Johnson Controls Unitary Products DHQ024 User manual

R-410A
DHQ024-060
2-5 Ton
ISO 9001
Certified Quality
Management System
1101790-UIM-C-0414
TABLE OF CONTENTS
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Rigging And Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Ductwork. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Roof Curb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Condensate Drain. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Service Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Thermostat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Power And Control Wiring. . . . . . . . . . . . . . . . . . . . . . . . . 10
Compressors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Gas Heat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Flue Vent Hood. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Airflow Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Bottom Duct Application . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Side Duct Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Blower Speed Selection . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Sequence Of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Start-Up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Adjustment of Temperature Rise . . . . . . . . . . . . . . . . . . . 30
Checking Gas Heat Input . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Natural Gas. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Typical Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Start-Up Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
LIST OF TABLES
1 Unit Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Weights and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Unit Accessory Weights . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4 Unit Dimensions Front. . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5 Unit Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6 Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7 DHQ024-060 Two Stage Gas Heat . . . . . . . . . . . . . . . . 12
8 Natural Gas Pipe Sizing Chart . . . . . . . . . . . . . . . . . . . . 14
9 Propane (LP) Gas Pipe Sizing Chart . . . . . . . . . . . . . . . 14
10 Natural Gas Application Data-Two Stage . . . . . . . . . . . . 15
11 Propane (LP) Gas Application Data-Two Stage . . . . . . . 15
12 DHQ024-060 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
13 DHQ024-060 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
14 Additional Static Resistance . . . . . . . . . . . . . . . . . . . . . . 22
15 Indoor Blower Specifications. . . . . . . . . . . . . . . . . . . . . . 23
16 Delay Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
17 Dual Fuel Package Unit Operating Chart . . . . . . . . . . . . 27
18 Ignition Control Board Flash Codes . . . . . . . . . . . . . . . . 28
19 Gas Rate Cubic Feet Per Hour. . . . . . . . . . . . . . . . . . . . 31
20 DHQ24 Charging Table . . . . . . . . . . . . . . . . . . . . . . . . . 34
21 DHQ030 Charging Table . . . . . . . . . . . . . . . . . . . . . . . . 34
22 DHQ036 Charging Table . . . . . . . . . . . . . . . . . . . . . . . . 35
23 DHQ42 Charging Table . . . . . . . . . . . . . . . . . . . . . . . . . 35
24 DHQ48 Charging Table . . . . . . . . . . . . . . . . . . . . . . . . . 36
25 DHQ060 Charging Table . . . . . . . . . . . . . . . . . . . . . . . . 36
LIST OF FIGURES
1 Component Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Unit 4 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Unit Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4 Dimensions Front and Bottom . . . . . . . . . . . . . . . . . . . . . 8
5 Dimensions Back and Bottom . . . . . . . . . . . . . . . . . . . . . 8
6 Roof Curb. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7 Typical Field Control Wiring Diagram For Dual Fuel Heat
Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
8 Typical Field Power Wiring Diagram . . . . . . . . . . . . . . . 11
9 External Supply Connection External Shut-Off . . . . . . . 13
10 Flue Vent Outlet Air Hood . . . . . . . . . . . . . . . . . . . . . . . 14
11 Control Board Speed Tap Location . . . . . . . . . . . . . . . . 23
12 Two Stage Gas Valve Front. . . . . . . . . . . . . . . . . . . . . . 30
13 Two Stage Gas Valve Rear . . . . . . . . . . . . . . . . . . . . . . 30
14 Proper Flame Adjustment . . . . . . . . . . . . . . . . . . . . . . . 30
15 R-410A Quick Reference Guide . . . . . . . . . . . . . . . . . . 39
General
Unitary Products Model DHQ units are dual fuel heat pump
units designed for outdoor installation. Only gas piping, electric
power and duct connections are required at the point of
installation.
The two stage gas-fired heaters have spark to pilot ignition. The
tubular heat exchangers are aluminized steel.
The refrigerant system is fully charged with R-410A Refrigerant,
and is tested and factory sealed.
Safety Considerations
This is a safety alert symbol . When you see this symbol on
labels or in manuals, be alert to the potential for personal injury.
Understand and pay particular attention the signal words
DANGER, WARNING or CAUTION.
DANGER indicates an imminently hazardous situation, which,
if not avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation, which,
if not avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation, which, if
not avoided may result in minor or moderate injury.It is also
used to alert against unsafe practices and hazards involving
only property damage.

1101790-UIM-C-0414
2Johnson Controls Unitary Products
Due to system pressure, moving parts, and electrical
components, installation and servicing of air conditioning
equipment can be hazardous. Only qualified, trained service
personnel should install, repair, or service this equipment.
Untrained personnel can perform basic maintenance functions
of cleaning coils and filters and replacing filters.
Observe all precautions in the literature, labels, and tags
accompanying the equipment whenever working on air
conditioning equipment. Be sure to follow all other applicable
safety precautions and codes including ANSI Z223.1 or CSA-
B149.1- latest edition.
Wear safety glasses and work gloves. Use quenching cloth and
have a fire extinguisher available during brazing operations.
Inspection
As soon as a unit is received, it should be inspected for possible
damage during transit. If damage is evident, the extent of the
damage should be noted on the carrier’s freight bill. A separate
request for inspection by the carrier’s agent should be made in
writing.
Renewal Parts
Contact your local Unitary Products parts distribution center for
authorized replacement parts.
Improper installation may create a condition where the
operation of the product could cause personal injury or
property damage. Improper installation, adjustment,
alteration, service or maintenance can cause injury or
property damage. Refer to this manual for assistance or
for additional information, consult a qualified contractor,
installer or service agency.
This product must be installed in strict compliance with
the installation instructions and any applicable local,
state and national codes including, but not limited to
building, electrical, and mechanical codes.
Before performing service or maintenance operations on
unit, turn off main power switch to unit. Electrical shock
could cause personal injury. Improper installation,
adjustment, alteration, service or maintenance can
cause injury or property damage. Refer to this manual.
For assistance or additional information consult a
qualified installer, service agency or the gas supplier.
This system uses R-410A Refrigerant which operates at
higher pressures than R-22. No other refrigerant may be
used in this system. Gage sets, hoses, refrigerant
containers and recovery systems must be designed to
handle R-410A. If you are unsure, consult the equipment
manufacturer. Failure to use R-410A compatible servicing
equipment may result in property damage or injury.
If the information in this manual is not followed exactly, a
fire or explosion may result causing property damage,
personal injury or loss of life.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
a. Do not try to light any appliance.
b. Do not touch any electrical switch; do not use any
phone in your building.
c. Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
d. If you cannot reach your gas supplier, call the fire
department.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
Lo-NOx furnaces requiring propane (LP) gas must have
the NOx screens removed prior to operation. Failure to
do so may result in operational problems and/or reduced
heat exchanger life. Follow the instructions below for
removal of the NOx screens.
This product must be installed in strict compliance with
the enclosed installation instructions and any applicable
local, state and national codes including, but not limited
to, building, electrical, and mechanical codes.
The furnace and its individual shut-off valve must be
disconnected from the gas supply piping system during
any pressure testing at pressures in excess of 1/2 PSIG.
Pressures greater than 1/2 PSIG will cause gas valve
damage resulting in a hazardous condition. If it is
subjected to a pressure greater than 1/2 PSIG, the gas
valve must be replaced.
The furnace must be isolated from the gas supply piping
system by closing its individual manual shut-off valve
during any pressure testing of the gas supply piping
system at test pressures equal to or less than 1/2 PSIG

