JRC JAX-9B - User manual

INSTALLATION
INSTALLATION
MANUAL
MANUAL
JAX-9B
JAX-9B
WEATHER FACSIMILE
WEATHER FACSIMILE
RECEIVER
RECEIVER
01ETM ISO 9001, ISO 14001 Certified
Printed in Japan
Marine Service Department
[phone]
[phone]
[email protected]
Telephone :
Facsimile :
e-mail :
AMSTERDAM Branch
Telephone :
Facsimile :
e-mail :
[phone]
[phone]
[email protected]
SEATTLE Branch
Telephone :
Facsimile :
e-mail :
[phone]
[phone]
[email protected]
CODE No.7ZPNA4096
CODE No.7ZPNA4096
APR. 2008 Edition 1 JRC
APR. 2008 Edition 1 JRC
Not use the asbestos
For further information,contact:
URL http://www.jrc.co.jp

JAX-9B W-FAX Installation Manual
7ZPNA4096
RECORD OF REVISION
Rev. Description Date
1.0 First edition 29-MAY.-08

JAX-9B W-FAX Installation Manual
7ZPNA4096

JAX-9B W-FAX Installation Manual
i
7ZPNA4096
Pictorial Indication
In this Installation Manual and on the product, we use various pictorial indications to
handle the product safely and correctly and to prevent you from harming yourself and
other people or damaging those properties beforehand.
Meanings of the indications are shown below. Understand the meanings of signs
before proceeding to read the main text.
DANGER
This indication is shown where any person is supposed to be in danger
of being killed or seriously injured if this indication is neglected or
equipment is not operated correctly.
WARNING
This indication is shown where any person is supposed to be in danger
of being killed or seriously injured if this indication is neglected or
equipment is not operated correctly.
CAUTION
This indication is shown where any person is supposed to be injured or
any property damage is supposed to occur if this indication is neglected
or equipment is not operated correctly.
Examples of Pictorial Indication
Electric shock
marks indicate CAUTION (including DANGER and WARNING).
Detailed contents of CAUTION (“Electric Shock” in the example on left) are
shown in the mark.
Disassembly prohibited
marks indicate prohibition.
Detailed contents of prohibited actions (“Disassembling Prohibited” in the
example on left) are shown in the mark.
Remove Plug
marks indicate a specific action that must be followed or instruction.
Detailed contents of instructions (“Disconnect the power plug” in the example on
left) are shown in the mark.

JAX-9B W-FAX Installation Manual
ii
7ZPNA4096
Do not disassemble or remodel this equipment.
Such action may cause a fire, electric shock, or malfunction of the equipment.
Do not use any power supply voltage other than the specified one.
Such an action may cause a fire, an electric shock, or equipment malfunction.
Turn off power supply switch before connecting or disconnecting cables to any external
equipment. Not turning it off may cause a fire or an electric shock.
If the power supply cable is damaged, ask for the replacement to the sales department of Japan
Radio Co., Ltd (JRC), a nearby branch office, business office, or any agents of JRC.
The use of damaged cables may cause a fire or an electric shock.
If water enters into the equipment, shut off the power, disconnect the plug from the outlet, and
contact the sales department of JRC, a nearby branch office, business office, or any agents of
JRC. Using it as it is may cause a fire, electric shock, or malfunction.
Do not attempt inspections or repairs on the internal part of the equipment by yourself.
Inspections or repairs by anyone other than qualified maintainers may cause a fire or electric
shock. Ask for internal inspections or repairs of the equipment to the sales department of
JRC, a nearby branch office, business office, or any agents of JRC.
If equipment malfunctions, shut off its power and contact the sales department of JRC, a
nearby branch office, business office, or any agents of JRC. The continuous use of the
equipment may cause a fire or electric shock.
Never replace the back-up battery by yourself.
Replacement by anyone other than qualified maintainers may cause a fire, an electric shock, or
a malfunction.
For the back-up battery replacement, contact the sales department of JRC, a nearby branch
office, business office, or any agents of JRC.

