Jonsered LT2216A2 Guide

SERVICE
Spare parts
Ersatzteile
Pièces détachées
Reserve onderdelen
Repuestos
Reservdelar
I0700042
IPL, LT2216 A2, 2007-03, 504 11 16-06
LT2216A2
504 11 16-06
96041003700

408737 Rev. 4
ILLUSTRATED PARTS LIST
MODEL NO. 96041003700
CUSTOMER CATALOG NO. LT2216A2
PRODUCT NO. 960 41 00-37

2
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
KEY PART
NO. NO. DESCRIPTION
6
2
1
3
11
410
598
7
wheel_art_1-tex
WHEELS AND TIRES
KEY PART
NO. NO. DESCRIPTION KEY PART
NO. NO. DESCRIPTION
1 532 05 91-92 Cap Valve Tire
2 532 06 51-39 Stem Valve
3 532 13 83-36 Rim Asm 6" Front Service
4 532 05 99-04 Tube Front (Service Item Only)
5 532 10 62-22 Tire F T 15 x 6 0 - 6 Service
6 532 12 49-57 Fitting Grease (Front Wheel Only)
7 532 12 49-59 Bearing Flange (Front Wheel Only)
8 532 17 50-39 Cap Axle Blk 1 50 x 1 00
9 532 12 20-82 Tire R T 20 x 10-8 Service
10 532 12 49-26 Tube Rear (Service Item Only)
11 532 13 83-37 Rim Asm 8" Rear Service
- - 532 14 43-34 Sealant, Tire (10 oz. Tube)
11
9
1 532 40 03-89 Decal, Operators
2 532 18 95-53 Decal, Hood
3 532 19 68-41 Decal, Warning Eng. Symbols
4 532 40 93-70 Decal, Hood Panel
5 532 15 97-36 Decal, Chassis Hot Muffler
6 532 18 04-32 Decal, Fender 100 DB/CE
7 532 18 21-66 Decal, Cutfinger CE
8 532 40 86-26 Decal, Rpl
9 532 14 50-05 Decal, Battery Dnge/Poi
10 532 14 08-37 Decal, Saddle Brake Parking
11 532 19 63-57 Decal, Warning
12 532 16 03-96 Decal, Mower V-Belt Schematic
13 532 15 97-37 Decal, Brake/Clutch Symbol
14 532 40 94-61 Decal, Eng. HP
16 532 18 57-73 Decal, Steering
17 532 18 39-30 Decal, Cover Belt
18 532 40 93-71 Decal, Fender
- - 532 40 95-05 Pad, Footrest, LH
- - 532 41 12-73 Pad, Footrest, RH
- - 532 16 25-98 Decal, Drawbar Load Limit
- - 532 16 69-60 Decal, Bypass
- - 532 40 87-30 Manual Oper. Euro
- - 532 40 87-32 Manual Oper. Scand
- - 532 40 87-33 Manual Oper. E-Bloc
- - 532 40 87-34 Manual Oper. Baltic
12
2
4
2
1
8
5
6
10
13
3
5
7
16
14
18
17
TRACTOR - - MODEL NO. LT2216A2 (96041003700), PRODUCT NO. 960 41 00-37
DECALS
27
27

3
M
FUSE
STARTER
SOLENOID
BATTERY
CLUTCH/BRAKE
(PEDAL UP)
REVERSE SWITCH
(NOT IN REVERSE)
SEAT SWITCH
(NOT OCCUPIED)
SHORTING
CONNECTOR
CHASSIS
HARNESS
IGNITION
UNIT
HOUR
METER
CHASSIS HARNESS
CONNECTOR
(MATING SIDE)
DASH HARNESS
CONNECTOR
(MATING SIDE)
LIGHT
SWITCH
HEADLIGHTS
FUEL
LINE
FUEL SHUT-OFF
SOLENOID
(IF SO EQUIPPED)
JUNCTION
CONNECTOR
SM
B
GL
2
3
1
6
A2
A1
M
63
52
41
6
5
4
3
2
1
SPARK
PLUGS GAP
(2 PLUGS ON
TWIN CYL. ENGINES)
(OPTIONAL)
NON-REMOVABLE
CONNECTIONS
REMOVABLE
CONNECTIONS
WIRING INSULATED CLIPS
NOTE: IF WIRING INSULATED
CLIPS WERE REMOVED FOR
SERVICING OF UNIT, THEY
SHOULD BE RE-INSTALLED TO
PROPERLY SECURE YOUR
WIRING.
SCH10
IGNITION SWITCH
CIRCUITPOSITION
OFF B+A1
RUN/OVERRIDE
B+S+A1START
M+G+A1
B+A1RUN
“MAKE”
L+A2
03107
ATTACHMENT CLUTCH
(CLUTCH OFF)
REGULATOR STATOR
28 VOLTS AC @ 3600 RPM (REGULATOR DISCONNECTED)
CHARGING SYSTEM OUTPUT
9-16 AMP DC @ 3600 RPM
RED
BLACK
BLACK /WHITE
ORANGE
BROWN
BLUE
BLUE
BLACK
BLACK
BLACKBLACK
BLACK
BLACK
BLACK
BLACK
BLACK
DER
RED
WHITE
WHITE
GRAY
GRAY
BLACK
BLACK
POWER OUTLET
(OPTIONAL)
12V
BLACK
A
AMMETER
(OPTIONAL)
TRACTOR - - MODEL NO. LT2216A2 (96041003700), PRODUCT NO. 960 41 00-37
SCHEMATIC
38
38