1101790-UIM-C-0414
Johnson Controls Unitary Products 3
Approvals
Design certified by CSA as follows:
1. For use as a cooling only unit, cooling unit with
supplemental electric heat or a forced air furnace.
2. For outdoor installation only.
3. For installation on combustible material and may be
installed directly on combustible flooring or, in the U.S., on
wood flooring or Class A, Class B or Class C roof covering
materials.
4. For use with natural gas (convertible to LP with kit).
Nomenclature
Installation
Installation Safety Information
Read these instructions before continuing this appliance
installation. This is an outdoor combination heating and cooling
unit. The installer must assure that these instructions are made
available to the consumer and with instructions to retain them
for future reference.
1. Refer to the unit rating plate for the approved type of gas
for this product.
2. Install this unit only in a location and position as specified
on Page 5 of these instructions.
3. Never test for gas leaks with an open flame. Use
commercially available soap solution made specifically for
the detection of leaks when checking all connections, as
specified on Pages 3 and 14 of these instructions.
4. Always install furnace to operate within the furnace's
intended temperature-rise range with the duct system and
within the allowable external static pressure range, as
specified on the unit name/rating plate, specified on
Page 17 of these instructions.
5. This equipment is not to be used for temporary heating of
buildings or structures under construction.
Limitations
These units must be installed in accordance with the following:
In U.S.A.:
1. National Electrical Code, ANSI/NFPA No. 70 - Latest Edition
2. National Fuel Gas Code, ANSI Z223.1 - Latest Edition
This product must be installed in strict compliance with
the enclosed installation instructions and any applicable
local, state, and national codes including, but not limited
to, building, electrical, and mechanical codes.
Improper installation may create a condition where the
operation of the product could cause personal injury or
property damage.
This system uses R-410A Refrigerant which operates at
higher pressures than R-22. No other refrigerant may be
used in this system.
D 7 036 056 06
D
HQ
Product Category
D = Single Package Air Conditioner
Product Generation
7 = 7th Generation
Factory Installed Gas Heat
D = Two Stage (Single Phase Only)
Product Identifier
HQ = R-410A 14 SEER, 11 EER
Dual Fuel Heat Pump
Voltage Code
06 = 208/230-1-60
024 = 24,000 BTUH
030 = 30,000 BTUH
036 = 36,000 BTUH
042 = 42,000 BTUH
048 = 48,000 BTUH
060 = 60,000 BTUH
Nominal Cooling Capacity (MBH)
Nominal Gas Heating Output Capacity
(Nominal Low Gas Heat Output Capacity)
056 = 56,000 BTUH (36,400 BTUH)
072 = 72,000 BTUH (46,800 BTUH)
090 = 90,000 BTUH (56,160 BTUH)
110 = 110,000 BTUH (70,200 BTUH)
NX
Additional Option
NX = Low Nox
FIRE OR EXPLOSION HAZARD
Failure to follow the safety warning exactly could result
in serious injury, death or property damage.
Never test for gas leaks with an open flame. use a
commercially available soap solution made specifically
for the detection of leaks to check all connections. A fire
or explosion may result causing property damage,
personal injury or loss of life.

1101790-UIM-C-0414
4Johnson Controls Unitary Products
3. Gas-Fired Central Furnace Standard, ANSI Z21.47a. -
Latest Edition
4. Local building codes, and
5. Local gas utility requirements
In Canada:
1. Canadian Electrical Code, CSA C22.1
2. Installation Codes, CSA - B149.1.
3. Local plumbing and waste water codes, and
4. Other applicable local codes.
Refer to unit application data found in this document.
After installation, gas fired units must be adjusted to obtain a
temperature rise within the range specified on the unit rating plate.
If components are to be added to a unit to meet local codes,
they are to be installed at the dealer’s and/or customer’s
expense.
Size of unit for proposed installation should be based on heat
loss/heat gain calculation made according to the methods of Air
Conditioning Contractors of America (ACCA).
This furnace is not to be used for temporary heating of buildings
or structures under construction.
Figure 1: Component Location
Direct Drive
Condenser Fan Motor
Highly Efficient Enhanced Copper
Tube/Aluminum Fin Evaporator Coil
Highly Efficient Enhanced Copper Tube/Enhanced Aluminum Fin
Decorative Protective Coil Guard
High Efficiency
Compressor Rigidly
Mounted
Pilot Assembly
High Grade Aluminized In-Shot Burners
Low Voltage Terminal Block
Spark Ignition Control
Automatic Gas Valve
(1/2" - NPTF)
Power Draft Motor
Direct Drive Blower Motor With
Slide-Out Blower Assembly
Heavy Gauge
Removable Base Rails
Rear and Bottom Return Air
and Supply Airduct Openings
Matted Textured
Finish
Blow-Through Design With
Reliable Aluminized Steel
Tubular Heat Exchangers
CFM Selector Board
York Guard Defrost Control
Table 1: Unit Limitations
Model
(Tons) Unit Voltage Unit Limitations
Applied Voltage Outdoor DB Temp
Min Max Max (°F)
DHQ024
(2.0) 208/230-1-60 187 252 125
DHQ030
(2.5) 208/230-1-60 187 252 125
DHQ036
(3.0) 208/230-1-60 187 252 125
DHQ042
(3.5) 208/230-1-60 187 252 125
DHQ048
(4.0) 208/230-1-60 187 252 125

1101790-UIM-C-0414
Johnson Controls Unitary Products 5
Location
Use the following guidelines to select a suitable location for
these units:
1. Unit is designed for outdoor installation only.
2. Condenser coils must have an unlimited supply of air.
Where a choice of location is possible, position the unit on
either north or east side of building.
3. Suitable for mounting on roof curb.
4. For ground level installation, a level pad or slab should be
used. The thickness and size of the pad or slab used
should meet local codes and unit weight. Do not tie the
slab to the building foundation.
5. Roof structures must be able to support the weight of the
unit and its options/accessories. Unit must be installed on a
solid, level roof curb or appropriate angle iron frame.
6. Maintain level tolerance to 1/8” across the entire width and
length of unit.
Clearances
All units require particular clearances for proper operation and
service. Installer must make provisions for adequate
combustion and ventilation air in accordance with section 5.3 of
Air for Combustion and Ventilation of the National Fuel Gas
Code, ANSI Z223.1 – Latest Edition (in U.S.A.), or Sections 7.2,
7.3, or 7.4 of Gas Installation Codes, CSA-B149.1 (in Canada) -
Latest Edition, and/or applicable provisions of the local building
codes. Refer to Table 5 for clearances required for combustible
construction, servicing, and proper unit operation.
Rigging And Handling
Exercise care when moving the unit. Do not remove any
packaging until the unit is near the place of installation. Rig the
unit by attaching chain or cable slings to the lifting holes
provided in the base rails. Spreader bars, whose length
exceeds the largest dimension across the unit, MUST be used
across the top of the unit.
Units may be moved or lifted with a forklift. Slotted openings in
the base rails are provided for this purpose.
DEQ060
(5.0) 208/230-1-60 187 252 125
Table 1: Unit Limitations
Model
(Tons) Unit Voltage Unit Limitations
Applied Voltage Outdoor DB Temp
Min Max Max (°F)
Excessive exposure of this furnace to contaminated
combustion air may result in equipment damage or
personal injury. Typical contaminates include:
permanent wave solution, chlorinated waxes and
cleaners, chlorine based swimming pool chemicals,
water softening chemicals, carbon tetrachloride,
Halogen type refrigerants, cleaning solvents (e.g.
perchloroethylene), printing inks, paint removers,
varnishes, hydrochloric acid, cements and glues,
antistatic fabric softeners for clothes dryers, masonry
acid washing materials.
Do not permit overhanging structures or shrubs to
obstruct condenser air discharge outlet, combustion air
inlet or vent outlets.
If a unit is to be installed on a roof curb other than a
Unitary Products roof curb, gasketing must be applied to
all surfaces that come in contact with the unit underside.
Before lifting, make sure the unit weight is distributed
equally on the rigging cables so it will lift evenly.
All panels must be secured in place when the unit is
lifted.
The condenser coils should be protected from rigging
cable damage with plywood or other suitable material.

