JS Automation Corp FA-G410 User manual

FA-G410
ATX motherboard
supports Intel®LGA775 Core™ 2
Duo/Quad processor
with 800/1066/1333 MHz FSB,
including VGA, PCIe x16,
PCIe x4 (x1 signal), PCI,
dual PCIe GbE, USB 2.0, COM, CF,
SATA 3Gb/s and Audio
User's Manual (V1.0)
健昇科技股份有限公司
JS AUTOMATION CORP.
新北市汐止區中興路 100 號6樓
6F., No.100, Zhongxing Rd.,
Xizhi Dist., New Taipei City, Taiwan
TEL：[phone]
FAX：[phone]
http://www.automation.com.tw
http://www.automation-js.com/
E-mail：[e-mail]

1
Contents
1. Forward................................................................................................................................................2
2. Features................................................................................................................................................3
3. Specifications.......................................................................................................................................4
4. Dimensions ..........................................................................................................................................6
5. Jumper and Connector Locations ........................................................................................................7
5.1 FA-G410 Layout..........................................................................................................................7
5.2 Peripheral Interface Connectors...................................................................................................8
5.3 External Interface Panel Connectors............................................................................................9
6. Connector and Jumper setting............................................................................................................10
6.1 Peripheral Interface Connectors.................................................................................................10
6.1.1 Audio Connector....................................................................................................................10
6.1.2 CPU Fan Connector...............................................................................................................10
6.1.3 System Fan Connectors .........................................................................................................10
6.1.4 CPU Power Input Connector .................................................................................................11
6.1.5 Digital I/O Connector ............................................................................................................11
6.1.6 Front Panel Connector...........................................................................................................11
6.1.7 IDE Connector.......................................................................................................................12
6.1.8 Infrared Interface Connector..................................................................................................12
6.1.9 Memory Slots.........................................................................................................................13
6.1.10 PCIe Power Input Connector.............................................................................................13
6.1.11 Power Connector................................................................................................................13
6.1.12 RS-232 Serial Port Connectors..........................................................................................14
6.1.13 RS-232/422/485 Serial Port Connector .............................................................................14
6.1.14 SATA Drive Connectors.....................................................................................................14
6.1.15 SMBus Connector..............................................................................................................15
6.1.16 SMBus Connector..............................................................................................................15
6.1.17 SPI Flash Connector ..........................................................................................................15
6.1.18 TPM Connector..................................................................................................................16
6.1.19 USB Connectors ................................................................................................................16
6.2 External Interface Connector.....................................................................................................17
6.2.1 Audio Connector....................................................................................................................17
6.2.2 Keyboard/Mouse Connector..................................................................................................17
6.2.3 LAN Connectors....................................................................................................................18
6.2.4 Parallel Port Connector..........................................................................................................18
6.2.5 Serial Port Connector (COM1)..............................................................................................19
6.2.6 USB Connectors ....................................................................................................................19
6.2.7 VGA Connector .....................................................................................................................19
7. Ordering information.........................................................................................................................20

2
1. Forward
Thank you for your selection of FA-G410 cpu card.
Any comment is welcome,
please visit our website: www.automation.com.tw for the up to date information.

3
2. Features
ATX form factor
RoHS compliant
LGA775 CPU socket
Supports two DDR3 DIMMs
Supports dual display by VGA port and an optional PCIe x16 SDVO expansion card
Two Gigabit Ethernet connectors
Four SATA connectors
Eight USB ports
Six serial ports
Supports PCI and PCIe x4 (PCIe x1 signal) expansion cards

