Joinwit JW3116 User manual

Handheld Optical Light Source-JW3116
Shanghai Joinwit Optoelectronic Co.,Ltd.
NOTICE
All the trademarks mentioned in this manual are registered property
of Joinwit. The right to interpret this manual is reserved by Joinwit.
This publication is protected by the copyright laws of the People’s Republic of China and
other countries, with all rights reserved. No part of this publication may be reproduced,
stored in a retrieval system, translated, transcribed, or transmitted, in any means manual,
electric, electronic, electromagnetic, or otherwise, without prior explicit written permission
of Joinwit Optoelectronic Technology Co., Ltd.
…………………………………………………………………………………
The information contained in this document is assumed to be correct
and current. The manufacturer is not responsible for errors of omissions
and reserves the right to change specifications at any time without
notice.

Handheld Optical Light Source-JW3116
Shanghai Joinwit Optoelectronic Co.,Ltd.
Safety Sign:
When using the optical power meter, always take bask safety precautions to reduce the harm for
the testers, and injury to persons. All the safety sign may not mark in this manual.
Warning：Prohibited misconduct and operation, to prevent any improper conduct and
operation of the damage.
Notice：notic the important information, notification, and referencs, thse notice
information should be understand.
Safety sign on the instrument：
WEEE Sign：Users of electrical and electronic equipment from private households
should have the possibility of returning WEEE at least free of charge.

Handheld Optical Light Source-JW3116
Shanghai Joinwit Optoelectronic Co.,Ltd.
Safety Advice
1.When the tester use Disposable alkaline batteries, do not charge it. Ensure the correct
polarity installation,when replace the battery.
2．When the products are not in use, please remove the batteries and kept separate to avoid
instrument damage caused by battery leakage. If leakage occurred, Please do not touch.
3. To prevent electric shock, do not open the product case, only the authorized qualified
professionals can do the maintenance; Do not expose the testers to rain or wet conditions, to
avoid the risk of fire or electric shock
4. Instruments used LCD screen. Do not fall the instrument. If the LCD are seriously hit, it may
cause fluid leakage. And please do not touch.

Handheld Optical Light Source-JW3116
Contents
Chapter 1 Standard Configuration---------------------------------------------------------------------------------1
Chapter 2 Overview ---------------------------------------------------------------------------------------------------1
Features------------------------------------------------------------------------------------------------------------1
Chapter 3 Specifications------------------------------------------------------------------------------------------2
Chapter 4 Function ------------------------------------------------------------------------------------------------3
4.1Front ------------------------------------------------------------------------------------------------------------3
4.2 Left Side-------------------------------------------------------------------------------------------------------4
4.3 Top--------------------------------------------------------------------------------------------------------------5
4.4 Backside-------------------------------------------------------------------------------------------------------6
Chapter 5 Operation Instruction---------------------------------------------------------------------------6
5.1 Ways of power supply-------------------------------------------------------------------------------------6
5.2 Power on the laser source--------------------------------------------------------------------------------8
5.3 Backlight Setting --------------------------------------------------------------------------------------------9
5.4 Output Power --------------------------------------------------------------------------------------------- 10
5.5 Wavelength Automatic Identification--------------------------------------------------------------- 12
5.6 Frequency detection------------------------------------------------------------------------------------- 12
5.7 Power Off--------------------------------------------------------------------------------------------------- 13
Chapter 6 Trouble shooting.--------------------------------------------------------------------------------- 13
Chapter 7 General Maintenance ------------------------------------------------------------------------------ 14
Chapter 8 Quality Warranty ------------------------------------------------------------------------------------ 14

Handheld Optical Light Source-JW3116
1
Chapter 1 Standard Configuration
No.
Name
Qty
1
JW3116 Optical Light Source
1
2
User Manual
1
3
1.5V AA battery
3
4
Power Supply Unit
1
5
Cotton Swabs
1
6
Carry Bag
1
Chapter 2 Overview
JW3116 is a handheld optical light source, the new released tester in 2010, designed for
the fiber optical network installation, acceptance, and maintenance. Used with JW3216,
can provide a accurate fiber network solution. According with client’s requirements,
JW3116 can provide 1~4 wavelength with stable output power, and featured with
continuous adjustable output power. The Intelligent backlight control function can save the
power, JW3116 have smooth appearance, good touching, and friendly design, which can
meet clients’ largest requirements.
Features
⚫Wave ID information can be transmitted when used with JW3216 Optical Power
Meter.
⚫Tone generation, 270HZ,330HZ,1KHZ,2KHZ
⚫Output power can be adjustable
⚫Output power value is shown on LCD display
⚫Intelligent backlight control (light intensity can be adjusted properly
according to ambient light, which greatly reduced power consumption)
⚫AA alkaline and AC adapter for power supply
⚫Low battery indication