1101790-UIM-C-0414
6Johnson Controls Unitary Products
Figure 2: Unit 4 Point Load Weight
X
CENTER OF
GRAVITY
49-1/8
FRONT
OF
UNIT
Y47-1/4
"D"
"C"
"B"
"A"
Table 2: Weights and Dimensions
Model
(Tons) Weight (lbs.) Center of Gravity 4 Point Load Location (lbs.) 6 Point Load Location (lbs.)
ShippingOperatingX YABCDABCDEF
DHQ024
(2.0) 418 413 25 20.1 81 88 128 116 53 56 60 87 81 76
DHQ030
(2.5) 431 426 24.4 20.1 85 89 129 123 56 58 60 86 84 81
DHQ036
(3.0) 438 433 24.6 20.1 86 91 132 124 57 59 61 89 85 82
DHQ042
(3.5) 519 514 25.1 20.4 101 112 158 143 66 71 76 107 100 93
DHQ048
(4.0) 545 540 25.3 20.8 107 121 165 146 70 76 82 112 103 96
DHQ060
(5.0) 554 549 25.5 20.5 107 122 171 149 70 76 83 117 106 97
Table 3: Unit Accessory Weights
Unit Accessory Model Weight (lbs.)
Shipping Operating
Add Economizer All 45 40

1101790-UIM-C-0414
Johnson Controls Unitary Products 7
Figure 3: Unit Dimensions
A
B
VENT AIR OUTLET HOOD
BLOWER SERVICE ACCESS
COMPARTMENT PANEL
GAS SUPPLY
1-1/4" DIAMETER HOLE
(1/2" NPTF CONNECTION)
UNIT CONDENSATE
CONNECTION 3/4" NPTF
(TRAP RECOMMENDED)
HIGH VOLTAGE
CONN. 1-3/8" DIA.
KNOCKOUT
3-3/4
2-1/2
GAS SUPPLY
1-1/4" DIA. KNOCKOUT
(1/2" NPTF CONNECTION)
LOW VOLTAGE
CONN.1-3/8" DIA.
KNOCKOUT x 7/8" HOLE
(OVERALL)
(OVERALL)
CONDENSER COIL
2-3/8
REFRIGERANT
CONNECTIONS
COMBUSTION AIR
INLET LOUVERS
FRONT
GAS/ELECTRIC CONTROL
SERVICE ACCESS
COMPARTMENT PANEL
1-1/2
2-5/8
3-1/3
12-3/4
11
5-3/8
49-1/8
47-1/4
LEFT
FRONT
RIGHT
Table 4: Unit Dimensions Front
Unit Model Dimensions
“A” “B”
DHQ024, 030, 036 33-1/2 18-1/4
DHQ042, 048, 060 41-1/2 23-1/8
Table 5: Unit Clearances12
1. A 1" clearance must be provided between any combustible material and the supply air duct work.
2. The products of combustion must not be allowed to accumulate within a confined space and recirculate.
Direction Distance
(in.) Direction Distance
(in.)
Top3
3. Units must be installed outdoors. Over hanging structure or shrubs should not obscure condenser air
discharge outlet.
36 Right 12
Front 36 Left 24
Rear 0 Bottom4
4. Units may be installed on combustable floors made from wood or class A, B or C roof covering
materials.
0

1101790-UIM-C-0414
8Johnson Controls Unitary Products
Figure 4: Dimensions Front and Bottom
Figure 5: Dimensions Back and Bottom
6
19-1/4
11-7/8
8-7/8
FRONT GAS SUPPLY 1-5/8"
DIA. KNOCKOUT (1/2"
NPTF CONNECTION)
LOW VOLTAGE
CONN. 7/8" DIA.
KNOCKOUT
4-5/8
26-3/4
CONDENSATE
DRAIN 3/4" NPTF
HIGH VOLTAGE
CONN. 1-3/32"
DIA. KNOCKOUT
4
14-1/2
28-3/8
14-1/2
BACK
3-3/8
SIDE RETURN
AIR OPENING
14-1/2
4-1/4
3-1/2
15
1-3/4
1-3/4
BOTTOM RETURN
AIR OPENING
15
28-9/16
15
1-3/4
BOTTOM SUPPLY
AIR OPENING
*CONDENSER
COIL
SIDE SUPPLY
AIR OPENING

1101790-UIM-C-0414
Johnson Controls Unitary Products 9
Figure 6: Roof Curb1
Ductwork
These units are adaptable to downflow use as well as rear
supply and return air duct openings. To convert to downflow,
use the following steps:
1. Remove the duct covers found in the bottom return and
supply air duct openings. There are four (4) screws
securing each duct cover (save these screws to use in
Step 2).
2. Install the duct covers (removed in step one) to the rear
supply and return air duct openings. Secure with the four
(4) screws used in step one.
3. Seal duct covers with silicone caulk.
Duct work should be designed and sized according to the
methods of the Air Conditioning Contractors of America
(ACCA), as set forth in their Manual D.
A closed return duct system shall be used. This shall not
preclude use of economizers or ventilation air intake. Flexible
joints may be used in the supply and return duct work to
minimize the transmission of noise.
NOTE: Be sure to note supply and return openings.
Refer to Figures 4 and 5 for information concerning rear and
bottom supply and return air duct openings.
Roof Curb
On applications when a roof curb is used, the unit must be
positioned on the curb so the front of the unit is tight against the
curb.
Filters
Single phase units are shipped without a filter or filter racks. It is
the responsibility of the installer to secure a filter in the return air
ductwork or install a Filter/Frame Kit (1FF0110, 1FF0112 or
1FF0114).
A filter rack and high velocity filters are standard on three phase
units.
Filters must always be used and must be kept clean. When
filters become dirt laden, insufficient air will be delivered by the
blower, decreasing your units efficiency and increasing
operating costs and wear-and-tear on the unit and controls.
Filters should be checked monthly; this is especially important
since this unit is used for both heating and cooling.
1. 8” Roof Curb also available.
1
RECOMMENDED
DUCT SIZE
17-1/8" x 21-1/2"
RECOMMENDED
DUCT SIZE
17-1/2" x 16-3/4"
OPENING FOR
RETURN AIR DUCT
OPENING FOR
SUPPLY AIR DUCT
42-3/4
40-3/4 17-5/8 17-1/4 43-1/4
22
45-1/8
3-1/2
14