4
3. Specifications
Form Factor : ATX
CPU Supported : Socket LGA775 Intel®Core™2 Duo/Quad, Pentium®D or Celeron®
processor
Front Side Bus (FSB) : 800/1066/1333 MHz
Northbridge Chipset : Intel®G41
Memory : Two 240-pin 800/1066 MHz dual-channel DDR3 SDRAM DIMMs
(system max. 4 GB)
Graphic Engine : Intel® GMAX4500 supports DirectX 10 / OpenGL 1.5
Integrated Graphics : VGA integrated in Intel®G41 supports up to 2048 x 1536 @ 75 MHz
Southbridge Chipset : Intel®ICH7
BIOS : UEFI BIOS
Digital I/O : 8-bit, 4-bit input/4-bit output
Ethernet Controllers : Two Realtek RTL8111E PCIe GbE controllers
(LAN1 with ASF2.0 support)
Audio : Realtek ALC888 HD Audio codec
Super I/O Controller : Fintek F81865
Watchdog Timer : Software programmable supports 1~255 sec. system reset
Expansion
One PCIe x16 socket
One PCIe x4 socket (with PCIe x1 signal)
Five PCI sockets
I/O Interface
Audio Jack : One line-in One line-out One mic-in
Fan connector : One 4-pin wafer for CPU fan
Three 3-pin wafer for system fans
Keyboard/Mouse : Two external PS/2 connectors
Serial Ports : Five RS-232 COM connectors
One RS-232/422/485 COM connector with auto flow control
USB 2.0/1.1 ports : Four internal via pin header
Four external USB ports
Infrared : One infrared connector via 5-pin header
Parallel Port : One external parallel port
Serial ATA : Four independent SATA channels with 3.0 Gb/s data transfer rates
IDE : One 40-pin IDE connector
CompactFlash® : One CF Type II slot
SMBus : One 4-pin wafer SMBus connector
TPM : One TPM module connector via 20-pin header

5
Environmental and Power Specifications
Power Supply : ATX power supported
Power Consumption : 5 V @ 5.45 A 12 V @ 4.80A 3.3 V @ 0.16 A -12 V @ 0.06A
(2.83 GHz Intel® Core™2 Quad Q9550
with 2 GB 1333 MHz DDR3 DIMM)
Operating temperature : -10ºC ~ 60ºC
Humidity : 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions : 305 mm x 244 mm
Weight GW/NW : 1200 g / 750 g

6
4. Dimensions

7
5. Jumper and Connector Locations
5.1 FA-G410 Layout

8
5.2 Peripheral Interface Connectors
Connector
Type
Label
Audio connector
10-pin header
FP_AUDIO1
Fan connector (CPU)
4-pin wafer
CPU_FAN1
Fan connector (system)
3-pin wafer
SYS_FAN1, SYS_FAN2,
SYS_FAN3
CPU power input connector
4-pin connector
CPU12V1
Digital I/O connector
10-pin header
DIO1
Front panel connector
14-pin header
F_PANEL1
IDE connector
40-pin box header
IDE1
Infrared connector
5-pin header
IR1
Memory slot
240-pin DDR3 DIMM slot
DIMM1, DIMM2
PCI slots
PCI slot
PCI1, PCI2, PCI3,
PCI4, PCI5
PCIe x4 slot
PCIe x4 slot
PCIE2
PCIe x16 slot
PCIe x16 slot
PCIE1
PCIe power connector
4-pin connector
PCN1
Power connector
24-pin connector
PWR2
RS-232 serial port connector
10-pin box header
COM3, COM4,
COM5, COM6
RS-232/422/485 serial port connector
14-pin box header
COM2
SATA drive connectors
7-pin SATA drive
connectors
SATA1, SATA2,
SATA3, SATA4
SMBus connector
4-pin wafer
CN9
SPDIF connector
5-pin header
SPDIF1
SPI Flash
8-pin header
JSPI1
TPM connector
20-pin header
TPM1
USB connectors
8-pin header
USB3, USB4

9
5.3 External Interface Panel Connectors
Connector
Type
Label
Audio connector
Audio jack
CN8
Keyboard/Mouse connector
PS/2
KBMS2
LAN connector
RJ-45
LAN1, LAN2
Parallel port
DB-25 Female
3IN1_DSUB1A
Serial port connector
DB-9 Male
3IN1_DSUB1B
USB connector
USB port
USB1, USB2
VGA connector
15-pin Female
3IN1_DSUB1C

10
6. Connector and Jumper setting
6.1 Peripheral Interface Connectors
6.1.1 Audio Connector
(FP_AUDIO1: 10-pin header)
Pin
Description
Pin
Description
1
MIC_L
2
Audio GND
3
MIC_R
4
FP_AUO_DETECT
5
LINE_R
6
PD
7
F_SENSE
8
NC
9
LINE_L
10
PD
6.1.2 CPU Fan Connector
(CPU_FAN1: 4-pin wafer)
The fan connector attaches to a CPU cooling fan.
Pin
Description
1
GND
2
+12 V
3
FANIN1
4
Fan Control1
6.1.3 System Fan Connectors
(SYS_FAN1, SYS_FAN2, SYS_FAN3: 3-pin wafer)
The fan connector attaches to a system cooling fan.
Pin
Description
1
FANIN2
2
+12 V
3
GND