Handheld Optical Light Source-JW3116
2
Chapter 3 Specifications
Model
JW3116
Operating wavelength（nm）
1310/1550 (others specify on requests）
Applicable fiber
SM ,MM
Laser type
FP-LD(others specify on requests)
Maximum Output Power（dBm）
-5（can be adjustable, others specify）
Adjustable step size（dBm）
＜0.5 (adjustable between -5~-12dBm)
Stability(dB，15min，20℃)
±0.1
Stability(dB，30min，20℃)
±0.05
Modulation（Hz）
CW，270，330，1K，2K
Fiber Port
FC/PC or FC,SC,ST interchangeable
Alkaline Battery
3*AA，1.5V
Power SupplyAdaptor(V)
8.4
Battery Operating time(h)
45
Operation Temperature(℃)
-10～+60
Storage Temperature(℃)
-25～+70
Outline size（mm）/weight
175*90*44.5/255g
Model
JW3116
Operating wavelength（nm）
1310/1550
（others specify on requests）
Applicable fiber
SM，MM
Laser type
FP-LD(others specify on requests)
Output Power(dBm)
-7（adjustable）
Adjustable Step(dBm)
＜0.5
Adjustable Range
≥5
Stability(dB，30min，20℃)
0.15
Modulation（Hz）
CW，270，330，1K，2K
Fiber Port
FC/PC
Alkaline Battery
3*AA，1.5V
Power SupplyAdaptor(V)
8.4
Battery Operating time(h)
45 without backlight
Operation Temperature(℃)
-10～+60
Storage Temperature(℃)
-25～+70
Dimension(mm)
175*90*44.5
Weight (g)
255

Handheld Optical Light Source-JW3116
3
Chapter 4 Function
4.1Front
4-1
(1) Power Key
ON/OFF the instrument
Power Saving setting: the unit will automatically shut off after 10 minutes idle time, Once choose
this setting, the “auto-off” will display on the left bottom of the screen. This power saving is the
default setting, once open the power meter, will enter into this mode.
(2) Wavelength Selection
After on the tester, first press to laser on, then press to select the wavelength and
display the current wavelength on the left top of the screen.
(3) backlight control. JW3116 have two type of backlight control, press to choose
one mode:
“LDR” the intelligent backlight control mode. Power meter will off/on the backlight within 15second
based on the outside light condition, and this is the default mode.
Back light control key mode. Press to on/off the back light
(8)
(7)
(6)
(5)
(4)
(3)
(2)
(1)
(9)
(10)

Handheld Optical Light Source-JW3116
4
(4) Rated power:
Rated output power
(5) Down the rated power
Down the rated output power
(6) Modulation adjustment/wavelength identifying
Laser on. After on the tester, firstly press , to laser on the light source. Short press shift the
frequency. (270、330、1K、2KHz) OHz means do not Loading frequency.
Long press enter into/exit the wavelength identify mode, on the right top of the screen “--AU”display when
enter into the wavelength identify mode.
(7) output power up
Up the output power
(8) “B/L SET”backlight indicator
Indicate the backlight control mode, when the indicator green, which means “LDR” in the
Intelligent back light control mode, when the indicator red, which means the backlight in
the key control mode.
(9) “LDR” Intelligent backlight controller
In the intelligent backlight control mode, the controller will automatically adjust the
backlight with the outside light, which to save the power.
(10)Screen
Display the data and the instrument working mode.
4.2 Left Side
4-2
AC adaptor port

Handheld Optical Light Source-JW3116
5
Connect theAC adaptor with the port
4.3 Top
4-3
(1) Dust cap
In order to protect the optical connector, avoid damage on the connector, so when not in use make sure
that you place the dust cap over the connectors.
(2) Optical Connector
The standard of this optical connector is FC/PC(4-4), can connect with FC/PC
adaptor.
4-4 FC/PC connector
Notice: the tinny dust on the connector will affect the accurate of the measurement value,
so please clean the connector and the patch cord end-face before do the test.
Use the alcohol and the cotton swab to clean the connector. Dip the cotton swab with alcohol, insert
the cotton swab in the connector, slightly rotating the cotton swab, after that change a dry cotton
swab and clean it again.(4-5)
4-5
Cotton Swab
(2)
(1)