4
30 33
34
90
22
79 21
41
42
26
8
1
99
100
91
227
43 27
24
40
71
28
55
16
87
With 12V Outlet Option
59
103
With Service Minder Option
4646
25
T01S
94
92
29
93
TRACTOR - - MODEL NO. LT2216A2 (96041003700), PRODUCT NO. 960 41 00-37
ELECTRICAL
32
32

5
KEY PART
NO. NO. DESCRIPTION
1 532 14 49-27 Battery
2 874 76 04-12 Bolt Hex Head 1/4-20 x 3/4
8 532 18 64-91 Box Battery
16 532 17 61-38 Switch Interlock Push-In
21 532 18 37-59 Harness Socket Light w/4152J
22 532 00 41-52 Bulb Light
24 532 40 02-53 Cable Battery
25 532 40 16-62 Cable Starter
26 532 17 51-58 Fuse
27 873 51 04-00 Nut Keps Hex 1/4-20 unc
28 532 14 54-91 Cable,Ground
29 532 40 15-45 Switch, Seat
30 532 19 33-50 Switch, Ign
33 532 14 04-01 Key, Ignition
34 532 11 07-12 Switch Light/Reset
40 532 40 10-98 Harness Ign. Dash
41 817 72 04-08 Screw Thd Cut 1/4-20 x 1/2
42 532 13 15-63 Cover, Terminal
43 532 19 25-07 Solenoid
46 532 40 17-63 Hourmeter
55 817 06 05-12 Screw Thdrol 5/16-18 x 3/4 TYTT
71 532 19 42-76 Harness Chassis
79 532 17 52-42 Socket Asm. Bulb Twistlock
87 532 19 78-02 Switch Interlock Clutch Cable
90 532 40 07-24 Cover Terminal
91 532 19 02-70 Strap Battery Mount Front
92 532 19 66-15 Harness Pigtail Reverse Switch
93 532 19 25-40 Screw Plastite 10-14 x 2.0
94 532 19 18-34 Module Reverse ROS
99 817 67 04-12 Screw 1/4-20 x 3/4
100 819 09 14-16 Washer 9/32 x 7/8 x 16 Ga.
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
TRACTOR - - MODEL NO. LT2216A2 (96041003700), PRODUCT NO. 960 41 00-37
ELECTRICAL
32
32