1101790-UIM-C-0414
10 Johnson Controls Unitary Products
Condensate Drain
A condensate trap is recommended to be installed in the
condensate drain. The plumbing must conform to local codes.
Use a sealing compound on male pipe threads. Install the
condensate drain line (3/4” NPTF) to spill into an open drain.
Service Access
Access to all serviceable components is provided at the
following locations:
• Blower compartment access panel
• Gas control/electrical access panel
• Refrigerant connections
Refer to Figure 3 for location of these access locations and
minimum clearances in Table 5.
Refer to Figure for the R-410A Quick Reference Guide.
Thermostat
The room thermostat should be located on an inside wall
approximately 56" above the floor where it will not be subject to
drafts, sun exposure or heat from electrical fixtures or
appliances. Follow manufacturer's instructions enclosed with
the thermostat for general installation procedure. Color coded
insulated wires (minimum #18 AWG) should be used to connect
thermostat to unit. See Figures thru 8.
Power And Control Wiring
Field wiring to the unit must conform to provisions of the current
N.E.C. ANSI/NFPA No. 70 or C.E.C. and/or local ordinances.
The unit must be electrically grounded in accordance with local
codes or, in their absence, with the N.E.C./C.E.C. Voltage
tolerances which must be maintained at the compressor
terminals during starting and running conditions are indicated
on the unit Rating Plate and Table 6.
The wiring entering the cabinet must be provided with
mechanical strain relief.
A fused disconnect switch should be field provided for the unit.
If any of the wire supplied with the unit must be replaced,
replacement wire must be of the type shown on the wiring
diagram.
Electrical line must be sized properly to carry the load. Each
unit must be wired with a separate branch circuit fed directly
from the meter panel and properly fused.
Refer to Figures thru 8 for typical field wiring and to the
appropriate unit wiring diagram for control circuit and power
wiring information.
Hand tighten only.
This system uses R-410A Refrigerant which operates at
higher pressures than R-22. No other refrigerant may be
used in this system. Gage sets, hoses, refrigerant
containers and recovery systems must be designed to
handle R-410A. If you are unsure, consult the
equipment manufacturer. Failure to use R-410A
compatible servicing equipment may result in property
damage or injury.
Wear safety glasses and gloves when handling
refrigerants. Failure to follow this warning can cause
serious personal injury.

1101790-UIM-C-0414
Johnson Controls Unitary Products 11
Figure 7: Typical Field Control Wiring Diagram For Dual Fuel Heat Pump
Figure 8: Typical Field Power Wiring Diagram
Equipment Control Wiring
259/Y
258/B
262/R
263/W
264/G
265/O
YGVI
X/L
Terminal
Y2 C O
W2 EY1 R G X/L
Thermostat
CFMCB
Common
Terminal
(Programmable
Thermostat Only)
Table 6: Electrical Data
Model
(Tons) Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor MCA1
(Amps)
1. Minimum Circuit Ampacity.
Max
Fuse2/
Breaker3
Size
(Amps)
2. Maximum Over Current Protection per standard UL 1995.
3. Fuse or HACR circuit breaker size installed at factory or field installed.
RLA LRA MCC FLA FLA
DHQ024
(2.0) 208/230-1-60 11.6 58 18 2.8 4.3 21.6 30
DHQ030
(2.5) 208/230-1-60 13.1 73 20 2.8 6.8 26 35
DHQ036
(3.0) 208/230-1-60 15.2 83 24 2.8 6.8 28.6 35
DHQ042
(3.5) 208/230-1-60 17.9 96 28 2.8 9.1 34.3 45
DHQ048
(4.0) 208/230-1-60 21.1 104 33 2.8 9.1 38.3 50
DHQ060
(5.0) 208/230-1-60 28.8 153 45 2.8 9.1 47. 60

1101790-UIM-C-0414
12 Johnson Controls Unitary Products
Table 7: DHQ024-060 Two Stage Gas Heat
Component Models
DHQ024 DHQ030 DHQ036 DHQ042 DHQ048 DHQ060
Nominal Tonnage 2.0 2.5 3.0 3.5 4.0 5.0
AHRI COOLING PERFORMANCE
Gross Capacity @ AHRI A point (MBH) 23.7 30.1 37.2 43.5 47.7 55.0
AHRI net capacity (MBH) 22.8 29.0 34.6 41.0 45.5 52.5
EER 11.0 11.0 11.0 11.0 11.0 11.0
SEER 14.0 14.0 14.0 14.0 14.0 14.0
Nominal CFM 850 950 1050 1400 1400 1550
System power (KW) 2.1 2.6 3.2 3.8 4.2 4.8
Refrigerant type R410A R410A R410A R410A R410A R410A
Refrigerant charge (lb-oz) 10-10 9-0 9-6 12-4 12-14 12-14
AHRI HEAT PUMP PERFORMANCE
47ºF capacity rating (MBH) 21.0 26.5 30.5 38.0 44.4 51.4
System power (KW) / COP 3.30 3.30 3.15 3.30 3.20 3.10
17ºF capacity rating (MBH) 11.5 15.0 18.5 21.6 23.6 31.0
System power (KW) / COP 2.15 2.10 2.15 2.15 2.10 2.15
HSPF (Btu/Watts-hr) 8.0 8.0 8.0 8.0 8.0 8.0
AHRI GAS HEAT PERFORMANCE
Heating model D056 D056 D056 D072 D090 D090 D110 D090 D110
Heat input (K Btu) 70/45.5 70/45.5 70/45.5 90/58.5 108/70.2 108/70.2 135/87.8 108/70.2 135/87.8
Heat output (K Btu) 56/36.4 56/36.4 56/36.4 72/46.8 87/56.2 87/56.2 108/70.2 87/56.2 108/70.2
AFUE181.0 81.0 81.0 81.0 81.0 81.0 81.0 81.0 81.0
No. burners 3 3 3 4 4 4 5 4 5
No. stages 2 2 2 2 2 2 2 2 2
Temperature Rise Range (ºF) 30-60 30-60 25-55 30-60 45-75 35-65 45-75 35-65 45-75
Max. Outlet Air Temp. (ºF) 175 175 175 175 175 175 175 175 175
Gas Limit Setting (ºF) 160 160 160 160 175 175 170 175 170
Gas piping connection (in.) 1/2 1/2 1/2 1/2 1/2 1/2
DIMENSIONS (inches)
Length 49 1/8 49 1/8 49 1/8 49 1/8 49 1/8 49 1/8
Width 47 1/4 47 1/4 47 1/4 47 1/4 47 1/4 47 1/4
Height 33 1/2 33 1/2 33 1/2 41 1/2 41 1/2 41 1/2
OPERATING WT. (lbs.)
Unit Weight (lbs.) 413 426 433 514 540 549
COMPRESSOR
Type Scroll 2-speeds Scroll 2-speeds Scroll 2-speeds Scroll 2-speeds Scroll 2-speeds Scroll 2-speeds
CONDENSER COIL DATA
Face area (Sq. Ft.) 11.9 11.9 11.9 15 15 15
Rows 2 2 2 2 2 3
Fins per inch 16 16 16 16 16 13
Tube diameter 3/8 3/8 3/8 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced Interlaced Interlaced Interlaced
EVAPORATOR COIL DATA
Face area (Sq. Ft.) 3.4 3.4 3.4 4.4 4.4 4.4
Rows 4 4 4 4 4 4
Fins per inch 13 13 13 13 13 13
Tube diameter 3/8 3/8 3/8 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced Interlaced Interlaced Interlaced
Refrigerant control TXV TXV TXV TXV TXV TXV
CONDENSER FAN DATA
Fan diameter (Inch) 22 22 22 22 22 22
Type Prop Prop Prop Prop Prop Prop
Drive type Direct Direct Direct Direct Direct Direct
No. speeds 1 2 2 2 2 2
Motor HP 1/3 1/3 1/3 1/3 1/3 1/3
RPM 850 1100 1100 1100 1100 1100
Nominal total CFM 2000 2400 2400 3200 3200 3200
DIRECT DRIVE EVAP FAN DATA
Fan Size (Inch) 10 x 8 10 x 8 11 x 10 12 x 11 12 x 11 12 x 11
Type Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal
Motor HP 1/2 3/4 3/4 1 1 1
RPM Variable Variable Variable Variable Variable Variable
Frame size 48 48 48 48 48 48
FILTERS
Quantity - Size 1 - 20 x 20 x 1 1 - 20 x 20 x 1 1 - 20 x 20 x 1 2 - 20 x 12 x 1 2 - 20 x 12 x 1 2 - 20 x 12 x 1
1. 208/230 volt single phase only.