11
6.1.4 CPU Power Input Connector
(CPU12V1: 4-pin connector)
The CPU power input connector provides power to the CPU.
Pin
Description
1
GND
2
GND
3
+12V
4
+12V
6.1.5 Digital I/O Connector
(DIO1: 10-pin header)
The digital I/O connector provides programmable input and output for external devices. The
digital I/O provides 4-bit output and 4-bit input.
Pin
Description
Pin
Description
1
GND
2
VCC5S
3
Output 0
4
Output 1
5
Output 2
6
Output 3
7
Input 0
8
Input 1
9
Input 2
10
Input 3
6.1.6 Front Panel Connector
(F_PANEL1 : 14-pin header)
The front panel connector connects to the indicator LEDs and buttons on the computer's front
panel.
Function
Pin
Description
Function
Pin
Description
Power
1
Power LED
Buzzer
2
BEEP_PWR
LED
3
NC
4
NC
5
GND
6
NC
Power
7
PWRBTSW#
8
PC_BEEP
Button
9
GND
10
NC
HDD
LED
11
HDD LED+
Reset
12
RESET
13
HDD LED-
14
GND

12
6.1.7 IDE Connector
(IDE1 : 40-pin box header (2x20))
The IDE connector can connect to an IDE hard drive or optical device.
Pin
Description
Pin
Description
1
RESET#
2
GROUND
3
DATA 7
4
DATA 8
5
DATA 6
6
DATA 9
7
DATA 5
8
DATA 10
9
DATA 4
10
DATA 11
11
DATA 3
12
DATA 12
13
DATA 2
14
DATA 13
15
DATA 1
16
DATA 14
17
DATA 0
18
DATA 15
19
GROUND
20
N/C
21
IDE DRQ
22
GROUND
23
IOW#
24
GROUND
25
IOR#
26
GROUND
27
IDE CHRDY
28
GROUND
29
IDE DACK
30
GROUND–DEFAULT
31
INTERRUPT
32
N/C
33
SA1
34
N/C
35
SA0
36
SA2
37
HDC CS0#
38
HDC CS1#
39
HDD ACTIVE#
40
GROUND
6.1.8 Infrared Interface Connector
(IR1 CN Type: 5-pin header (1x5))
The infrared connector attaches to an infrared receiver for use with remote controls.
Pin
Description
1
+5V
2
NC
3
IR-RX
4
GND
5
IR-TX

13
6.1.9 Memory Slots
(DIMM1, DIMM2 : DIMM slot)
The DIMM slots are for DDR3 DIMM memory modules.
6.1.10 PCIe Power Input Connector
(PNC1: 3-pin wafer (1x3))
The PCIe power input connector provides extra power to the PCIe card.
Pin
Description
1
VCC +5 V
2
GND
3
GND
4
VCC +12 V
6.1.11 Power Connector
(PWR2: 24-pin connector)
The power connector connects to an ATX power supply.
Pin
Description
Pin
Description
1
+3.3V
13
+3.3V
2
+3.3V
14
-12V
3
GND
15
GND
4
+5V
16
PS_ON
5
GND
17
GND
6
+5V
18
GND
7
GND
19
GND
8
NC
20
NC
9
+5V
21
+5V
10
+12V
22
+5V
11
+12V
23
+5V
12
+3.3V
24
GND

14
6.1.12 RS-232 Serial Port Connectors
(COM3, COM4, COM5, COM6: 10-pin box header)
Pin
Description
1
NRLSD
2
NDSR
3
NRX
4
NRTS
5
NTX
6
NCTS
7
NDTR
8
NRI
9
GND
10
NC
6.1.13 RS-232/422/485 Serial Port Connector
(COM2: 14-pin box header)
Pin
Description
Pin
Description
1
NDCD
2
NDSR
3
NRX
4
NRTS
5
NTX
6
NCTS
7
NDTR
8
NRI
9
GND
10
NC
11
TX+
12
TX
13
RX+
14
RX-
6.1.14 SATA Drive Connectors
(SATA1, SATA2, SATA3, SATA4 :7-pin SATA drive connectors)
The SATA drive connectors can be connected to SATA 3Gb/s drives.