6








 
CHASSISTEX?GTHUSQ?R
































14









165
TRACTOR - - MODEL NO. LT2216A2 (96041003700), PRODUCT NO. 960 41 00-37
CHASSIS AND ENCLOSURES
39
39

7
5 532 41 20-69 Dash
14 532 42 69-83 Hood
15 532 18 97-54 Lens LH
18 532 19 29-15 Grille
25 532 18 97-55 Lens RH
34 532 19 61-25 Plate Engine
36 817 06 05-12 Screw 5/16-18 x 3/4
37 532 44 12-66 Fender
52 873 68 05-00 Nut Crown Lock 5/16
68 817 49 05-08 Screw THDROL 5/16-18 x 1/2
130 532 19 16-11 Screw
137 532 18 49-21 Bumper Dash
138 532 40 97-30 Cupholder
150 532 18 43-22 Air Duct
151 532 40 78-07 Bracket Pivot
152 532 19 95-35 Shield Browning
161 532 41 20-72 Window Fuel
162 532 14 24-32 Screw 1/4 x 1/2
165 532 19 68-26 Support Tank Rear
175 532 19 32-43 Crossmember
176 532 40 07-76 Screw 10-24 x 5/8
177 532 19 52-28 Bushing Steering
180 532 19 54-57 Chassis
181 532 40 47-96 Bushing Mtg. Fender Crgo
182 532 19 30-57 Dash Lower
183 874 78 05-20 Bolt 5/16-18 unc x 1-1/4
186 532 18 97-53 Insert Grille
189 817 00 05-12 Screw 5/16-18 x 3/4
194 873 90 05-00 Nut Lock Hex Flange 5/16-18
196 532 40 97-28 Console Asm. Deck Lift
207 532 18 38-33 Bezel RH
208 532 18 38-32 Bezel LH
213 874 76 05-12 Bolt 5/16-18 x 3/4
217 532 15 65-24 Rod Pivot Hood
218 532 19 63-95 X-Piece Hood Stop
222 532 13 77-29 Screw 1/4-20 x 5/8
228 532 19 51-61 Stud Fastener
230 532 17 01-65 Bolt Shoulder 5/16-18
235 532 40 61-29 Spacer Fender
236 873 93 05-00 Nut Lock 5/16-18 unc
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
KEY PART
NO. NO. DESCRIPTION
TRACTOR - - MODEL NO. LT2216A2 (96041003700), PRODUCT NO. 960 41 00-37
CHASSIS AND ENCLOSURES
39
39

8















 



DRIVETEX?(USQª4UFF4ORQ?R



















ª
 













ª














TRACTOR - - MODEL NO. LT2216A2 (96041003700), PRODUCT NO. 960 41 00-37
DRIVE
40
40

9
KEY PART
NO. NO. DESCRIPTION KEY PART NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
1 532 40 82-14 Transaxle, TUFFTORQ K46
(Internal parts not available)
2 532 12 35-83 Key
15 819 13 13-16 Washer 13/32 x 13/16 x 16 Ga.
17 532 41 36-78 Spring Brake
22 532 19 76-60 Rod Shift
23 532 13 05-64 Knob
29 532 40 38-06 Rod, Brake
33 812 00 00-01 Ring E
35 532 19 77-22 Rod Brake Park
42 532 12 48-72 Cover Foot Pedal
49 872 11 06-14 Bolt
50 532 19 43-27 Pulley Idler Flat
51 873 90 06-00 Lock Nut 3/8-16
52 532 19 43-26 Idler V-Groove 910" Offset
56 532 13 09-69 V-Belt Drive
64 532 19 62-00 Shaft Asm. Pedal Brake Control
70 532 41 13-29 Console
73 874 49 05-44 Bolt Hex Flghd 5/16-18 Gr. 5
74 532 14 24-32 Screw 1/4 x 1/2
80 532 40 44-83 Strap Torque
99 532 40 59-03 Rod Bypass
116 873 90 05-00 Nut Lock Hex Flange 5/16-18
125 817 00 05-12 Screw 5/16-18 x 3/4
143 817 49 05-08 Screw 5/16-18 x 1/2
153 532 12 47-88 Retainer Spring
159 876 02 04-12 Pin Cotter 1/8 x 3/4
160 532 16 94-84 Retainer Clip
161 532 19 54-03 Spring Return Clutch
166 532 19 72-90 Nut Push
167 532 40 52-57 Latch Brake Parking
170 532 19 43-22 Keeper Belt Centerspan
171 872 11 06-16 Bolt RDHD SQNK 3/8-16 unc x 2
174 532 19 72-89 Nut Push
175 532 40 62-08 Shaft Asm Shift
176 532 19 62-14 Arm Clevis Rod Shift
178 532 19 74-56 Spring Shift
183 532 13 70-57 Spacer Split
184 532 41 12-89 Handle Parking Brake
185 872 11 06-20 Bolt Rdhd Sqnk 3/8-16 x 2-1/2
186 532 19 43-21 Spacer Retainer
187 819 13 32-10 Washer
188 532 19 43-23 Link Clutch Ground Drive
189 532 19 43-17 Bellcrank Ground Drive
190 532 19 43-18 Keeper Bellcrank Ground Drive
205 532 12 17-48 Washer
211 532 19 62-12 Bushing Brake Shaft
216 532 19 61-31 Bracket Pulley Idler
221 532 40 31-87 Retainer Spring Clip Handle
225 532 40 33-19 Keeper Belt Trans.
226 532 40 15-64 Bracket Mount Touque
230 532 18 89-67 Washer Hardened
233 532 40 52-96 Washer Serrated
276 874 78 07-16 Bolt 7/16-14 x 1 Gr. 5
279 532 40 62-07 Link Shift
TRACTOR - - MODEL NO. LT2216A2 (96041003700), PRODUCT NO. 960 41 00-37
DRIVE
40
40