1101790-UIM-C-0414
Johnson Controls Unitary Products 13
Compressors
The scroll compressor used in this product is specifically
designed to operate with R-410A Refrigerant and cannot be
interchanged.
The compressor also uses a polyolester (POE oil), Mobil 3MA
POE. This oil is extremely hydroscopic, meaning it absorbs
water readily. POE oil can absorb 15 times as much water as
other oils designed for HCFC and CFC refrigerants. Take all
necessary precautions to avoid exposure of the oil to the
atmosphere.
POE (polyolester) compressor lubricants are known to cause
long term damage to some synthetic roofing materials.
Procedures which risk oil leakage include, but are not limited to,
compressor replacement, repairing refrigerant leaks, replacing
refrigerant components such as filter drier, pressure switch,
metering device or coil.
Units are shipped with compressor mountings which are
factory-adjusted and ready for operation.
Gas Heat
These single or two stage gas-fired heaters have aluminized-
steel tubular heat exchangers with spark to pilot ignition.
Gas Piping
Proper sizing of gas piping depends on the cubic feet per hour
of gas flow required, specific gravity of the gas and the length of
run. National Fuel Gas Code Z223.1 or CSA B149.1 should be
followed in all cases unless superseded by local codes or gas
company requirements. Refer to Tables 8 and 9.
The heating value of the gas may differ with locality. The value
should be checked with the local gas utility.
NOTE: There may be a local gas utility requirement specifying
a minimum diameter for gas piping. All units require a
1/2 inch pipe connection at the gas valve.
Gas Connection
The gas supply line can be routed through the hole located on
the left side of the unit. Refer to Figure 3 to locate these access
openings. Typical supply piping arrangements are shown in
Figure 9.
Gas piping requirements:
1. A drip leg and a ground joint union must be installed in the
gas piping.
2. When required by local codes, a manual shut-off valve may
have to be installed outside of the unit.
3. Use wrought iron or steel pipe for all gas lines. Pipe dope
should be applied sparingly to male threads only.
Figure 9: External Supply Connection External Shut-Off
This system uses R-410A Refrigerant which operates at
higher pressures than R-22. No other refrigerant may be
used in this system.
Do not leave the system open to the atmosphere. Unit
damage could occur due to moisture being absorbed by
the POE oil in the system. This type of oil is highly
susceptible to moisture absorption
Exposure, even if immediately cleaned up, may cause
embrittlement (leading to cracking) to occur in one year
or more. When performing any service that may risk
exposure of compressor oil to the roof, take precautions
to protect roofing.
Do not loosen compressor mounting bolts.
1/2” x 1/2” GAS COCK
1/2” x 1/2” UNION
AUTOMATIC GAS VALVE
1/2” - NPTF
DRIP LEG

1101790-UIM-C-0414
14 Johnson Controls Unitary Products
4. All piping should be cleaned of dirt and scale by
hammering on the outside of the pipe and blowing out the
loose dirt and scale. Before initial start-up, be sure that all
of the gas lines external to the unit have been purged of air.
5. The gas supply should be a separate line and installed in
accordance with all safety codes as prescribed under
Limitations, shown on Page 3. After the gas connections
have been completed, open the main shut-off valve
admitting normal gas pressure to the mains. Check all
joints for leaks with soap solution or other material suitable
for the purpose. NEVER USE A FLAME.
6. The furnace must be isolated from the gas supply piping
system by closing its individual manual shut-off valve
before conducting any pressure testing of the gas supply
piping system at test pressures equal to or greater than 1/2
psig (3.48 kPa).
Flue Vent Hood
The flue vent hood with screen is shipped loose. This hood must
be installed to assure proper unit operation. The hood must be
fastened to the outside of the side gas control/electrical
compartment with the screws provided in the bag attached to the
inside of the gas control/electrical compartment, see Figure 10.
Figure 10: Flue Vent Outlet Air Hood
Table 8: Natural Gas Pipe Sizing Chart1
1. Maximum capacity of pipe in cubic feet of gas per hour (based
upon a pressure drop of 0.3 inch water column and 0.6 specific
gravity gas).
Length
In Feet Nominal Inches Iron Pipe Size
1/2” 3/4” 1” 1-1/4”
10 132 278 520 1,050
20 92 190 350 730
30 73 152 285 590
40 63 130 245 500
50 56 115 215 440
60 50 105 195 400
70 46 96 180 370
80 43 90 170 350
90 40 84 160 320
100 38 79 150 305
Table 9: Propane (LP) Gas Pipe Sizing Chart1
1. Maximum capacity of pipe in thousands of BTU per hour
(based upon a pressure drop of 0.5 inch water column).
Length
In Feet Nominal Inches Iron Pipe Size
1/2” 3/4” 1” 1-1/4”
10 275 567 1,071 2,205
20 189 393 732 1,496
30 152 315 590 1,212
40 129 267 504 1,039
50 114 237 448 913
60 103 217 409 834
70 96 196 378 771
80 89 185 346 724
90 83 173 322 677
100 78 162 307 630
If flexible stainless steel tubing is allowed by the
authority having jurisdiction, wrought iron or steel pipe
must be installed at the gas valve and extend a
minimum of two (2) inches outside of the unit casing.
Natural gas may contain some propane. Propane being
an excellent solvent, will quickly dissolve white lead or
most standard commercial compounds. Therefore, a
special pipe dope must be applied when wrought iron or
steel pipe is used. Shellac base compounds such as
gaskoloc or stalastic, and compounds such as
rectorseal # 5, Clyde’s or John Crane may be used.
FIRE OR EXPLOSION HAZARD
Failure to follow the safety warning exactly could result
in serious injury, death or property damage.
Never test for gas leaks with an open flame. use a
commercially available soap solution made specifically
for the detection of leaks to check all connections. A fire
or explosion may result causing property damage,
personal injury or loss of life.
Flue hood surfaces may be hot.
The flue exhaust hood must be properly installed and
within the recommended clearances. Further
communications and action must be given to the home
or building owner(s) to eliminate any unauthorized
human contact around this area during the heating
cycle. Flue hood surface and the immediate area reach
high temperatures during the heating cycle.
VENT OUTLET SCREEN
FLUE VENT OUTLET
AIR HOOD