JAX-9B W-FAX Installation Manual
iii
7ZPNA4096
When disposing of this unit, abide by local laws and regulations. For lithium battery,
however, contact the sales department of JRC, a nearby branch office, business office, or any
agents of JRC without discarding it as it is.
Do not insert or drop any foreign objects such as metallic pieces into an air vent or opening.
Otherwise, it may cause a fire, electric shock or malfunction.
If anything abnormal such as smoke, strange smell or unusual heat is emitted, shut OFF the
POWER switch of the equipment immediately and pull the power cable out of power supply
unit. Then, contact the sales department of JRC, a nearby branch office, business office, or
any agents of JRC. The continued use of the equipment may cause a fire or electric shock.
Be careful not to allow any wire dust or metallic pieces to get into the inside of JAX-9B.
Otherwise, it may cause a fire, electric shock, or malfunction.
Do not install the equipment on the location where infringed by water, humidity, steam, dust,
or soot.
Otherwise, it may cause a fire, electric shock, or malfunction.
Do not touch the equipment if your hands or gloves are wet either with freshwater or seawater.
Otherwise, it may cause an electric shock, or a malfunction.
Be sure to hold power supply plug when pulling it out of outlet.
Pulling the power cable without holding the plug can damage the cable and may cause a fire or
an electric shock.
Do not connect or disconnect the power supply cable with wet hands.
Otherwise, it may cause an electric shock.
If the equipment is splashed either with seawater or fresh water, wipe it dry immediately.
Otherwise, it may cause a failure or operational malfunctions.

JAX-9B W-FAX Installation Manual
iv
7ZPNA4096
Do not use organic solvents such as thinner or benzene to clean the surface. These agents
can damage the surface coating. Remove dirt and dust on the surface if any and wipe it with
a clean dry cloth.
Use the recording paper (6ZPTS00108) as specified by JRC.
The use of any other unspecified paper may cause recording density blurs, abnormal paper
feed, much dust, resulting in the damage of the recording device.
Connect the earth line to the earth terminal firmly.
Otherwise, it may cause an electric shock when the equipment has a failure or electric leak.
Do not rub the heating element (contacting with the papar) in the recording device with a
screwdriver, file or any other hard objects.
Otherwise, it destroys the recording device.
Do not store recording papers in the place exposed to a high temperature, high humidity or
direct sunlight. Otherwise, it may cause recording density blurs.
Do not connect the power cable to the common power outlet with any other cables with high
power noise (such as for an air conditioner). Otherwise, it may cause a receiving
interference.
Do not install the equipment on the unstable place such as on the shaky stand or inclined
surface. Otherwise, it may drop or fall down, resulting in an injury or malfunction.
Do not install the equipment under the direct sunlight.
The high temperature may discolor the recording paper or cause an equipment malfunction.
Do not install the equipment near any other radio equipment.
Otherwise, it may cause a receiving disturbance.
Do not bring the equipment in the cooled state suddenly to a high-temperature room.
Otherwise, the air inside the equipment may be condensated, resulting in a malfunction.

JAX-9B W-FAX Installation Manual
v
7ZPNA4096
Turn on or off the POWER switch after waiting more than one second.
Turning it back ON right after being turned OFF in no time may cause the equipment
malfunction.
Clean the thermal head with a piece of soft cloth always. Do not rub it with a screw driver or
file. Otherwise, it destroys the thermal head.
Do not replace the backup battery by customers.
Even if the POWER switch on the equipment is turned OFF, some parts may remain
electrically charged, causing an electric shock or malfunction.
Request replacing the backup battery to the sales department of JRC, a nearby branch office,
business office, or any agents of JRC.
Use the JRC-specified backup battery (CR2032-type lithium battery).
The use of any unspecified battery may cause a malfunction or failure of the equipment.
The prohibited matters over lithium battery are as follows;
• Short-circuit of electrodes, • Any unspecified uses of battery, •Decomposing, •Converting, •
Discarding, •Throwing into the fire, •Heating, • Use of battery that passes exchange time.
Otherwise, these may cause following trouble;
• Electrolyte leakage, •Generation of Heat, •Fire •Explosion, •Destruction, •Burn
In returning used lithium battery to JRC, take the isulating treatment such as attaching a tape
to the +/– terminals. If the battery is short-circuited with no insulating treatment, it may
cause a heat, explosion or fire.
Do not conduct operations with wet hands.
Otherwise, it may cause an electric shock.
Turn off power supply switch before opening the top cover to replace the recording paper.
Otherwise, it may cause an electric shock, malfunction, or burn.