15
6.1.15 SMBus Connector
(CN9: 4-pin wafer)
The SMBus (System Management Bus) connector provides low-speed system management
communications.
Pin
Description
1
GND
2
SMBDATA
3
SMBCLK
4
+5V
6.1.16 SMBus Connector
(SPDIF1: 5-pin header)
Use the SPDIF connector to connect digital audio devices to the system.
Pin
Description
1
+5V
2
NC
3
SPDIF OUT
4
GND AUDIO
5
SPDIF IN
6.1.17 SPI Flash Connector
(JSPI1: 8-pin header)
The 8-pin SPI Flash connector is used to flash the BIOS.
Pin
Description
Pin
Description
1
+3.3V
2
GND
3
CS#
4
CLOCK
5
SO
6
SI
7
NC
8
NC

16
6.1.18 TPM Connector
(TPM1: 20-pin header (2x10))
The Trusted Platform Module (TPM) connector secures the system on bootup.
Pin
Description
Pin
Description
1
TPMCLK
2
GND
3
LFRAME
4
NC
5
PCIRST4
6
+5 V
7
LAD3
8
LAD2
9
LAD0
10
LAD1
11
GND
12
GND
13
SMBCLK_MAIN
14
SMBDATA_MAIN
15
+3.3 V
16
SERIRQ
17
GND
18
CLKRUN
19
+3.3 V
20
LDRQ-
6.1.19 USB Connectors
(USB3, USB4: 8-pin header)
The USB connectors connect to USB devices. Each pin header provides two USB ports.
Pin
Description
Pin
Description
1
+5V
2
GND
3
USBP4/6#
4
USBP5/7
5
USBP4/6
6
USBP5/7#
7
GND
8
+5V

17
6.2 External Interface Connector
6.2.1 Audio Connector
(CN8 : Audio jack)
The audio jacks connect to external audio devices.
Line In port (Light Blue): Connects a CD-ROM, DVD player, or
other audio devices.
Line Out port (Lime): Connects to a headphone or a speaker.
With multi-channel configurations, this port can also connect to
front speakers.
Microphone (Pink): Connects a microphone.
6.2.2 Keyboard/Mouse Connector
(KBMS2 : PS/2)
The keyboard and mouse connector is a standard PS/2 connector.
Pin
Description
Pin
Description
1
KB_DATA
8
NC
2
NC
9
GND
3
GND
10
5 V
4
5 V
11
MS_CLK
5
KB_CLK
12
NC
6
NC
13
KB_GND
7
MS_DATA
14
KB_GND

18
6.2.3 LAN Connectors
(LAN1, LAN2: RJ-45)
The LAN connector connects to a local network.
Pin
Description
Pin
Description
1
3.3 V
8
LAN1/2_MDI3+
2
LAN1/2_MDI0+
9
LAN1/2_MDI3-
3
LAN1/2_MDI0-
10
GND
4
LAN1/2_MDI1+
11
LAN1/2_LINK100
5
LAN1/2_MDI1-
12
LAN1/2_LINK1000
6
LAN1/2_MDI2+
13
LAN1/2_LED0
7
LAN1/2_MDI2-
14
3.3 V
6.2.4 Parallel Port Connector
(3IN1_DSUB1A: DB-25 Female)
The parallel port connects to parallel port device, typically a printer.
Pin
Description
Pin
Description
1
STROBE#
14
AUTO FORM FEED #
2
DATA 0
15
ERROR#
3
DATA
16
INITIALIZE
4
DATA
17
PRINTER SELECT LN#
5
DATA
18
GROUND
6
DATA
19
GROUND
7
DATA
20
GROUND
8
DATA
21
GROUND
9
DATA
22
GROUND
10
ACKNOWLEDGE
23
GROUND
11
BUSY
24
GROUND
12
PAPER EMPTY
25
GROUND
13
PRINTER SELECT

19
6.2.5 Serial Port Connector (COM1)
(3IN1_DSUB1B (COM1) : DB-9 Male)
The serial port connects to a RS-232 serial communications device.
Pin
Description
Pin
Description
1
DCD
6
DSR
2
RX
7
RTS
3
TX
8
CTS
4
DTR
9
RI
5
GND
6.2.6 USB Connectors
(USB1, USB2 : USB port)
The USB connector can be connected to a USB device.
Pin
Description
Pin
Description
1
USBPWR1
2
USBP0/2
3
USBP0/2+
4
GND
5
USBPWR1
6
USBP1/3
7
USBP1/3+
8
GND
6.2.7 VGA Connector
(3IN1_DSUB1C : 15-pin Female)
The VGA connector connects to a monitor that accepts a standard VGAinput.
Pin
Description
Pin
Description
1
RED
2
GREEN
3
BLUE
4
CRT_PLUG#
5
GND
6
GND
7
GND
8
GND
9
VGAVCC
10
GND
11
NC
12
DDC DAT
13
HSYNC
14
VSYNC
15
DDCCLK