1101790-UIM-C-0414
Johnson Controls Unitary Products 15
Table 10: Natural Gas Application Data-Two Stage
Available On Models Input (MBH)1
High Fire/Low Fire
1. Heating capacity valid for elevations up to 2000 feet above sea level. For elevations above 2,000 feet, rated capacity should be reduced by
4% for each 1,000 feet above sea level.
Output
(MBH)
High Fire/Low Fire
Gas Rate2
Ft.3/Hr.
High Fire/Low Fire
2. Based on 1075 BTU/Ft.3.
Number of
Burners
Temp. Rise ºF
At Full Input3
3. The air flow must be adequate to obtain a temperature rise within the range shown. Continuous return air temperature should not be below 55°F.
Min. Max.
2 Ton 70 / 45.5 56 / 36.4 65 / 42 3 30 60
3 Ton 70 / 45.5 56 / 36.4 65 / 42 3 25 55
3 Ton 90 / 58.5 72 / 46.8 84 / 54 4 30 60
4, 5 Ton 108 / 70.2 87 / 56.2 100 / 65 4 35 65
4, 5 Ton 135 / 87.75 108 / 70.2 126 / 82 5 45 75
Table 11: Propane1(LP) Gas Application Data-Two Stage
1. Propane applications are accomplished by field installation of a Propane Conversion Accessory, Model 1NP0809 for 2 and 3 Ton units
with 33-1/2" tall cabinets and Model 1NP0810 for 4 and 5 Ton units with 41-1/2" tall cabinets.
Available On Models Input Capacity (Mbh)2
High Fire/Low Fire
2. Heating capacity valid for elevations up to 2,000 feet above sea level. For elevations above 2,000 feet, rated capacity should be reduced
by 4% for each 1,000 feet above sea level.
Output Capacity
(Mbh)
High Fire/Low Fire
Gas Rate3
Ft.3/Hr.
High Fire/Low Fire
3. Based on 2500 BTU/Ft.3.
Number of Burners Temp. Rise ºF At Full Input4
4. The air flow must be adequate to obtain a temperature rise within the range shown. Continuous return air temperature should not be below 55°F.
Min. Max.
2 Ton 70 / 45.5 56 / 36.4 28 / 18.2 3 30 60
3 Ton 70 / 45.5 56 / 36.4 28 / 18.2 3 25 55
3 Ton 90 / 58.5 72 / 46.8 36 / 23.4 4 30 60
4, 5 Ton 108 / 70.2 87 / 56.2 43 / 27.95 4 35 65
4, 5 Ton 135 / 87.75 108 / 70.2 54 / 35.1 5 45 75

1101790-UIM-C-0414
16 Johnson Controls Unitary Products
Airflow Performance
Bottom Duct Application
Table 12: DHQ024-060
Model
(Tons) Mode Thermostat Input Speed Tap CFM External Static Pressure (Inch Water Gauge)
0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Watts Watts Watts Watts Watts Watts Watts Watts Watts
DHQ024
(2.0)
Cool
Low
Y1+O COOL-A 580 89 112 134 159 184 206 229 252 276
Y1+O COOL-B 400 43 62 81 101 121 137 153 173 192
Y1+O COOL-C 600 96 119 142 167 193 216 239 263 287
Y1+O COOL-D 667 120 145 170 198 225 250 275 301 328
High
Y1+Y2+O COOL-A 870 215 248 281 315 349 380 410 444 477
Y1+Y2+O COOL-B 600 95 119 142 167 193 216 239 263 287
Y1+Y2+O COOL-C 900 232 266 301 335 370 402 434 468 503
Y1+Y2+O COOL-D 1000 292 332 371 410 448 482 516 555 594
Heat
Pump
Low
Y1 COOL-A 600 96 119 142 167 193 216 239 263 287
Y1 COOL-B 500 65 86 107 130 152 172 192 213 235
Y1 COOL-C 467 57 77 97 119 141 159 178 199 220
Y1 COOL-D 667 120 145 170 198 225 250 275 301 328
High
Y1+Y2 COOL-A 900 232 266 301 335 370 402 434 468 503
Y1+Y2 COOL-B 750 155 183 211 241 271 299 326 355 384
Y1+Y2 COOL-C 700 133 159 186 214 243 269 295 322 349
Y1+Y2 COOL-D 1000 292 332 371 410 448 482 516 555 594
Heat D056
W1 HEAT-A 670121146172199227----
W1 HEAT-B 690129155181209237----
W1 HEAT-C 710137164191219248----
W1 HEAT-D 750155183211241271----
W1+W2 HEAT-A 940255291328364400----
W1+W2 HEAT-B 970273311349386424----
W1+W2 HEAT-C1000292332371410448----
W1+W2 HEAT-D1050326368410450490----
DHQ030
(2.5)
Cool
Low
Y1+O COOL-A 634 119 142 164 192 220 245 269 294 319
Y1+O COOL-B 500 98 118 137 160 182 203 224 244 264
Y1+O COOL-C 700 136 160 185 215 245 272 298 325 351
Y1+O COOL-D 834 183 212 242 275 308 339 369 397 425
High
Y1+Y2+O COOL-A 950 239 273 308 342 377 410 444 472 500
Y1+Y2+O COOL-B 750 151 178 204 235 267 295 323 350 377
Y1+Y2+O COOL-C 1050 298 337 376 411 446 482 519 546 573
Y1+Y2+O COOL-D 1250 446 496 547 580 613 655 697 718 739
Heat
Pump
Low
Y1 COOL-A 700 136 160 185 215 245 272 298 325 351
Y1 COOL-B 634 119 142 164 192 220 245 269 294 319
Y1 COOL-C 767 157 184 211 243 275 303 331 359 387
Y1 COOL-D 834 183 212 242 275 308 339 369 397 425
High
Y1+Y2 COOL-A 1050 298 337 376 411 446 482 519 546 573
Y1+Y2 COOL-B 950 239 273 308 342 377 410 444 472 500
Y1+Y2 COOL-C 1150 367 411 456 490 525 564 603 628 652
Y1+Y2 COOL-D 1250 446 496 547 580 613 655 697 718 739
Heat D056
W1 HEAT-A 680130154178208237----
W1 HEAT-B 735146172198229260----
W1 HEAT-C 790166193221253286----
W1 HEAT-D 840186215245278312----
W1+W2 HEAT-A1050298337376411446----
W1+W2 HEAT-B1135356399443478512----
W1+W2 HEAT-C1220421470519552585----
W1+W2 HEAT-D1300489543597629660----

