89 P0566089 SWITCH CORD
90 P0566090 HOUSING PLATE
91 PSB31M CAP SCREW M8-1.25 X 25
92 P0566092 CAM
93 P0566093 MOTOR CORD
94 PLN03M LOCK NUT M6-1
95 PN02M HEX NUT M10-1.5
96 PW04M FLAT WASHER 10MM
97 P0566097 ADJUST BOLT
98A PSB60M CAP SCREW M8-1.25 X 55
99 PN03M HEX NUT M8-1.25
100 P0566100 LOCATE PLATE
101 PFH39M FLAT HD SCR M5-.8 X 16
102 P0566102 SPRING
103 P0566103 BUSHING
104 P0566104 PRESS BLOCK
105 PSS07M SET SCREW M5-.8 X 5
106 P0566106 BEARING 51201
107 PSS07M SET SCREW M5-.8 X 5
108 P0566108 TENSION LINE
109 P0566109 SHAFT

-58- G0566/G0568/G0669 Industrial Bandsaw
G0566 Parts List
REF PART # DESCRIPTIONREF PART # DESCRIPTION
184-4 P0566184-4 LOCATE SHAFT
184-5 P0566184-5 POINTER
184-6 P0566184-6 STEP SCREW
184-7 P0566184-7 HANDLE
184-8 P0566184-8 MITER GAUGE BODY
184-9 PFH9M FLAT HEAD SCR M6-1 X 6
184-10 PS06 PHLP HD SCR 10-24 X 3/8
184-11 PS56M PHLP HD SCR M4-.7 X 16
184-12 PN04M HEX NUT M4-.7
184-13 PW01M FLAT WASHER 8MM
185 PN06M HEX NUT M5-.8
186 PFS07M FLANGE SCREW M5-.8 X 10
187 P0566187 COVER
188 PLW04M LOCK WASHER 8MM
189 PSB11M CAP SCREW M8-1.25 X 16
190 PFH19M FLAT HD SCR M4-.7 X 10
191 P0566191 EXTENSION RACK
192 P0566192 COVER
193 P0566193 FIXED BOLT
194 P0566194 PINION GEAR
195 P0566195 FIXED PLATE
196 P0566196 WORM CYLINDER
197 PN05M HEX NUT M16-1.5
198 P0566198 GUIDE BRACKET
199 PW01M FLAT WASHER 8MM
200 PSBS04M BUTTON HD CAP SCR M8-1.25 X 35
201 P0566201 BUSHING
202 P0566202 SWITCH BUSHING
203 PSB06M CAP SCREW M6-1 X 25
204 P0566204 HANDWHEEL
205 PW01M FLAT WASHER 8MM
206 P0566206 UPPER GUIDE BAR
207 P0566207 RACK
208 PSB01M CAP SCREW M6-1 X 16
209 PN04M HEX NUT M4-.7
210 PS38M PHLP HD SCR M4-.7 X 10
211A P0566211A UPPER GUIDE SUPPORT BLOCK
212 PB83M HEX BOLT M6-1 X 16
213 P0566213 GUIDE BRACKET
149 PLW04M LOCK WASHER 8MM
150 PW05M FLAT WASHER 4MM
151 PLN03M LOCK NUT M6-1
152 PN03M HEX NUT M8-1.25
153 P0566153 CORD CLAMP 5/16”
154 PHTEK15M TAP SCREW M4 X 10
155 P0566155 FENCE
156 P0566156 KNOB SCREW M10-1.5 X 25
157 P0566157 POINTER
158 PFS01M FLANGE SCREW M5-.8 X 8
159 PW01M FLAT WASHER 8MM
160 PLW04M LOCK WASHER 8MM
161 PB09M HEX BOLT M8-1.25 X 20
162 PSB72M CAP SCREW M10-1.5 X 30
163 PLW06M LOCK WASHER 10MM
164 PW04M FLAT WASHER 10MM
165 P0566165 TRUNNION HOUSING
166 P0566166 BLADE GUARD
167 PFS11M FLANGE SCREW M6 X 10
168 P0566168 PRESS SHAFT
169 P0566169 MICRO ADJUSTING RING
170 PSB14M CAP SCREW M8-1.25 X 20
171 PLW04M LOCK WASHER 8MM
172 P0566172 HANDLE SHAFT
173 P0566173 HANDLE KNOB M12-1.75 (FEMALE)
174 PSB84M CAP SCREW M10-1.5 X 35
175 PLW06M LOCK WASHER 10MM
176 PW04M FLAT WASHER 10MM
177 P0566177 TRUNNION BLOCK
178 P0566178 PRESS BLOCK