JAX-9B W-FAX Installation Manual
vi
7ZPNA4096
Contents
1. Specification ........................................................................................................................................... 1
1.1. Function......................................................................................................................................................1
1.2. Features ......................................................................................................................................................1
1.3. Components................................................................................................................................................1
1.4. Spare Parts .................................................................................................................................................2
1.5. System Diagram.........................................................................................................................................3
1.6. Electrical Circuit Board ............................................................................................................................4
1.7. Block Diagram ...........................................................................................................................................5
1.8. Glossary......................................................................................................................................................6
1.9. Specifications of JAX-9B...........................................................................................................................7
2. Installation ............................................................................................................................................. 9
2.1. Vicinity clearance.......................................................................................................................................9
2.2. Installation of JAX-9B.............................................................................................................................10
2.3. Installation of Rectifier Unit ...................................................................................................................12
2.4. Precautions for Installation.....................................................................................................................13
2.5. Installation of Whip Antenna..................................................................................................................14
2.6. Display received image on PC (Option) .................................................................................................18
2.7. Installation of Communication I/F unit (RS-422 / USB Converter)....................................................19
2.8. Remote Maintenance System (Option) ..................................................................................................20
2.9. Putting the PC interface kit in JAX-9B .................................................................................................21
3. Wiring................................................................................................................................................... 23
3.1. Wiring table..............................................................................................................................................23
3.2. Cable .........................................................................................................................................................24
3.3. Wiring of Standard configuration ..........................................................................................................25
3.4. Power supply wiring when connecting to AC power supply (Option).................................................26
3.5. Connecting to Personal Computer (Option)..........................................................................................27
3.6. Connection to Remote Maintenance server (Option) ...........................................................................28
3.7. Assembling antenna connector...............................................................................................................29
3.8. How to connect to terminals ...................................................................................................................30
3.9. Connection of a Decoder (by Kyodo News Service in Japan) ..............................................................31
4. Setting................................................................................................................................................... 33
4.1. Setting at installation...............................................................................................................................33
4.2. Changing Display language (to Japanese) .............................................................................................34
4.3. Connection of GPS Receiver...................................................................................................................35

JAX-9B W-FAX Installation Manual
vii
7ZPNA4096
5. Setup of the PC for receiving FAX image (Option) (under development) ....................................... 37
5.1. Installing the device driver of the RS-422/USB converter ...................................................................37
5.2. ”The Found New Hardware wizard” of the RS-422/USB converter...................................................41
5.3. Installing the Software for receiving FAX images.................................................................................44
6. Checking operation ............................................................................................................................. 45
6.1. Operation of Standard configuration.....................................................................................................45
6.2. Displaying the receiving FAX images by the PC (Option) ...................................................................45
7. Outline drawing................................................................................................................................... 47
7.1. Weather Facsimile JAX-9B.....................................................................................................................47
7.2. Rectifier Unit NBA-5143 .........................................................................................................................48
7.3. 6m Whip antenna NAW-60 .....................................................................................................................49
7.4. Junction box JQD-69C.........................................................................................................................50
7.5. RS-422/USB Converter 7ZZNA4017 ..................................................................................................51