1101790-UIM-C-0414
Johnson Controls Unitary Products 17
DHQ036
(3.0)
Cool
Low
Y1+O COOL-A 734 123 158 194 229 264 298 331 365 398
Y1+O COOL-B 600 78 113 147 179 210 238 265 291 315
Y1+O COOL-C 834 165 202 238 276 313 350 388 426 465
Y1+O COOL-D 900 197 235 273 311 350 390 430 471 512
High
Y1+Y2+O COOL-A 1100 314 355 396 439 482 526 571 617 663
Y1+Y2+O COOL-B 900 197 235 273 311 350 390 430 471 512
Y1+Y2+O COOL-C 1250 422 466 510 555 601 647 694 741 788
Y1+Y2+O COOL-D 1350 503 550 597 643 690 737 783 830 876
Heat
Pump
Low
Y1 COOL-A 767 136 172 208 244 279 315 350 385 420
Y1 COOL-B 834 165 202 238 276 313 350 388 426 465
Y1 COOL-C 900 197 235 273 311 350 390 430 471 512
Y1 COOL-D 967 233 271 310 350 391 432 474 517 561
High
Y1+Y2 COOL-A 1150 348 390 432 476 520 564 610 657 704
Y1+Y2 COOL-B 1250 422 466 510 555 601 647 694 741 788
Y1+Y2 COOL-C 1350 503 550 597 643 690 737 783 830 876
Y1+Y2 COOL-D 1450 591 642 691 739 787 834 880 925 969
Heat
D056
W1 HEAT-A 680103139173207240----
W1 HEAT-B 735123159194229264----
W1 HEAT-C 790145182218254290----
W1 HEAT-D 840168204241279316----
W1+W2 HEAT-A1050282322362404446----
W1+W2 HEAT-B1140341383425468512----
W1+W2 HEAT-C1220399442486531576----
W1+W2 HEAT-D1300461507552598645----
D072
W1 HEAT-A 790145182218254-----
W1 HEAT-B 855175212249286-----
W1 HEAT-C 920207245283322-----
W1 HEAT-D 975237276315355-----
W1+W2 HEAT-A1200384427470514-----
W1+W2 HEAT-B1300461507552598-----
W1+W2 HEAT-C1400546595643690-----
W1+W2 HEAT-D1480619671721770-----
DHQ042
(3.5)
Cool
Low
Y1+O COOL-A 934 225 253 281 317 352 384 415 447 479
Y1+O COOL-B 800 208 233 258 277 297 331 351 374 398
Y1+O COOL-C 1000 239 268 298 341 384 414 451 487 523
Y1+O COOL-D 1100 266 298 330 383 437 466 510 552 594
High
Y1+Y2+O COOL-A 1400 396 435 473 551 629 663 725 782 839
Y1+Y2+O COOL-B 1200 301 335 369 432 495 525 575 623 670
Y1+Y2+O COOL-C 1500 455 496 537 622 706 743 808 870 931
Y1+Y2+O COOL-D 1650 560 604 648 740 832 876 946 1013 1081
Heat
Pump
Low
Y1 COOL-A 934 225 253 281 317 352 384 415 447 479
Y1 COOL-B 867 214 241 268 295 323 356 381 409 437
Y1 COOL-C 1000 239 268 298 341 384 414 451 487 523
Y1 COOL-D 1100 266 298 330 383 437 466 510 552 594
High
Y1+Y2 COOL-A 1400 396 435 473 551 629 663 725 782 839
Y1+Y2 COOL-B 1300 345 381 417 488 559 591 647 699 752
Y1+Y2 COOL-C 1500 455 496 537 622 706 743 808 870 931
Y1+Y2 COOL-D 1650 560 604 648 740 832 876 946 1013 1081
Heat D090
W1 HEAT-A 870 215 241 268 296 325 357 - - -
W1 HEAT-B 920 222 250 278 312 346 378 - - -
W1 HEAT-C 985 235 264 293 335 376 407 - - -
W1 HEAT-D 1050 251 282 313 361 409 439 - - -
W1+W2 HEAT-A 1330 359 396 433 506 580 612 - - -
W1+W2 HEAT-B 1400 396 435 473 551 629 663 - - -
W1+W2 HEAT-C 1500 455 496 537 622 706 743 - - -
W1+W2 HEAT-D 1600 523 566 609 699 788 830 - - -
Table 12: DHQ024-060 (Continued)
Model
(Tons) Mode Thermostat Input Speed Tap CFM External Static Pressure (Inch Water Gauge)
0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Watts Watts Watts Watts Watts Watts Watts Watts Watts

1101790-UIM-C-0414
18 Johnson Controls Unitary Products
DHQ048
(4.0)
Cool
Low
Y1+O COOL-A 967 231 260 289 328 368 398 432 467 501
Y1+O COOL-B 800 208 233 258 277 297 331 351 374 398
Y1+O COOL-C 1101 266 298 330 383 437 466 510 552 594
Y1+O COOL-D 1301 345 381 418 489 560 591 647 700 752
High
Y1+Y2+O COOL-A 1450 425 464 504 586 667 702 766 825 885
Y1+Y2+O COOL-B 1200 301 335 369 432 495 525 575 623 670
Y1+Y2+O COOL-C 1650 560 604 648 740 832 876 946 1013 1081
Y1+Y2+O COOL-D 1950 822 873 924 1024 1124 1189 1262 1339 1416
Heat
Pump
Low
Y1 COOL-A 1067 256 287 318 368 418 448 490 530 570
Y1 COOL-B 1000 239 268 298 341 384 414 451 487 523
Y1 COOL-C 1134 277 310 342 399 455 485 531 575 619
Y1 COOL-D 1301 345 381 418 489 560 591 647 700 752
High
Y1+Y2 COOL-A 1600 523 566 609 699 788 830 898 964 1030
Y1+Y2 COOL-B 1500 455 496 537 622 706 743 808 870 931
Y1+Y2 COOL-C 1700 598 644 689 783 877 924 995 1064 1133
Y1+Y2 COOL-D 1950 822 873 924 1024 1124 1189 1262 1339 1416
Heat D090
W1 HEAT-A 870 215 241 268 296 325 357 383 411 439
W1 HEAT-B 920 222 250 278 312 346 378 408 439 470
W1 HEAT-C 985 235 264 293 335 376 407 442 478 513
W1 HEAT-D 1050 251 282 313 361 409 439 479 519 558
W1+W2 HEAT-A 1330 359 396 433 506 580 612 670 723 777
W1+W2 HEAT-B 1400 396 435 473 551 629 663 725 782 839
W1+W2 HEAT-C 1500 455 496 537 622 706 743 808 870 931
W1+W2 HEAT-D 1600 523 566 609 699 788 830 898 964 1030
Heat D110
W1 HEAT-A 940226254282319-----
W1 HEAT-B 970232261290329-----
W1 HEAT-C1050251282313361-----
W1 HEAT-D1100266298329383-----
W1+W2 HEAT-A1450425464504586-----
W1+W2 HEAT-B1500455496537622-----
W1+W2 HEAT-C1600523566609699-----
W1+W2 HEAT-D1700598644689783-----
DHQ060
(5.0)
Cool
Low
Y1+O COOL-A 1034 247 277 307 354 401 431 470 508 546
Y1+O COOL-B 1101 266 298 330 383 437 466 510 552 594
Y1+O COOL-C 1167 289 322 355 415 475 505 553 599 645
Y1+O COOL-D 1334 361 398 435 509 582 615 673 727 781
High
Y1+Y2+O COOL-A 1550 488 530 572 659 746 786 853 916 980
Y1+Y2+O COOL-B 1650 560 604 648 740 832 876 946 1013 1081
Y1+Y2+O COOL-C 1750 639 685 732 828 923 974 1045 1116 1187
Y1+Y2+O COOL-D 2000 872 925 977 1077 1178 1248 1320 1398 1476
Heat
Pump
Low
Y1 COOL-A 1167 289 322 355 415 475 505 553 599 645
Y1 COOL-B 1234 315 350 385 450 516 546 599 648 697
Y1 COOL-C 1301 345 381 418 489 560 591 647 700 752
Y1 COOL-D 1334 361 398 435 509 582 615 673 727 781
High
Y1+Y2 COOL-A 1750 639 685 732 828 923 974 1045 1116 1187
Y1+Y2 COOL-B 1850 726 775 824 922 1021 1078 1150 1224 1298
Y1+Y2 COOL-C 1950 822 873 924 1024 1124 1189 1262 1339 1416
Y1+Y2 COOL-D 2000 872 925 977 1077 1178 1248 1320 1398 1476
Heat D090
W1 HEAT-A 870 215 241 268 296 325 357 - - -
W1 HEAT-B 920 222 250 278 312 346 378 - - -
W1 HEAT-C 985 235 264 293 335 376 407 - - -
W1 HEAT-D 1050 251 282 313 361 409 439 - - -
W1+W2 HEAT-A 1330 359 396 433 506 580 612 - - -
W1+W2 HEAT-B 1400 396 435 473 551 629 663 - - -
W1+W2 HEAT-C 1500 455 496 537 622 706 743 - - -
W1+W2 HEAT-D 1600 523 566 609 699 788 830 - - -
Heat D110
W1 HEAT-A 940 226 254 282 319 355 386 - - -
W1 HEAT-B 985 235 264 293 335 376 407 - - -
W1 HEAT-C 1035 247 277 308 355 401 431 - - -
W1 HEAT-D 1100 266 298 329 383 436 466 - - -
W1+W2 HEAT-A 1450 425 464 504 586 667 702 - - -
W1+W2 HEAT-B 1500 455 496 537 622 706 743 - - -
W1+W2 HEAT-C 1600 523 566 609 699 788 830 - - -
W1+W2 HEAT-D 1700 598 644 689 783 877 924 - - -
Table 12: DHQ024-060 (Continued)
Model
(Tons) Mode Thermostat Input Speed Tap CFM External Static Pressure (Inch Water Gauge)
0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Watts Watts Watts Watts Watts Watts Watts Watts Watts