Handheld Optical Light Source-JW3116
6
4.4 Backside
4-6
(1)Label
Content include the function, and the instrument information
(2) bracket
Collapsible metal bracket, 0~90 degree can adjusted.
(3)Battery Pack
Can insert 3 1.5AA batteries.
Notice: When insert the batteries, take a note of their positive(+)and negative(-)
connector orientation, The negative battery connector should be against the spring. And do recycle the
battery, do not throw the battery to the dustbin, or that will happen the dangerous.
。
Chapter 5 Operation Instruction
5.1 Ways of power supply
JW3116 can be either battery powered or AC adaptor powered, giving total flexibility for most testing sites
and situations
5.1.1 AA battery
When useAA battery, will display on the left top of the screen，5-1。
(3)
(2)
(1)

Handheld Optical Light Source-JW3116
7
5-1
There are 5 Grades for the battery power indication：
left 70%～100% electricity
left 40%～70% electricity
left 30%～40% electricity
left 20%～30% electricity。
not enough electricity, left less than 20%，the power meter will be forced power off.
Fit the battery，refer to below figure 5-2
5-2
Press the clip fastener on the battery compartment cover down. Remove the battery compartment cover,
remove all three batteries making a note of their positive and negative connector orientation. The
negative battery connector should be against the spring. Insert 3 new 1.5VV AA battery. Refit the battery
compartment cover. The clip fastener should click shut.
Notice：Make sure that you insert the batteries with their positive and negative
connectors correctly aligned.
5.1.2 Power Supply Unit
When the battery is used out, can use the power supply unit, and at this time on the left top of the
screen, there will be a (5-3)。When the battery in the power meter, and still have enough
electricity, the tester will chooseAC power supply as the priority.
Battery Power indicate

Handheld Optical Light Source-JW3116
8
5-3
When use the AC adaptor, connect the power plug as pic, and insert to the AC socket.
5-4
Notice：Please use only the power supply unit supplied with the tester, use other kind of
PSU may cause damage for the instruments.
5.2 Power on the laser source
First of all insert the battery or the PSU, press on the tester, at this time the laser are still off, the
opening displaying as 5-5
5-5
AC power supply
sign
Electricity indicate
Laser off
Rated power
Power saving
mode(Auto-off)
Power Supply
Power Plug
AC adaptor
Selected wavelength

Handheld Optical Light Source-JW3116
9
When the tester is standby, press key can cancel or choos auto-off function.If auto-off fucniton are
choosed, the “Auto-off” will display on the left bottom of the screen.
5.3 Backlight Setting
After open the optical power meter, long press , choose backlight control mode.
5.3.1 “LDR” Intelligent backlight control mode
Long press ,“B/L SET” is green (6-6),after 10 seconds, the green indicate off, the LDR the controller
will automatically adjust the backlight within 15 seconds with the outside light, which to save the power.
5-6
5.3.2 Choose the key control backlight mode
Long press , “B/L SET” indicator turns to red(6-7), enter into key control backlight mode, after 10
seconds the indicator off, short press can ON/OFF the backlight.
5-7
indicator(Green)
Indicator(red)

Handheld Optical Light Source-JW3116
10
5.4 Output Power
Notice: Preheating is normally required to ensure a stable output power for
the laser source. Normally less than 15 minutes would be okay.
5.4.1 Open the dust cap, connect with the patch cord.
Notice: Make sure the connector and the end-face of the patch cord is clean, and take
notice on the type of the patch cord, make sure the correct patch cord are connected.
5.4.2 Laser on the light source.
When open JW3116, the laser source still laser off, only after press or can
laser on the diode (5-8 & 5-9)
Laser off
5-8 Press to laser on the diode
Laser off
5-9 press to laser on the diode
Notice: To avoid risk of serious eye damage, Do not look into the interfaces
at any time.
5.4.3 Select the wavelength
Laser on(output wavelength 1310nm,
rated output power-5.00dBm，270Hz
frequency0Hz means do not load the
frequency
Laser on(output wavelength 1310nm, rated
output power-5.00dBm，0Hz means do not
load the frequency

Handheld Optical Light Source-JW3116
11
Press , select the output wavelength, display at the top of the screen. 5-10
5-10
5.4.4 Output power
Every selected wavelength can adjust the output power within the range (-5～-12dBm),
and also can load with the output frequency.
Press to down the output power, while to load the output frequency, (5-11～
5-13)
5-11
5-12 press down the output power
5-13 press to load the frequency
For the same principle, press to up the output power, while to load the
output frequency.
Output wavelength