1. Specification
JAX-9B W-FAX Installation Manual
1
7ZPNA4096
1. Specification
1.1. Function
JAX-9B is capable of receiving facsimile broadcasting such as weather charts and marine charts
transmitted in the high-frequency band (2 to 25MHz) and records them on the recording paper..
The received (recorded) image is displayed on the PC by adding a optional kit.
1.2. Features
1.2.1. Various recording modes
1) Automatic recording mode (AUTO)
In the AUTO mode, all operations such as startup, various settings, image recording, paper feed, and
stop of recording are automatically performed by the remote signals from the broadcasting station.
However, the halftone recording is manually controlled.
2) Manual recording mode (MANU)
In the MANU mode, the index of cooperation (IOC), scan speed and halftone are manually controlled,
though the recording and stop are performed automatically.
3）Forced recording mode (# REC)
When the equipment is in any other mode than the mode 1) or 2) (e.g. midway during broadcasting),
received images can forcedly be recorded manually as an extension of the MANU mode.
4）Programmed recording mode (TIMER)
JAX-9B can perform unattended operations linked with the internal timer built in its main body by
programming the program channel, start and stop times, startup mode, recording frequency and
halftone recording.
1.2.2. 16-gradation halftone recording
Cloud photos received from a weather satellite can be recorded in 16-gradation halftone contrast.
1.2.3. Fine-line compensation circuit
The equipment adopts the JRC’s original system that can clearly reproduce fine lines in maps and latitude
and longitude grids.
1.2.4. Synthesizer-based receiver capable of storing 90 frequencies
Receiving frequencies can freely be preset from a numeric keypad and up to 90 frequencies (There are 10
groups and 1 group can store 9 frequencies.) can be stored in the internal memory.
In addition, the preset frequencies can be swapped with others on the spot, allowing swift response to any
new broadcasts or frequency changes

1. Specification
JAX-9B W-FAX Installation Manual
2
7ZPNA4095
1.2.5. Automatic frequency selection
A frequency with the best receiving condition can be automatically selected among 9 frequencies in the
same group. This function can demonstrate a superior effect in program recording because it is not
necessary to search a frequency with a good receiving condition.
1.2.6. Internal clock
The equipment incorporates an internal clock as a timer for program recording, which can indicate time.
1.2.7. Automatic time correction
By connecting a GPS receiver, the internal clock can be corrected automatically.
1.2.8. Displaying received image on PC (Option)
The equipment outputs received image data to a Personal Computer. The PC is able to display a received
image.
OS of the PC: Windows 2000/Xp (Vista (on schedule))
1.2.9. Remote Maintenance System (Option)
JAX-9B supports the Remote Maintenance System.

1. Specification
JAX-9B W-FAX Installation Manual
1
7ZPNA4096
1.3. Components
Table of Components for Weather Facsimile Receiver
No. Name Type Quantity
Mass
1Unit (kg)
Remarks
Standard Components
1 Weather facsimile receiver JAX-9B 1 5.3
with a recording paper for testing
2 Protective cover MTT312734 1 0.08
3 Coaxial connector M-P-7 1 0.02
for antenna cable
4 Power supply connector
721-103/037-000 1 0.01 Terminal block for DC power supply
5 External I/F connector 8213BFK/8TOP
K(25.840.0853.0) 1 0.02
Terminal block for AF signal, BK
signal and GPS data
6 Label in Japanese MPNN32192 1 0.01 Switch name label for Japanese
7 Spare parts 7ZXNA4003 1 0.04
Fuse (5A, 8A) Four pieces each
Instruction Manual (JPN) 7ZPNA4035 0.3 with Operation Card
(7ZPNA4102)
8
Instruction Manual (ENG) 7ZPNA4036
1
0.3 with Operation Card
(7ZPNA4103)
Options
9 Rectifier unit NBA-5143 1 3.5
10 PC Interface kit 7ZZNA4016 1 0.2 Terminal Block (TB103)
for connecting PC, Cable clamp
11 FAX image display kit 7ZZNA4017 1 1 PC software for displaying image
Communication I/F Unit
12 Junction box JQD-69C 1 1 Cable insertion 12mm diameters
13 Whip antenna (L=6MT) NAW-60 1 3.5 6m
14 Recording paper 6ZPTS00108 ______ 0.4
NOTE JAX-9B is shipped with a test recording paper roll and the antenna connector fitted in it.
The rectifier unit makes 100VAC or 220VAC power supply available to JAX-9B.