1101790-UIM-C-0414
Johnson Controls Unitary Products 19
Side Duct Application
Table 13: DHQ024-060
Model
(Tons) Mode Thermostat
Input Speed Tap CFM External Static Pressure (Inch Water Gauge)
0.20.30.40.50.60.70.80.91.0
Watts Watts Watts Watts Watts Watts Watts Watts Watts
DHQ024
(2.0)
Cool
Low
Y1+O COOL-A 580 89 112 134 159 184 206 229 252 276
Y1+O COOL-B 400 43 62 81 101 121 137 153 173 192
Y1+O COOL-C 600 96 119 142 167 193 216 239 263 287
Y1+O COOL-D 667 120 145 170 198 225 250 275 301 328
High
Y1+Y2+O COOL-A 870 215 248 281 315 349 380 410 444 477
Y1+Y2+O COOL-B 600 95 119 142 167 193 216 239 263 287
Y1+Y2+O COOL-C 900 232 266 301 335 370 402 434 468 503
Y1+Y2+O COOL-D 1000 292 332 371 410 448 482 516 555 594
Heat
Pump
Low
Y1 COOL-A 600 96 119 142 167 193 216 239 263 287
Y1 COOL-B 500 65 86 107 130 152 172 192 213 235
Y1 COOL-C 467 57 77 97 119 141 159 178 199 220
Y1 COOL-D 667 120 145 170 198 225 250 275 301 328
High
Y1+Y2 COOL-A 900 232 266 301 335 370 402 434 468 503
Y1+Y2 COOL-B 750 155 183 211 241 271 299 326 355 384
Y1+Y2 COOL-C 700 133 159 186 214 243 269 295 322 349
Y1+Y2 COOL-D 1000 292 332 371 410 448 482 516 555 594
Heat D056
W1 HEAT-A 670 121 146 172 199 227 - - - -
W1 HEAT-B 690 129 155 181 209 237 - - - -
W1 HEAT-C 710 137 164 191 219 248 - - - -
W1 HEAT-D 750 155 183 211 241 271 - - - -
W1+W2 HEAT-A 940 255 291 328 364 400 - - - -
W1+W2 HEAT-B 970 273 311 349 386 424 - - - -
W1+W2 HEAT-C 1000 292 332 371 410 448 - - - -
W1+W2 HEAT-D 1050 326 368 410 450 490 - - - -
DHQ030
(2.5)
Cool
Low
Y1+O COOL-A 634 119 142 164 192 220 245 269 294 319
Y1+O COOL-B 500 98 118 137 160 182 203 224 244 264
Y1+O COOL-C 700 136 160 185 215 245 272 298 325 351
Y1+O COOL-D 834 183 212 242 275 308 339 369 397 425
High
Y1+Y2+O COOL-A 950 239 273 308 342 377 410 444 472 500
Y1+Y2+O COOL-B 750 151 178 204 235 267 295 323 350 377
Y1+Y2+O COOL-C 1050 298 337 376 411 446 482 519 546 573
Y1+Y2+O COOL-D 1250 446 496 547 580 613 655 697 718 739
Heat
Pump
Low
Y1 COOL-A 700 136 160 185 215 245 272 298 325 351
Y1 COOL-B 634 119 142 164 192 220 245 269 294 319
Y1 COOL-C 767 157 184 211 243 275 303 331 359 387
Y1 COOL-D 834 183 212 242 275 308 339 369 397 425
High
Y1+Y2 COOL-A 1050 298 337 376 411 446 482 519 546 573
Y1+Y2 COOL-B 950 239 273 308 342 377 410 444 472 500
Y1+Y2 COOL-C 1150 367 411 456 490 525 564 603 628 652
Y1+Y2 COOL-D 1250 446 496 547 580 613 655 697 718 739
Heat D056
W1 HEAT-A 680 130 154 178 208 237 - - - -
W1 HEAT-B 735 146 172 198 229 260 - - - -
W1 HEAT-C 790 166 193 221 253 286 - - - -
W1 HEAT-D 840 186 215 245 278 312 - - - -
W1+W2 HEAT-A 1050 298 337 376 411 446 - - - -
W1+W2 HEAT-B 1135 356 399 443 478 512 - - - -
W1+W2 HEAT-C 1220 421 470 519 552 585 - - - -
W1+W2 HEAT-D 1300 489 543 597 629 660 - - - -

1101790-UIM-C-0414
20 Johnson Controls Unitary Products
DHQ036
(3.0)
Cool
Low
Y1+O COOL-A 734 123 158 194 229 264 298 331 365 398
Y1+O COOL-B 600 78 113 147 179 210 238 265 291 315
Y1+O COOL-C 834 165 202 238 276 313 350 388 426 465
Y1+O COOL-D 900 197 235 273 311 350 390 430 471 512
High
Y1+Y2+O COOL-A 1100 314 355 396 439 482 526 571 617 663
Y1+Y2+O COOL-B 900 197 235 273 311 350 390 430 471 512
Y1+Y2+O COOL-C 1250 422 466 510 555 601 647 694 741 788
Y1+Y2+O COOL-D 1350 503 550 597 643 690 737 783 830 876
Heat
Pump
Low
Y1 COOL-A 767 136 172 208 244 279 315 350 385 420
Y1 COOL-B 834 165 202 238 276 313 350 388 426 465
Y1 COOL-C 900 197 235 273 311 350 390 430 471 512
Y1 COOL-D 967 233 271 310 350 391 432 474 517 561
High
Y1+Y2 COOL-A 1150 348 390 432 476 520 564 610 657 704
