JONATHAN Y JYL6130A User manual

WARNING
INSPECT ITEM CAREFULLY BEFORE ATTEMPTING TO INSTALL. IF THERE IS ANY DAMAGE OR
OBVIOUS DEFECT, DO NOT INSTALL. ITEM MAY NOT BE RETURNED ONCE IT HAS BEEN INSTALLED.
CARE AND MAINTENANCE
Model# JYL6130A
Product Dimensions: 14"Lx10.875"Wx61"H
Unplug lamps before using any cleaning solutions. Dust shades with a feather duster or with an appropriate
vacuum-brush attachment. Wipe with a soft, dry cloth and clean lamp bases with the methods appropriate to
the material. Avoid the use of chemicals and household cleaners as they may damage the finish.
NOTICE& IMPORTANT SAFETY INSTRUCTIONS
* Please make sure that you have all parts indicated before you begin assembly of this item
* This item should be assembled on a soft surface to prevent scratching the finish during assembly
* To reduce the risk of fire, electrical shock or injury to persons or property, please follow the guideline below
for safe use and installation
*The external flexible cable or cord of this lamp cannot be replaced;
If the cord is damaged, the lamp shall be destroyed
**This portable lamp has a polarized plug (one blade is wider than the other) as a safety feature to reduce
the risk of electric shock. this plug will fit in a polarized outlet only one way. if the plug does not fit fully in
the outlet, reverse the plug, if it still does not fit, contact a qualified electrician. Never use with an
extension cord unless the plug can be fully inserted. do not attempt to disregard this safety feature.
Part List and Hardware List
PIECE DESCRIPTION PICTURE QUANTITY PIECE DESCRIPTION PICTURE QUANTITY
A lamp body 1X
E Tooth washer 1X
F Hexagon nut 1X
B Shade 1X G Bulb 1X
C Ring 1X H Wrench 1X
D Lamp base 1X
1/2

PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware
contents list. If any part is missing or damaged, do not attempt to assemble the product.
Estimated Assembly Time: 15 minutes.
PLEASE USE ON/OFF TYPE"A" BULB MAX 40-WATT OR CFL BULB MAX 13-WATT OR LED BULB MAX 9-WATT
THERE IS LED 9-WATT BULB IN THE BOX
Step 1 Step 2 Step 3
Make sure all parts could be aligned before assemble Put the lamp shade (B)into the lamp body(A) Put the light on a level surface to check
Do not rotate lamp body too hard avoid base screw broken Use the ring (C) to lock the shade (B) if everything is stable.
Screw the Lamp body (A2) onto the Lamp body(A1) Insert the bulb(G) into the socket
Screw the Lamp body (A3) onto the Lamp body(A2)
Screw the Lamp body (A4) onto the Lamp body(A3)
Screw the Lamp body (A5) onto the Lamp body(A4)
Put the lamp base(D) onto the lamp body(A5)
Put the tooth washer(E) onto the lamp base(D)
Put the hexagon nut(F) onto lamp body(A5), tighten with wrench(H)
ENJOY YOUR LAMP
H
F
E
D
A5
A4
A3
A2
A1
1
2
C
G
B
A
D
3
2/2