179 PS38M PHLP HD SCR M4-.7 X 10
180 P0566180 POINTER
181 P0566181 GUARD RAIL
182 P0566182 TABLE
183 P0566183 TABLE INSERT
184 P0566184 MITER GAUGE ASSY
184-1 P0566184-1 GUIDE
184-2 P0566184-2 GUIDE BAR
184-3 P0566184-3 LOCATE BRACKET

G0566/G0568/G0569 Industrial Bandsaw -59-
G0566 Parts List
REF PART # DESCRIPTIONREF PART # DESCRIPTION
253A P0566253A PROTECT COVER ASSY
254 PW03M FLAT WASHER 6MM
255 PSB04M CAP SCREW M6-.1 X 10
256A P0566256A SLIDING PLATE
257 P0566257 PLASTIC WASHER 6MM
258 PFS11M FLANGE SCREW M6-1 X 10
259A P0566259A ADJUST BAR
260A P0566260A BLADE GUIDE SUPPORT
261 PB83M HEX BOLT M6-1 X 16
262A P0566262A UPPER SPACING SLEEVE
263A P6201 BALL BEARING 6201ZZ
264A PR03M EXT RETAINING RING 12MM
265 PSB01M CAP SCREW M6-1 X 16
266 PW03M FLAT WASHER 6MM
267A P0566267A ADJUSTING SHAFT
273 PB47M HEX BOLT M6-1 X 40
274 P0566274 HANDLE BUSHING
275 P6202 BALL BEARING 6202ZZ
276 PR05M EXT RETAINING RING 15MM
277A P0566277A ECCENTRIC SHAFT
279A P0566279A SUPPORT BRACKET
280 PB83M HEX BOLT M6-1 X 16
287 PSS07M SET SCREW M5-.8 X 5
288 PSB04M CAP SCREW M6-1 X 10
289 PW03M FLAT WASHER 6MM
290A P0566290A SUPPORT
291A P0566291A PROTECT TUBE 1/2”X1100mm(L)
292 P0566292 CORD BUSHING
293 P0566293 MACHINE ID LABEL
294 PLABEL-20 DON’T OPEN LABEL
295 PLABEL-19 HANDS/BS BLADE 2”X3 5/16”H.
296 PLABEL-18 UNPLUG BANDSAW LABEL
297 PLABEL-14 ELECTRICITY LABEL
298 PLABEL-12 READ MANUAL 2”W X 3 5/16”
299 PLABEL-11 SAFETY GLASSES 2” X 3 5/16”
300 P0566300 TENSION LEVER LABEL
301 P0566301 TABLE LOCK LABEL
214 PSB14M CAP SCREW M8-1.25 X 20
215 PLW04M LOCK WASHER 8MM
216 P0566216 SUPPORT PLATE
217 PW01M FLAT WASHER 8MM
218 PSBS01M BUTTON HD CAP SCR M8-1.25 X 20
219 PSB04M CAP SCREW M6-1 X 10
220 PLN04M LOCK NUT M8-1.25
221 PW01M FLAT WASHER 8MM
222 P0566222 SLIDING PLATE
223 PB30M HEX BOLT M8-1.25 X 55
224 PLW03M LOCK WASHER 6MM
225 P0566225 WORM CYLINDER
226 PN05M HEX NUT M16-1.5
227 P0566227 HANDWHEEL
228 PS52M PHLP HD SCR M4-.7 X 20
229 PSB06M CAP SCREW M6-1 X 25
230 P0566230 BUSHING
231 P0566231 SWITCH BUSHING
232 PSS07M SET SCREW M5-.8 X 5
233 PN06M HEX NUT M5-.8
234 PLW04M LOCK WASHER 8MM
235 PSB11M CAP SCREW M8-1.25 X 16
236 PFS07M FLANGE SCREW M5-.8 X 10
237 P0566237 COVER
238 P0566238 COVER
239 P0566239 SPECIAL BOLT
240 P0566240 CORD CONNECTOR 224-201
241 PFH19M FLAT HD SCR M4-.7 X 10
242 P0566242 RACK
243 P0566243 SQUARE TUBE
244 PFS05M FLANGE SCREW M4-.7 X 10
245 PN04M HEX NUT M4-.7
246 P0566246 PINION GEAR
247 PSB04M CAP SCREW M6-1 X 10
248 PLW03M LOCK WASHER 6MM
249 PW03M FLAT WASHER 6MM
250 P0566250 SUPPORT PLATE
251 PW03M FLAT WASHER 6MM
252 PSB04M CAP SCREW M6-1 X 10