Handheld Optical Light Source-JW3116
12
5.5 Wavelength Automatic Identification
⚫Connect JW3116 light source with its same serials power meter JW3216.
⚫Enable light source be Under “Wave ID” operation mode: press or of light source to
laser on JW2116, Hold down for few seconds，light source will be enter into Wave ID mode,
also “--AU” will be shown on the upper right of LCD for a indication.
⚫Enable power meter be under “Wave ID”operation mode: Hold down for few seconds，power
meter will be enter into Wave ID mode, also “--AU”will be shown on the upper right of LCD for a
indication.
⚫Once the ID information is changed from light source(press to change wavelength), after 3 to
5 seconds later, the detected information on optical power meter also will be changed automatically
according to light source. Please refer to below figure(5-14) for easy understanding.
⚫Exit Wave ID mode: Hold down again to exit Wave ID mode from power meter and hold
down again to exit Wave ID mode from light source.
JW3116 Light source JW3216 Power Meter
5-14
5.6 Frequency detection
⚫Connect JW3116 light source with its same serials power meter JW3216.
⚫Output frequency from JW3116 optical light source: Press or to emerge light
from the unit, press for very short second，JW3116 light source will output frequencies
of 270Hz、330Hz、1KHz、2KHz accordingly，which will be shown on the upper right of the LCD
in JW3116 light source. In the mean time, the JW3216 power meter will detect the
corresponding frequency automatically from JW3116 light source. Please refer to below figure
(5-15) for better understanding:
1310nm(xxdBm)
1550nm(xxdBm)
……
1310nm(xxdBm)
1550nm(xxdBm)
……

Handheld Optical Light Source-JW3116
13
JW3116 Light Source JW3216 Power Meter
5-15
Note：Frequency ID and wave ID cannot be operated at the same time.
To avoid risk of serious eye damage, please do not look into the optical port of laser source at any time.
5.7 Power Off
Automatic power off: When auto-off function is activated, the unit will turn itself off automatically after
10minutes idle time, whatever the power supply is with alkaline batteries or is with power supply adaptor
directly.
Manual power off: Under any operation mode, hold down for a few seconds to turn the unit off.
Note: With either power off operation, the unit will store the last calibration wavelength and backlight
control mode automatically, which will be the default setting when user turns unit on next time.
Chapter 6 Trouble shooting.
Problems
Possible cause
Solution
Faint display on the LCD
screen
1. Power is off
2. The battery power is
too low
1. Press key.
2. Change the batteries
When on the laser
source, the output
power is not stable
After 15 min. preheat
270Hz
330Hz
1KHz
2KHz
270Hz
330Hz
1KHz
2KHz

Handheld Optical Light Source-JW3116
14
Chapter 7 General Maintenance
7.1 Always keep the connector ports of your laser source are clean.
7.2 Try to use only the adaptor supplied.
7.3 Once not in use, make sure dust-proof cap is placed properly over the optical
ports.
7.4 Carefully plug in/out for fiber connectors/adapters to avoid scratches on the port v
of the power meter.
7.5 Keep regular cleanings on optical port of power meter, please clean with cotton
swabs supplied using alcohol properly.
Chapter 8 Quality Warranty
Details of warranty terms and conditions are given as below:
1) Joinwit. warrants that JW3116 Optical Light Source will be free from defects in material and
workmanship for a period of 18 months. The date will be started from the date of goods shipment.
2) If any defectives happened due to quality problems of the product during the warranty period, Joinwit.
promises to repair or replace free of charge. But the freight cost and related taxes will be shared by
both parties. Joinwit. will pay the shipping cost from customer side to Joinwit. and pay the import
taxes in China. Customer will pay the shipping cost from Joinwit. to customer side and its local import
taxes accordingly.
3) This warranty is limited to defects in workmanship and materials and does not cover damages from
accident, acts of god, neglect, wrong usage or abnormal conditions of operation.
4) Joinwit. will charge corresponding fees for the cost of materials, repair and shipping in conditions of
below:
⚫Defects occurred under normal use and service but out of the warranty period.
⚫Failures and damages occurred do not because of defects in material and workmanship of
products.
⚫Failures and damages occurred because of failing to comply with the Operation Instruction and
necessary attention.
⚫abnormal conditions of operation or handling：
Such as artificial damage, or operating in abnormal conditions of like high temperature、high voltage,
humidity and etc., Joinwit. will charge depend on the actual failure rating.

Handheld Optical Light Source-JW3116
15
An important message from JOINWIT
JOINWIT guarantees that any information you supply will remain
confidential.
By returning this card, you will automatically be notified about
updates, modifications, and recalibration.
CUSTOMER SERVICE
Phone: [phone]
Fax: [phone]
[email protected]
www.joinwit.com
-----------------------------------------------------------------------------------------------------
Warranty Registration Card
Serial Number:
Model Number:
Date of Purchase:
Company Name:
Company Address:
TEL: FAX:
E-mail:
Note：Please fax this note within one month from the date of receiving units。
Do you have any comments on the quality of this product or the service from
Joinwit?