1. Specification
JAX-9B W-FAX Installation Manual
2
7ZPNA4095
1.4. Spare Parts
7ZXNA4003
SHIP NO
WEATHER FACSIMILE RECEIVERMODEL: JAX-9B
ITEM
NO.
NAME OF
PART SPARE
PER
SET
1
2
3
4
5
6
9
10
SPARE PARTS LIST FOR U S E SETS PER
VESSEL
PER
VESS
QUANTITY REMARKS
OUT LINE
(DIMENSION IN M/M)
WORKING
7
8
MFR'S NAME DRW.NO.
24
FUSE
FUSE
φ5.2
20
φ5.2
－4
MF51NR 250V 5A
5ZFGD00183
MF51NR 250V 8A
5ZFGD00119
DESCRIPTION
JRC CODE NO.
SUB
MARK OF
BOX NO.
20
Note: Spare Part (DESCRIPTION, JRC CODE NO.) may be replaced to the compatible part without notice.

1. Specification
JAX-9B W-FAX Installation Manual
3
7ZPNA4096
1.5. System Diagram

1. Specification
JAX-9B W-FAX Installation Manual
4
7ZPNA4095
1.6. Electrical Circuit Board
Equipment Circuit Board Model Remark
Control Board CKK-535
CMA-767 Receiver Board of JAX-9A
Only the first 200 sets have the CMA-767.
Receiver Board
CMA-906 New Receiver Board
Chassis CWB-1464
JAX-9B
DC/DC Power supply Board 7EPNA4001

1. Specification
JAX-9B W-FAX Installation Manual
5
7ZPNA4096
1.7. Block Diagram
J501
J509
J503
J505
J504
J510 J508 J502 J507
543 21
J512 J511
116
J506

1. Specification
JAX-9B W-FAX Installation Manual
6
7ZPNA4095
1.8. Glossary
Scanning When a facsimile broadcasting is received and recorded, the recording of the
received image starts one dot by one dot from the left end of the paper. When
the recording reaches the right end, it is returned to the left end of the paper again
and the same operation is repeated until the image recording is completed. This
operation is called “scanning”.
Primary scanning Scanning in the horizontal direction as shown above
Secondary scanning Scanning in the vertical direction as shown above
Scan line density The number of scan lines plotted while the paper moves one millimeter in the
secondary scanning direction during the recording of received signals.
Scan speed Primary scanning speed: for example, 120 primary scannings per minute are
performed at 120 spm (scan per minute).
Index of cooperation
(IOC)
If the paper size transmitted from a broadcasting station is different from the
recording paper size on the receiving side, it is necessary to equal the vertical and
horizontal reduction or enlargement of the original paper to keep a similar figure.
The coefficient to keep a similar figure between transmitting and receiving sides is
called “index of cooperation”.
Halftone recording This is a method of displaying the contrast of clouds in recording cloud photos
taken by a meteorological satellite, in which the contrast is displayed by the
difference in the density of black dots like in a black/white photo in a newspaper.
It is indicated as HALF in this manual.
Start signal Start signal is the signal transmitted at the beginning of the facsimile
broadcasting to indicate the start of the broadcast.
JAX-9B uses it for the automatic setting of the index of cooperation (IOC) and
starts the automatic recording by receiving this signal.
Phase signal Phase signal is the signal transmitted next to the start signal. It is indicated at the
both ends of the image when synchronization is made. It is used for the
automatic setting of scan speed and it is an essential signal used for the automatic
recording (AUTO), manual recording (MANU), and timer program recording.
Similar phase signal Similar phase signal appears at the same position as the phase signal in the image
signal. Depending on broadcasting stations, it may not be included in the image
signal. In JAX-9B, this signal is used for phase matching in the manual
recording and forced recording.
